Lynx MiniModule S VD 3062 User manual

Series 3000
© LYNX Technik AG
Brunnenweg 3
64331 Weiterstadt
Germany
www.lynx-technik.com
Reference Manual
S VD 3062
SDI 6 > 2 Input Switch
MiniModule
s
Version 1.4

Reference Manual S VD 3062 Version1.4
Page 2
Information in this document is subject to change without notice. No
part of this document may be reproduced or transmitted in any form
or by any means, electronic or mechanical for any purpose, without
express written permission of LYNX Technik AG.
LYNX Technik AG may have patents, patent applications,
trademarks, copyrights or other intellectual property rights covering
the subject matter in this document. Except as expressly written by
LYNX Technik AG, the furnishing of this document does not give you
any license to patents, trademarks, copyrights or other intellectual
property of LYNX Technik AG or any of its affiliates.
© LYNX Technik AG 2004 - 2005 all rights reserved

Reference Manual S VD 3062 Version1.4
Page 3
Warranty
LYNX Technik AG warrants that the product will be free from defects
in materials and workmanship for a period of two (2) years from the
date of shipment. If this product proves defective during the
warranty period, LYNX Technik AG at its option will either repair the
defective product without charge for parts and labor, or will provide
a replacement in exchange for the defective product.
In order to obtain service under this warranty, customer must notify
LYNX Technik of the defect before expiration of the warranty period
and make suitable arrangements for the performance of service.
Customer shall be responsible for packaging and shipping the
defective product to the service center designated by LYNX Technik,
with shipping charges prepaid. LYNX Technik shall pay for the return
of the product to the customer if the shipment is within the country
which the LYNX Technik service center is located. Customer shall be
responsible for payment of all shipping charges, duties, taxes and
any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure, or damage
caused by improper use or improper or inadequate maintenance
and care. LYNX Technik shall not be obligated to furnish service
under this warranty a) to repair damage resulting from attempts by
personnel other than LYNX Technik representatives to install, repair or
service the product; b) to repair damage resulting from improper use
or connection to incompatible equipment; c) to repair any damage
or malfunction caused by the use of non LYNX Technik supplies; or d)
to service a product which has been modified or integrated with
other products when the effect of such modification or integration
increases the time or difficulty servicing the product.
THIS WARRANTY IS GIVEN BY LYNX TECHNIK WITH RESPECT TO THIS
PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED.
LYNX TECHNIK AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. LYNX
TECHNIK`S RESPONISIBILITY TO REPAIR AND REPLACE DEFECTIVE
PRODUCTS IS THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE
CUSTOMER FOR BREACH OF THIS WARRANTY. LYNX TECHNIK AND ITS
VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTAL DAMAGES IRRESPECTIVE OF
WHETHER LYNX TECHNIK OR THE VENDOR HAS ADVANCE NOTICE OF
THE POSSIBILITY OF SUCH DAMAGES.

Reference Manual S VD 3062 Version1.4
Page 4
Regulatory information
Europe
Declaration of Conformity
USA
FCC 47 Part 15
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to the part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to
correct the interference at his own expense
We LYNX Technik AG
Sandstrasse 7
D-64404 Bickenbach
Germany
Declare under our sole responsibility that the product
TYPE: S VD 3062
To which this declaration relates is in conformity with the following
standards (Environments E1-E3):
EN 55103-1 /1996
EN 55103-2 /1996
EN 60950 /2001
Following the provisions of 89/336/EEC and 73/23/EEC directives.
Winfried Deckelmann
Weiterstadt, November 2004
Place and date of issue Legal Signature

Reference Manual S VD 3062 Version1.4
Page 5
Contents
Warranty....................................................................................3
Regulatory information ............................................................4
Europe......................................................................................................4
Declaration of Conformity ..................................................................4
USA .........................................................................................................4
FCC 47 Part 15....................................................................................4
Contents....................................................................................5
Getting Started .........................................................................7
Packaging.................................................................................................7
Product Description .................................................................................7
Functional Diagram .................................................................................8
Module Layout.........................................................................................8
Connections ...........................................................................10
Video Connections.................................................................................10
Remote Control Panel............................................................................11
Connector...............................................................................................11
for Remote Control Panels.....................................................................11
Power Connections ................................................................................12
DC Power Connector ........................................................................12
Installation...............................................................................13
Mechanical.............................................................................................13
Stand Alone Operation......................................................................13
Multiple Units ...................................................................................14
Electrical Installation. ............................................................................15
Stand Alone Operation......................................................................15
Multiple Units ...................................................................................16
Settings and Control...............................................................16
Switch Settings ......................................................................................17
Switch Function Detail......................................................................17
Factory Preset Condition...................................................................18
Connector for Remote Control Panels ...................................................19
Parallel Interface ...............................................................................20
Panel Version 1 .................................................................................21
Panel Version 2 .................................................................................21
Panel Version 3 .................................................................................22
Alarm/LED Status Indicators ..................................................25
Channel Condition Indicators ...........................................................25
Front Panel Alarm Indicator..............................................................25
Locate Function.................................................................................26

