MAG Complete 12 Quick start guide

Complete 12
Complete 15
Specications & rigging guide
2 Merezhna str., Bila Tserkva, Kiev oblast, 09112, Ukraine v1.1

Complete series speaker sets offer complete sound rein-
forcement solution for portable and xed installations alike.
Cost-effective powered systems include two 8”+1” or 10”+1”
satellites and master 12” or 15” powered subwoofers, provid-
ing neccessary amplication and EQ for satellites.
Regardles of its size, Complete sets are packing enough
punch to compare them to bigger, conventional FOH systems.
Small size and light weight makes Complete sets perfect solu-
tion for mobile audio applications, and due to easy plug&play
connections can be used by even non-professionals.
2
2 Merezhna str., Bila Tserkva, Kiev oblast, 09112, Ukraine v1.1
This contents & System application ....................................................... 2
Complete 12 specications ...................................................................... 3
Complete 15 specications ...................................................................... 4
Installation options & Accessories ....................................................... 5
Connections & integrated processor setups ........................................ 6
CONTENTS
SYSTEM APPLICATION

Complete 12
Type Portable speaker set
Acoustical
Frequency range (-10 dB) 45 - 18000 Hz
Max sound pressure level 130 dB
Satellite
LF driver 8” M0821
HF driver 1” N110
Coverage 90° x 60°
Subwoofer
LF driver 12” M1261
Amplier
Power 1400 W
Satellite 2x 350 W
Subwoofer 700 W
Amplier type D-class
Input sensitivity -2,2 dBV
Cooling Fan
Connections 2xXLR Male + 2xXLR Female, 2x Speakon
Processing options
Protection RMS, peak, thermal prot.
Controls 2 volume knobs, preset switch
Enclosure (satellite)
Dimensions (WxHxD) 230x420x260 mm
Net weight 10,5 kg
Mounting Pole mount adapter
Enclosure (subwoofer)
Dimensions (WxHxD) 430x480x555 mm
Net weight 30 kg
Enclosure materials 15 mm birch plywood, textured paint
Grill Steel painted grill, acousticaly transparent cloth
Colour Black
Mounting Distance pole socket
Portable speaker set
Complete 12 is small and powerfull speaker set for small installations or
mobile FOH. Full-range speakers are based on 8” cone driver and 1” HF
driver on a exponential horn, and are backed with effective 12” subwoof-
er, housing amplication, crossover and EQ for the entire system.
3
2 Merezhna str., Bila Tserkva, Kiev oblast, 09112, Ukraine v1.1
416 75
255230
430 555
480255
M20

Complete 15 Portable speaker set
Complete 12’s big brother, Complete 15 is packing even more power, still
remaining mobile and affordable. Satellites house 10” cone and 1” HF
drivers. 15” effective subwoofers have built-in amplication, crossover
and EQ for the entire system.
4
2 Merezhna str., Bila Tserkva, Kiev oblast, 09112, Ukraine v1.1
Type Portable speaker set
Acoustical
Frequency range (-10 dB) 40 - 18000 Hz
Max sound pressure level 132 dB
Satellite
LF driver 10” M1020
HF driver 1” N110
Coverage 90° x 60°
Subwoofer
LF driver 15” M1503
Amplier
Power 2100 W
Satellite 2x 350 W
Subwoofer 1400 W
Amplier type D-class
Input sensitivity -2,2 dBV
Cooling Fan
Connections 2x XLR Male + 2x XLR Female, 2x Speakon
Processing options
Protection RMS, peak, thermal prot.
Controls 2 volume knobs, preset switch
Enclosure (satellite)
Dimensions (WxHxD) 255x466x290 mm
Net weight 12 kg
Mounting Pole mount adapter
Enclosure (subwoofer)
Dimensions (WxHxD) 440x485x550 mm
Net weight 37 kg
Enclosure materials 15 mm birch plywood, textured paint
Grill Steel painted grill, acousticaly transparent cloth
Colour Black
Mounting Distance pole socket
271
447
320
121
485
506
545
255
M20

5
Installation options
Installation with tripod
stand
2 Merezhna str., Bila Tserkva, Kiev oblast, 09112, Ukraine v1.1
Double distance
pole stand
Accessories
Installation with double
distance pole stand
80 mm castor
wheels
optionaly available for subwoofers
Transportation
bags
Tri-pod speaker
stand

6
2 Merezhna str., Bila Tserkva, Kiev oblast, 09112, Ukraine v1.1
Integrated processor setups
Complete series speakers come with integrated Class-D amplication and DSP sound processing for ease
of installation and system setup.
Use the Preset switch to choose mode suitable for your application:
Preset 1 : STEREO Satellites are in stereo mode and subwoofer in summed mono mode.
Preset 2: MONO Satellites as well as subwoofers are receiving summed mono signal.
Preset 3: EXT SPEAKER For instances where third party speaker connection is required.
Connect signal cable for subwoofer and satellites to LEFT input and signal cable
for external speaker to RIGHT input. Connect external speaker to RIGHT output
for it to receive unprocessed signal.
Complete series integrated amplier’s con-
nection and controls panel
Connections
Complete 12 & Complete 15’s ampliers are built into subwoofers,
with passive satellite connection.
Use XLR-XLR cables to connect amplier’s input to signal source
(e.g., mixer).
Use IEC standard mains cable to power the amplifer.
Use 1+ 1- Speakon - Speakon cables to connect both satellites
to the subwoofer.
Speakon-Speakon
Complete series
connection diagram
IN L IN R Link L Link R
To the left
satellite
To the right
satellite
Mains
socket
Speakon-Speakon
Preset switch
