M-Audio Axiom A.I.R. Mini 32 User manual

Mini Keyboard
Axiom A.I.R. Mini 32
SERVICE MANUAL

Contents
2
Specifications.................................................................................................................................3
Panel Description.........................................................................................................................4
General Exploded Drawing and List.............................................................................................6
Circuit Boards...............................................................................................................................7
Parts List.....................................................................................................................................11
PCB Boards................................................................................................................................17
Diagnosis.....................................................................................................................................21
Spare Part List................................................................................................................... ..........23

3
Specifications
Specifications
32 Velocity sensitive keys
Note range: C to G Low profile, filled front mini-keys
Pitch bend buttons
Pitch bend control
Modulation button
Modulation control
Octave/Transpose buttons
2 –oct + / oct -, multi color
“Play” Button
MIDI control ,User Programmability,Uses keybed in conjunction with
“edit”button
“Stop” Button
“Record” Button
Navigation “Arrow” buttons (4);
“Enter” Button(1)
MIDI control,User Programmability,Uses keybed in conjunction with
“edit”button
Knobs (8)
8 Knobs for MIDI control
Drum Pads (8)
8 Drum pads,velocity sensitive, able to access 16 notes via two
way “bank” switch.
Memory Locations (10)
User can store the parameter assignments of all controllers/pads
in 10 user programmable locations addressable via the edit
mode and the keybed
MIDI Control (131)
Controls can be assigned to send standard MIDI CC’s up to 127
and extended custom messages from 128 to 131 (Channel
Aftertouch)
Velocity Curve(4)
There are four velocity curves available –Low, Normal and High
–and it is also possible to set the velocity to be a fixed value
between 4 and 127
Avid Ignite
Avid will supply the software.
USB Connectivity
USB Mini jack. Class compliant MIDI. work with desktop and
laptop computers as well as tablets under bus power. Second
port for HyperControl.
USB Audio Device Specification 1.0 (MIDI) Class Compliant
HyperControl
Firmware support Avid’s “HyperControl” Control surface protocol.
Device respond to a (SysEx) query from software by sending an
identifier as a response. In HyperControl Mode, Pre Defined
MIDI CCs as (defined by the HyperControl Protocol document)
will be sent through a secondary port instead of the user preset
on the main port.
DFU
User can update firmware over USB (Device Firmware Update)
Power
USB bus power (5V,<100MA)
display
LED

4
Panel Description
Front Panel
Panel Description
Top Panel
1.Edit Button
Enter edit mode
2.HyperControl Mode Button
Switch HyperControl Mode
3.HyperControl Mode LED
4.Assignable Control Knobs
5.Drum Pad Bank Button
Switch pad bank
6.Drum Pad Bank LEDs
7.Drum Pads
8.Sustain Button
9.Octave/Data Buttons
10.Pitch Bend Buttons
11.Modulation Button
12.Directional Buttons
13.Transport buttons
14. Keybed

5
Panel Description
Side Panel
Side Panel
1.USB Jack
USB Mini-B
2.Kensington Security Slot

General Exploded Drawing and List
6

Circuit Boards
7
Main Board

8
Circuit Boards
Function Board

Circuit Boards
9
Key Board

10
Circuit Boards
Drum pad control Board

PartList
11
Level
Part NO.
Description
Specification
QTY
UOM
Remark
+
1020104060
Unpacking part of the
electronic keyboard
Piranha
1.00
set
++
1020501740
Bottom cabinet ASSY
Piranha
1.00
set
+++
1020600970
Keyboard ASSY
Piranha
1.00
set
++++
1010801030
Keyboard ASSY
Piranha
1.00
set
+++++
101080102
Keyboard ASSY(AI part)
Piranha
1.00
set
++++++
503030031
PCB Single layer 22F
1.6mm
Piranha key board PCB
V01 blue coating
printing caborn
1.00
pcs
++++++
608050001
Switch Diode DIP
IN4148 DIP TYPE
64.00
pcs
+++++
6280601700
FPC soft flat cable
16pin L=85mm pitch
1.0mm
1.00
pcs
++++
62901003801
Conductive rubber
Keystation32
Material rubber
printing carbon
partices matt finish
30 degree
3.00
pcs
++++
20401001501
Black key DL-1765
ABS black surface
finish after change
3.00
pcs
+++++
298010001
Plastic
ABS
0.03
kg
++++
20501009701
white Keys 3A DL-1766
ABS injection white N/A
after change
2.00
pcs
+++++
298010001
Plastic
ABS
0.03
kg
++++
20501009801
White keys 4A DL-1766
ABS injection white N/A
after change
2.00
pcs
+++++
298010001
Plastic
ABS
0.03
kg
++++
20501009901
White keys 3B DL-1766
ABS white N/A after
change
1.00
pcs
+++++
298010001
Plastic
ABS
0.01
kg
++++
20501010001
White keys 4B DL-1766
ABS N/A after change
1.00
pcs
+++++
298010001
Plastic
ABS
0.01
kg
++++
301230010
Countersunk head screws
FB
2.6*12FB white
crisscross Flat tail
tapping Double teeth
8.00
pcs
++++
301020007
Flat round head screws
PB
Φ2.6*6PB black
crisscross flat tail
tapping
7.00
pcs
+++
202040008
Bottom cabinet
ABS injection RAL9005
black screen printing
Pantone 877C
1.00
pcs
++++
202010082
Bottom cabinet
ABS injection RAL9005
N/A
1.00
pcs
+++++
298010001
Plastic
ABS
0.15
kg

