Magic-Pro Computer MP-6VIP-D User manual

MP-6VIP-D
Motherboard
User’s Manual
Product Name:MP-6VIP-D
Manual Revision:English, 1.00
Release Date:January, 2000

POST-CONSUMER
RECYCLED PAPER
Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the following two
conditions:
wThis device may not cause harmful interference
wThis device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy. If this equipment is not installed and
used in accordance with the manufacturer's instructions, it may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
wReorient or relocate the receiving antenna.
wIncrease the separation between the equipment and receiver.
wConnect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
wConsult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is required to
assure compliance with FCC regulations. Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the user's authority to operate
this equipment.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for audio noise emissions from
digital apparatusses set out in the Radio Interference Regulations of the Canadian
Department of Communications.
Manufacturer's Disclaimer Statement
The information in this document is subject to change without notice and does not represent a
commitment on the part of the vendor. No warranty or representation, either expressed or implied,
is made with respect to the quality, accuracy or fitness for any particular purpose of this document.
The manufacturer reserves the right to make changes to the content of this document and/or the
products associated with it at any time without obligation to notify any person or organization of such
changes. In no event will the manufacturer be liable for direct, indirect, special, incidental or
consequential damages arising out of the use or inability to use this product or documentation, even
if advised of the possibility of such damages. This document contains materials protected by
copyright. All rights are reserved. No part of this manual may be reproduced or transmitted in any
form, by any means or for any purpose without expressed written consent of it's authors. Product
names appearing in this document are mentioned for identification purposes only. All trademarks,
product names or brand names appearing in this document are registered property of their
respective owners.
Copyright Magic-Pro Computer Co., LTD.
All rights reserved
Author : Raymond
Printed in Taiwan January 2000

MAGIC-PRO MP-6VIP-D
2
CONTENT
Default setting: Intel Celeron 300A/66MHz; Pentium II/III 450/
100MHz 5
SW1 DIP1 ~ DIP4: Bus Ratio Select 7
SW1 DIP5 ~ DIP6: Bus Clock Select 7
Onboard AC97 Audio Codec Controller driver installation
11
STANDARD CMOS SETUP 13
BIOS FEATURES SETUP 15
CHIPSET FEATURES SETUP 19
POWER MANAGEMENT SETUP 22
PnP/PCI CONFIGURATION SETUP 26
LOAD SETUP DEFAULTS 29
CPU SPEED SETTING 30
INTEGRATED PERIPHERALS 32
SUPERVISOR/USER PASSWORD 36
IDE HDD AUTO DETECTION 37
SAVE & EXIT SETUP 37

MAGIC-PRO MP-6VIP-D
3
EXIT WITHOUT SAVING 37
Appendix A
Flash Memory Update Installation 38
Appendix B
Driver installation 39
Appendix C
THE USAGE OF RT2 41

MAGIC-PRO MP-6VIP-D
4
MP-6VIP-D
VIA 82C693A SOCKET-370
2x Ultra ATA33/66 Bus Master IDE ports.
4x USB ports.
1x PS/2 mouse connector an 1x PS/2 keyboar connector.
1x 2.88MB Floppy port, 2x High Spee 16550A UART ports
an 1x IrDA TX / RX Hea er.
ONBOARD I/O
ATX power supply connector.
Power-On by LAN(WOL), RTC Alarm, Mo em Ring.
POWER
2MB FLASH BIOS.
License AWARD BIOS, supports SCSI / ZIP / LS-120 / CD-
ROM boot an ACPI Power Management.
BIOS
1x AGP slot supports 1x / 2x mo e bus; 1x AMR (Au io
Mo em Riser)slot; 5x PCI Bus Master slots; 1x ISA slot.
SLOT
ATX, 4 layers PCB, 18.5cm x 30.5cm size.
FORM FACTOR / PCB
F E A T U R E
Supports Intel PPGA Celeron 370 / FC-PGA Pentium III
(Coppermine) CPUs 300 ~ 550E or higher.
Supports 66/ 75*/ 83*/ 100/ 103*/ 105*/ 124*/ 133/ 140*/ 150*MHz
system bus spee s.
Clock multipliers up to 8x.
PROCESSOR
CHIPSET
VIA 82C693A + 686A (133MHz FSB ).
3x 3.3V DIMM sockets.
8MB to 768MB DRAM size.
ECC or Parity support.
SYSTEM MEMORY
Har ware Monitor.
Supports BIOS Writing Protection.
OTHER FEATURES
Built-In AC97 Au io Co ec.
Supports Line-In, Mic-In, Speaker-Out / Line-Out connector
an MIDI port.
ONBOARD SOUND

