MAG TOOLS MPF59038 User manual

final page size: 8.5 x 5.5 in
If you have questions or comments, contactus.
Pour toute question ou tout commentaire, nouscontacter.
Si tiene dudas o comentarios,contáctenos.
MACTOOLS.COM 1-800-662-8665
Instruction Manual | Guide D’utilisation | Manual de instrucciones
MPF59038
3/8" to 1/2" High-Powered Air Ratchet
Cliquet pneumatique très puissant 3/8po à 1/2po
Trinquete Neumático de Alta Potencia de 3/8" a 1/2"

ENGLISH
English (original instructions) 1
Français (traduction de la notice d’instructions originale) 9
Español (traducido de las instrucciones originales) 18

ENGLISH
1
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.
(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.
WARNING: Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
If you have any questions or comments about this or
any MacTools tool, call us toll free at:
1–800-MAC-TOOLS (1–800–622–8665).
1 3/8" or 1/2" square drive
2 Variable speed trigger
3 1/4" inlet
4 Rubber grip handle
5 Forward/reverse switch
6 Sealed head
7 Torque Assist™ clutch
8 3/8" Square drive anvil
9 1/2" Square drive anvil
Fig. A
2
3
1
5
4
6
7
98

ENGLISH
2
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING: Improper operation or maintenance of
this product could result in serious injury and property
damage. Read and understand all warnings and
operating instructions before using this equipment.
When using air tools, basic safety precautions
should always be followed to reduce the risk of
personalinjury.
6.2 Bars
(90 PSI/
620 kPa)
Do not use damaged, frayed or deteriorated air
hoses andfittings.
6.2 Bars
(90 PSI/
620 kPa)
Air powered tools can vibrate in use. Vibration,
repetitive motions or uncomfortable positions
may be harmful to your hands and arms. Stop
using any tool if discomfort, tingling feeling
or pain occurs. Seek medical advice before
resuminguse.
6.2 Bars
(90 PSI/
620 kPa)
Do not carry the tool by thehose.
6.2 Bars
(90 PSI/
620 kPa)
Keep body stance balanced and firm. Do not
overreach when operating thistool.
6.2 Bars
(90 PSI/
620 kPa)
Always wear hearing protection when operating
thistool.
6.2 Bars
(90 PSI/
620 kPa)
Always wear ANSI Z87.1 CAN CSA Z94.3 eye
protection when operating or performing
maintenance on thistool.
6.2 Bars
(90 PSI/
620 kPa)
Always turn off the air supply and disconnect
the air supply hose before installing, removing
or adjusting any accessory on this tool, or before
performing any maintenance on this tool.
6.2 Bars
(90 PSI/
620 kPa)
Operate at 90 PSI (6.2 Bar) Maximum
airpressure.
WARNING:
• Prevent unintentional starting. Ensure the trigger
is in the off position before connecting to air
source, picking up or carrying the tool. Carrying
power tools with your finger on the switch or
energizing power tools that have the switch on
invitesaccidents.
• Do not operate this tool for long periods of time.
Vibration caused by tool action may be harmful
to your hands and arms. Stop using any tool if
discomfort, tingling feeling or pain occurs. Seek
medical advice before resuminguse.
• Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the
hands of untrainedusers.
• Do not use oxygen or reactive gases; explosion
mayoccur.
• Exceeding the maximum pressure of 90 PSI
(6.2Bar) will lead to the risk of danger such as
excessive speed, tool wear, breaking parts, higher
torque or force that may destroy the tool and its
accessories or the part being workedon.
• Read all manuals included with this product
carefully. Be thoroughly familiar with the controls
and the proper use of theequipment.
• Only persons well acquainted with these rules
of safe operation should be allowed to use the
airtool.
• Do not exceed any pressure rating of any
component in thesystem.
• Disconnect the air tool from air supply before
changing tools or attachments and during
non‑operation.
• Always wear safety glasses and ear protection
during operation. Always wear approved safety
glasses with shields. Always wear approved
hearingprotection.
• Do not wear loose fitting clothing or apparel
which contains loose straps or ties, etc. Which
could become entangled in moving parts of the
tool and results in serious personalinjury.
• Do not wear jewelry, watches, identifications,
bracelets, necklace, etc. When operating any tool,
they may become caught in moving parts and
result in seriousinjury.
• Do not depress trigger when connecting the air
supplyhose.