12
Circuit Boards
+++
629990102
Rubber Sleeving
nbr matt finish
50*30*11.8
32.00
pcs
+++
631030170
White felt
373*8.0*4.5mm hardness
50 degree single-sided
adhesive
1.00
pcs
+++
631030171
Black felt
373*8.0*4.0mm hardness
50 degree single-sided
adhesive
1.00
pcs
+++
629990154
Arc foot pad
Silica gel diameter of
30mm thickness of 2.3mm
the arc surface
4.00
pcs
+++
901030102
Lubricant oil PL-388F
Silicone oil PL-388F
grease
3.00
g
+++
301020008
Flat round head screws
PB
2.6*14PB black
crisscross head
3.00
pcs
+++
320060001
KEY METAL PLATE O2
Stainless steel surface
nigrescence disposal
Thickness0.8mm
1.00
pcs
++++
320010005
Key ironware sheet O2
Stainless steel
Thickness0.8mm
1.00
pcs
+++++
398010002
SECC
0.8mm
0.00
kg
+++
10101063300
1
Main board ASSY
Piranha
1.00
set
++++
10101063400
1
Main board ASSY(SMD
part)
Piranha
1.00
set
+++++
507040033
PCB Four layer FR4 1.6mm
Piranha main PCB V01
spray tin silkscreen
green oil
1.00
pcs
+++++
6010107610
IC SMD
NUC120LC1BN LQFP-48
1.00
pcs
+++++
6010104220
IC SMD
LM358 SOP TYPE
1.00
pcs
+++++
610030018
Crystal SMD 49S
12MHz -50PPM+50PPM FND
PAR 32PF SMT HC49SD
1.01
pcs
+++++
603030003
CAP Tantalum SMD
10uf/10V +10% -10% A
3.2X1.6
3.02
pcs
+++++
603030011
CAP Tantalum SMD
4.7uf/10V +10%-10% A
3.2X1.6 SMD
1.01
pcs
+++++
602030003
Resistor chain SMD
100 ohm(1/16w)+5%-5%
CRN164
4.02
pcs
+++++
602030020
Resistor chain SMD
4.7K ohm(1/16w)+5%-5%
CRN164
2.01
pcs
+++++
606010006
Ferrite Bead SMD row
SMBG3216K4-102
2.01
pcs
+++++
606010015
Ferrite Bead SMD
BLM18BD102SN1 0603
2.02
pcs
+++++
603010014
CAP CERAMIC SMD
0.01uf/50V +10% -10%
0603 SMD
1.01
pcs
+++++
603010118
CAP CERAMIC SMD
0.1uf/16V +10%-10% 0603
X7R
5.05
pcs
+++++
603010044
CAP CERAMIC SMD
220pf/50V +5% -5%
0603(NPO) SMD
2.02
pcs
+++++
603010038
CAP CERAMIC SMD
20pf/50V +20% -20% 0603
SMD
2.02
pcs
+++++
603010184
CAP CERAMIC SMD
2.2uF/25V ±10% 0805
SMD
1.01
pcs