MAGIC-PRO MP-6VIP-D
5
Default setting: Intel Celeron 300A/66MHz; Pentium II/III 450/
100MHz
NOTE: For 100MHz/133MHz CPU environment, the SDRAM sepc must comply with
PC-100/PC-133 spec.
MOTHERBOARD DIAGRAM
1 3
1 3
JP6
JP7
1 3
JP9
1 3
JP8
1 3
1 3
1 3
1 4
1 4
JP3
JP4 JP5
1
3
JP11
1 3
JBAT1
1 3 1 3 1 3
JP14 JP13 JP12
SPK RST PWR/LED SUSLED
HD/LED IR PWR SUSPEND
FAN2
FAN1
J2 J3
1 1
LPT1
COM2 COM1
GAME/MIDI PORT
LINE OUT
LINE IN
MIC
JWOL1
SW1
CD_IN2
CD_IN1
AMR
AGP
ISA
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
DIMM1 DIMM2 DIMM3
FDC1 IDE2 IDE1
SOCKET 370
RT2
RT1
ATX POWER
FLASH BIOS
Li
Battery
ON DIP
1 2 3 4 5 6
USB2
2 16 1 15
AC'97
Codec
Clock
Generator
PS/2 MOUSE PS/2 K/B
upper
lower
USB1 USB0
upper
lower
VIA
693A
VIA
686A

MAGIC-PRO MP-6VIP-D
6
CPU Type Configuration
CPU CLOCK SETTI G
OFF OFF OFF
ON ON ON
ON
1 2 3 4 5 6
Celeron 333/66
PentiumIII 500E/100* 5.0x
OFF OFF OFF OFF
ON ON
ON
1 2 3 4 5 6
Celeron 366/66
PentiumIII 550E/100* 5.5x
OFF OFF
ON ON ON ON
ON
1 2 3 4 5 6
Celeron 400/66 6.0x
OFF OFF OFF
ON ON ON
ON
1 2 3 4 5 6
Celeron 433/66 6.5x
OFF OFF OFF
ON ON ON
ON
1 2 3 4 5 6
Celeron 466/66 7.0x
OFF OFF OFF OFF
ON ON
ON
1 2 3 4 5 6
Celeron 500/66 7.5x
OFF OFF OFF
ON ON ON
ON
1 2 3 4 5 6
Celeron 533/66 8.0x
OFF OFF OFF
ON ON ON
ON
1 2 3 4 5 6
Celeron 233/66 3.5x
OFF OFF
ON ON ON ON
ON
1 2 3 4 5 6
Celeron 266/66 4.0x
OFF OFF OFF
ON ON ON
ON
1 2 3 4 5 6
Celeron 300/66 4.5x
CPU MODEL SW1 CPU RATIO
* : Pentium III Coppermin FC-PGA CPUs.