• Always use attachments designed for use with air
powered impacttools.
• Do not use the tool if it has beendamaged.
• Use rated accessories recommended by MacTools
only. Inspect accessories before use. Do not use
cracked or damaged accessories. Just because the
accessory can be attached to your power tool, it
does not assure safeoperation.
• Never trigger the tool when not applied to a work
object. Attachments must be securely attached.
Loose attachments can cause seriousinjury.
• Protect air lines from damage orpuncture.
• Never point an air tool at oneself or any other
person. Serious injury couldoccur.
• Check air hoses for weak or worn condition before
each use. Make sure all connections aresecure.
• Keep all nuts, bolts and screws tight and ensure
equipment is in safe workingcondition.
• Keep hands and other body parts, loose clothing
and long hair away from the moving end oftool.
• Accessories and tools can get hot during
operation. Wear gloves when touchingthem.
• Do not discard the safety instructions; give them
to theoperator.

ENGLISH
3
• Do not modify this tool. Modifications can reduce
the effectiveness of safety measures and increase
the risks to theoperator.
• Whipping hoses can cause severe injury. Always
check for damaged or loose hoses andfittings.
WARNING: (Air and Supply and Connections)
• Do not use oxygen, combustible gases, or bottled
gases as a power source for this tool as the tool
may explode, possibly causinginjury.
• Do not use supply sources which can potentially
exceed 200 PSI (13.8 Bar) as tool may burst,
possibly causinginjury.
• The connector on the tool must not hold pressure
when air supply is disconnected. If a wrong fitting
is used, the tool can remain charged with air after
disconnecting and thus will be able to after the air
line is disconnected possibly causinginjury.
• Before connecting the tool to the air inlet, ensure
the trigger is not blocked in the on position by
anobstacle.
• The pneumatic tool must be fitted and connected
to the compressed air network via quick
disconnects to facilitate shutdown in the event
ofdanger.
• In the event of blockage, release the trigger
and disconnect the tool from the compressed
airnetwork.
• Be sure all hoses and fittings are the correct size
and are tightlysecured.
WARNING: Do not operate tool if:
• There is any damage to air hose or fitting.
• The tool leaks air.
• The tool has received a sharp blow, malfunctions
or is dropped or damaged in any manner. Return
tool to the nearest authorized service facility for
examination, repair, or mechanicaladjustment.
• Warning labels are missing ordamaged.
• Tool is not in proper working order. Tags and
physical segregation shall be used forcontrol.
WARNING: When operating the tool:
• Keep work area clean and well lit. Cluttered or
dark areas inviteaccidents.
• Anticipate and be alert for sudden changes in
motion during start up and operation of any
powertool.
• Do not use in wetconditions.
• Always handle the tool with care:
• Never engage inhorseplay.
• Never point the tool at yourself orothers.
• Keep bystanders and children away while
operatingtool.
• Respect tool as a workingimplement.
• Stay alert, focus on your work and use common
sense when working withtools.
• Do not use tool while tired, after having consumed
drugs or alcohol, or while under the influence
ofmedication.
• Do not overreach. Only use in a safe
workingplace.
• Keep proper footing at alltimes.
• This tool produces SPARKS during operation.
NEVER use the tool near flammable substances,
gases or vapors including lacquer, paint, benzine,
thinner, gasoline, adhesives, mastics, glues
or any other material that is ‑‑ or the vapors,
fumes or byproducts of which are ‑‑ flammable,
combustible or explosive. Using the fastenerer in
any such environment could cause an EXPLOSION
resulting in personal injury or death to user
andbystanders.
• For overhead work, wear a safetyhelmet.
• If the tool appears to malfunction, remove
from use immediately and arrange for service
andrepair.
• The tool is not electrically insulated. Never use
the tool if there is any chance of it coming into
contact with liveelectricity.
• Do not lock, tape, wire, etc., the on/off trigger in
the run position. The trigger must always be free
to return to the “off” position when it isreleased.
• Never lay a tool down unless the working
attachment has stoppedmoving.
• Always ensure that the forward/reverse switch is
in the desired position before starting thetool.
• Do not use sockets with excessive wear to the
input or output drives. Periodically check the
square drive on the impact wrench.Make surer
the socket, extension bar, or other attachment is
securely fitted before operatingtool.
