Luxibel COBPAR 100 RGBWA-UV User manual

LX163
LUXIBEL COBPAR 100 - RGBWA-UV COB LED
USER MANUAL

LX163
V. 01 –21/04/2015 2 ©Velleman nv

LX163
V. 01 –21/04/2015 3 ©Velleman nv
USER MANUAL
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle
could harm the environment. Do not dispose of the unit (or batteries) as unsorted municipal
waste; it should be taken to a specialized company for recycling. This device should be
returned to your distributor or to a local recycling service. Respect the local environmental
rules.
If in doubt, contact your local waste disposal authorities.
Thank you for choosing Luxibel®! Please read the manual thoroughly before bringing this device into
service. If the device was damaged in transit, do not install or use it and contact your dealer.
2. Safety Instructions
Keep this device away from children and unauthorized users.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Children shall be supervised to ensure that they do not play with the appliance.
Indoor use only. Keep this device away from rain, moisture, splashing and
dripping liquids. Never put objects filled with liquids on top of or close to the
device.
Risk of electroshock when opening the cover. Touching live wires can cause life-
threatening electroshocks. Do not disassemble or open the housing yourself. Have the
device repaired by qualified personnel.
Be very careful during the installation: touching live wires can cause life-threatening
electroshocks.
DO NOT disassemble or open the cover under any circumstances. Touching live wires can
cause life-threatening electroshocks.
Do not crimp the power cord and protect it against damage.
Warning! If the power cord is damaged, it must be replaced by the manufacturer, its
service agent, or similarly qualified persons in order to avoid any hazard.
Always disconnect mains power when the device is not in use or when servicing or
performing maintenance activities. Handle the power cord by the plug only.
DO NOT disassemble or open the cover. There are no user-serviceable parts inside the
device. Refer to an authorized dealer for service and/or spare parts.
Do not stare directly at the light source, as this may cause
epileptic seizure in sensitive people
temporarily loss of sight (flash blindness)
permanent (irreversible) eye damage.
Do not use the device when noticing damage to housing or cables. Do not attempt to
service the device yourself but contact an authorised dealer.
This is a Safety Class 1 device.

LX163
V. 01 –21/04/2015 4 ©Velleman nv
3. General Guidelines
Refer to the Velleman®Service and Quality Warranty on the last pages of this manual.
Keep this device away from dust and extreme temperatures. Make sure the ventilation
openings are clear at all times. For sufficient air circulation, leave at least 1" (± 2.5 cm)
in front of the openings.
Protect this device from shocks and abuse. Avoid brute force when operating the device.
Familiarise yourself with the functions of the device before actually using it.
Do not modify the device for safety reasons. The warranty does not cover damage caused by user
modifications to the device.
Only use the device for its intended purpose. Using the device in an unauthorised way will void the
warranty.
Only use the device for its intended purpose. All other uses may lead to short circuits, burns,
electroshocks, crash, etc. Using the device in an unauthorized way will void the warranty.
The warranty does not cover damage caused by disregard of certain guidelines in this manual and
the dealer will not accept responsibility for any ensuing defects or problems.
Nor Velleman nv nor its dealers can be held responsible for any damage (extraordinary, incidental or
indirect) –of any nature (financial, physical…) arising from the possession, use or failure of this
product.
Do not switch the device on immediately after it has been exposed to changes in temperature.
Protect the device against damage by leaving it switched off until it has reached room temperature.
Keep this manual for future reference.
4. Features
The high-output COB (chip-on-board) from the COBPAR 100 RGBWA-UV produces a large wash of
coloured light. The LX163 is designed for washing and other special effects on podiums and theatre
stages.
variable electronic dimmer (0-100 %) with 4 dimmer options available via DMX
electronic shutter
built-in programme with speed adjustment
16-bit dimmer effect and white balance
temperature sensor via software to control fan speed against overheating
DMX-controlled via 13 channels
o3-channel mode: RGB
o4-channel mode: dimmer, RGB
o6-channel mode: RGBWA-UV
o7-channel mode: dimmer, RGBWA-UV
o8-channel mode: dimmer, RGBWA-UV, shutter
o13-channel mode: dimmer, RGBWA-UV, colour range, shutter, macros, macro speed, dimmer
macros, ID selection
clear LED display for menu setting
5. Overview
Refer to the illustrations on page 2 of this manual.
1
DMX input
4
setting buttons
2
DMX output
5
power cable
3
display