MAGIC-PRO MP-6VIP-D
7
SW1 DIP1 ~ DIP4: Bus Ratio Select
SW1 DIP5 ~ DIP6: Bus Clock Select
3.0x
3.5x
4.0x
4.5x
5.0x
5.5x
14
ON
ON ON ON
OFF
14
ON
ON ON
OFF OFF
14
ON
ON ON ON
OFF
14
ON
ON ON
OFF OFF
14
ON
ON ON
OFF OFF
14
ON
ON
OFF OFF OFF
6.0x
6.5x
7.0x
7.5x
8.0x
14
ON
ON ON ON
OFF
14
ON
ON ON
OFF OFF
14
ON
ON ON
OFF OFF
14
ON
ON
OFF OFF OFF
14
ON
ON ON
OFF OFF
66/100/133MHz
Auto Select
(default)
ON
OFF
ON
1 2 3 4 5 6
ON
OFF
ON
1 2 3 4 5 6
ON
OFF OFF
1 2 3 4 5 6
100MHz
133MHz
SW1 DIP5 ~ DIP6 JP11: FSB Select
1
3
1
3
1
3

MAGIC-PRO MP-6VIP-D
8
JUMPER SETTI G
A. : HDD LED
C. : POWER SWITCH
E. : SPEAKER
G. : POWER LED
I. : SUSPEND LED
B. : INFRARED (IR)
D. : NONE
F. : RESET SWITCH
H. : NONE
1
1
15
15
J2
J3
A.
E. F. G. H. I.
B. C. D.
FA # FU CTIO
FA 1 CPU FA
FA 2 SYSTEM FA
FA #: Onboard FA (12V) Connector.
JP3 / JP4: USB Port Select (1)
USB Port Select JP3 / JP4
Redirect USB port3 to
USB2 connector (default) !
!
JP3
JP4
Redirect USB port3 to
AMR !
!
JP3
JP4
USB Port Select JP6 / JP7
Redirect USB port2 to
USB2 connector (default) !
!
JP6
JP7
Redirect USB port2 to
AGP !
!
JP6
JP7
JP6 / JP7: USB Port Select (2)

MAGIC-PRO MP-6VIP-D
9
JP8: Power Lost Resume
This feature must work with BIOS. Please refer to the BIOS Power On
After PWR-Fail sector.
Power Lost Resume JP8
!

Enabled
!

ormal (default)
JBAT1: Clear CMOS Data
Before you clear the CMOS data, its necessary to turn the power off first
(including +5V standby power . Otherwise, the system may work
abnormally or malfunction.
CMOS Status JBAT1
!

Retain Data (default)
!

Clear CMOS Data
JP12 / JP13 / JP14: Intel / Cyrix CPU Select
CPU Type
Intel CPU (default)
Cyrix JOSHUA CPU
JP14
!

!

JP12
!

!

JP13
!

!

JP5 / JP9: AC97 Codec Control
AC97 Codec JP5 / JP9
Disabled
!

!
JP5 JP9
Enabled (default)
!

!
JP5 JP9

MAGIC-PRO MP-6VIP-D
10
CD_I 1/CD_I 2: CD-ROM Audio Connector
RT2: Thermal Sensor Connector
GAME/MIDI Port:
Connect joystick or MIDI to this connector.
MIC :Microphone Jack
Connect to microphone device.
LI E I : Audio In Jack
Connect audio line in.
LI E OUT/SPEAKER OUT: Audio Out Jack
Connect audio line out or speaker out.
JWOL1: Wake On LA (WOL) Connector
This connector is designed to boot up system via LAN. Connect the wake
on signal form the LAN card to this connector.
Left Channel
PIN 1 Left Channel
CD_IN2PIN # CD_IN1
GND
PIN 2 GND
GND
Right Channel
PIN 3 GND
PIN 4 Right Channel

MAGIC-PRO MP-6VIP-D
11
NOTE 1: IF USER WANTS TO USE EXTERNAL SOUND CARD, USER MUST RUN
BIOS PROGRAM TO DISABLE Onchip Soun  OPTION IN THE Chipset
Feature Setup AND Onboar Legacy Au io OPTION IN THE
Integrate Pheripherals.
NOTE 2: UNDER WINDOWS 95, USER MUST INSTALL DirectX AND USBSUPP.EXE
FOR AGP ENVIRONMEMT.
NOTE 3: VIA Patch Co e, VIA AGP VxD Driver & VIA PCI IRQ Routing
Miniport installation, please refer to Appen ix B.
DRIVERS & SOFTWARES I STALLATIO
Onboard AC97 Audio Codec Controller driver installation
For Win ows95 / Win ows98:
1. Go to CD-ROM irectory, we suggest thats D:\.
2. Fin an run D:\MB\VIA\AUDIO\SETUP.EXE
3. The installation will etect your O.S. to install relative files into your
system.
4. Reboot the computer.