• When loosening fasteners first ensure that there
is sufficient clearance behind the tool to avoid
hand entrapment. The tool will move away from
the threaded joint as the nut/bolt is loosened and
rides up the thread, moving the tool withit.
WARNING: Disconnect tool:
• When not inuse.
• Before making adjustments;
• When performing any maintenance or repairs,
• When elevating, lowering or otherwise moving
tool to a newlocation.
• When tool is outside of the operator's supervision
orcontrol.
• When moving to a different work area, as
accidental actuation may occur, possibly
causinginjury.
WARNING: When maintaining the tool:
• Always shut off air supply, and disconnect tool
from air supply when not inuse.

ENGLISH
4
• When working on air tools note the warnings in
this manual and use extra care when evaluating
problemtools.
• Do not lubricate tools with flammable or volatile
liquids such as kerosene, diesel or jetfuel.
• When the life of the tool has expired, it is
recommended that the tool be disassembled,
degreased and parts be separated by material so
that they can berecycled.
Additional Safety Information
WARNING: ALWAYS use safety glasses. Everyday
eyeglasses are NOT safety glasses. Also use face or
dust mask if cutting operation is dusty. ALWAYS WEAR
CERTIFIED SAFETYEQUIPMENT:
• ANSI Z87.1 eye protection (CAN/CSA Z94.3),
• ANSI S12.6 (S3.19) hearing protection,
• NIOSH/OSHA/MSHA respiratoryprotection.
WARNING: Some dust created by power sanding,
sawing, grinding, drilling, and other construction
activities contains chemicals known to the State
of California to cause cancer, birth defects or
other reproductive harm. Some examples of these
chemicalsare:
• lead from lead‑based paints,
• crystalline silica from bricks and cement and other
masonry products, and
• arsenic and chromium from chemically‑
treatedlumber.
Your risk from these exposures varies, depending on how
often you do this type of work. To reduce your exposure to
these chemicals: work in a well ventilated area, and work with
approved safety equipment, such as those dust masks that are
specially designed to filter out microscopicparticles.
• Avoid prolonged contact with dust from power
sanding, sawing, grinding, drilling, and other
construction activities. Wear protective clothing and
wash exposed areas with soap and water. Allowing
dust to get into your mouth, eyes, or lay on the skin may
promote absorption of harmfulchemicals.
WARNING: Use of this tool can generate and/
or disperse dust, which may cause serious and
permanent respiratory or other injury. Always use
NIOSH/OSHA approved respiratory protection
appropriate for the dust exposure. Direct particles
away from face andbody.
WARNING: Always wear proper personal hearing
protection that conforms to ANSI S12.6 (S3.19)
during use. Under some conditions and duration
of use, noise from this product may contribute to
hearingloss.
CAUTION: When not in use, place tool on its side
on a stable surface where it will not cause a
tripping or falling hazard. Some tools may stand
upright but may be easily knockedover.
SAVE THESE INSTRUCTIONS FOR
FUTURE USE
COMPONENTS (FIG. A)
WARNING: Never modify the power tool or any part
of it. Damage or personal injury couldresult.
Refer to Figure A at the beginning of this manual for a
complete list ofcomponents.
Intended Use
This air ratchet is designed for driving, tightening and
loosening threaded fasteners, usually nuts and bolts, when
fitted with a suitable socket. Always use extension bars,
universal joints and socket adapters between the square
output drive of the air ratchet and the female square drive
of thesocket.
DO NOT use the tool for any other purpose than that
specified without consulting the manufacturer or the
manufacturer’s authorized supplier. To do so may
bedangerous.
Never use the air ratchet as a hammer to dislodge or
straighten cross threaded fasteners. Never attempt to modify
the tool for otheruses.
DO NOT use under wet conditions or in presence of
flammable liquids orgases.
This air ratchet is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
Glossary
CFM: Cubic feet perminute.
SCFM: Standard cubic feet per minute; a unit of measure of
airdelivery.
L/s: Liters per second; a metric unit of measure of
airdelivery.
PSI: Pounds per square inch; a unit of measure ofpressure.
Bar: A metric unit of measure ofpressure.
Code Certification: Products that bear one or more of the
following marks: UL, CUL, ETL, CETL, have been evaluated
by OSHA certified independent safety laboratories and
meet the applicable Underwriters Laboratories Standards
forSafety.
RPM: Revolutions per minute; is a measure of the frequency
of a rotation
NPT: National pipe thread (tapered thread); is a U.S.
standard for tapered threads used on threaded pipes
andfittings.