LX163
V. 01 –21/04/2015 5 ©Velleman nv
6. Mounting
Safety
Before mounting the product, read and follow the safety recommendations indicated in the Safety
Instructions.
Rigging
Overhead mounting requires extensive experience: calculating workload limits, determining the
installation material to be used… Have the material and the device itself checked regularly. Do not
attempt to install the device yourself if you lack these qualifications as improper installation may
result in injuries.
The carrying construction must be able to support 10 times the weight of the device for 1 hour
without deforming.
Always secure the installation with a secondary attachment such as a safety cable (e.g. VDLSC7N or
VDLSC8N). The secondary attachment shall be designed and mounted in such a way that no part of
the device can fall if the primary attachment fails.
Make sure that the safety cables can carry 10 times the weight of the device. Make sure that the
maximum height of drop is limited so that no injuries can occur. If the safety cables are long, wrap
them around the truss multiple times to reduce the height of drop to a safe level.
Never stand directly below the device when it is being mounted, removed or serviced. Have a
qualified technician check the device once a year and once before you bring it into service.
Install the device in a location with few passers-by that is inaccessible to unauthorised persons.
Make sure there is no flammable material within a 0.5 m radius of the device.
7. Connection
Power
Connect the device to the mains with the power plug.
Power all devices directly off a grounded switched circuit.
Do not connect the device to a rheostat or dimmer circuit, even when using the rheostat or dimmer
channel solely for 0 % to 100 % switching.
Have a qualified electrician carry out the electric connection.
DMX-512 Connection
When applicable, connect an XLR cable to the female XLR output of a controller (not incl.) and the
other side to the male XLR input of the device. Multiple devices can be linked through serial linking.
The linking cable shall be a dual core, screened cable with XLR input and output connectors.
A DMX terminator is recommended for installations where the DMX cable has to run a long distance
or is in an electrically noisy environment (e.g. discos). The terminator prevents corruption of the
digital control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120 Ω
resistor between pins 2 and 3, which is then plugged into the XLR output socket of the last device in
the chain.
8. Operation
8.1 Control Panel
Access the control panel functions using the four buttons below the display.
button
function
MENU
to access the menu, quit the current function without saving the setting, or quit the menu
UP
to scroll upward in a list of functions or options, or increase a value
DOWN
to scroll downward in a list of functions or options, or decrease a value
ENTER
to confirm and save a selected option or value

LX163
V. 01 –21/04/2015 6 ©Velleman nv
8.2 Menu
menu
options
function
STAT
R.000
red setting from 0-255
G.000
green setting from 0-255
b.000
blue setting from 0-255
Y.000
amber setting from 0-255
W.000
white setting from 0-255
U.000
UV setting from 0-255
ST.00
strobe setting from 0-20
AUTO
AT.01-AT.10
auto mode selection
PR.01-PR.10
programme selection
SOUd
MOD1
sound control with colour change
MOD2
sound control with colour strobe
RUN
dMX
DMX mode
SLAV
slave mode
dMX
001-512
DMX value setting
PERS
STRG
static mode (13 channels with DMX protocol)
ARC.1
3-channel mode
AR1.d
4-channel mode
ARC.2
6-channel mode
AR2.d
7-channel mode
AR2.5
8-channel mode
HSV.
hue, saturation and value setting (0-255)
Id
ID setting from ID01-ID66
TEMP
CURR
current running temperature of the device
EdIT
PR.01-PR.10
10 programmes
SC.01-SC.30
30 scenes
R.000
setting red from 0-255
G.000
setting green from 0-255
b.000
setting blue from 0-255
Y.000
setting amber from 0-255
W.000
setting white from 0-255
U.000
setting UV from 0-255
ST.00
setting strobe from 0-20
T.000
setting auto mode total running time
F.000
setting auto mode fade time 0-255
SET
UPLd
data transfer to next device with custom-made built-in programme
REST.
reset function
Id
on/off
RGbW.
CAL2 on/off
POW.
power consumption selection (high: 100 %, norm: 33 %)
dIM
off/DIM1/DIM2/DIM3/DIM4
CAL1
WT.01-WT.11
white balance from 0-255
CAL2
setting RGBWA from 25-255
8.3 Stand-Alone Mode
The device starts running in stand-alone mode after connection to the mains. This mode allows you to
use the device without controller.
1. Connect the device to the mains to switch it on
2. Press MENU to enter the menu.
3. Navigate to <AUTO> or <SOUD> with UP or DOWN and press ENTER to confirm.
4. Select an option with UP or DOWN and press ENTER to confirm.