12
MAGIC-PRO MP-6VIP-D
This VIA 82C693A chipset comes with the AWARD BIOS from AWARD Soft-
ware I c. E ter the AWARD BIOS program Mai Me u by:
1. Tur o or reboot the system. After a series of diag ostic checks, the
followi g message will appear:
PRESS <DEL> TO ENTER SETUP
2. Press the <DEL> key a d the mai program scree will appear as follows:
3. Usi g the arrows o your keyboard, select a optio , a d press <E ter>.
Modify the system parameter to reflect the optio s i stalled i your
system.
4. You may retur to the Mai Me u a ytime be pressi g <ESC>.
5. I the Mai Me u, SAVE AND EXIT SETUP saves your cha ges a d
reboots the system, a d EXIT WITHOUT SAVING ig ores your cha ges
a d exits the program.
STANDARD CMOS SETUP
BIOS FEATURES SETUP
CHIPSET FEATURES SETUP
POWER MANAGEMENT SETUP
PNP/PCI CONFIGURATION
LOAD SETUP DEFAULTS
Esc : Quit
F10 : Save & Exit Setup
ROM PCI/ISA BIOS (2A6LGSNC)
CMOS SETUP UTILITY
AWARD SOFTWARE, INC.
: Select Item
(Shift)F2 : Change Color
CPU SPEED SETTING
INTEGRATED PERIPHERALS
SUPERVISOR PASSWORD
USER PASSWORD
IDE HDD AUTO DETECTION
SAVE & EXIT SETUP
EXIT WITHOUT SAVING

13
MAGIC-PRO MP-6VIP-D
Sta dard CMOS Setup allows you to record some basic system hardware co -
figuratio a d set the system clock a d error ha dli g. You o ly eed to modify
the co figuratio values of this optio whe you cha ge your system hardware
co figuratio or the co figuratio stored i the CMOS memory gets lost or
damaged.
Ru the Sta dard CMOS Setup as follows:
1. Choose STANDARD CMOS SETUP from the Mai Me u a d a scree
with a list of optio s will appear.
2. Use o e of the arrow keys to move betwee optio s a d modify the
selected optio s by usi g PgUp/PgD /+/- keys.
S ANDARD CMOS SE UP
ROM PCI/ISA BIOS (2A69KSNH)
STANDARD CMOS SETUP
AWARD SOFTWARE, INC.
Date (mm:dd:yy) : Tue, Oct 19 1999
Time (hh:mm:ss) : 15 : 6 : 26
Drive A : 1.44, 3.5 in.
Drive B : None
Video : EGA/VGA
Halt On : All Errors
HARD DISK TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE
Primary Master : Auto 0M 0 0 0 0 0 AUTO
Primary Slave : Auto 0M 0 0 0 0 0 AUTO
Secondary Master : Auto 0M 0 0 0 0 0 AUTO
Secondary Slave : Auto 0M 0 0 0 0 0 AUTO
Base Memory : 640K
Extended Memory : 64512K
Other Memory : 384K
Total Memory : 65536K
Esc : Quit
F1 : Help
: Select Item
(Shift) F2 : Change Color
PU/PD/+/- : Modify