ID: Inner diameter
Technical Data
MPF59038
Square drive 3/8" or 1/2"
Maximum torque (reverse) 80 Ft. lbs (108 Nm)
Free speed @ 90 PSI (6.2 Bar) 300 rpm
Net weight 3.5 lbs (1.57 kg)
Exhaust type Front

ENGLISH
5
MPF59038
Average air consumption free speed 35 SCFM (17 L/s)
4.9 CFM (2.3 L/s)
Average air consumption at load 35 SCFM (17 L/s)
4.9 CFM (2.3 L/s)
Air intlet size 1/4" NPT(F)
Recommended hose size 3/8" (10 mm)
Maximum air pressure 90 PSI (6.2 Bar)
Noise values and vibration values (triax vector sum) according to
EN ISO 11148-6:
LPA (emission sound pressure level) dB(A) 91
LWA (sound power level) dB(A) 102
K (uncertainty for the given sound level) dB(A) 3
Vibration emission value a
h
= m/s23.0
Uncertainty K = m/s21.5
Work Stations
Your air ratchet should only be used as a hand operated
tool. It is always recommended that the tool is used when
standing with solid footing. It can be used in other positions
but before any such use, the operator must be in a secure
position having a firm grip and footing and be aware that
when loosening fasteners the tool can move quite quickly
away from the fastener being undone. An allowance must
always be made for this rearward movement so as to avoid
the possibility of hand/arm/bodyentrapment.
Features
Forward/Reverse Switch (Fig. A)
The forward/reverse switch 5 allows the tool to operate in a
forward or reverse direction for easier and robustoperation.
3/8" and 1/2" Square Drive (Fig. A)
The 3/8" and 1/2" square drive 1 allows the attachment of
3/8" and 1/2" drivesockets.
Sealed Head (Fig. A)
The sealed head 6 design prevents yoke spread under
heavy torqueapplication.
Rubber Grip Handle (Fig. A)
This air tool has a rubber grip handle 4 made of molded
thermoplastic elastomer (TPE) designed for improved
comfort, slippage reduction, and better tool control.
Variable Speed Trigger (Fig. A)
The variable speed trigger 2 allows the operator to control
the start and stop of the airtool.
1/4" Inlet (Fig. B)
The tool’s 1/4" inlet 3 located at the bottom of the handle
is used for connecting an air supply with a standard 1/4"
NPT Americanthread.
3
Fig. B
Torque Assist™ Clutch (Fig. C)
The integrated Torque Assist™ clutch 7 is designed to
give the user control by limiting torque as needed. This
can prevent damaging fasteners and reduce kickback in
tightening applications. The Torque Assist™ clutch features
two settings and a max setting to deliver fullpower.
7
Fig. C
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove air supply before
making any adjustments or removing/installing
attachments or accessories. An accidental start‑up
can causeinjury.
Attaching and Removing Square Drive
Anvils (Fig. A)
Your tool is supplied with two anvils, a 3/8" square drive
anvil 8 and a 1/2" square drive anvil 9 , suitable for use
with the corresponding sized sockets. To install an anvil just
push it into the square drive 1 until you hear a "click". The
anvil can be installed on the front or back of the head in
order to enable you to more versatility to get the tool into
tight spaces morecomfortably.
To remove the anvil from the air ratchet, push the button on
the back of the anvil and slide the unitout.
Air Supply (Fig. D)
The recommended hook-up is shown in Figure D.
Pneumatic tools operate on a wide range of air pressures.
For maximum efficiency and longer tool life, the pressure of
the air supplied to these tools MUST not exceed the rated
PSI at the tool when the tool is running. Using a higher than
rated pressure will cause faster wear and drastically shorten

ENGLISH
6
the tool’s life. A higher air pressure can also cause an unsafe
condition andexplosion.
The inside diameter of the hose should be increased to
compensate for unusually long air hoses (over 25 feet
[7.6m]). Minimum hose diameter should be 3/8" (10mm)
I.D. and fittings should have 1/4" NPTthread.
The use of air line lubricators and air line filters is
recommended to prevent water in the line that can
damage the tool. Drain the air tank daily. Clean the air
inlet filter screen on at least a weekly schedule to remove
accumulated dirt or other matter that can restrict airflow.
