Lynx CardModule D VD 5010 User manual

Series 5000
© LYNX Technik AG
Brunnenweg 3
D-64331 Weiterstadt
Germany
www.lynx-technik.com
Reference Manual
D VD 5010
Reclocking SDI Distribution Amplifier
CardModul
e
Version 1.0

Reference Manual D VD 5010 Version 1.0
Page 2
Information in this document is subject to change without
notice. No part of this document may be reproduced or
transmitted in any form or by any means, electronic or
mechanical for any purpose, without express written permission
of LYNX Technik AG.
LYNX Technik AG may have patents, patent applications,
trademarks, copyrights or other intellectual property rights
covering the subject matter in this document. Except as
expressly written by LYNX Technik AG, the furnishing of this
document does not give you any license to patents,
trademarks, copyrights or other intellectual property of LYNX
Technik AG or any of its affiliates.
© LYNX Technik AG 2006 all rights reserved

Reference Manual D VD 5010 Version 1.0
Page 3
Warranty
LYNX Technik AG warrants that the product will be free from
defects in materials and workmanship for a period of two (2)
years from the date of shipment. If this product proves defective
during the warranty period, LYNX Technik AG at its option will
either repair the defective product without charge for parts and
labor, or will provide a replacement in exchange for the
defective product.
In order to obtain service under this warranty, customer must
notify LYNX Technik of the defect before expiration of the
warranty period and make suitable arrangements for the
performance of service. Customer shall be responsible for
packaging and shipping the defective product to the service
center designated by LYNX Technik, with shipping charges
prepaid. LYNX Technik shall pay for the return of the product to
the customer if the shipment is within the country which the LYNX
Technik service center is located. Customer shall be responsible
for payment of all shipping charges, duties, taxes and any other
charges for products returned to any other locations.
This warranty shall not apply to any defect, failure, or damage
caused by improper use or improper or inadequate
maintenance and care. LYNX Technik shall not be obligated to
furnish service under this warranty a) to repair damage resulting
from attempts by personnel other than LYNX Technik
representatives to install, repair or service the product; b) to
repair damage resulting from improper use or connection to
incompatible equipment; c) to repair any damage or
malfunction caused by the use of non LYNX Technik supplies; or
d) to service a product which has been modified or integrated
with other products when the effect of such modification or
integration increases the time or difficulty servicing the product.
THIS WARRANTY IS GIVEN BY LYNX TECHNIK WITH RESPECT TO THIS
PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR
IMPLIED. LYNX TECHNIK AND ITS VENDORS DISCLAIM ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. LYNX TECHNIK`S RESPONISIBILITY TO REPAIR AND
REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND EXCLUSIVE
REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS
WARRANTY. LYNX TECHNIK AND ITS VENDORS WILL NOT BE LIABLE
FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES IRRESPECTIVE OF WHETHER LYNX TECHNIK OR THE
VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH
DAMAGES.

Reference Manual D VD 5010 Version 1.0
Page 4
Regulatory information
Europe
Declaration of Conformity
USA
FCC 47 Part 15
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to the part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own
expense
We LYNX Technik AG
Brunneweg 3
D-64331 Weiterstadt
Germany
Declare under our sole responsibility that the product
TYPE: D VD 5010
To which this declaration relates is in conformity with the following
standards (environments E1-E3):
EN 55103-1 /1996
EN 55103-2 /1996
EN 60950 /2001
Following the provisions of 89/336/EEC and 73/23/EEC directives.
Winfried Deckelmann
Weiterstadt, February 2006
Place and date of issue Legal Signature

Reference Manual D VD 5010 Version 1.0
Page 5
Contents
Warranty .................................................................. 3
Regulatory information........................................... 4
Europe .............................................................................4
Declaration of Conformity..........................................4
USA.................................................................................4
FCC 47 Part 15............................................................4
Contents .................................................................. 5
Getting Started........................................................ 7
Packaging........................................................................7
Product Description ........................................................7
Functional Diagram ........................................................8
Module Layout................................................................8
Connections.......................................................... 10
Video Connections........................................................10
Installation ............................................................. 11
Settings and Control ............................................. 12
Alarm/LED Status Indicator .................................. 12
Locate Function ........................................................13
Specifications (D VD 5010) .................................. 14
Available Options................................................. 15
Parts List.................................................................. 15
Service ................................................................... 16
Contact Information ............................................. 17

Reference Manual D VD 5010 Version 1.0
Page 6
This page is intentionally left blank