LX163
V. 01 –21/04/2015 7 ©Velleman nv
8.4 Master/Slave Mode
Notes
The master/slave mode allows for connecting several devices to a single master device in a daisy
chain.
All slave devices will then work synchronously with the master device.
Configure all slave units before connecting the master unit to the daisy chain.
The maximum number of slave units you can connect to a master unit is 18.
Slave units:
1. Connect the DMX input from your slave device to the DMX output of the previous device in the
chain.
2. Connect the slave device to the mains to switch it on.
3. Press MENU to enter the menu.
4. Navigate to <RUN> with UP or DOWN and press ENTER to confirm.
5. Select <SLAV> with UP or DOWN and press ENTER to confirm.
6. Repeat these steps for all slave units.
Master unit
1. Connect the master device to the mains to switch it on.
2. Set the master unit to work in one of the running modes.
3. Connect the master unit as the first unit in the chain by connecting the DMX output of the master
device to the DMX input of the first slave unit.
8.5 DMX Mode
The DMX mode allows you to control the device with any universal DMX controller.
All DMX-controlled devices need a digital start address so that the correct device responds to the
signals. This digital start address is the channel number from which the device starts to “listen” to
the DMX controller. The same starting address can be used for a whole group of devices or an
individual address can be set for every device.
When all devices have the same address, all the units will “listen” to the control signal on one
particular channel. In other words: changing the settings of one channel will affect all devices
simultaneously. If you set individual addresses, each device will “listen” to a separate channel
number. Changing the settings of one channel will only affect the device in question.
To set the device to work with a DMX controller:
1. Press MENU until <Channel> is displayed and press ENTER.
2. Use UP and DOWN to select a channel and press ENTER.
3. Press MENU until <Address> is displayed and press ENTER.
4. Use <UP> and <DOWN> to set the DMX start address and press ENTER.
Start addresses
Use the table below to define the correct address. The table shows the settings for units 1 to 3. Apply the
same principle for the other units. Example:
Channel mode
1st unit
2nd unit
3rd unit
Highest start address
13
start address
1
14 (1 + 13)
26 (14 + 13)
500
channel
1 - 13
14 - 25
26 - 38
DMX Channel Values
3-Channel Mode (ARC.1)
channel
from
to
function
description
1
0
255
red
red from 0-100 %
2
0
255
green
green from 0-100 %
3
0
255
blue
blue from 0-100 %