The tool’s air inlet used for connecting an air supply has
standard 1/4" NPT American thread.
Air hose
Leader hose Nipple
Oiler Filter
Drain daily
Coupler
1/2" (or larger)
pipe and fittings
Fig. D
Tool
OPERATION
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove air supply before
making any adjustments or removing/installing
attachments or accessories. An accidental start‑up
can causeinjury.
Proper Hand Position (Fig. E)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the rubber grip
handle 4 .
Fig. E
4
Prepping the Air Tool
WARNING: Risk of unsafe operation. Firmly grasp air
hose with hand when installing or disconnenting to
prevent hosewhip.
WARNING: Risk of bursting. Too much air pressure
causes a hazardous risk of bursting. Check the
manufacturer’s maximum pressure rating for air tools
and accessories. The regulator output pressure must
never exceed the maximum pressurerating.
• Drain water from air compressor tank and condensation
from air lines. (Please refer to air compressor’s
operationmanual.)
• Lubricate the tool. (Please refer to the Maintenance
section in the manual.)
• Connect the air ratchet to air source with the hose of
recommendedsize.
Operating Procedures
Air Supply (Fig. D)
CAUTION: This air tool requires lubrication BEFORE
initial use, also before and after each additionaluse.
WARNING: Use a clean lubricated air supply that
will give a measured air pressure at the tool of
90PSI/6.2bar when the tool is running with the
trigger fully depressed.
Use recommended hose size. It is recommended that the
tool is connected to the air supply as shown in FigureD.
Do not connect the tool to the air line system without
incorporating an easy to reach and operate air shut off
valve. The air supply should be lubricated. It is strongly
recommended that an air filter, regulator, lubricator (FRL)
is used as shown in Figure D as this will supply clean,
lubricated air at the correct pressure to the tool. Details of
such equipment can be obtained from your supplier. If such
equipment is not used then the tool should be lubricated by
shutting off the air supply to the tool and then
depressurizing the line by pressing the trigger on the tool.
Disconnect the air line and pour into the air inlet 1teaspoon
of a suitable pneumatic motor lubricating oil, preferably
incorporating a rust inhibitor. Reconnect tool to air supply
and run tool slowly for a few seconds to allow air to circulate
theoil.
Lubricate tool daily if used frequently, or when it starts to
slow or losepower.
Start-Up (Fig. A, F)
1. Turn on the air compressor and allow the air tank to
befilled.
2. Set the air compressor regulator to 90 PSI (6.2 Bar)
This air tool operates at a maximum of 90 PSI (6.2 Bar)
airpressure.
3. Adjust the forward/reverse switch 5 to either forward
or reverseposition.
FORWARD REVERSE
5
Fig. F
4. Depress the variable speed trigger 2 to start operating
thetool.

ENGLISH
7
Shut-Down (Fig. A)
1. Release the variable speed trigger 2 in order to stop
thetool.
2. When changing sockets, always disconnect air supply
to avoidinjury.
3. When job is completed, turn off the air compressor and
store the air tool afterlubrication.
Operating Instructions
1. Securely fit the socket or attachment to the airratchet.
2. Ensure that the forward/reverse switch is in the correct
position for tightening or loosening thefastener.
3. The nut/bolt can then run down the thread using the
power drive of the tool. For loosening a joint the tool
can be used in the reversesequence.
MAINTENANCE
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove air supply before
making any adjustments or removing/installing
attachments or accessories. An accidental start‑up
can causeinjury.
Lubrication
Air tools require lubrication throughout the lifetime of
thetools.
The air motor and bearing uses compressed air to power
the tool. The compressed air contains moisture that will rust
the air motor and other parts in side of the tools, therefore
lubrication is required daily. Failure to lubricate the air tool
properly will dramatically shorten the life of the tool and will
void the warranty
CAUTION:This air tool requires lubrication BEFORE
initial use, also before and after each additionaluse.
To Lubricate the Air Tool Manually
1. Remove any attachment on the drive of air tools, such
as: sockets, chisels andetc.
2. Disconnect the tool from the air supply source, place
the air inlet faceup.
3. Depress the trigger and place about 1 teaspoon of air
tool oil into the air inlet. (Depressing the trigger will help
circulate oil in the motor.)
NOTE: Use SAE #10 weight oil if air tool oil is
notavailable.
WARNING: Keep out of the reach of children. If
taken internally, do not induce vomiting, call a
doctorimmediately.
