3 CCT 2’, 3’, 4’ T8 LR34231, LR34233, LR34235
• CAUTION - RISK OF FIRE. IF LAMP DOES NOT LIGHT WHEN THE
LUMINAIRE IS ENERGIZED, REMOVE LAMP FROM LUMINAIRE AND
CONTACT LAMP MANUFACTURER OR QUALIFIED ELECTRICIAN.
• CAUTION - RISK OF FIRE OR ELECTRIC SHOCK. When working with
electronics ballast, please check compatible list first. If you do not find your
ballast on the list, then please bypass the fixture as TYPE B installation or
contact us for support. Do not install the LED tube with the ballast which not on
the ballast compatible list.
• To prevent damage to lamp, lamp must NOT be energized when color (CCT)
selector switch is changed.
WARNINGS
TYPE B Application (DIRECT WIRE, Ballast-Free)
To avoid personal injury and/or possible product damage, the following
cautions must be followed:
• Read all safe information and instructions before installation.
• RISK OF ELECTRIC SHOCK. Disconnect power at fuse or circuit breaker
before installing or servicing.
• To prevent damage to lamp, lamp must NOT be energized when color (CCT)
selector switch is charged.
• Suitable for damp locations - Not for use where directly exposed to water.
• CAUTION: DO NOT use with dimmers.
• This device is not intended for use with emergency exits.
• To prevent early lamp failure, lamp should only be installed in operating
environments ranging between: -4ºF and 113ºF ( -20ºC and 45ºC)
• WARNING - RISK OF FIRE OR ELECTRICK SHOCK. LED Retrofit Kit installa-
tion requires knowledge of luminaires electrical systems. If not qualified, do
not attempt installation. Contact a qualififed electrician.
• WARNING - RISK OF FIRE OR ELECTRIC SHOCK. Install this kit only in the
luminaires that have the construction features and dimensions shown in the
photographs and/or drawings and where the input rating of the retrofit kit does
not exceed the input rating of the luminaire.
• Do not make or alter any open holes in an enclosure of wiring or electrical
components during kit installation.
• WARNING - To prevent wiring diagram damage or abrasion, do not expose
wiring to edges of sheet metal or other sharp objects.
• Installers should not disconnect existing wires from lamp socket terminals to
make new connections at lamp socket terminals. Instead, installer should cut
existing lamp socket leads away from the lamp socket and make new electrical
connections to lamp socket lead wires by employing connectors suitable for
the application.
• THIS RETROFIT KIT IS ACCEPTED AS A COMPONENT OF A LUMINAIRE
WHERE THE SUITABILITY OF THE COMBINATION SHALL BE DETERMINED
BY AUTHORITIES HVING JURISDICTION. PRODUCT MUST BE INSTALLED
BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH THE APPLICABLE
AND APPROPRIATE ELECTRICAL CODES. THE INSTALLATION GUIDE
DOES NOT SUPERSEDE LOCAL OR NATIONAL REGULATIONS FOR
ELECTRICAL INSTALLATIONS.
• Examine all parts that are not intended to be replaced by the retrofit kit for
damage and replace any damaged parts prior to installation of the retrofit kit.
• The tube is installed as Type B, the luminaire, once modified as retrofit
fixture, will no longer operate fluorescent lamps.
• For a linear tubular LED lamp conversion, there shall be text or a diagram
showing how the supply connections were made to the lamp holders so the
correct connections will be made to the lamp when the lamp is installed or
replaced.
NOTE: This product complies with Part 18 of the FCC rules but may cause
interference to radios, tv’s, wireless telephones and remote controls. If
interference occurs, move the product away from those devices or plug it into
a different outlet. Do not install this product near maritime safety communica-
tions equipment or other critical navigation or communication equipment
operating between 0.45-30Mhz.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more
of the following measures: Reorient or relocate the receiving antenna,
Increase the separation between the equipment and receiver, Connect the
equipment into an outlet on a circuit from that to which the receiver is connected,
Consult the dealer or an experienced ratio/tv technician for help. This Class B
digital apparatus complies with Canadian ICES-005.
The units covered by this report were intended to retrofit surface mount with
diffuser for these models, Type IC or non-IC recessed mount listed fluorescent
luminaires that use maximum two tubular lamps, the minimum lamp
compartment dimensions are tabulated below:
Model
MINIMUM LAMP COMPARTMENT DIMENSIONS
[Length x Width x Height][mm]
Lamp
Quanty
1218 x573 x 65 4
920 x 568 x 65
4
623 x 563 x 67 4
PARTS/COMPONENTS INCLUDED IN KIT:
- INSTALLATION INSTRUCTIONS
- LED TUBE LAMP
- LUMINAIRE MARKING LABELS. Only for Type B installation, please apply
the following lamp replacement label on the retrofit luminaire after the retrofit
kit has been installed, where readily visible by the user during relamping, and
after installation.
WARNINGS
TYPE A Application (PLUG & PLAY, Ballast compatible)
To avoid personal injury and/or possible product damage, the following
cautions must be followed:
• Read all safety information and instructions before installation.
