Lynx All-Sear series User manual

ALL-SEAR CARE & USE/INSTALLATION
MAKE THE MOST OF YOUR

2
|ALL-SEAR CARE & USE/INSTALLATION
WARNINGS
READ THIS MANUAL CAREFULLY and completely before using your grill to reduce the risk of:
1. Fire
2. Burn hazard, personal injury or property damage
3. Ruined steaks or other unpleasant cooking experiences
4. Unapproved installation or servicing.
THIS PRODUCT IS DESIGNED FOR OUTDOOR USE ONLY. Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read this manual thoroughly before installation, use, or servicing of this product.
1. The burning of gas cooking fuel generates some by-products which are on the list of substances which are
known by the State of California to cause cancer or reproductive harm.
2. California law requires businesses to warn customers of potential exposure to such substances. To minimize
exposure to the substances, always operate this unit according to the use and care instructions found in this
manual. Be certain to provide adequate ventilation when cooking.
3. California Proposition 65 lists “Silica, crystalline” which is used in one of the components of the IR burner, as
an agent known to the state of California to cause cancer.
IF YOU SMELL GAS:
1. Shut off all gas supply lines to the grill.
2. Extinguish any open flames.
3. Carefully open the lid. Remember, it may be
extremely hot!
4. If odor continues, keep everyone away from the
grill and immediately call your gas supplier or
your fire department.
1. DO NOT store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.
2. An LP cylinder not connected for use shall not
be stored in the vicinity of this or any other
appliance.
S’IL Y A UNE ODEUR DE GAZ:
1. Coupez l’admission de gaz de l’appariel.
2. Éteindre toute flamme nue.
3. Ouvrir le couvercle. Rappelez-vous qu’il peut
être extrêmement chaude
4. Si l’odeur persiste, éloignez-vous de l’appareil
et appelez immédiatement le fournisseur de
gaz ou le service d’incendie.
1. Ne pas entreposer ni utiliser de l’essence ni
d’autres vapeurs ou liquides inflammables
dans le voisinage de l’appareil, ni de tout
autre appareil.
2. Une bouteille de propane qui n’est pas
raccordée en vue de son utilisation, ne doit
pas être entreposée dans le voisinage de cet
appareil ou de tout autre appareil.
WARNING
DANGER
WARNING
DANGER
AVERTISSMENT
WARNING! CALIFORNIA PROPOSITION 65

ALL-SEAR CARE & USE/INSTALLATION |3
1. Before each use, complete the checklist below.
2. Make sure all burner control knobs are in the “OFF” position.
3. Push and hold the control knob in for 2 – 5 seconds, allowing the igniter to heat up.
4. Turn the knob to the “LITE” position.
5. After ignition set the knob to the desired setting.
HOW TO LIGHT YOUR ROTISSERIE BURNER
HOW TO LIGHT YOUR GRILL
PART NO. 33526 REV. C 02/2015
• Do you smell gas? If yes, shut off everything and call the
gas company or a qualified plumber to check for leaks, if
not please continue.
• Are you prepared to stay with the grill during the entire
cooking process? If not, gather what you need before
starting the lighting process. If yes, please continue.
• Is your cooking area free and clear of any combustibles,
besides your food, that might ignite? If no, clear the
area before starting the lighting process, If yes, please
continue.
• Do all control knobs turn freely? If not, call for service, if
yes, please continue.
• If you are using a portable propane cylinder, is it
connected and leak tested? If not, check the connection
before continuing. If yes please continue.
• Do you know where your grill’s main gas supply shut off
valve is located? If not, locate it before continuing. If yes,
please continue.
• Are all burners properly seated in the grill? If not, seat
the burners properly before continuing. If yes please
continue.
• Is the wind blowing just lightly and not blowing on the
back of the grill? If not, wait until the wind subsides or
turn your free standing grill so the wind goes into the
front of the grill. If yes, please continue with the lighting
process.
CHECKLIST BEFORE EACH USE (FOR YOUR SAFETY)
Note: The rotisserie burner features a thermocouple sensor with a safety valve that automatically shuts off
the flow of gas if the burner goes out for any reason.
1. Before each use, complete the checklist below.
2. Make sure all burner control knobs are in the “OFF” position.
3. Push and hold the control knob for 2 – 5 seconds.
4. Turn the knob to the “LITE” position and continue to hold the knob in for an additional 30 – 60 seconds to
allow the thermocouple to heat up and keep the safety valve open.