WARNING: Any excess oil in the motor is immediately
expelled from the exhaust port. Always direct exhaust
port away from people orobjects.
4. Connect the tool to an air source, cover the exhaust end
with a towel and run for about 20 to 30seconds.
5. After every 48 hours or operation, or as experience
indicates, inject about 1 teaspoon of approved
pneumatic grease into the greasefitting.
Storage
The air tool must be lubricated beforestoring.
Follow Steps 1–3 in To Lubricate the Air ToolManually.
Cleaning
WARNING: Blow dirt and dust out of all air vents with
clean, dry air at least once a week. To minimize the risk
of eye injury, always wear ANSI Z87.1 approved eye
protection when performingthisprocedure.
WARNING: Never use solvents or other harsh
chemicals for cleaning the non‑metallic parts of
the tool. These chemicals may weaken the plastic
materials used in these parts. Use a cloth dampened
only with water and mild soap. Never let any liquid
get inside the tool; never immerse any part of the tool
into aliquid.
Accessories
WARNING: Since accessories, other than those
offered by MacTools, have not been tested with this
product, use of such accessories with this tool could be
hazardous. To reduce the risk of injury, only MacTools
recommended accessories should be used with
thisproduct.
Recommended accessories for use with your tool are
available at extra cost from your local dealer or authorized
service center. If you need assistance in locating any
accessory, please contact MacTools, 505 North Cleveland
Ave., Westerville, Ohio 43082, call 1-800-MAC-TOOLS
(1-800-622-8665) or visit our website www.mactools.com.
UK Customer Service: Mac Tools UK, Europa Court, Sheffield
Business Park, Sheffield, England S9 1XE
Tel: [phone] Fax: [phone]
Email: [email protected]
Repairs
WARNING: To assure product SAFETY and
RELIABILITY, repairs, maintenance and adjustment
(including brush inspection and replacement, when
applicable) should be performed by a MacTools
factory service center or a MacTools authorized
service center. Always use identical replacementparts.
Register Online
Thank you for your purchase. Register your product nowfor:
• WARRANTY SERVICE: Registering your product will
help you obtain more efficient warranty service in case
there is a problem with yourproduct.
• CONFIRMATION OF OWNERSHIP: In case of
an insurance loss, such as fire, flood or theft, your
registration of ownership will serve as your proof
ofpurchase.
• FOR YOUR SAFETY: Registering your product will
allow us to contact you in the unlikely event a safety
notification is required under the Federal Consumer
SafetyAct.
Register online at www.mactools.com.

ENGLISH
8
Two Year Limited Warranty
MacTools will repair, without charge, any defects due
to faulty materials or workmanship for two years from
the date of purchase. This warranty does not cover part
failure due to normal wear or tool abuse. For further detail
of warranty coverage and warranty repair information,
visit www.mactools.com or call 1-800-MAC-TOOLS
(1-800-622-8665). This warranty does not apply to
accessories or damage caused where repairs have been
made or attempted by others. THIS LIMITED WARRANTY
IS GIVEN IN LIEU OF ALL OTHERS, INCLUDING THE IMPLIED
WARRANTY OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, AND EXCLUDES ALL INCIDENTAL
OR CONSEQUENTIAL DAMAGES. Some states do not allow
limitations on how long an implied warranty lasts or the
exclusion or limitation of incidental or consequential
damages, so these limitations may not apply to you. This
warranty gives you specific legal rights and you may have
other rights which vary in certain states orprovinces.
LATIN AMERICA: This warranty does not apply to products
sold in Latin America. For products sold in Latin America,
see country specific warranty information contained in
the packaging, call the local company or see website for
warrantyinformation.
FREE WARNING LABEL REPLACEMENT: If your
warning labels become illegible or are missing, call
1-800-MAC-TOOLS (1-800-622-8665) for a freereplacement.
EC-Declaration of Conformity
Machinery Directive
3/8" to 1/2" High-Powered Air Ratchet
MPF59038
Mac Tools declares that these products described under
Technical Data are in compliance with:
EN ISO11148-6:2012.
The undersigned is responsible for compilation of the
technical file and makes this declaration on behalf
ofMacTools.
Markus Rompel
Vice-President Engineering, PTE-Europa
Mac Tools UK, Europa Court, Sheffield Business Park,
Sheffield, England S9 1XE
22.10.2018