PartList
13
+++++
6280102170
FPC connector
20PIN pitch 1.0mm
underneath toaching
1.005
pcs
+++++
6280200180
FPC Connector
16PIN PITCH1.0mm next
toaching 2124-16
1.005
pcs
+++++
603990007
CAP chain SMD
4*10pF±10％ 50V NPO
0603
2.02
pcs
+++++
606010009
Ferrite Bead SMD
600R@100Mhz 0603
4.04
pcs
+++++
602010004
Resistor SMD
0 ohm(1/10w)+5%-5% 0603
3.03
pcs
+++++
602010010
Resistor SMD
100 ohm(1/8w)+5%-5%
0603
3.03
pcs
+++++
602010018
Resistor SMD
10K ohm(1/8w)+5%-5%
0603
3.03
pcs
+++++
602010025
Resistor SMD
1M ohm(1/8w)+5%-5% 0603
1.01
pcs
+++++
602010114
Resistor SMD
3.3K ohm(1/10w)+5%-5%
0603
1.01
pcs
+++++
602010108
Resistor SMD
33 ohm(1/16w)+5%-5%
0603
1.01
pcs
+++++
602010268
Resistor SMD
390 ohm(1/16w)+1%-1%
0603
1.01
pcs
+++++
603010008
CAP CERAMIC SMD
1nf/25V +5% -5%
0603(NP0) SMD
1.01
pcs
+++++
603990006
CAP chain SMD
4*220pF±10％ 50V NPO
0603
4.04
pcs
+++++
602010118
Resistor SMD
33K ohm(1/10w)+5%-5%
0603
1.01
pcs
++++
620050009
MINI USB JACK
7PIN worizontal type
DIP
1.00
pcs
++++
605000002
Coil
TC623-30UH*2-F-03 DIP
1.00
pcs
++++
628010228
Masculine connector
7Pins/2.00mm single
line straight feet DIP
with fastener
1.00
pcs
+++
6280601710
FPC soft flat cable
20PIN L=135mm
PITCH1.0mm
1.00
pcs
+++
631040259
EVA
Black 27*27*1.0mm one
side with viscosity
2.00
pcs
+++
631040260
EVA
Black 15*15*1.0mm one
side with viscosity
2.00
pcs
+++
6070000120
Ferrite Toroid Core
26*5*9.5mm inner bore
22.6*0.9*9.5 flat type
1.00
pcs
+++
631020017
Black Velvet paper
66*30*0.3mm viscosity
1.00
pcs
+++
301020011
Flat round head screws
PB
φ2.6*8PB black
crisscross flat tail
tapping
8.00
pcs
+++
301020007
Flat round head screws
PB
Φ2.6*6PB black
crisscross flat tail
tapping
8.00
pcs
+++
629990176
Small foot pad2
Silica gel 15*4.6*2.0mm
single-sided adhesive
1.00
pcs
+++
629990155
Small foot pad
Silica gel 15*4.0*1.7mm
single-sided adhesive
1.00
pcs
++
1020402200
Top cabinet ASSY
Piranha
1.00
set
+++
201030477
Top cabinet
ABS Injection RAL9005
spray oil RAL 9005
1.00
pcs

14
Circuit Boards
BLACK silkscreen P=877C
M-AUDIO
++++
201010128
Top cabinet
ABS injection RAL9005
N/A
1.00
pcs
+++++
298010001
Plastic
ABS
0.08
kg
+++
301020012
Flat round head screws
PB
φ3.0*6PB black
crisscross flat tail
tapping
7.00
pcs
+++
1010302820
Function board ASSY
Piranha
1.00
set
++++
6280102170
FPC connector
20PIN pitch 1.0mm
underneath toaching
1.00
pcs
++++
6110100980
ROTARY Potentiometer
R0911N0XV1B103FE0000
8.00
pcs
++++
628071109
Colorized flat cable
with cathode plug
9pin L=40mm one side
with 9pin/2.0 cathode
plug the other side 3mm
dip soldering 28#
1.00
pcs
++++
628071110
Colorized flat cable
with cathode plug
7pin L=70mm one side
with 7pin/2.0 cathode
plug the other side 3mm
dip soldering 28#
1.00
pcs
++++
6010200220
DIP IC
CD4051 DIP16 TYPE
2.00
pcs
++++
609020010
Transistor DIP
8050D DIP high
frequency low power DIP
3.00
pcs
++++
603070012
CAP CERAMIC DIP
0.1uf/50V +20%-20% DIP
2.00
pcs
++++
603070004
CAP CERAMIC DIP
0.001uf(1000pf)50V +10%
-10% DIP
8.00
pcs
++++
603070024
CAP CERAMIC DIP
220pf/50V +10%-10%
distance3mm
8.00
pcs
++++
619010010
LED
height red light WEJ-
2115D DIP
5.00
pcs
++++
1010302830
Function board ASSY(AI
part)
Piranha
1.00
set
+++++
608050001
Switch Diode DIP
IN4148 DIP TYPE
17.00
pcs
+++++
602040008
Resistor DIP
100 ohm(1/8w)+5%-5%
3.00
pcs
+++++
602040099
Resistor DIP
2.7K ohm(1/8w)+5%-5%
3.00
pcs
+++++
602040145
Resistor DIP
4.7K ohm(1/8w)+5%-5%
3.00
pcs
+++++
602040070
Resistor DIP
22 ohm(1/8w)+5%-5%
4.00
pcs
+++++
1010302840
Function board ASSY(SMD
part)
Piranha
1.00
set
+++++
+
505030005
PCB Fake Dual layer 22F
1.6mm
Piranha function board
V01 blue glue + printed
carbon + roller coating
1.00
pcs
+++++
+
6190100580
Bi-color LED
SB-195SD/YG-CT Red
green double color
patch
2.01
pcs
+++++
+
619010016
LED
blue 0603 WEJT61BC-D76
SMD
2.02
pcs
+++++
602040025
Resistor DIP
120 ohm(1/8w)+5%-5%
7.00
pcs
+++++
628140007
jump
single flat cable 6mm
4.00
pcs
+++++
628140011
jump
single flat cable 8mm
6.00
pcs
+++++
628140015
jump
single flat cable 10mm
7.00
pcs
+++++
628140021
jump
single flat cable 13mm
1.00
pcs