4
|ALL-SEAR CARE & USE/INSTALLATION
WARNINGS
WARNING
This product complies with ANSI standard Z21.58/CSA
1.6 latest edition and has been tested and approved by
Intertek.
To obtain replacement parts or service contact:
Lynx Grills, Inc.
7300 Flores Street
Downy, CA 90242
888-289-5969
• Never use dented, rusty or damaged propane cylinders. Never store additional or empty propane cylinders
in the grill cabinet or in the vicinity of this or any other appliance. Do not store propane cylinders indoors or
on their sides.
• Children should never be left alone or unattended in an area where a grill is located. Place your grill well
away from areas where children play. Do not store items that may interest children in or around the grill, in
the cart, or in the masonry enclosure.
• Never move the grill when hot. When in use, portions of the grill are hot enough to cause severe burns.
• Always maintain the required clearances from combustibles as detailed. The grill is designed for outdoor
use only. Never use in a garage, building, shed, breezeway, or other enclosed area. Do not use this grill
under any unprotected overhead combustible construction.
• Gas grills are not designed or certified for and are not to be installed in or on recreational vehicles, portable
trailers, boats or any other moving installation.
• Always have an ABC Fire Extinguisher accessible — never attempt to extinguish a grease fire with water or
other liquids.
• Storing your grill: Store your grill in a well-ventilated area. If stored indoors, detach and leave L.P. cylinder
outdoors in a well-ventilated area away from heat and away from where children may tamper with it.
• Keep any electrical supply cord and the fuel supply hose away from any heated surfaces. Electrical cords
should be placed away from walkways to avoid tripping hazard.
• Do not repair or replace any part of the grill unless specifically recommended in this manual. Other service
should be performed by a qualified technician.
• If the grill is installed by a professional installer or technician, be sure that he/she shows you where your
gas supply shut-off is located. All gas lines must have a shut-off that is readily and easily accessible. If you
smell gas, check for gas leaks immediately. Check only with a soap and water solution. (See INDEX: “Leak
Testing” for further details.) Never check for gas leaks with an open flame.
• Inspect the LP gas supply hose prior to each use of the grill. If there is evidence of excessive abrasion or
wear, or the hose is cut, it must be replaced before using the grill.
• Never remove the grounding prong from the plug or use this product with an ungrounded, 2-prong
adapter.
THIS MANUAL MUST REMAIN WITH THE PRODUCT OWNER FOR FUTURE REFERENCE.

ALL-SEAR CARE & USE/INSTALLATION |5
You’ve just joined the world of Lynx cooks … a discriminating
collection of amateur and professional chefs that take outdoor
cooking to a new level.
Your grill has been designed and built with meticulous attention
to detail and it offers some unique and powerful features. You can
achieve maximum performance and enjoyment of these features
only by carefully reading this manual ... before your first cook-out.
This manual includes important safety tips and great hints for better
grilling. You’ll want to keep it handy for easy reference.
Also, at Lynx, we enjoy hearing from our customers. We like to hear
about your successes but also about any difficulties you are having.
Please feel free to contact us with any questions or problems, or just
to share a new recipe. Please include the model number of your grill
in your correspondence.
With the proper use and care this product will provide years of
trouble-free service.
Should your Lynx grill change ownership, please make sure that the
new owner receives this manual.
Thanks again for your purchase. Enjoy!
A MESSAGE TO OUR CUSTOMERS

6
|ALL-SEAR CARE & USE/INSTALLATION
HOW TO LIGHT YOUR GRILL 3
HOW TO LIGHT YOUR ROTISSERIE BURNER 3
CHECKLIST BEFORE EACH USE 3
A MESSAGE TO OUR CUSTOMERS 5
USE & CARE GUIDELINES 7
Lynx Grill Models 7
IMPORTANT SAFETY PRECAUTIONS 8
GRILLING IN WINDY CONDITIONS 9
USING YOUR LYNX GRILL 10
Pre-Grill Checklist 10
Lighting your Grill 11
Basic Grilling 13
Using the Rotisserie Burner 14
Using the Smoker Box 16
CLEANING YOUR LYNX GRILL 17
TROUBLESHOOTING YOUR LYNX GRILL 19
Potential Problems 19
Contacting Lynx Customer Care 22
The Lynx Story 22
LYNX LIMITED WARRANTY 23
LYNX COMMON AREA LIMITED WARRANTY 24
BEFORE YOU START 26
If Shipment Arrives Damaged 26
Important Notes 26
SPECIFICATIONS & INSTALLATION 28
UNPACKING & ASSEMBLY 30
ELECTRICAL CONNECTIONS 31
GAS CONNECTIONS 32
Natural Gas 32
LP Gas 33
FINAL CHECKS 34
Leak Testing 34
SIDE BURNER HOOK UP 36
WIRING SCHEMATICS 37
L30ASR & L30ASFR 37
L36ASR & L36ASFR 38
L42ASR & L42ASFR 39
LYNX PROFESSIONAL ALL-SEAR GRILL EXPLODED PARTS VIEW 40
LYNX PROFESSIONAL ALL-SEAR GRILL PARTS LIST 41
MODEL-SPECIFIC BTU OUTPUTS & MAX. RUNS FOR APPLIANCES 42
INDEX 43
TABLE OF CONTENTS

ALL-SEAR CARE & USE/INSTALLATION |7
This use & care manual covers the Lynx grill models listed below. Some features and options will vary based upon
the model that you purchased.
LYNX GRILL MODELS
USE & CARE GUIDELINES
BUILT-IN FREESTANDING
L30ASR L30ASFR
L36ASR L36ASFR
L42ASR L42ASFR

