Introduction
The purpose of this document is to describe how the external control interface of the device works.
Home Automation System Integration
The Lyngdorf Audio TDAI-3400 is compatible with home automation systems via the RS232 and network
connectors on the rear socket panel. The TDAI-3400’s IR and trigger connections can also be programmed
for use in a home automation system.
Control Via Network
Open a TCP connection on port 84 and use the control protocol as described in this document. For control
from a PC, use Telnet, Putty, or similar programs to open the TCP connection.
If you do not know the IP address of the TDAI-3400 on your local network, the TDAI-3400 supports Apple´s
Bonjour Discovery service, which must be on the computer you want to set up the TDAI-3400 with. The
software is built-in as part of the Apple OS X operating system. For Windows operating systems, the
software can be found at http://www.apple.com/support/bonjour/
The control protocol is announced via bonjour as the service “slactrl”.
Pressing the “INFO” button on the remote and toggling through the “Info” of the unit will also display the
current IP address of the unit.
The TDAI-3400 can also be controlled via the network by accessing http://tdai-3400.local in your browser.
Control Via Serial Port
The serial port on the TDAI-3400 is wired as a DCE, so for communication with a PC or similar use a
standard straight through cable
The port settings should always be 8 data bits, no parity, one stop bit and no hardware handshake. The
baud rate is 115200 bits per second. All commands and responses are in ASCII form.
When controlling the TDAI-3400 via the serial port, it can wake up even when the standby mode has been
set to “deep sleep.” However, the TDAI-3400 will miss the first characters transmitted when in deep sleep,
because it needs to wake up first. To make sure the TDAI-3400 is ready for the command, send the ON-
command a couple of times in succession to guarantee that the command is always received, even if the
unit is in deep sleep

Lyngdorf Audio TDAI-3400 – External control manual
3
Control Protocol
Commands
Every command starts with ‘!’ character and ends with carriage return (ascii 0x0D, referred to in this
document as <CR>). There are two types of commands: commands and status requests. Commands are
used to emulate remote key presses or to set a certain volume etc. Status requests are used to query the
current state of the controller (volume, current source etc.). Commands with invalid formats are simply
ignored. For example, sending a command !VOL(100)garbage!MUTEON<CR> will only result in volume
being muted, because volume command is not terminated properly.
Responses and Feedback Level
There are three levels of responsiveness, called feedback levels. Each level adds something new to the
previous level. Feedback levels can be set from the control interface with command “!VERB(X)<CR>” (X can
be 0, 1 or 2). All responses start either with ‘!’ (status messages) or ‘#’ (echo messages) and end with <CR>.
Feedback level 0: Data is sent only when data is requested by a status request command. For example,
command “!VOL?<CR>” would return “!VOL(XXX)<CR>”, where “XXX” would be current volume.
Feedback level 1: Feedback level 1: Data is sent whenever any status changes. The data format is the same
as for responses to status request commands.
Feedback level 2: Each command is also echoed back with the ‘#’ in front of the command instead of ‘!’
character. For example, command “!VOL?<CR>” would return “#VOL?<CR>!VOL(XXX)<CR>”.

