USER MANUAL
M-DL6000

- 1 -
Safety Precautions
Never expose this unit, amplifier, and
speakers to moisture or water to prevent
electric sparks or fire.
Please don't change the fuse on the power
cord without professional guidance, using
improper fuse may cause damage to this unit
or even cause fire.
Please contact your nearest dealer if one of
the following symptoms is experienced:
(a). Water or other objects enters the unit.
(b). There is smoke.
(c). Peculiar smell.
Only connect the unit to a 12-volt power
supply with negative grounding.
MUTE
OK
MUTE
OK
Never install this unit where the operation &
condition for safe driving is impaired.
Never use the video display function in the
front when driving to prevent the violation of
laws & regulations and also to reduce the
risk of traffic accident except for using rear
view video camera.
MUTE
OK
MUTE
OK
MUTE
OK
MUTE
OK
Thank you for purchasing this product. Please
read through these operating instructions
so you will know how to operate your model
properly. After you’ve finished reading the
instructions, keep this manual in a safe place
for future reference.
To ensure safe driving, please adjust the
volume to a safe and comfortable level in
case of emergency situations.

- 2 -
1. Never disassemble or adjust the unit without any professional guidance.
For details, please consult any professional car shop / dealer for inquiry.
2. If the front panel or TFT monitor is dirty, please use a clean silicone cloth and neutral detergent
to wipe off the spot. Using a rough cloth and non-neutral detergent such as alcohol for cleaning
may result in scratching or decoloration to the monitor.
3. If any abnormal behavior of the unit is found, please refer to trouble shooting guide of this
manual. If no relevant information is found, please press the [RESET] key on the front panel to
resume factory default.
4. If you have parked the car in hot or cold weather for a long time, please wait until the
temperature in the car becomes normal before operating the unit.
5. Using the car heater in low temperature environment may result in moisture inside the unit, DO
NOT use the unit in this situation. Eject the disc and wipe off the moisture on the disc. If the unit
still doesn't work after a few hours, please contact the service center.
6. Do not impact the LCD monitor which could cause damage.
7. To prevent damage to the screen, avoid touching it with sharp objects.
8. To provide a clear demonstration and an alternative for easy understanding to the operation of
this unit, graphic illustrations are used.
However, some illustrations are different from the actual images displayed on the screen.
9. Operate the unit correctly according to this manual to prevent unnecessary problem. The
guarantee won't be valid if the problem is caused by inappropriate operation.
Safety Precautions
Information on disposal of unit
This product bears the selective sorting symbol for waste electrical and electronic
equipment (WEEE).
This means that this product must be handled to the local collecting points or given back to
retailer when you buy a new product, in a ratio of one to one (or one to zero if the external
dimension is less than 25 cm) pursuant to European Directive 2012/19/EC in order to be
recycled or dismantled to minimize its impact on the environment.
For further information, please contact your local or regional authorities.
Electronic products not included in the selective sorting process are potentially dangerous for the
environment and human health due to the presence of hazardous substances.
The unlawful disposal of the product carries a fine according to the legislation currently in force.

- 3 -
Contents
Safety Precautions ....................................1-2
Contents........................................................ 3
Produc overview ........................................... 4
Front Panel............................................... 4
Basic Operations .......................................... 5
Detect parking brake................................ 5
Mute .......................................................... 5
Power On / Off .......................................... 5
Audible Beep Confirmation...................... 5
Playing Source Selection ......................... 5
Audio control ................................................ 6
Adjust EQ Parameters.............................. 6
Select Preset Equalizer............................ 6
Adjust EQ Parameters.............................. 6
Adjust FAD BAL ....................................... 6
Set Date .................................................... 7
Set Clock Mode......................................... 7
Set Time.................................................... 7
Radio Mode................................................... 8
Tuner TFT Display .................................... 8
Select Radio as Playing Source ............... 8
Select One Radio Band............................. 8
Tune the radio........................................... 8
Preset Station........................................... 9
local Seeking ............................................ 9
RDS Basics ............................................... 9
Adjust RDS Settings ................................. 9
RDS ( Radio Data System )..................... 10
AF Function............................................. 10
EON ( Enhanced Other Networks ) ........ 10
TA Function............................................. 10
CT (Clock Time) ...................................... 10
PTY Function........................................... 10
Playback Mode ........................................... 11
Touch Screen Controls .......................... 11
Controlling Playback.............................. 11
Connect a USB Device............................ 11
Remove a USB Device............................ 11
Insert a SD/MMC Card ........................... 11
Remove a SD/MMC Card........................ 11
Play/Pause.............................................. 11
Previous/Next ......................................... 11
Search for a Folder ................................ 12
Repeat..................................................... 13
Shuffle (Random) Play............................ 13
Playback Information ............................. 14
Direct Track Entry .................................. 14
Rotate Pictures....................................... 14
Zoom ....................................................... 14
Video Setup............................................. 14
Bluetooth Mode .......................................... 15
Pair the Bluetooth-enabled Devices...... 15
Disconnect Bluetooth Device................. 15
Make a Call............................................. 15
Receive a Call ......................................... 16
Adjust Bluetooth Settings ...................... 16
Bluetooth Musci Mode ........................... 16
Settings....................................................... 17
General settings ..................................... 17
Calibration .............................................. 17
Video settings ......................................... 17
Sound settings........................................ 18
Time settings.......................................... 18
Language settings.................................. 18
Bluetooth settings.................................. 18
Reset....................................................... 19
Volume settings...................................... 19
Other Modes ............................................... 20
ther Devices............................................ 20
Reset....................................................... 20
Replace a Fuse....................................... 20
Navigation (GPS)..................................... 20
SWC Programming ................................ 20
Specifications ........................................21-22
Troubleshooting ......................................... 23
Wire Connections ....................................... 24