8
|ALL-SEAR CARE & USE/INSTALLATION
1. NEVER LEAVE THE GRILL UNATTENDED WHILE
COOKING.
2. Ensure all tie-down wires have been removed from the
burners.
3. Always use caution when operating the grill in a windy
area. (See INDEX: “Grilling in Windy Conditions” for
further details.)
4. Avoid wearing loose-fitting garments or long sleeves
while grilling. They could ignite.
5. Never touch the grill racks, hood or immediate sur-
rounding metal surfaces with your bare hands while
grilling.
6. Use an insulated glove or mitt when opening and
operating the grill. Always open the grill lid slowly to
allow heat and smoke to escape before fully opening.
7. The grill hood must be fully opened while lighting the
grill. Releasing fuel into a closed grill before lighting
will not make it light sooner or more efficiently. It will
only risk explosion and personal injury or death. Never
lean over a hot grill surface or look directly into the grill
when attempting to light.
8. Do not heat unopened food containers as pressure
build-up will cause the container to explode.
9. Do not use aluminum foil to line grill racks or drip pans.
This will alter the airflow or trap excessive heat in the
control area and can melt control knobs and ignition
modules. Such damage is specifically excluded from
your warranty.
10. Never use charcoal or any other solid fuel in the grill.
11. Cooking excessively fatty meats and oils will cause flare
ups. Internal fires or damage caused by them or by the
grill being left unattended while cooking are not cov-
ered under the terms and conditions of our warranty.
12. Never grill without the drip pan in place. Always ensure
the drip pan is pushed all the way to the back of the
grill. Hot grease can leak downward and produce a fire
or explosion.
13. Grease is extremely flammable. Let hot grease cool
down before attempting to handle or dispose of it.
The drip tray should be cleaned of grease on a regular
basis.
14. Do not use the grill unless a leak check has been per-
formed on all gas connections. (See INDEX: “Leak Test
Procedure” for further details.)
15. Never operate the grill while under the influence of
alcohol or drugs.
16. Do not lean on side shelves and never place a load
weighing more than 25 pounds on a side shelf.
17. If any burner does not light or goes out during opera-
tion, turn off all gas control knobs, open the hood and
wait five (5) minutes before attempting to re-light.
18. Portable LP cylinders: Always shut off the main valve
on the LP cylinder after each use.
19. Spiders and insects like to nest in the burners, venturis,
valves and orifices of a grill, disrupting the gas flow.
This very dangerous condition can cause a fire be-
hind the control panel, damaging the grill and risking
personal injury. If your grill has been unused for a long
time, inspect and clean the burners, venturis, valves
and orifices. (See INDEX: “Cleaning your Lynx Grill” for
further details.)
IMPORTANT SAFETY PRECAUTIONS
PLEASE REVIEW THESE IMPORTANT SAFETY PRECAUTIONS BEFORE YOU USE YOUR GRILL.

ALL-SEAR CARE & USE/INSTALLATION |9
GRILLING IN WINDY CONDITIONS
Outdoor grills create more heat than interior kitchen
ranges. That’s how they sear and grill steaks and other
foods.
These high-performance burners require a constant, steady
supply of fresh air to mix with the fuel. Your Lynx grill pulls air
in through the front and vents hot gases out through the rear.
Using your grill in windy conditions may disrupt the front-
to-back air flow. If, while grilling with all burners on high
and the hood closed, you notice that the temperature
gauge fails to rise ... be careful. If wind has kept hot gases
from exiting the rear of the grill the control panel and knobs
may have become extremely hot.
Your Lynx grill features an exclusive, patent-pending Heat
Stabilizer that will deflect wind and, in most cases, prevent
this situation.
But there are a few things you can do to further prevent
the possibility of improper heat buildup:
• On breezy days, be careful not to leave the front hood
down for more than 15 minutes when the burners are on
high. (Never leave the grill unattended when in operation)
• If you suspect the grill is overheating, using an oven mitt,
open the front hood. Then adjust the burner control knob
to a lower setting.
• Install your grill with a wind break behind it.
• Orient the grill so prevailing winds are not blowing into
the rear of the grill.
Please Note: Any damage caused from use in windy
conditions, such as melted knobs or igniter wires,
or control panel discoloration from heat buildup, is
excluded from warranty coverage.
Wind hitting the back of the grill can
disrupt proper exhaust.
Air enters through the front of the grill.