Reference Manual D VD 5010 Version 1.0
Page 7
Getting Started
Packaging
The shipping carton and packaging materials
provide protection for the module during transit.
Please retain the shipping cartons in case
subsequent shipping of the product becomes
necessary.
Product Description
The D VD 5010 is a high quality reclocking digital
video distribution amplifier designed primarily for
broadcast and professional applications.
8 reclocked outputs are provided with auto
detection of standard digital video bit rates
(143Mbit/s, 177Mbit/s, 270Mbit/s, 360Mbit/s)
The D VD 5010 is part of the 5000 series of
CardModules, which offer high quality, modularity
and flexibility in a small form factor ideal for
applications where space is at a premium.
CardModules are installed in the series 5000 card
frame that can accommodate up to 10
CardModules. All modules are hot swappable and
Options include full redundant power and a range
of controller options.

Reference Manual D VD 5010 Version 1.0
Page 8
Functional Diagram
Figure 1 below is the basic functional diagram for
the D VD 5010 CardModule.
Figure 1- D VD 5010 Functional Diagram
Module Layout
Figure 2 shows the layout of the D VD 5010
CardModule and the rear connection panel.
Please refer the connections section of this manual
for wiring details for the connectors.

Reference Manual D VD 5010 Version 1.0
Page 9
Figure 2 – Module Layout
Caution
Use static precautions when handling the
PCB. Static discharge could result in serious
damage to the module.

Reference Manual D VD 5010 Version 1.0
Page 10
Connections
Video Connections
The D VD 5010 CardModule is configured with
standard 75 Ohm BNC connectors. Connection is
self-explanatory. We recommend the use of high
quality video cable for digital video connections to
reduce the risk of interference or errors due to
excessive cable attenuation. Some guidelines for
max cable length are shown below.
250m (820 feet) Belden 8281 (270Mbits/s)
150m (492 feet) Belden 8281 (540Mbits/s)
Note. Due to the compact design of the
connection plate it will be necessary to use a
connection tool to secure the BNC video
connectors.

Reference Manual D VD 5010 Version 1.0
Page 11
Installation
Caution
The CardModule is shipped in a
protective anti-static bag. Please take
suitable precautions to avoid static
discharge onto any part of the PCB or
components when handling module or
serious damage could result.
Each Card Module is supplied with a rear
connection panel and two mounting screws.
Please follow the following procedure for
installation of the card module into the Series 5000
Card Frame.
a) Select a slot in the card frame where the
CardModule will be located
b) Remove the blank connection panel from the
rear of the rack (if fitted)
c) Install the rear connection panel using the
screws supplied. Do not tighten the screws fully
d) Slide the card module into the card frame and
carefully check the CardModule easily
connects to the rear connection plate. The
card should fit easily and should not require
excessive force to insert, if you feel any
resistance, there could be something wrong
with the rear connection panel location. Do not
try and force the connection. Remove the rear
connection panel and check alignment with
the CardModule.
e) Insert and remove the CardModule a few times
to ensure correct alignment and then tighten
the two screws to secure the rear connection
plate

Reference Manual D VD 5010 Version 1.0
Page 12
Settings and Control
The D VD 5010 has an integrated micro-controller,
which enables the module to be controlled locally
or from remote when using one of the optional
controllers and control software.
The D VD 5010 has a fixed configuration, signal
presence detection is indicated via the Alarm LED
on the front card edge or via the LYNX control
system when using one of the optional controllers
and control software.
Alarm/LED Status Indicator
The D VD 5010 module has an integral LED
indicator, which serve as alarm indication for the
module.
This is visible through the card frame front cover
and provides a general indication of the module
status.
LED OFF indicates power is lost, or there is a power
supply fault.
LED Color Indication
Green Signal Present (locked)
Red Input signal lost

Reference Manual D VD 5010 Version 1.0
Page 13
Locate Function
For larger systems which may have multiple cards
of the same type in a single rack, or multiple rack
systems on a large central control system we have
added a useful utility which will help to visually
locate a suspect module quickly (When used in
conjunction with the optional control system and
software)
Once the specific module has been selected on
the control system there is a locate button on the
top of the GUI:
Locate Function in Control System
When Locate is selected the status indicator on the
GUI and the alarm LED will flash yellow in the
following continuous sequence.
3 short flashes…. Pause…. 3 short flashes …
Use of the locate function will not interfere with the
normal operation of the module.
For more details on this feature please check the
documentation supplied with the controller
software.