14
MAGIC-PRO MP-6VIP-D
3. Press <ESC> a d follow the scree i structio s to save or disregard
your setti g.
Set the current date and time.
Date (mm: :yy)
Time (hh:mm:ss)
This field records the specification for all non-SCSI Hard Disk
Drives installed in your system. Refer to the respective docu-
mentation on how to install the drives.
Primary (Secon ary)
Master / Slave
Set the field to the type(s of Floppy Disk drive(s installed in
your system.
The choice:
360KB, 5.25in.
1.2MB, 5.25in.
720KB, 3.5in.
1.44MB, 3.5in.
2.88MB, 3.5in.
Drive A / B
Set the field to the type of video display card installed in your
system.
The choice:
Monochrome,
Color 40x25,
EGA / VGA, (default
Color 80x25
Vi eo
Set this warning feature for the type of errors that will cause
the system to halt.
The choice:
All Errors, (defaults
No Errors,
All But Keyboard,
All But Diskette,
All But Disk / Key
Halt On

15
MAGIC-PRO MP-6VIP-D
BIOS FEA URES SE UP
BIOS Features Setup allows you to improve your system performa ce or set
up system features accordi g to your prefere ce.
Ru the BIOS Features Setup as follows:
1. Choose BIOS FEATURES SETUP from the Mai Me u a d a scree
with a list of optio s will appear.
2. Use o e of the arrow keys to move betwee optio s a d modify the
selected optio s by usi g PgUp/PgD /+/- keys. A expla atio of the
<F>keys follows:
<F1>: Help gives optio s available for each item.
<Shift> + <F2>: Cha ge BIOS scree color.
<F5>: Get the previous values. These values are the values with the
user started i the curre t sessio .
<F6>: Load all optio s with the BIOS default values.
<F7>: Load all optio s with the Setup default values.
Virus Warning : Disabled
CPU Internal Cache : Enabled
External Cache : Enabled
CPU L2 Cache ECC Checking : Enabled
Processor Number Feature : Disabled
Quick Power On Self Test : Enabled
Boot Sequence : A,C,SCSI
Swap Floppy Drive : Disabled
Boot Up Floppy Seek : Disabled
Boot Up NumLock Status : On
IDE HDD Block Mode : Enabled
Gate A20 Option : Fast
Memory Parity/ECC Check : Disabled
Typematic Rate Setting : Disabled
Typematic Rate (Chars/Sec) : 6
Typematic Delay (Msec) : 250
Security Option : Setup
PCI/VGA Palette Snoop : Disabled
OS Select For DRAM > 64MB : Non-OS2
Video BIOS Shadow : Enabled
C8000-CBFFF Shadow : Disabled
CC000-CFFFF Shadow : Disabled
D0000-D3FFF Shadow : Disabled
D4000-D7FFF Shadow : Disabled
D8000-DBFFF Shadow : Disabled
DC000-DFFFF Shadow : Disabled
ROM PCI/ISA BIOS (2A6LGSNC)
BIOS FEATURES SETUP
AWARD SOFTWARE, INC.
ESC : Quit
F1 : Help
F5 : Old Value
F7 : Load Setup Defaults
: Select Item
PU/PD/+/- : Modify
(Shift)F2 : Color

16
MAGIC-PRO MP-6VIP-D
Choose Enabled (default or Disabled. This option allows user
to enable or disable the external cache memory.
External Cache
Default is A , C, SCSI. This option determines which drive
to boot at first for an operating system.
Boot Sequence
Choose Enabled (default or Disabled. This option allows user
to enable or disable the CPU internal cache.
CPU Internal Cache
Default is A, C, SCSI. This option determines which drive
to boot at first for an operating system.
Swap Floppy Drive
Choose Enabled (default or Disabled. This option allows user
to speed up the Power-On-Self-Test routine.
Quick Power On Self
Test
Choose Enabled (default or Disabled.
CPU L2 Cache ECC
Checking
Note: Many diagnostic (or boot manager) programs which
attempt to access the boot sector table can cause
the above warning message. If you will be running
such a program, we recommend that you disable the
virus protection first.
Enabled: Activates automatically when the system boots up
causing a warning message to appear if there is
anything attempting to access the boot sector or
Hard Disk partition table.
Disabled: No warning message will appear when there is
something attempting to access the boot sector or
Hard Disk partition table.
Virus Warning
Choose Enabled or Disabled (default .
Processor Number
Feature