10
|ALL-SEAR CARE & USE/INSTALLATION
BEFORE YOUR FIRST USE
There are a few must-check safety precautions to consider
before you use your grill. Please be sure that:
• All packing materials and tie-downs have been removed
from the burners. (See INDEX: “Unpacking and
Assembly” for further details.)
• You have fuel connected. (See INDEX: “Gas
Requirements” for further details.)
• You have electric connected. (See INDEX: “Electric
Requirements” for further details.)
• A qualified plumber has performed a leak test on all the
fittings that supply fuel to your grill.
• IF YOUR GRILL DOES NOT LIGHT IN 4 TO 5
SECONDS you may need to purge the line. (See INDEX:
“Purging the Gas Line”
AT EACH NEW SEASON
At the start of each new grilling season you should remove
the grilling racks and check the burners, venturis, orifices
and valves for obstructions.
Spiders and insects often nest in these areas of the grill
and can disrupt air flow, causing damage to the grill and
personal injury.
Also, check all hoses and fittings for damage, abrasion,
wear and tear.
BEFORE EACH USE
Before any use, always make sure that:
• ... you do not smell gas before you light the grill. If you
do smell gas, shut everything off and have a qualified
plumber check for leaks.
• … the cooking area is free and clear of any combustibles,
besides your food, that might ignite.
• … the control knobs turn freely.
• … if you are using a portable propane cylinder, it is
securely connected and leak tested. (See INDEX:
“Cylinder Retention Instructions” for details.)
• … you know where the main gas supply shut-off is
located.
• … the burners are seated properly in the grill. The main
burners must sit level and firmly on the burner mounting
support frame. (See INDEX: “Unpacking and Assembly”
for further details.)
• … wind is not blowing too strongly or blowing on the
back of grill.
USING YOUR LYNX GRILL
Grilling requires high heat for searing and low, controlled
heat for slow cooking.
Thinner cuts of food are often cooked at a “HI” heat
setting with the lid open.
On the other hand, large, thick pieces of meat or poultry
are often first seared at the high setting and then grilled
at a lower setting ... sometimes with the lid closed …
achieving the best results in the middle of the food without
burning the outside.
Some foods are cooked using direct heat and some using
indirect heat.
Your Lynx grill features a variety of professional-level
burners and tools for meeting the wide variety of cooking
challenges. We will reveal how these features work for you.
So please read and enjoy!
Depending on the model you chose, your Lynx grill may be
equipped with two different burner types. The operation of
each type varies, so it is important to understand them.
PRE-GRILL CHECKLIST
ProSear™ 2 Burner
This advanced infrared burner
provides high-intensity infrared heat
for searing foods and sealing in
flavor.
Rotisserie Burner
This infrared burner spans the back of the
cooking surface and provides consistent
heat for slow rotisserie cooking.

ALL-SEAR CARE & USE/INSTALLATION |11
ELECTRIC IGNITION
Before proceeding, make sure you have completed the
“Before Each Use” checklist.
Follow these steps to light any of the burners on your grill:
First, make sure all burner control knobs are set to OFF.
For the ProSear™ 2 Burner:
Push and hold the control knob in for 2 seconds, allowing
the igniter to heat up. Then rotate the knob to “LITE”. After
ignition, set the knob to the desired heat setting.
For the Rotisserie Burner:
The rotisserie burner features a thermocouple sensor with
a safety valve that automatically shuts off the flow of gas if
the burner goes out. (See INDEX: “Windy Conditions” for
tips on how to prevent burner blow out)
To light the rotisserie burner, push and hold the control
knob in for 2 seconds and then turn the knob to the “LITE”
position.
After ignition CONTINUE HOLDING THE CONTROL KNOB
IN for 30 to 60 seconds. During this time the thermocouple
will heat up and the safety valve will remain open.
If you release the control knob before the thermocouple
has heated up, the safety valve will shut off the flow of gas
to the rotisserie burner and you will have to re-light the
burner.
LIGHTING YOUR GRILL
1. Never attempt to light a burner if you smell gas.
2. Always keep the lid open (side-burner lids must be completely removed) when lighting your grill.
3. Releasing fuel into a closed grill before lighting will increase the risk of explosion, property damage , personal
injury or death.
4. Keep your face and body as far from the grill as possible when lighting. Any time a burner doesn’t light within
5 seconds, turn off the control, wait 5 minutes for gas to dissipate, and repeat the lighting procedure.
5. YOU NEVER LEAVE THE GRILL UNATTENDED WHILE COOKING.
WARNING

12
|ALL-SEAR CARE & USE/INSTALLATION
MANUAL LIGHTING
If a burner doesn’t light after several attempts, it can be
match lit using the lighting rod stored in the drip tray.
First, make sure you’ve returned all of the control knobs
to the OFF position and have allowed 5 minutes for any
accumulated gas to dissipate before attempting to match
light a burner.
ProSear™ 2 Burners
To match-light the burners, use the lighting rod to insert a
lit match through the cooking grate.
Push and turn the corresponding burner control knob to
“LITE”. If the burner doesn’t light within 5 seconds turn the
knob off and wait 5 minutes before attempting to light it
again.
LIGHTING YOUR GRILL ...continued
Extremely cold temperatures may cause your
ProSear™ 2 burners to light inside the burners
instead of outside. Once lit, if you hear a ‘whoosh-
ing’ sound, immediately turn the burner knobs
off to extinguish the flame and then immediately
re-light the burners.
COLD WEATHER WARNING:
PROPANE