Lyngdorf Audio TDAI-3400 – External control manual
4
The following commands and requests are available on the TDAI-3400:
Commands
& Requests
Return format
Values
Description
!AUDIOSTATUS?
!AUDIOSTATUS
("Audiostring")
Audiostring is a string describing
the current audio input.
Requests format information for the
current audio input.
!BAL?
!BAL(balance)
Balance describes the balance
setting in this range:
L1 to L10: Balance is to the left.
0: Balance is centered
R1 - R10: Balance is to the right
Requests the current balance trim
setting
!BAL(balance)
-
Balance describes the balance
setting in this range:
L1 to L10: Balance is to the left.
0: Balance is centered
R1 - R10: Balance is to the right
Sets the balance trim setting
!BASS?
!BASS(n)
n = -12 to 12 (dB)
Requests the current bass gain trim
setting
!BASS(n)
-
n = -12 to 12 (dB)
Sets the bass gain trim setting
!BASSFREQ?
!BASSFREQ(n)
n = 20 to 800 (Hz)
Requests the current bass frequency
trim setting
!BASSFREQ(n)
-
n = 20 to 800 (Hz)
Sets the bass frequency trim setting
!DEVICE?
!DEVICE(TDAI-3400)
-
Requests identifying information.
!HP?
!HP(x)
x is 1 if headphones are connected,
otherwise 0
Requests the connection status of
headphones.
!HPMUTE?
!HPMUTE(ON) or !HPMUTE(OFF)
-
Requests the current headphone mute
state.
!HPMUTE
-
-
Toggles the current headphone mute
state.
!HPMUTEON
-
-
Mutes the headphones.
!HPMUTEOFF
-
-
Demutes the headphones.
!HPVOL?
!HPVOL(n)
-999 to 120 (steps of 0.1dB)
Requests the current headphone
volume.
!HPVOL(n)
-
-999 to 120 (steps of 0.1dB)
Sets the current headphone volume to a
new value.
!HPVOLCH(n)
-
-999 to 999 (steps of 0.1dB)
Changes the headphone volume by the
requested amount.
!HPVOLDN
-
-
Headphone volume down (by 0.5dB).
!HPVOLUP
-
-
Headphone volume up (by 0.5dB).
!IPWIFI?
!IPWIFI(xxx.xxx.xxx.xxx)
IP for the Wi-Fi interface. If not
connected,
the return value will be an empty
string.
Requests the IP of the Wi-Fi interface
!IPWIRED?
!IPWIRED(xxx.xxx.xxx.xxx)
IP for the Ethernet interface. If not
connected,
the return value will be an empty
string.
Requests the IP of the Ethernet
interface

Lyngdorf Audio TDAI-3400 – External control manual
5
!MACWIFI?
!MACWIFI(xx:xx:xx:xx:xx:xx)
MAC address for the Wi-Fi
interface.
Requests the IP of the Wi-Fi interface
!MACWIRED?
!MACWIRED(xx:xx:xx:xx:xx:xx)
MAC address for the Wired
interface.
Requests the IP of the Ethernet
interface
!MUTE?
!MUTE(ON) or !MUTE(OFF)
-
Requests the current mute state.
!MUTE
-
-
Toggles the current mute state. Same
function as the mute button on the
remote.
!MUTEON
-
-
Mutes the amplifier.
!MUTEOFF
-
-
Demutes the amplifier.
!OFF
-
-
Turns the amplifier off.
!ON
-
NOTE: When TDAI-3400 is set for
Deep Sleep Stand-by, you should
send the command twice.
Turns the amplifier on.
!PWR?
!PWR(ON) or !PWR(OFF)
-
Requests the current power state of the
amplifier.
!PWR
-
-
Toggles power state of the amplifier.
Same function as pressing the power
button on the remote.
!RP?
!RP(n)
0: Bypass
1-8: Focus positions 1 to 8
9: Global
Requests the currently selected
RoomPerfect position.
!RP(n)
-
0: Bypass
1-8: Focus positions 1 to 8
9: Global
Selects a new RoomPerfect position (if
available)
!RPDN
-
-
Selects previous RoomPerfect position.
Same as pressing down-arrow on the
remote.
!RPUP
-
-
Selects next RoomPerfect position.
Same as pressing up-arrow on the
remote.
!RPLIST?
!RPCOUNT(N)
!RPNAME(a,"Name")
!RPNAME(b,"Name")
N is the total number of positions
in the list.
a, b etc are the numbers of the
RoomPerfect Positions and
Name is the corresponding name.
One line will be send for each
available position.
Requests the index and name for each
available RoomPerfect Position.
!RPNAME?
!RPNAME(n,"Name")
n is the current RoomPerfect
position
Name: A string with the name of
the position.
Requests the name of the currently
selected RoomPerfect position.
!RPNAME(n)?
!RPNAME(n,"Name")
n is the number of the
RoomPerfect position.
Name: A string with the name of
the position.
If the requested position does not
exist, Name will be an empty
string.
Requests the name of RoomPerfect
position n.