• RISK OF ELECTRIC SHOCK. Disconnect power at fuse or circuit breaker
before installing or servicing.
• Suitable for damp locations - Not for use where directly exposed to water.
- CAUTION - DO NOT use with dimmers.
• This device is not intended for use with emergency exits.
• CAUTION - RISK OF FIRE. USE ONLY IN PLACE OF FLUORESCENT LAMPS
SPECIFIED ON PRODUCT LABEL.
• CAUTION - RISK OF FIRE - IF THE LAMP OR LUMINAIRE EXHIBITS UNDE-
SIRABLE OPERATION (BUZZING, FLICKERING, ETC.), IMMEDIATELY
TURN OFF POWER, REMOVE LAMP FROM LUMINAIRE AND CONTACT
MANUFACTURER.
LR34235
LR34233
LR34231

www.allstarlighting.com
233 Randolph Ave. • Avenel NJ 07001 | 732-882-1500
INSTALLATION GUIDE
L
N
OR
TYPE A - WIRING DIAGRAM
NOTE: The wiring diagram should be the same with the ballast wiring
diagram. When work with ballast, please check the compatible list first. If you
do not find your ballast on the list, then please bypass the fixture, or contact us.
Do not install the LED tube with the ballast that is not on the compatible list.
TYPE A - INSTALLATION GUIDE
2. Double-ended power input. Input voltage: 120-277V 50/60Hz
INSTRUCTIONS
1. Switch off power to the luminaire.
2. Remove diffuser (if provided)
3. Remove the existing fluorescent lamps from
the luminare.
4. Select the color temperature through the CCT
switch on the LED lamp base.
•Using the color (CCT) selector switch on the base, select the desired color
temperature (3000K - Soft White, 4100K - Cool White or 5000K Daylight).
• To prevent damage to lamp, lamp must not be energized when color (CCT)
selector switch is changed.
5. Install the LED tube lamp.
6. Install diffuser (if removed in Step 2)
7. Switch on power to the luminaire.
8. Before installation, please check specifications for the most current ballast
compatibility list. If no match, please insert LED tubes according to below Type
B installation instructions
TYPE B - WIRING DIAGRAM
1. Single-ended power input. Input voltage: 120-277V 50/60Hz
1
OFF
2
Fluorescent Lamp
3
Fluorescent Lamp
4
LED T8
5
LED T8
6
CCT SWITCH
7
ON Disconnect power to luminaire or circuit (if possible). Ensure all power is off by
using a voltmeter or other method to confirm.
2. Remove existing tube lamp(s)
a. Remove troffer lens, if pressend
b. Remove existing fluorescent by rotating one quarter turn and sliding
lamp(s)
c. Remove ballast cover. (Cover may be secured with screws or tabs)
3. Retrofit Luminaire
Modify the circuit according to the following wiring diagram.
IMPORTANT NOTES:
• The tube can work with either single-ended power input or double ended
power input, but when work with single-ended power input, need power input
from the end WITHOUT CCT switch.
• For single-ended wiring installation of tubes, un-shunted lamp holders must
be used.
• For double-ended wiring installation, it is not needed to change the
sockets/lamp holders (if they are in good condition) regardless of the type of
sockets.
TYPE B - INSTALLATION GUIDE
Please competely comply with these instructions and notes to ensure that the
product is operated in a safe condition. Important safety information - read all
instructions before installation.
INSTRUCTIONS
1. Disconnect power form luminaire.
a) Troffer and lamps b) Remove tube lamps c) Remove ballast cover
(lens removed)
L
N
L
N
L
N
Electronic Ballast
Electronic Compatible (Type A)
L
N
Electronic Ballast
Electronic Compatible (Type A)

33 Randolph Ave. • Avenel NJ 07001 | 732-882-1500 3
www.allstarlighting.com
INSTALLATION GUIDE
4. Select the CCT
Select the color temperature through the CCT switch on the LED lamp’s base.
• Using the color (CCT) selector switch on the base, select the desired color
temperature (3000K - Soft White, 4100K - Cool White, or 5000K - Daylight).
• To prevent damage to lamp, lamp must not be energized when color (CCT)
selector switch is changed.
5. Insert LED Tubes
a. Read label on the LED tube to ensure the power end of LED is aligned with
powered tube socket, then insert LED lamp in the normal way by sliding pins
into sockets and rotating a quarter turn until LED tube locks in place.
b. LED lamps are now fully installed.
c. Replace troffer lens, if present.
d. After modification completed. Attach the Replacement Marking and
Cautionary Label to a visible place on the luminaire and keep it visible after
installation. Be sure to mark the type of wiring on the luminaire label (single or
double-ended)
6.Restore the power of luminaire
Restore power to circuit/luminaire and test light. If necessary, adjust position
of LED tube, and enjoy your new LED tube light.
Single Ended Input (Type B)
Double Ended Input (Type B)
L
N
L
N
L
N
CCT SWITCH