ALL-SEAR CARE & USE/INSTALLATION |13
PRE-HEATING
Pre-heating your grill every time you use it is extremely
important. Pre-heating allows the grill to properly heat up,
providing more even and more consistent cooking results.
Pre-heat your grill by igniting all of the burners and setting
them to “HI”.
Then close the hood and allow the grill to heat for 5 to
10 minutes. Once you’ve reached your desired pre-heat
temperature, turn off the burners that you won’t be using to
cook your food.
TYPES OF COOKING
The main burners in your Lynx grill are capable of creating
a range of heat intensities. By varying the heat output, the
number of burners used and the position of the hood, you
can create either direct or indirect heat or a combination of
both and develop a wide variety of succulent recipes. There
are two basic types of grilling in an outdoor grill... Direct
Heat and Indirect Heat
Direct Heat
Direct heat cooking occurs when foods are placed directly
over the heat source. This form of heat is known as
“radiant” heat because the heat radiates directly from the
source to the food.
Direct heat is a must when you want to sear the outside
of your food to seal in flavor. Lynx ProSear™ 2 Burners
provide the heat necessary to sear foods and seal in flavor.
Indirect Heat
Indirect heat cooking occurs when the food is not close to
the heat source. Heat reaches the food via air movement
within the cooking area. This form of heat is known as
“convection” heat.
Indirect, or “convection” cooking is achieved by placing
the food on one side of the grill and igniting burners on the
other side. You leave the burner below the food “OFF”.
You should keep the hood closed as much as possible
during this type of cooking to maintain even heat around
the food. You regulate the heat by adjusting the burner,
using the hood thermometer to monitor the temperature.
BASIC GRILLING
DO NOT LEAVE THE GRILL UNATTENDED
DURING THE PRE-HEAT CYCLE OR AT ANY TIME
WHILE THE GRILL IS IN USE.
PRE-HEATING FOR MORE THAN 15 MINUTES
MAY OVERHEAT THE GRILL, CAUSING DAMAGE
TO THE GRILL.
WARNING!

14
|ALL-SEAR CARE & USE/INSTALLATION
Professional restaurant chefs rely on a different type of heat
... infrared heat ... to create a higher searing temperature
than what standard burners can achieve. So Lynx provides
the ProSear™ 2 infrared burner.
Infrared burners work by focusing the gas flame through a
ceramic element filled with tiny holes.
These holes focus the flame on the surface of the element,
creating an intense heat much higher than that of a
standard brass burner. It allows you to sear your food more
quickly while leaving the inside rare, if desired.
The ProSear™ 2 burner, with its advanced components,
requires particular attention to lighting, usage and cleaning
guidelines. Refer to the different sections of this manual
that address these issues.
Pre-Heating the ProSear™ 2 Burner
Always pre-heat the entire grill before cooking to achieve
consistent, successful results. (See INDEX: “Pre-Heating”
for further details.)
You should pre-heat the ProSear™ 2 burners for 5 to 10
minutes or until they glow red.
Never place food over the ProSear™ 2 burners before they
are fully pre-heated because food particles and grease
dripping onto a cold ProSear™ 2 burner can clog the tiny
ports and damage the burner.
For the same reason you should minimize water spills
on the ProSear™ 2 burner and should not use water to
control flare-ups. Take special care to minimize dropping
any liquids on the ProSear™ 2 burner while cleaning the
cooking grids.
HOW TO SEAR
Searing locks in flavor and juices while allowing the food’s
outer surface to absorb smoke and food-born aromas
produced when drippings are vaporized by the burner.
The result is a restaurant-style finish … crisp, flavorful
outside with a tender, juicy inside. The ProSear™ 2 infrared
burner is specifically designed for this purpose.
USING THE PROSEAR™ 2 BURNER
Lynx grill cooking grids are heavy duty. Dropping
them on the ProSear™ 2 burners will damage
the burners. Such damage is not covered by the
product warranty and will cause a fire, burns or
other personal injury.
PROSEAR™ 2 CLEANING
It’s easy to keep your ProSear™ 2 burners
operating at peak performance. Just run them on
“HI” with the hood open for 5 minutes after each
use to burn away any food particles or drippings.
SAFETY PRECAUTIONS