- 4 -
MENU
NAVI
Front Panel
1. Button [ ]
Press to turn the unit ON. Press and hold to turn the unit OFF.
2. [MENU] Button
Press to switch between the available audio/video sources applied to the unit.
3. [VOL/ ] Knob
Rotate to adjust the volume.
Press momentarily to activate the MUTE function. Press again to resume normal listening.
4. [NAVI] Button
Press to switch to navigation mode.
5. Reset Button
Press to reset system settings to factory default (except password and parental lock settings).
6. SD card slot :
nsert an SD card for playback of music/video/picture files.
7. USB por:
Connect a USB device for playback of music/video files.
8. Map Slot
The Mini SD card is used for the Navigation Map only, not for music or other files.
This may be used for firmware updates if required.
9. Remote Sensor
Product overview
Notice:
The graphic in this manual is for reference only, and may be different from the actual unit.
18
2
3
4
5
6
7
9
M-DL6000

- 5 -
Detect parking brake
• Connect the cable "BRAKE" to the parking brake switch to view video files on the TFT monitor.
Engage the parking brake for viewing videos.
• When the parking brake is not engaged, the monitor displays "Warning!!!, Video playback is
disabled for your safety. Engage parking brake to watch video.", preventing the driver to watch
content while driving. The rear screens are not interested in this inhibition.
Mute
Press knob to mute the volume from the unit. Press again to restore the volume. [ ] is displayed
on the LCD. Adjusting the volume or using any of the audio setup features cancels the mute
function.
Power On / Off
Press the [ ] knob on the unit to turn the unit on. The buttons on the front of the unit light up for
a moment and the current mode status appears in the LCD.
Press gain [ ] knob to power off the unit.
Audible Beep Confirmation
An audible beep tone confirms each function selection. The Beep tone can be disabled through the
Setup menu.
Playing Source Selection
Press the [ MENU ] button on the front panel to display the playing source menu. The playing mode
is displayed on the screen.
1. Date and Time display.
2. Function icons.
3. All SRC.
Basic Operations
12
322
Volume Adjustment
To increase or decrease the volume level, turn the
volume knob on the front panel. The volume ranges
from “0” to “50”. The LCD or TFT screen displays the
volume level for 3 seconds.

- 6 -
Select Preset Equalizer
1. Enter the EQ setup mode
Touch the [ ] icon in the user interface and the
EQ setup interface will display on the screen.
2. Select EQ mode
Touch the desired EQ selection: [ Optional ] /
[ Classic ] / [ Rock ] / [ Jazz ] / [ Techno ] / [ Pop ],
and the EQ mode will change.
Adjust EQ Parameters
To adjust EQ parameters, touch and drag the parameters adjustment bar.
[ User ]: Set the desired audio effect.
[ Flat ]: Select the original audio effect.
[ Reset ]: Cancel the equalizer function settings.
[ Loud: On/Off ]: When listening to music at low volumes, this featurewill selectively boost certain
bass and treble frequencies.
Adjust FAD BAL
You can adjust front/back/left/right balance of the speaker and the subwoofer volume to get
balanced listening effect according to the surroundings and your interest.
1. Enter the EQ setup mode
Touch the [ ] icon in the user interface and the EQ
setup interface will display on the screen.
2. Adjust subwoofer volume
Touch [ ] / [ ] or drag [ ] to adjust subwoofer
volume from -12 to +12.
3. Adjust fader / balance value
Touch [ ] / [ ] / [ ] / [ ] to adjust fader /
balance value from -20 to +20.
[ ]: Front speaker
[ ]: Rear speaker
[ ]: Left speaker
[ ]: Right speaker
Audio control
EQ Menu
The Audio Control feature allows you to easily adjust your audio system to meet the acoustical
characteristics of your vehicle, which vary depending on the type of vehicle and its measurements.
Proper setting of the Fader and Balance boosts the effects of the cabin equalizer.
Notes:
1. The parameters of the EQ modes has been preset and you can not change them besides ‘User’.
2. The EQ mode will change to ‘User’ automatically when you adjust the frequency value under the
modes besides ‘User’.
3. The value of Sub is independent of EQ mode and can be adjusted separately.