Lyngdorf Audio TDAI-3400 – External control manual
6
!SPEAKER?
!SPEAKER(n)
0: There is only one speaker setup.
1: Speaker setup 1 selected.
2: Speaker setup 2 selected.
Requests the currently selected speaker
setup.
!SPEAKER(n)
-
1 or 2
Selects speaker setup n
(if speaker setup 2 is activated).
!SRC?
!SRC(n)
n is the index of the currently
selected source.
Requests the currently selected source.
!SRCLIST?
!SRCCOUNT(N)
!SRCNAME(a,"Name")
!SRCNAME(b,"Name")
…
N is the total number of positions
in the list.
A, b etc. are the numbers of the
sources and
Name is the name of the source.
One line will be send for each
enabled source.
Requests a list of all available and
enabled sources.
!SRC(n)
-
n can be any index from the list
returned by !SRCLIST?
Selects the source n.
!SRCDN
-
-
Selects the previous source. Same
function as pressing "SRC -" on the
remote.
!SRCUP
-
-
Selects the next source. Same function
as pressing "SRC +" on the remote.
!SRCNAME?
!SRCNAME(n,"Name")
n is the currently selected source.
Name is the name of the currently
selected source.
Requests the name of the currently
selected source.
!SRCNAME(n)?
!SRCNAME(n,"Name")
Name is the name of source n
If the requested source does not
exist or is disabled, Name will be
an empty string.
Requests the name of source n.
!STREAMTYPE?
!STREAMTYPE(n)
n is the current stream type
playing.
0 = none
1 = vTuner
2 = Spotify
3 = Airplay
4 = uPnP
5 = USB File
6 = Roon Ready
7 = Unknown stream
Requests the stream type being played.
!SWVER?
!VER
(Verstring)
Verstring is a string describing the
SW versions.
Requests the current software version
information.
!TREBLE?
!TREBLE(n)
n = -12 to 12 (dB)
Requests the current treble gain trim
setting
!TREBLE(n)
-
n = -12 to 12 (dB)
Sets the treble gain trim setting
!TREBLEFREQ?
!TREBLEFREQ(n)
n = 1500 to 16000 (Hz)
Requests the current treble frequency
trim setting
!TREBLEFREQ(n)
-
n = 1500 to 16000 (Hz)
Sets the treble frequency trim setting

Lyngdorf Audio TDAI-3400 – External control manual
7
!VERB?
!VERB(n)
n is the current VERBOSITY setting.
See table for values.
Requests the current verbosity setting.
!VERB(n)
-
n is the new verbosity level. See
table.
Sets a new verbosity level for the
interface.
!VOI?
!VOI(n)
n is the currently selected voicing.
Requests the currently selected voicing.
!VOI(n)
-
n is the voicing to select.
Can be any value from the list
returned by !VOILIST?
Selects a new voicing.
!VOIDN
-
-
Selects the previous voicing. Same
function as pressing the left arrow on
the remote.
!VOIUP
-
-
Selects the next voicing.
Same function as pressing the right
arrow on the remote.
!VOILIST?
!VOICOUNT(N)
!VOINAME(a,"Name")
!VOINAME(b,"Name")
…
N is the total number of positions
in the list.
A, b etc. are the numbers of the
voicings and
Name is the name of the voicing
One line will be send for each
voicing.
Requests a list of available voicings.
!VOINAME?
!VOINAME(n,"Name")
n is the currently selected voicing.
Name is the name of the currently
selected voicing.
If the requested voicing does not
exist, Name will be an empty
string.
Requests the name of the currently
selected voicing.
!VOINAME(n)?
!VOINAME(n,"Name")
Name is the name of voicing n.
Requests the name of voicing n.
!VOL?
!VOL(n)
-999 to 120 (steps of 0.1dB)
Requests the current volume.
!VOL(n)
-
-999 to 120 (steps of 0.1dB)
Sets the current volume to a new value.
!VOLCH(n)
-
-999 to 999 (steps of 0.1dB)
Changes the volume by the requested
amount.
!VOLDN
-
-
Volume down (by 0.5dB).
!VOLUP
-
-
Volume up (by 0.5dB).

