LYNXTechnik Yellobrik ORX 1802 User manual
yellobrik Quick
Reference
ORX 1802 (LC,ST,SC,MM)
3Gbit Fiber Optic to SDI Receiver
SDI Video
Output 1
Receiving
Data
DC Power Input
Power
Connected
SDI Video
Output 2
WARNING
WARNING
CLASS 1M LASER PRODUCT
yellobrik
®
LYNXTechnik AG Broadcast Television Equipment
®
We are constantly adding additional yellobrik modules.
Please visit our website for the latest product updates.
www.lynx-technik.com
®
LASER RADIATION
Do not view directly with
optical instruments
LC
Singlemode
ST
Singlemode
SC
Singlemode
LC
Multimode
Fiber Input - Four options are available
L
C
ST
SC
L
C
Fiber In
p
ut - Four o
p
tions are availabl
e
Technical Specifications
Fiber Input
Singlemode
1 x fiber optic Input
LC, ST or SC connection
SMPTE 297M - 2006
Input range (wavelength) 1260nm to 1620nm
RX sensitivity -3dBm to -19dBm
Fiber Input
Multimode
1 x Fiber Optic Input
LC Connection
SMPTE 297M - 2006
Input range (wavelength) 780nm to 880nm
RX sensitivity 0dBm to -15dBm
SDI Output 2 x SDI video on 75 Ohm BNC connectors
SMPTE 424M, SMPTE 292M, SMPTE 259M, DVB-ASI
Multi-standard operation from 270Mbit/s to 3Gbit/s
Return Loss: > 15dB to 1.5GHz and > 10dB up to 3GHz
Power +12VDC power supply (included)
Supports external power input from 9 - 14 VDC
Power LED on side of module. Power Consumption 1.4W
Power Lead Strain Relief
The module has a small hole in the case located above the power
connection to prevent the power lead being accidentally pulled out.
Use the supplied tie-wrap and secure the lead as shown below.
Connections
The SDI video outputs are connected to the corresponding 75 Ohm
BNC connections provided. The ber connection is made to the ber
SFP sub module as indicated on the module.
Four versions of the module are available, the only dierence is the SFP
sub module installed into the basic module.
ORX 1802 LC - Singlemode LC ber connection
ORX 1802 ST - Singlemode ST ber connection
ORX 1802 SC - Singlemode SC ber connection
ORX 1802 MM - Multimode LC ber connection
The module ber connection is supplied with a rubber plug installed,
this is to prevent dust contamination. Please retain the plug and use if
the cable is ever disconnected from the module.
Operation
Operation of the ORX 1802 is fully automatic. The SDI video format is
automatically detected, reclocked and provided on two SDI output
connections. The module supports all SDI video standards as well as
DVB/ASI.
The ORX 1802 supports hot swapping and hot plugging of
connections.
No user settings are provided for this module.
Power
The module requires a 12V DC power input and a LED is provided to
conrm power is connected. A power supply is provided, but if
applying your own power, please provide a clean 12V DC power
source. Module power consumption is approx 1.4W
SFP Fiber sub modules plug into the basic base
module
LC
Singlemode
ST
Singlemode
SC
Singlemode
LC
Multimode
g
O
RX 1802 MM
-
Multimode LC
ber connectio
n
L
C
Singlemode
ST
Singlemode
SC
Singlemode
LC
Multimode