ALL-SEAR CARE & USE/INSTALLATION |15
Rotisserie cooking
provides an even
delivery of heat
to your foods. It
has no equal. The
constant rotation not only cooks foods evenly, it also self
bastes. As juices rise to the surface of the food, they natu-
rally flow around it as it rotates. And, by moving the burner
out from beneath the food, you avoid scorching flare-ups.
Your foods will be more evenly
cooked, more tender and juicier
when slow-roasted on a Lynx’s
rotisserie.
The Lynx rotisserie system
consists of four main parts, the motor, the skewer, the forks
and the infrared burner.
The Motor
Install the motor by sliding it into
one of the slots shown here. Use
the top slot for small foods or fast
cooking and the lower slot for
large foods and slower cooking.
Plug the motor power cord into the motor and into the
built-in power outlet on the rear left
panel. Your grill must be plugged into
an AC power supply for the rotisserie
to work.
Place a basting pan in the grill to pre-
vent food accumulations on the burn-
ers. But BE SURE YOU REMOVE IT
before using any of the other burners.
The location of the
rotisserie burner makes
it more susceptible to
strong wind conditions
(more so than the main
grill burners).
For this reason it features a safety valve that automatically
closes any time the rotisserie burner is not properly lit …
like if it were to extinguish in windy conditions. During
windy conditions, it’s best to keep the lid closed and to
periodically check the burner.
When the rotisserie is not in use the rotisserie motor should
be stored in a cool dry location.
The Skewer & Forks
The rotisserie can handle large food items up to 50 lbs. You
should prepare any item and first mount it on the skewer.
Swing the warming rack up and out of the way. It will rest in
place.
Then mount the skewer on the grill before lighting the
rotisserie infrared burner. Lighting the burner first could
result in burning your hands while trying to mount the
skewer on the grill.
It’s okay to remove the grill racks to make room for large
foods on the skewer.
To load the skewer, slide one of the forks onto the skewer.
Push the skewer through the center of the food, then slide
the second fork onto the skewer. Center the food to be
cooked on the skewer then push the forks firmly together.
Tighten the thumb screws (use pliers if necessary). You
should wrap any loose, dangling pieces of food (like wings)
with butcher’s string (never use nylon or plastic string).
With the food secured to the skewer slowly roll the skewer
in the palms of your hands to check for balance. It should
rotate smoothly. If you find it has a heavy side, adjust where
the skewer pierces the meat. An unbalanced skewer will
cause uneven rotation and uneven cooking. It’s normal for
the skewer to flex with large foods.
USING THE ROTISSERIE BURNER
Rotisserie
Motor Mount

16
|ALL-SEAR CARE & USE/INSTALLATION
Slide the pointed end of the skewer into the motor and rest
the other end on the rollers on the other side of the grill.
The notched portion of the skewer must rest on the rollers
for proper operation.
The Rotisserie Burner
To light the rotisserie infrared burner, first mount the
skewered food item on the grill then follow the rotisserie
lighting procedure. (See INDEX: “Lighting Rotisserie
Burner” for further details.)
Once lit, the rotisserie burner should reach cooking
temperatures in about 1 minute. It will glow evenly across
its surface in about 5 minutes.
NOTE: The grill thermometer should not be used for
rotisserie cooking. It is not designed to read direct infrared
heat.
If the burner will not stay lit when you release the control
knob, re-light it and hold the control knob in for at least 60
seconds to allow the thermocouple to heat up.
If, after holding the control knob in for at least 60 seconds,
the burner still will not stay lit when releasing the control
knob, call for service.
(See INDEX: “Obtaining service from Lynx” for further
details.)
USING THE ROTISSERIE BURNER ...continued
Must rest
on rollers
Professional chefs far and wide set their restaurant cuisine
apart by cooking
over wood fires.
Imparting a delicate
hint of wood smoke
enhances food,
raising your culinary
skills to the next
level.
Your new grill comes
with the new Lynx
Smoker Set with handle. This oval shaped Lynx Smoker
box can be placed anywhere on the grates directly over
any burner. The unique handle and interlock mechanism
is designed to allow quick removal or refilling of the Lynx
smoker box.
The smoker box is designed with special draft and flow
through for maximum smoke. It is constructed of 304 Heavy
Gauge Stainless Steel for years of use.
The Lynx Smoker box can be used with smoker pellets
or wood chips. Whether using wood chips or pellets, we
recommend using approximately 3 oz. of either material.
There is no need for presoaking, just fill the smoker box.
Now use the handle to place
the smoker box directly on
the hot grates. Don’t forget
to remove the smoker handle
before closing the grill lid.
Smoke occurs at approximately
575 degrees F. at the grilling
surface. Set the burner knob to medium/medium low to
achieve this temperature. Use the handle to move or refill
the smoker box. Control the smoking by adjusting the heat
and being careful not to adjust it too high.
For best results keep the lid closed. The best absorption
of smoke flavor occurs early in the cooking process. When
finished with smoking, allow the smoker box to cool and
dispose of remnants.
USING THE SMOKER BOX
Handle the smoker box with care. The cover
becomes extremely hot when in use. Use sturdy,
properly insulated gloves or dry pot holders.
CAUTION