Lyngdorf Audio TDAI-3400 – External control manual
8
IR Codes / TDAI-3400
Commands NEC1 Code
Digit 1 0xE310, 0x00FF
Digit 2 0xE310, 0x01FE
Digit 3 0xE310, 0x02FD
Digit 4 0xE310, 0x03FC
Digit 5 0xE310, 0x04FB
Digit 6 0xE310, 0x05FA
Digit 7 0xE310, 0x06F9
Digit 8 0xE310, 0x07F8
Digit 9 0xE310, 0x08F7
Up 0xE310, 0x0AF5
Down 0xE310, 0x0BF4
Right 0xE310, 0x0CF3
Left 0xE310, 0x0DF2
Standby 0xE310, 0x0FF0
Volume Down 0xE310, 0x10EF
Mute 0xE310, 0x13EC
Menu 0xE310, 0x16E9
Select 0xE310, 0x19E6
Volume Up 0xE310, 0x1AE5
Digit 0 0xE310, 0x30CF
SRC Down 0xE310, 0x31CE
SRC Up 0xE310, 0x32CD
Info 0xE310, 0x33CC
Play 0xE310, 0x50AF
Previous 0xE310, 0x57A8
Next 0xE310, 0x58A7
Double Node 0xE310, 0x609F
Crossed Node 0xE310, 0x619E
Single Node 0xE310, 0x629D
Green 0xE310, 0x639C
Yellow 0xE310, 0x649B
Red 0xE310, 0x659A
Display 0xE310, 0x6699
Voice 0xE310, 0x6798
Audio 0xE310, 0x6897
Headphone Mute 0xE310, 0x6996
Back / Exit 0xE310, 0x6A95
Trim 0xE310, 0x6B94
Power On: 0xE310, 0x807F
Power Off: 0xE310, 0x817E
Input Dig 1 Coaxial 0xE310, 0x916E

Lyngdorf Audio TDAI-3400 – External control manual
9
Input Dig 2 Coaxial 0xE310, 0x926D
Input Dig 3 Optical 0xE310, 0x936C
Input Dig 4 Optical 0xE310, 0x946B
Input Dig 5 Optical 0xE310, 0x956A
Input Dig 6 Optical 0xE310, 0x9669
Input Dig 7 USB 0xE310, 0x9768
Input HDMI 1 0xE310, 0x9966
Input HDMI 2 0xE310, 0x9A65
Input HDMI 3 0xE310, 0x9B64
Input HDMI ARC 0xE310, 0x9C63
Input Analog 1 Unbal 0xE310, 0x9D62
Input Analog 2 Unbal 0xE310, 0x9E61
Input Analog 3 Unbal 0xE310, 0x9F60
Input Analog 4 Unbal 0xE310, 0xA05F
Input Analog 5 Unbal 0xE310, 0xA15E
Input Analog 6 Bal 0xE310, 0xA25D
Input vTuner Preset 0 0xE310, 0xA35C
Input vTuner Preset 1 0xE310, 0xA45B
Input vTuner Preset 2 0xE310, 0xA55A
Input vTuner Preset 3 0xE310, 0xA659
Input vTuner Preset 4 0xE310, 0xA758
Input vTuner Preset 5 0xE310, 0xA857
Input vTuner Preset 6 0xE310, 0xA956
Input vTuner Preset 7 0xE310, 0xAA55
Input vTuner Preset 8 0xE310, 0xAB54
Input vTuner Preset 9 0xE310, 0xAC53
Switch Speaker Setup 0xE310, 0xB04F
Input vTuner 0xE310, 0xB847
Input Spotify Connect 0xE310, 0xB946
Input AirPlay 0xE310, 0xBA45
Input Roon Ready 0xE310, 0xBB44
Input uPnP 0xE310, 0xBC43
Input USB File 0xE310, 0xBD42
Input Bluetooth 0xE310, 0xBE41

Lyngdorf Audio TDAI-3400 – External control manual
10