LX163
V. 01 –21/04/2015 8 ©Velleman nv
3-Channel Mode (HSV)
channel
from
to
function
description
1
0
255
hue
hue from 0-100 %
2
0
255
saturation
saturation from 0-100 %
3
0
255
value
value from 0-100 %
4-Channel Mode (AR1.d)
channel
from
to
function
description
1
0
255
dimmer
dimmer from 0-100 %
2
0
255
red
red from 0-100 %
3
0
255
green
green from 0-100 %
4
0
255
blue
blue from 0-100 %
6-Channel Mode (ARC.2)
channel
from
to
function
description
1
0
255
red
red from 0-100 %
2
0
255
green
green from 0-100 %
3
0
255
blue
blue from 0-100 %
4
0
255
warm white
warm white from 0-100 %
5
0
255
cold white
cold white from 0-100 %
6
0
255
UV
UV from 0-100 %
7-Channel Mode (AR2.d)
channel
from
to
function
description
1
0
255
dimmer
dimmer from 0-100 %
2
0
255
red
red from 0-100 %
3
0
255
green
green from 0-100 %
4
0
255
blue
blue from 0-100 %
5
0
255
warm white
warm white from 0-100 %
6
0
255
cold white
cold white from 0-100 %
7
0
255
UV
UV from 0-100 %
8-Channel Mode (AR2.5)
channel
from
to
function
description
1
0
255
dimmer
dimmer from 0-100 %
2
0
255
red
red from 0-100 %
3
0
255
green
green from 0-100 %
4
0
255
blue
blue from 0-100 %
5
0
255
warm white
warm white from 0-100 %
6
0
255
cold white
cold white from 0-100 %
7
0
255
UV
UV from 0-100 %
8
0
10
strobe
no function
11
255
strobe with increasing speed
13-Channel Mode (STRG)
channel
from
to
function
description
1
0
255
dimmer
dimmer from 0-100 %
2
0
255
red
red from 0-100 %
3
0
255
green
green from 0-100 %
4
0
255
blue
blue from 0-100 %
5
0
255
warm white
warm white from 0-100 %
6
0
255
cold white
cold white from 0-100 %
7
0
255
UV
UV from 0-100 %

LX163
V. 01 –21/04/2015 9 ©Velleman nv
8
0
30
colour
change
no function
31
50
R 100 % / G 0-100 % / B 0 % / W 0 % /
Y 0 % / U 0 %
51
70
R 100-0 % / G 100 % / B 0 % / W 0 % /
Y 0 % / U 0 %
71
90
R 0 % / G 100 % / B 0-100 % / W 0 % /
Y 0 % / U 0 %
91
110
R 0 % / G 100-0 % / B 100 % / W 0 % /
Y 0 % / U 0 %
111
130
R 0-100 % / G 0 % / B 100 % / W 0 % /
Y 0 % / U 0 %
131
150
R 100 % / G 0 % / B 100-0 % / W 0 % /
Y 0 % / U 0 %
151
170
R 100 % / G 0-100 % / B 100 % / W 0 % /
Y 0 % / U 0 %
171
190
R 100 % / G 100-0 % / B 100 % / W 0 % /
Y 0 % / U 0 %
191
200
R 100 % / G 100 % / B 100 % / W 100 % /
Y 0 % / U 0 %
201
255
different white colour
9
0
10
strobe
no function
11
255
strobe with increasing speed
10
0
20
built-in
programme
no function
21
30
fixed programme AT01
31
120
fixed programme AT02-AT10
121
130
built-in programme PR01
131
220
built-in programme PR02-PR10
221
240
colour change through sound control
241
255
strobe through sound control
11
0
255
speed
setting for
built-in
programme
speed from slow to fast
12
0
9
dimmer
options (to
be used with
channel 1)
dimmer speed
10
29
dimmer delay off
30
69
dimmer 1
70
129
dimmer 2
130
189
dimmer 3
190
255
dimmer 4
13
0
9
ID selection
no function
135
255
ID selection form ID01-ID66
9. Cleaning and Maintenance
Before starting any cleaning or maintenance activities:
1. Unplug the device's power cord from the mains.
2. Let the device cool down.
Cleaning
Clean the external optics and the housing with a slightly moist, soft cloth. Do not immerse the device
in any liquid.
Always be sure to dry all parts completely before plugging the unit back in.