ALL-SEAR CARE & USE/INSTALLATION |17
STAINLESS STEEL
Lynx products are known for their attractive appearance.
We achieve this by selecting only the finest grades of
stainless steel and applying exacting workmanship.
In order to maintain this attractive appearance over the life
of the grill it is important to take the following steps:
• After each use wipe down the exterior of the grill to
remove grease and splatters.
• Be sure to follow the cleaning instructions for keeping the
grates and burners clean and ready for use.
• Use a commercially available Stainless Steel cleaner to
clean and polish the exterior surfaces.
• Doing these things on a regular basis minimizes the
amount of effort required.
• Part of the appeal of your Lynx Grill is the fine grain finish.
When removing stubborn stains:
• Do not use metallic abrasives and always rub in the
direction of the grain.
• Some household cleaning products are not suitable for
stainless steel; be sure to read the label before using on
your Lynx Grill.
• Always use the mildest cleaning solution first, scrubbing
in the direction of the grain. Specks of grease may gather
in the grain of the stainless steel and bake on to the
surface, giving the appearance of rust.
• To remove these baked-on foods use a fine to medium
grit non-metallic abrasive pad (Scotch Brite is good) in
conjunction with a stainless steel cleaner.
• Solutions used for cleaning concrete and masonry can be
very corrosive and will ‘attack’ stainless steel. Ensure your
Lynx products are well protected before you allow the use
of such chemicals near your grill.
SPECIAL NOTE FOR LOCATIONS NEAR POOLS AND
COASTAL AREAS
The 304 stainless steel material used in the construction of
a Lynx Grill is highly rust resistant, however, chlorine in the
air from swimming pools or the salt from sea air may cause
surface rust to appear and even create some pitting if left
on the product.
Here are a few tips to avoid this:
• Regularly wipe down the exterior surfaces with a damp
cloth. (Micro fiber cloths such as Ecloth perform very
well).
• Allow the surfaces to dry before installing the cover. Do
not cover a damp grill.
• In extreme environments apply a rust inhibitor which
leaves a microscopic protective layer on the grill. Products
that provide a layer of vapor corrosion inhibitors (VpCI™)
protect the surface very well.
• For seasonal storage use the product referred to above,
ensure the grill is dry and then cover and secure the
cover to minimize the amount of damp air getting to the
surfaces.
THE LYNX LIMITED LIFE TIME WARRANTY PROVIDES
PROTECTION AGAINST RUST THROUGH OF PARTS THAT
RENDER THE PRODUCT INOPERATIVE. IT DOES NOT
COVER OCCASIONAL SURFACE RUST OR STAINING DUE
TO ENVIRONMENTAL CONDITIONS.
After your first use certain areas of the grill may discolor
from the intense heat given off by the burners - this is
normal and cannot be cleaned off.
For light and heavy food stains there are many different
stainless steel cleaners available.
DRIP TRAY
The drip tray should be cleaned after each use. After the
grill is completely cool, remove the drip tray by pulling it
out until it stops, then lifting the front edge until the drip
tray comes free.
Clean it with hot soapy water or an oven-style cleaning
product and re-install. When using an oven-style cleaning
product be sure to carefully follow the manufacturer’s
instructions. Many of these cleaners are toxic and can
damage the stainless steel finish if not used properly.
Also, check the tray after rain. If you’ve left the grill
uncovered, you may need to remove the drip tray drain
plug to drain the water from the tray. The drain plug can be
removed with a flat-head screwdriver.
CLEANING YOUR LYNX GRILL

18
|ALL-SEAR CARE & USE/INSTALLATION
GRILLING RACKS
The easiest way to clean the grill racks is to do so
immediately after turning off the burners, while they are
still hot. Wearing a long BBQ mitt to protect your hand
from steam, dip a brass bristle brush in hot water and scrub
the grill rack. Dip the brush frequently because the steam
helps remove baked-on foods.
PROSEAR™ 2 BURNERS
Make sure the grill is completely cool before proceeding.
Ensure that the gas supply is off and all control knobs are in
the “OFF” position.
It’s easy to keep your ProSear™ 2 burners operating at
peak performance. Just run them on “HI” with the hood
open for 5 minutes after each use to burn away any food
particles or drippings.
Every 3 to 6 months, remove the burners and inspect the
venturi (inlet) and orifice to ensure that they’re free of
obstructions.
Food debris on the inside of the burners can be gently
shaken out. Do not touch the ceramic surfaces.
Clean any obstruction with a straight paper clip.
When re-installing the ProSear™ 2 burners, be sure to
correctly position the burners. (See INDEX: “Unpacking
and Assembly” for further details.)
CLEANING YOUR LYNX GRILL ...continued
DO NOT ALLOW EXCESS GREASE OR LIQUIDS
TO ACCUMULATE IN THE DRIP TRAY AS THIS
MAY CREATE A FIRE HAZARD.
NEVER USE GRILL WITHOUT DRIP TRAY PROP-
ERLY INSTALLED.
WARNING
PROPER PLACEMENT OF EACH BURNER IS
CRITICAL. AFTER CLEANING THEY MUST BE
CENTERED ON THE BRASS ORIFICE,
RESTING LEVEL WITHOUT ANY ROCKING.
FAILURE TO MEET THESE CONDITIONS MAY
CAUSE A VERY DANGEROUS CONDITION THAT
CAN CAUSE PERSONAL INJURY AND PROPERTY
DAMAGE.
WARNING