PartList
15
+++++
628140025
jump
single flat cable 15mm
1.00
pcs
+++++
398040001
Light copper wire
0.00
kg
++++
218010033
LED Fixed column
Φ4.2*2mm N/A
5.00
pcs
+++
101090067
Drum control board ASSY
Piranha
1.00
set
++++
503030030
PCB Single layer 22F
1.6mm
Piranha drum control
board V01 blue coating
printing caborn
1.00
pcs
++++
628010227
Masculine connector
9Pins/2.00mm single
line straight feet DIP
with fastener
1.00
pcs
+++
629020305
Button single
Silicone black spray
feel oil carbon
2.00
pcs
+++
629020306
Button(3 connector)
Silicone black
silkscreen Spray feel
oil carbon
1.00
pcs
+++
629020307
Button(5 connector)
Silicone black
silkscreen Spray feel
oil carbon
1.00
pcs
+++
629020308
Button(7 connector)
Silicone primary+black
silkscreen Spray feel
oil carbon
1.00
pcs
+++
301230009
Countersunk head screws
FB
2.6*10FB white
crisscross Flat tail
tapping Double teeth
10.00
pcs
+++
208010047
Volume knob DL-1768
ABS black matt finish
8.00
pcs
++++
298010001
Plastic
ABS
0.00
kg
+++
642020035
Panel PC
English T=0.8 RAL9011
black background silver
words
1.00
pcs
+++
629990153
Drum pad
Silicone black spray
handle oil
1.00
pcs
+++
631040261
EVA
Black 388*7.0*1.0mm
single-sided adhesive
1.00
pcs
+++
621030030
Membrane switch
C220-057
1.00
pcs
+
1020202710
Outer packing materials
Piranha
1.00
set
++
643010002
Music stand bracket
PE 527*257*0.025mm no
printing
1.00
pcs
++
649002263
Carton(12pcs)
A=B die
line:450*425*505mm
0.08
pcs
++
647000425
Gift box
300g powder paper B9
die
line:434*238*66mm(LWH)
4C Matte Lamination
（Dumb glue）
transverse grooves beer
1.00
pcs
++
641010664
Label
English PC T=0.3mm
white on black back
glue new with KCC LOGO
1.00
pcs
++
639001175
Manual
508*508mm 127X127 100
lb Non-Gloss book or
match Four color
double-sided printing
1.00
pcs
++
646000021
Paper End left
Pulp
1.00
pcs

16
Circuit Boards
++
646000022
Paper End right
Pulp
1.00
pcs
++
6280800070
USB connector
L=1000mm±30 two side
with masculine plug
connector one side
USB“A”TYPE the other
side MINI USB 5PIN
1.00
pcs
++
641990220
Gift box packe label
Roundness 51mm blank
1.00
pcs
++
699000137
9100-65365-00 Rev A
(customer)
Axiom AIR Mini32
1.00
set
++
641040039
Carton bar code serial
number
White grounding with
black word
0.17
pcs
++
641040040
Serial number label
Black words on white
1.00
pcs
++
641040041
The color box bar code
label serial number
Black words on white
1.00
pcs
++
901020003
Sealing adhesive tape
48mm*50y Clarity
0.00
roll
++
640000201
Warranty card
127*127mm 100 lb non-
gloss book
1.00
pcs
++
641070078
Bar code
White words on black
0.08
pcs
++
640000197
Welcome leaflet
215.9*279.4mm fold to
139.7*215.9mm 100#gloss
text black+PMS2603C two
sided printing(2/1)
1.00
pcs
++
643010149
Manual bag
PE 226*148*0.04mm
1.00
pcs

PCBBoards
17
Main Board-Top
Main Board-Bottom

18
Circuit Boards
Function Board-Top

PCBBoards
19
Function Board-Bottom

20
Circuit Boards
KeyBoard
Drum Pad control Board