LX163
V. 01 –21/04/2015 10 ©Velleman nv
Maintenance
All screws should be tightened and free of corrosion.
The housing, visible parts, mounting supports and the installation location (e.g. ceiling, suspension,
trussing) should not be deformed, modified or tampered with e.g. do not drill extra holes in mounting
supports, do not change the location of the connections.
Wipe the device regularly with a slightly moist, lint-free cloth. Do not use alcohol or solvents.
There are no user-serviceable parts.
Contact an authorized dealer for spare parts if necessary.
10. Technical Specifications
power supply
110-240 V~, 50-60 Hz
power consumption
120 W
light source
RGBWA-UV COB 100 W EPISTAR
beam angle
60°
luminous flux
2330 lm @ 1 m
dimensions
370 x 250 x 250 mm
weight
3.8 kg
Use this device with original accessories only. Velleman nv cannot be held responsible in the
event of damage or injury resulting from (incorrect) use of this device. For more info
concerning this product and the latest version of this manual, please visit our website
www.luxibel.com. The information in this manual is subject to change without prior notice.
© COPYRIGHT NOTICE
The copyright to this manual is owned by Velleman nv. All worldwide rights reserved. No part
of this manual may be copied, reproduced, translated or reduced to any electronic medium or otherwise
without the prior written consent of the copyright holder.

Velleman® Service and Quality Warranty
Since its foundation in 1972, Velleman® acquired extensive experience in the electronics world
and currently distributes its products in over 85 countries.
All our products fulfil strict quality requirements and legal stipulations in the EU. In order to
ensure the quality, our products regularly go through an extra quality check, both by an
internal quality department and by specialized external organisations. If, all precautionary
measures notwithstanding, problems should occur, please make appeal to our warranty (see
guarantee conditions).
General Warranty Conditions Concerning Consumer Products (for EU):
• All consumer products are subject to a 24-month warranty on production flaws and defective
material as from the original date of purchase.
• Velleman® can decide to replace an article with an equivalent article, or to refund the retail
value totally or partially when the complaint is valid and a free repair or replacement of the
article is impossible, or if the expenses are out of proportion.
You will be delivered a replacing article or a refund at the value of 100% of the purchase price
in case of a flaw occurred in the first year after the date of purchase and delivery, or a
replacing article at 50% of the purchase price or a refund at the value of 50% of the retail
value in case of a flaw occurred in the second year after the date of purchase and delivery.
• Not covered by warranty:
- all direct or indirect damage caused after delivery to the article (e.g. by oxidation, shocks,
falls, dust, dirt, humidity...), and by the article, as well as its contents (e.g. data loss),
compensation for loss of profits;
- consumable goods, parts or accessories that are subject to an aging process during normal
use, such as batteries (rechargeable, non-rechargeable, built-in or replaceable), lamps, rubber
parts, drive belts... (unlimited list);
- flaws resulting from fire, water damage, lightning, accident, natural disaster, etc.…;
- flaws caused deliberately, negligently or resulting from improper handling, negligent
maintenance, abusive use or use contrary to the manufacturer’s instructions;
- damage caused by a commercial, professional or collective use of the article (the warranty
validity will be reduced to six (6) months when the article is used professionally);
- damage resulting from an inappropriate packing and shipping of the article;
- all damage caused by modification, repair or alteration performed by a third party without
written permission by Velleman®.
• Articles to be repaired must be delivered to your Velleman® dealer, solidly packed
(preferably in the original packaging), and be completed with the original receipt of purchase
and a clear flaw description.
• Hint: In order to save on cost and time, please reread the manual and check if the flaw is
caused by obvious causes prior to presenting the article for repair. Note that returning a non-
defective article can also involve handling costs.
• Repairs occurring after warranty expiration are subject to shipping costs.
• The above conditions are without prejudice to all commercial warranties.
The above enumeration is subject to modification according to the article
(see article’s manual).
Made in PRC
Imported by Velleman nv
Legen Heirweg 33, 9890 Gavere, Belgium
www.velleman.eu