Reference Manual D VD 5010 Version 1.0
Page 14
Specifications
(D VD 5010)
Inputs
Signal 1 Serial Digital Video. SMPTE 259M-C
Input Impedance 75 Ohms
Input level 0.8V p-p
Return loss > 15dB (270MHz)
Connection BNC
Outputs
Signal 8 Serial Digital Video. SMPTE 259M-C
Output Impedance 75 Ohms
Output Level 0.8V p-p nom.
Return loss > 15dB (270 Mbit/s)
Connection BNC
Performance
Cable Equalization Up to 250m using Belden 8281 (270Mbit/s)
Jitter < 0.2 UI
Status Monitoring (LED) Signal presence
Electrical Specifications
Operating Voltage + 5VDC
Power Consumption 2 W
Safety IEC 60950/ EN 60950/VDE 0805
Mechanical
Size 283mm x 78mm
Weight Card module 120g, connection panel 50g
Ambient
Temperature 5°C to 40°C Maintaining specifications
Humidity Max 90% non condensing
Supplied Accessories
Documentation D VD 5010 Reference Manual

Reference Manual D VD 5010 Version 1.0
Page 15
Available Options
Below is a list of related products for the D VD 5010
CardModule. Please refer to product brochures or
our web site for more detailed information.
Model Description
R FR 5010
Series 5000 Rack Frame (empty) with single
power supply
R FR 5011
Series 5000 Rack Frame (empty) with single
power supply and additional fans in the
front cover
R PS 5010
Redundant power supply for the R FR 5010
Card Frame
R CT 5020
Rack controller for the R FR 5010 Card
Frame
R CT 5030
Master controller with TCP/IP interface for
the R FR 5010 Card Frame
R CT 5010
Rack Bus Extension for the R FR 5010 Card
Frame. In combination with R CT 5020/5030
Parts List
Due to the very dense design and miniature
surface mount technology the module is not field
serviceable. The information for a replacement
assembly is below.
D VD 5010 CardModule (complete)
Description Recl. SDI Distribution Amplifier
Model Number D VD 5010
Part Number 6.155.005.010
Sub Assemblies:
D VD 5010 Processing Board only. (BS 5033_A)
Part Number 6.155.004.391
Rear Connection Panel for D VD 5010 (MA5001_B)
Part Number 6.155.008.371

Reference Manual D VD 5010 Version 1.0
Page 16
Service
If you are experiencing problems, or have questions
concerning your D VD 5010 CardModule please
contact your local distributor for assistance.
We offer a fixed cost service exchange program for
defective Series 5000 CardModules out of
Warranty. Please contact your distributor or check
our web site for details on this program.
More detailed information and product updates
may be available on our web site:
www.lynx-technik.com
You will also find links to contact us directly for
assistance.

Reference Manual D VD 5010 Version 1.0
Page 17
Contact Information
Please contact your local distributor; this is your
local and fastest method for obtaining support and
sales information.
LYNX Technik can be contacted directly using the
information below.
Address LYNX Technik AG
Brunnenweg 3
D-64331 Weiterstadt
Germany.
Website www.lynx-technik.com
E-Mail info@lynx-technik.com
LYNX Technik manufactures a complete range of
high quality modular products for broadcast and
Professional markets, please contact your local
representative or visit our web site for more product
information.

Reference Manual D VD 5010 Version 1.0
Page 18
Notes
This manual suits for next models
1
Table of contents
Other Lynx Amplifier manuals

Lynx
Lynx D VD 5020 User manual

Lynx
Lynx D VD 5830 User manual

Lynx
Lynx D VD 5820 User manual

Lynx
Lynx D AD 3220 B User manual

Lynx
Lynx D VD 5002 User manual

Lynx
Lynx D VA 3120 L User manual

Lynx
Lynx D AD 5220 D User manual

Lynx
Lynx DSX-1004 User manual

Lynx
Lynx D VD 5420 User manual

Lynx
Lynx D VA 3720 User manual

Lynx
Lynx SX Series User manual

Lynx
Lynx D VD 3020 User manual

Lynx
Lynx D VD 5810 User manual

Lynx
Lynx 2000 G-Touring 600 User manual

Lynx
Lynx D VA 3120 User manual

Lynx
Lynx D VA 5718 L User manual

Lynx
Lynx D AA 5320 D User manual

Lynx
Lynx D VD 3620 User manual

Lynx
Lynx Subamp Series User manual

Lynx
Lynx SBA Series User manual