- 7 -
Setting Date /Time
1. Touch [ Settings].
2. Touch [ Time ].
The date/time setup menu is displayed.
Set Date
1. Touch [ Date ].
2. Touch the date information on the screen .
A submenu is displayed.
3. Touch [ ] or [ ] to set year, month and day.
Set Clock Mode
1. Touch [Clock mode].
2. Touch [12Hr] or [24Hr] to switch clock mode.
Set Time
1. Touch [ Time ].
2. Touch the time on the screen, a submenu is displayed.
3. Touch [ ] or [ ] to set hour and minute.

- 8 -
Select Radio as Playing Source
Open the Source Menu and then touch [Radio].
Select One Radio Band
Touch the [ ] icon on the user interface to select one radio band among FM1, FM2, FM3, AM1 and
AM2.
Tune the radio
Auto Tunig
During auto tuning, the frequency will be changed in seek mode.
Touch the [ ] / [ ] icon on the user interface to tune in a higher / lower station.
Note: When a station is received, searching stops and the station is played.
Manual Tuning
Method 1:
Touch and hold [ ] / [ ] icon on the user interface more than 1 second to changed in steps
higher / lower station. Repeat the operation to change step by step.
Method 2:
1. Touch the numeric keypad icon [ ].
Numeric keyboard is displayed, touch number to
input frequency.
2. Touch [ ] to delete the input number step by step.
3. Touch [ OK ] to enter.
Radio Mode
1. Touch to view the MENU and select a new
playback source
2. Strong Local signal broadcasting indicator
3. Stereo broadcasting indicator
4. Current radio band indicator
5. Broadcaster information stored at the preset
6. Touch to view more on-screen buttons
7. Touch to seek backward
8. Touch for quick access to EQ level settings
9. Touch to seek forward
10. Touch to change between AM/FM bands
11. Clock
12. Current preset radio station
13. Current radio information
14. AF: Alternative Frequency indicator
15. TA: Traffic Announcement indicator
16. RDS setting options
17. Save the desired radio station
18. Touch to change between Local and Distance
19. Enter frequency directly
20. Search stations automatically
Tuner TFT Display 1 2 3 4
11
12
13
14
15
5
6
7 8 9 10
16 17 18 19 20

- 9 -
Local Seeking
Touch the [ ] icon and choose the Radio Local or Distance.
When the [ ] icon turns bright, only stations with a strong signal strength will be detected .
Default is “Distance”.
EQ Selection
Press the [ ] icon and enter the EQ setup.
RDS Basics
RDS transmits data to the radio which displays information such as name station, song artist, and
song title.
RDS service availability varies with areas.
Adjust RDS Settings
1. In Radio menu, touch [ ].
The option menu is displayed.
2. Touch on the selected option to change the setting.
[RDS]: To turn on or off “RDS” function.
[CT]: To turn on or off “Clock Time” synchronization function.
[EON]: To turn on or off “EON” function.
[TA]: To turn on or off “TA” function.
[PTY]: To show PTY list.
[ VOL]: Touch [ ] / [ ] to adjust TA volume.
Radio Mode
Preset Station
The unit has 5 bands, such as FM1, FM2, FM3, AM1, AM2, and each band can store 6 stations; the
unit can store 30 stations in total.
Search Stations Automatically
Touch [ ] to search station and store 6 strongest
stations in current band automatically.
Manual Store
1. Tune to a station.
2. Touch [ ].
3. Touch one of the channels P1 to P6 to save the select
band.
Tune to a Preset Station
1. Touch [Radio].
2. Select a band (if needed).
3. Touch one of the preset channels (P1 to P6) on the
screen.