Reference Manual S VD 3062 Version1.4
Page 6
Auto Store......................................................................................... 26
Specifications (S VD3062)..................................................... 27
Available Options.................................................................. 28
Parts List .................................................................................. 29
Service.................................................................................... 29
Contact Information.............................................................. 30

Reference Manual S VD 3062 Version1.4
Page 7
Getting Started
Packaging
The shipping carton and packaging materials provide
protection for the module during transit. Please retain
the shipping cartons in case subsequent shipping of
the product becomes necessary.
Product Description
The S VD 3062 is a high quality digital video 6 > 2 input
switch designed primarily for broadcast and
professional applications.
The S VD 3062 has 6 inputs for digital video signals,
which can be switched to two independent outputs. A
second input can be selected for emergency
switching. Outputs can be reclocked, or non-
reclocked. Auto detection of standard digital video bit
rates in reclocked mode (143Mbit/s, 177Mbit/s,
270Mbit/s, 360Mbit/s) and will transparently pass data
from 10Mbits/s to 620Mbits/s in non-reclocked mode.
A analog reference input allows clean switching for
synchronous inputs.
Inputs can be switched either via the service adapter
and the associated PC GUI SW (LYNX c3_local) or via
an optional remote control panel R CP 3062. Up to six
S VD 3062 can be controlled from one control panel.
The S VD 3062 is part of the 3000 series of MiniModules,
which offer high quality, modularity and flexibility in a
very small form factor ideal for applications where
space is at a premium.
The modules can be used either stand alone using the
optional power supply brick, or as part of a tightly
integrated space saving system where up to 10
MiniModules can be mounted utilizing the optional
LYNX R FR 3005 / 3010 rack housing. This includes
integrated power supply and optional remote control
interfaces.

Reference Manual S VD 3062 Version1.4
Page 8
3
Functional Diagram
Figure 1 below is the basic functional diagram for
the S VD 3062 MiniModule.
Figure 1- S VD 3062 Functional Diagram
Module Layout
Figure 2 shows the physical layout of the S VD 3062
MiniModule. Video I/O is made through standard BNC
video connectors. Module configuration is set via a
small dip-switch located behind a small access hole in
the bottom of the module. A connector for external
control panels is also provided on the module.
If the module is being used in a stand alone
application then the optional power supply (R PS 3001
E, R PS 3001 U or R PS 3001-3) is required to power the
module (not shown)

Reference Manual S VD 3062 Version1.4
Page 9
Figure 2 – Module Layout

Reference Manual S VD 3062 Version1.4
Page 10
Connections
Video Connections
The S VD 3062 MiniModule is configured with standard
75 Ohm BNC connectors. Connection is self-
explanatory. We recommend the use of high quality
video cable for digital video connections to reduce
the risk of interference or errors due to excessive cable
attenuation. Some guidelines for max cable length are
shown below.
250m (820 feet) Belden 8281 (270Mbits/s)
150m (492 feet) Belden 8281 (540Mbits/s)
Note. Due to the compact design of the module it will
be necessary to use a connection tool to secure the
BNC video connectors to the module.

Reference Manual S VD 3062 Version1.4
Page 11
Remote Control Panel
There are different possibilities for Remote control panels.
LYNX Technik AG provides one solution, the R CP 3062,
which is described on page 22 and 23 (parallel panel type
3)
Connector
for Remote Control Panels
A1
A13
B13 B1
PIN-ASSIGNMENT:
PIN B1 3-B8 = Input Sel ect (for OUT1 or Input sel ect f or Panel Version1 )
PINA13-A8 =Input Select(forOUT2)
PIN B7 = Output 1 select for PanelVersion 1
PIN B6 = Output 2 select for PanelVersion 1
PIN A7 = Pa nel co nne ct (Low=Panel conn ect)
PIN A6 = Pa nel Version (high=Ve rs ion 1, low=Version 2)
PIN A5-B5 =n ot us ed
PINA4 =RS-485 TX- (used for Panel on RS422)
PIN B4 = RS-485 TX+ (use d forP ane l on Rs422
PINA3 =RS-485 RX-( )used for Panel o n Rs4 22
P I N B3 = RS- 485 R X+ ( )used for Panel on Rs4 22
PINA2/B2= VCC (5V/100mA)
PINA1/B1= GND
Note. For more details see page 19.

