LYSON W3118 User manual

Instructions Manual
PREMIUM weighing scale charging
solar panel
Przedsiębiorstwo Pszczelarskie Tomasz Łysoń
Spółka z o.o. Spółka Komandytowa
34-125 Sułkowice, ul. Racławicka 162, Polska
www.lyson.com.pl, email: [email protected]
tel.[phone]
Headquarters: Klecza Dolna 148 ,34-124 Klecza Górna

This manual covers following devices (codes):
W3118
Table of contents
1. General safety rules
1.1. Intended use
1.2. Electrical safety
1.3. Operation safety
2. Product description
2.1. Design
2.2. Technical specifications
3. Storage
4. Maintenance and Cleaning
5. Waste disposal and environmental protection
6. Warranty

1. General safety instructions
Before first use read the manual carefully and follow
the instructions contained therein. The manufacturer
is not liable for damage caused by equipment used
inappropriately or by incorrect handling.
1.1. Intended use
1. The solar panel set is designed for charging the
PREMIUM weighing scale’s battery.
2. Before first use, the solar kit must be screwed onto
the hive's roof with screws and the power cable (3)
plugged into the socket on the scale controller.
1.2. Electrical safety
1. Pay special attention while mounting the panel on
the hive's roof to ensure no hard or heavy items fall
onto the glass panel, as this can damage the panel.
1. If the connecting cable is damaged and needs to
be replaced, this should be done by the qualified
personnel.
Do not use the set if the connecting cable is
damaged!
2. Do not pull the power cord.
Keep the power cord away from heat sources and
sharp edges to ensure its good condition.
1.3. Operation safety
1. The device is not intended for use by persons
(including children) with limited physical, sensory or
mental abilities, or by inexperienced users, unless
under supervision or with instructions given by an
accountable party.
This device is not a toy, and shouldn’t be used as
one. Children should not to play with it.
2. In the event of damage to the device, to avoid any
health and safety risks, repairs should be carried out
only by qualified personnel.
3. Never carry out any maintenance or repairs during
operation or if the device is plugged into the scale.
2. Product description
Photovoltaic panels exposed to sunlight generate
direct current with voltage of 12V, transferring it via
the charge regulator to the battery. Thanks to this
solution the PREMIUM weighing scale's battery is
constantly being charged during the day. The panel is
connected to the scale with a cable (3).
2.1 Design
1 2 3
Description:
1-mounting plate
2-solar panel
3-connection cable
2.2 Technical specifications
-max power: 10W
-voltage: 13,7V max
-power cable: 2,5m
-dimensions of the panel: 33x29cm
-dimensions with the mounting plate: 37x33cm
-weight: 2,20 kg.

3. Storage
Clean the unit thoroughly after use. Store the device
in a dry and frost-free room. An additional technical
check should be carried out periodically, and if any
defects are found, please contact the manufacturer.
4. Cleaning and maintenance
While cleaning ensure the safety of all electrical
components like the voltage regulator. Dry thoroughly
after cleaning. An additional technical check should
be carried out periodically, and if any defects are
found, please contact the manufacturer.
5. Waste disposal and environmental
protection
The used product must be disposed in accordance
with the local regulations. Return the device to a
collection point from where it can be submitted for
environmentally compatible recycling.
The consumer has the right to return used equipment
directly to the manufacturer's distribution network,
free of charge, while replacing it with a new unit as
long as the used device is of the same kind and same
application as the newly purchased device.
6. Warranty
The product purchased from the Lyson Company
is covered by a manufacturer's warranty. The
warranty period is 24 months from the date of
purchase.
All purchased products come with receipts or VAT
invoices.
Warranty details at:
www.lyson.com.pl