ALL-SEAR CARE & USE/INSTALLATION |19
BEFORE YOU CALL FOR SERVICE
Please check a few things before calling for service:
• Is there fuel supplied to the grill?
• Is the main shut-off valve open?
• Are you using the correct type of fuel? (LP or Natural Gas)
(See INDEX: “Gas Requirements” for further details.)
• Is your propane cylinder empty? Have you recently
refilled the propane cylinder? If so, is the connection
tight?
• Have you opened the valve on the propane cylinder?
• Is the grill plugged in to a live electric circuit?
• If you’ve checked the above items, review the trouble-
shooting list below before calling for Lynx for service.
TROUBLESHOOTING YOUR LYNX GRILL
GRILL WON’T LIGHT
First, confirm that the grill is getting electricity by turning
on the lights, then:
Check The Igniters
Your Lynx grill uses an electric ignition system that does not
spark. Instead, the igniters should glow constantly when a
control knob is pushed in.
• Ensure that all burner controls are set to OFF.
• Remove the cooking grates.
• Watch an igniter as you push in and hold the
corresponding control knob.
• (Be sure you push in the correct control knob and keep
the knob in the “OFF” position)
Check the remaining igniters. If igniters don’t glow,
proceed with troubleshooting or match-light the burner.
Check The Burners
If the igniters are working check to see if gas is reaching
the burners by attempting to match light a burner.
BE CAREFUL! IF THE BURNER FAILS TO IGNITE, WAIT
5 MINUTES BEFORE ATTEMPTING TO IGNITE OTHER
BURNERS! (See INDEX: “Match Lighting” for further
details.)
If match lighting doesn’t work, re-check fuel connections
for leaks and ensure the supply is of the correct type and is
of adequate pressure. (See INDEX: “Leak Test Procedure”
for further details.)
If the burner will light with a match, then the igniter may
not be functioning correctly. Call for service.
If the burner will not match light, and you know you are
getting gas, wait for any gas to dissipate and remove the
burner and check it for blockages.
SMELL OF GAS WHILE COOKING
IF YOU SMELL GAS WHILE THE GRILL IS OPERATING,
IMMEDIATELY TURN OFF ALL BURNERS AND SHUT OFF
THE MAIN FUEL SUPPLY.
• Perform a leak test (See INDEX: “Leak Test Procedure” for
further details.)
• Check for blockages
POTENTIAL PROBLEMS

20
|ALL-SEAR CARE & USE/INSTALLATION
LOW OR INSUFFICIENT HEAT
No part of the grill should ever be lined with aluminum foil.
Doing so will interfere with airflow and can cause a low heat
condition.
Ensure that you’ve pre-heated the main burners for at least
5 to 10 minutes with the hood closed.
Proper leveling during installation is critical. A grill that
is out of level will cause erratic burner combustion and
inefficient, uneven heating. A carpenter’s spirit level should
be used to level the grill both front-to-back and side-to-
side.
If the low heat problem persists:
• Check the gas supply line sizing requirements.
• Check the gas supply line for kinks or damage.
REPLACE any damaged supply lines.
• Check the Regulator
Make sure that the regulator & hose assembly is the one
designed for and supplied with your Lynx grill and that it
is correctly set up for the type of fuel you are using. (See
INDEX: “Regulator Conversion” for further details.)
The hose and regulator provided by Lynx must be used if
your grill is set-up for an LP Gas Cylinder.
Check that there is no physical pressure being applied to
the regulator attached to the back of the grill. The regulator
contains a flexible diaphragm and should not be allowed to
touch the grill body or its surroundings.
• Check for Obstructions
Ensure that the burners and drip tray are clean and free
from obstructions.
LP (Propane) units:
• Is the cylinder almost empty?
Almost-empty cylinders may not have sufficient pressure to
run the burners at high heat.
• Have the line pressure checked by a qualified technician
(See INDEX: “Gas Requirements” for further details.)
• Flow Limiting Device
Improper lighting procedures may have activated the LP
cylinder’s flow control device, reducing the heat output.
To reset the flow control:
• Shut off all burner controls and close the LP cylinder
valve.
• Wait 30 seconds and, very slowly, reopen the cylinder
valve.
• Wait a few seconds and relite a burner.
• Bulk LP Cylinder Users
Bulk LP cylinder lines must be properly regulated.
Ensure that you are using a 4/11 appliance regulator
supplied by Lynx and converted to LP gas. Also ensure that
you do not have more than one regulator in line.
Natural Gas units:
• Supply Line
Ensure that the supply line is at least 3/4” inside diameter
or 1” outside diameter.
• Check line pressure
Natural gas inlet pressure should be at least 7” W.C. and
manifold pressure not less that 4” W.C. under full load (with
all burners on.)
• Check burners for blockages
WIND HITTING GRILL
Wind hitting the grill while in use, especially winds blowing
into or across the hood gap from behind, can cause poor
performance and in some cases can cause the control panel
to get dangerously hot.
Steady or gusty winds can prevent the normal exhaust of
hot gases. Locate your grill away from prevailing winds and
avoid grilling in windy conditions.
POTENTIAL PROBLEMS ...continued