Reference Manual S VD 3062 Version1.4
Page 12
!
Power Connections
If using the module in a stand-alone application use
the separate R PS 1 E (for Europe), R PS 1 U (USA) power
brick option or the desk power supply R PS 3001-3.
DC Power Connector
The MiniModule has a captive power lead fitted to the
module, with a male 5 pin locking bayonet connector.
This connection provides DC power and also data
connectivity to the module. Connector wiring is shown
below.
3
4
51
2
GND
+ 5V
i2C-SDA (data)
i2C-SCL (clock)
Power ConnectionData Connection
Male Connector
(view looking into connector from front)
Caution
Only use the optional LYNX R PS power modules. Ensure
the 5-pin power connector is locked securely in place.

Reference Manual S VD 3062 Version1.4
Page 13
!
Installation
Mechanical
Stand Alone Operation
The S VD 3062 MiniModule can be used in a stand
alone application. There are two options for the use of
the module in this way.
a) Using the R FR 3005 Rack Frame 1 option. This allows
up to any 10 of the MiniModules to be secured
onto a rack frame assembly for 19 inch rack
mounting. This keeps the modules secured,
organized and out of the way. The R PS 3001 power
brick option or the R FR 3010 option is required to
power each module. Please refer to the R FR 3005
Reference Manual supplied with this option for
more details.
b) Single Use. The MiniModule can be powered
independently with the R PS 3001 option and used
in any location where this functionality is required.
Caution. Care needs to be taken when
using the module in this way, as it is not
physically secured. Keep the module
away from the floor to avoid the risk of
someone stepping or tripping on the unit,
and locate the unit away from excessive
sources of heat and any sources or
moisture.
If using more than one MiniModule in any installation,
the R FR 3005/3010 Rack frame combination is highly
recommended.

Reference Manual S VD 3062 Version1.4
Page 14
Multiple Units
Most applications will require more than one
MiniModule, which can include any of the available
Series 3000 MiniModule product range. There are two
options for mounting multiple units.
a) Using the R FR 3005 Rack Frame option. This allows
up to any 10 of the MiniModules to be secured
onto a rack frame assembly for 19 inch rack
mounting. The R PS 3001 power brick option or the R
FR 3010 option is required to power each module.
Please refer to the R FR 3005 Reference Manual for
more details.
b) Using the R FR 3010 Rack frame extension option.
Can be combined with the R FR 3005 Rack frame
option. Each module plugs into a connection bus,
which provides common power for all modules. (no
R PS external power supplies are needed). Remote
control and status monitoring of all modules is
possible with the addition of the R CT 5020 rack
controller and R CT 5030 master controller options.
Please refer to the respective reference manuals
for these options for details of mechanical
installation.
The very small size and density of the MiniModules
combined with the available rack frame options allows
the addition of a complex and custom signal
distribution system without taking any additional front
rack space. The rack frames are designed for
installation in the back of 19-inch racks where there is
normally plenty of available space. Ideal for mobile
truck installations and facility expansions where space
is at a premium.

Reference Manual S VD 3062 Version1.4
Page 15
!
!
Electrical Installation.
Stand Alone Operation
The MiniModule requires the R PS 3001 power brick
option for stand-alone operation. Three versions are
available: R PS 3001 E for European markets, R PS 3001
U for the US markets or the desk power supply R PS
3001-3. Please ensure you have the correct power
option for your region. The connection to the module is
made with a small 5-pin connector, which has a twist
bayonet securing system. Please make sure the
connection is solid and locked in place. A strain relief is
included within the module to prevent excessive strain
on the connection.
Signal connections should be made with care, please
ensure connections are correct and compatible
equipment is feeding / receiving the signals from the
module or damage can result.
Caution. Only use the optional Lynx R PS 3001
power modules. Ensure the 5-pin power
connector is locked securely in place.
Caution. Care needs to be taken when using
the module in this way, if it is not physically
secured. Keep the module away from the
floor to avoid the risk of someone stepping or
tripping on the unit, and locate the unit away
from excessive sources of heat and any
sources or moisture.

Reference Manual S VD 3062 Version1.4
Page 16
Multiple Units
When installing multiple MiniModule units it is
recommended you use the R FR 3005 Rack Frame 1
and / or R FR 3010 Rack Frame 2 options. Please refer to
the documentation supplied with these options for
details on electrical installation.
Settings and Control
The S VD 3062 has an integrated micro-controller,
which enables the module to be configured and
controlled locally via the integral dip-switch, or from
remote when using the optional R FR 3010 Rack Frame
and control system.
Input switching is possible via the LYNX Control SW or
an optional remote control panel, the module provides
a connector for control via an optional Remote Control
Panel.
Once set, all settings are automatically saved in non-
volatile internal memory. The module will always recall
the settings used to prior to power off.