17
MAGIC-PRO MP-6VIP-D
Choose Normal or Fast (default : This option allows the RAM
to access the memory above 1MB by using the fast gate A20
line.
Gate A20 Option
Choose Enabled or Disabled (default : Enable this option to
adjust the deystroke repeat rate.
Typematic Rate Setting
Choose 250 (default , 500, 750 and 1000. This option sets
the time interval for displaying the first and the second
characters.
Typematic Delay (Msec)
Choose System or Setup (default . This option prevents un-
authorized system boot up or use of BIOS Setup.
Security Option
On (default : Activate the NumLock function at boot up.
Off: Close the NumLock function at boot up.
Boot Up NumLock
Status
Range between 6 (default and 30 characters per second.
This option controls the speed of repeating keystrokes.
Typematic Rate
(Char / Sec)
Enabled (default : During POST, BIOS checks the track num-
ber for Floppy Disk drive to see whether its 40 or
80 tracks.
Disabled: During POST, BIOS will not check the track num-
ber for Floppy Disk drive.
Boot Up Floppy Seek
Choose Enabled or Disabled (default .
Memory Parity / ECC
Check
Choose Enabled (default or Disabled. If your hard disk is
larger than 540MB, choose Enabled. If you are using IDE
HDD AUTO DETECTION option, then BIOS will choose this
option automatically.
IDE HDD Block Mo e
Note: Some older model DDs do not provide this feature.

18
MAGIC-PRO MP-6VIP-D
3. Press <ESC> a d follow the scree i structio s to save or disregard
your setti g.
These options are used to shadow other expansion card
ROMs.
C8000-CBFFF to DC000-
DFFFF Sha ow
Enabled (default : Map the VGA BIOS to system RAM.
Disabled: Dont map the VGA BIOS to system RAM.
Vi eo BIOS Sha ow
Non-OS2 (default : For Non-OS/2 operating system.
OS: For OS/2 operating system.
OS Select for DRAM >
64MB
Choose Enabled or Disabled (default . It determines whether
or not the MPEG ISA cards can work with PCI / AGP.
PCI / VGA Palette
Snoop

19
MAGIC-PRO MP-6VIP-D
CHIPSE FEA URES SE UP
Chipset Features Setup cha ges the values of the chipset registers. These
registers co trol the system optio s.
Ru the Chipset Features Setup as follows:
1. Choose CHIPSET FEATURES SETUP from the Mai Me u a d a
scree with a list of optio s will appear.
2. Use o e of the arrow keys to move betwee optio s a d modify the
selected optio s by usi g PgUp/PgD /+/- keys.
Bank 0/1 DRAM Timing : SDRAM 10ns
Bank 2/3 DRAM Timing : SDRAM 10ns
Bank 4/5 DRAM Timing : SDRAM 10ns
SDRAM Cycle Length : 3
DRAM Clock : Host CLK
Memory Hole : Disabled
Read Around Write : Enabled
Concurrent PCI/Host : Disabled
System BIOS Cacheable : Disabled
Video RAM Cacheable : Disabled
AGP Aperture Size : 64M
AGP-2X Mode : Disabled
OnChip USB1 : Enabled
OnChip USB2 : Enabled
USB Keyboard Support : Disabled
OnChip Sound : Enabled
OnChip Modem : Disabled
ROM PCI/ISA BIOS (2A6LGSNC)
CHIPSET FEATURES SETUP
AWARD SOFTWARE, INC.
ESC : Quit
F1 : Help
F5 : Old Value
F7 : Load Setup Defaults
: Select Item
PU/PD/+/- : Modify
(Shift)F2 : Color