Reference Manual S VD 3062 Version1.4
Page 17
Switch Settings
Below the switch settings for the 8-position dip-switch
are defined.
Switch Function Detail
Dip Switch 1
This switch is used to enable or disable local
adjustments. Set to ON enables the setting of the other
dip switches to configure the module. Set to OFF will
prevent any switch settings taking effect.
If any setting is executed via the optional LYNX control
system, the local control will be disabled. In this case
DIP Switch one has to be toggled ON-OFF-ON to
reaquire local control. LED 3 will be on (GREEN) if local
control is enabled.
Note. The module has a microcontroller and flash ram. When this
switch 1 is set to ON any configuration settings made on the module
with the dip switches will automatically be written into flash ram and
stored. (see Auto Store) The module will function normally with the
switch left in the ON position but it is recommended to set it to OFF to
prevent accidental changes to the stored module configuration if
the switches are moved.
Switch Setting Function
ON Local adjustment enabled
1 OFF Local adjustment disabled
ON Output 1 reclocked
2 OFF Output 1 non-reclocked
ON Output 2 reclocked
3 OFF Output 2 non-reclocked
ON Emergency switch active
4 OFF Emergency switch disabled
5 Adr (0) Settimg for Remote Control Panel
6 Adr(1) Settimg for Remote Control Panel
7Adr(2) Settimg for Remote Control Panel
8Adr (3) Settimg for Remote Control Panel

Reference Manual S VD 3062 Version1.4
Page 18
Dip Switch 2
When set to ON this configures output 1 as reclocked, if
set to OFF output 1 is non-reclocked
Dip Switch 3
When set to ON this configures output 2 as reclocked, if
set to OFF output 2 is non-reclocked
Dip Switch 4
This switch configures enables emergency switching.
ON activates the emergency switch. If the selected
input is lost, the modules will switch automatically to the
next active input. OFF disables emergency switching.
Dip Switch 5-8
Used for address configuration for optional remote
control panel on parallel or RS485 interface:
ADR 0: Direct Connect for Panel Version 1 and 2
ADR 1 .. ADR 6: Address of S VD 3062 for connection to
Panel Version 3 or via RS 485
Factory Preset Condition
The S VD 3062 is delivered preset for the following
mode of operation:
Local control enabled
Outputs 1 non-reclocked
Outputs 2 non-reclocked
Emergency switch disabled
If this is the mode of operation required, then no
adjustments are necessary.

Reference Manual S VD 3062 Version1.4
Page 19
Connector for Remote Control Panels
The module provides a connector for optional remote
control panels. There are several possibilities:
-Simple panel, driven by the module. Distance is
restricted to 10m. Two versions are possible.
-Control Panel with RS422 interface for longer
distances
For connection of remote control panels an adapter to
a Sub D 25 female connector is provided with the
module.
Tables below show pinout of Sub D 25 pin female
connector as provided on the adapter.
Sub D 25 pin female
PIN Function
1-6 Config Input select for OUT 1 or Input select for Panel Version 1
14-19 Config Input select for OUT 2
7/8 Config Output select if Panel Version 1 used
20 Config Panel connect (Connect to GND)
21 Config Version select (high = Panel Version 1, low = Panel Version 2)
9, 22 Config not used
10 Config RS485 TX + used for Panel on RS422
23 Config RS485 TX -; used for Panel on RS422
11 Config RS485 RX +-; used for Panel on RS422
24 Config RS485 RX -; used for Panel on RS422
12,25 Power +5V / 100mA max.
13 Power GND

Reference Manual S VD 3062 Version1.4
Page 20
Parallel Interface
Version 1
OUT 1
Control-Panel
Internal Hardware for a simple
Control Panel with a parallel connection
Version 2
OUT 2
Channel IN OUT
Internal Hardware for a simple
Control Panel with a parallel connection
PIN1 PIN2 PIN3 PIN4 PIN5 PIN6 PIN7 PIN8
IN1 IN2 IN3 IN4 IN5 IN6 OUT1 OUT2
390R
390R 390R 390R 390R 390R 390R 390R
5V 5V 5V 5V 5V 5V 5V 5V
PIN12/25
5V
PIN13
GND
PIN20 PIN21
GND
(connect to GND
for Panel detect)
(unconnect for
Panel Version 1)
PIN1 PIN2 PIN3 PIN4 PIN5 PIN6
IN1-1 IN1-2 IN1-3 IN1-4 IN1-5 IN1-6
390R 390R 390R 390R 390R 390R
5V 5V 5V 5V 5V 5V
PIN14 PIN15 PIN16 PIN17 PIN18 PIN19
IN2-1 IN2-2 IN2-3 IN2-4 IN2-5 IN2-6
390R 390R 390R 390R 390R 390R
5V 5V 5V 5V 5V 5V
PIN12/25
5V
PIN13
GND
PIN20 PIN21
GND
(connect to GND
for Panel detect)
(connect to GND
for Panel Version 2)
GND
Control-Panel
