MAGINON QC-50S User manual

Quality products for Life.
QC-50S
RC Quadrocopter Drone
with HD Camera
Instruction Manual

A
B
6
3
2
1
5
4
78
9
10 12
11
16
17
18
13 14
19
20
10
15
24
23
22
21
25
15
Overview
3
Overview

C
D
26 2627
28
29 29
32 32
30
33
34 35
3636
37
7
31
Overview
4

Delivery contents/device parts
5
Delivery contents/device parts
1Maginon Quadrocopter
QC-50S 20 On/Off switch FB with power LED (blue)
2Remote control 21 Emergency stop
33x batteries type LR6 (AA) 22 Fixing device*
4Micro SD card with SD card
adapter 23 One key return
54x spare rotor blades 24 Left control stick pitch/yaw
6USB charging lead 25 Remote control battery
compartment
7Camera with SD card slot 26 Rear rotors
8Li-polymer battery with
600 mAh 27 Rear LED light (red)
9Screwdriver 28 Front LED light (blue)
10 Speed regulator 29 Front rotors
11 Start and Landing button 30 Battery
12 Headless mode 31 Micro USB port
13 Roll trim (left) 32 Rear position LEDs (red)
14 Nick trim (front) 33 On/Off switch Quadrokopter
15 Flip-Taste 34 Camera port
16 Direction control stick 35 Landing gear
17 Roll trim (right) 36 Front position LEDs (red)
18 Video recording* 37 Rotor shield
19 Nick trim (back)
*These buttons only work on quadrocopter models that have a camera.

Contents
6
Contents
Overview ............................................................................3
Delivery contents/device parts.........................................5
Preface................................................................................8
General ...............................................................................9
Read and keep instructions................................................. 9
Explanation of symbols ........................................................ 9
Safety.................................................................................11
Correct use ..............................................................................11
Safety instructions.................................................................11
Start .................................................................................. 18
Packaging contents..............................................................18
Preparing the quadrocopter........................................... 19
Inserting the batteries in the remote control..................19
Charging the quadrocopter................................................21
Mounting the camera.......................................................... 23
Inserting the memory card................................................ 23
Using the quadrocopter...................................................24
Switching on and off ........................................................... 24
Controls.................................................................................. 26
Adjusting the speed ............................................................ 28
Rolls und Flips....................................................................... 29
Emergency stop ....................................................................31
Trimming of the flight attitude...........................................31
One Key Return......................................................................31
Headless mode..................................................................... 32
Taking Photos and Videos .................................................. 32
Battery status display ......................................................... 33
Replacing rotor blades........................................................ 33

Contents
7
Technical Data ..................................................................34
FCC compliance statement...............................................35
Storing ..............................................................................36
Cleaning............................................................................36
Disposal ............................................................................38
Dispose of packaging.......................................................... 38
Disposal of used device....................................................... 38

Preface
8
Preface
Dear customer,
Congratulations on purchasing a high-quality MAGINON®
product.
You have chosen a modern quadrocopter with excellent
technical features and corresponding accessories that are
incredibly easy to operate.
The quadrocopter come with a 3-year warranty. In case of
a defect, you require the enclosed warranty card and proof
of purchase. Keep these in a safe place together with the
Instruction Manual.
Imprint
Issued by:
supra
Foto-Elektronik-Vertriebs-GmbH
Denisstr. 28A
67663 Kaiserslautern
Germany

General
9
General
Read and keep instructions
This manual belongs to this quadrocopter. They
contain important information about the setup and
use.
Read the Operating Instructions, especially the safety
instructions, carefully before using the quadrocopter. Failure
to follow these Operating Instructions may result in loss of
data or damage to the quadrocopter.
These Operating Instructions are based on valid standards
and regulations of the EU. Please also observe country-
specific guidelines and laws abroad!
Keep Operating Instructions for further use. When passing
on the quadrocopter to third parties, please make sure to
include these Operating Instructions.
Explanation of symbols
The following symbols and signal words are used in these
Operating Instructions, on the device, or on the packaging.
DANGER!
This signal symbol/word indicates a high-risk hazard, which if
not avoided, can cause death or serious injury.

General
10
WARNING!
This signal symbol/word indicates a medium-risk hazard,
which if not avoided, can cause death or serious injury.
CAUTION!
This signal symbol/word indicates a low-risk hazard, which if
not avoided, can cause minor or medium levels of injury.
NOTE!
This signal word warns against potential material damage.
This symbol provides useful additional
information about the assembly or
operation.
Declaration of conformity (see chapter
“Declaration Of Conformity”): Products
marked with this symbol comply with all
applicable Community regulations of the
European Economic Area.
Products containing this symbol are
operated with direct current.

Safety
11
Safety
Correct use
This quadrocopter is designed exclusively as a quadrocopter.
It is intended exclusively for private use and not for
commercial use.
Only use quadrocopter as described in the Operating
Instructions. Any other use is deemed to be incorrect and can
cause material damage and loss of data.
The manufacturers or dealers do not accept any liability for
damage resulting from improper or incorrect use.
Safety instructions
WARNING!
Risk of injury!
Risk of eye injuries! Keep a safe distance of 1-2 meters to protect
yourself or others from injury.
−To avoid accidents, never fly the quadrocopter near
people, animals or other obstacles. Keep hands, hair and
loose clothing away from the rotors. Do not reach into the
rotors!
−Check that the quadrocopter is assembled as instructed.
The installation must always be carried out under the
supervision of an adult.

Safety
12
WARNING!
Risk of electrocution!
Faulty electrical installations or excessive mains voltage can
cause electrocution.
−Do not operate the quadrocopter if it is visibly damaged or
the USB charging cable is defective.
−For charging, connect the quadrocopter only to a near
and easily accessible power source so that you can quickly
disconnect it from the power supply in the event of a fault.
−If the USB charging cable of the quadrocopter is damaged,
it must be replaced by the manufacturer or his service
representative or a similarly qualified person.
−The quadrocopter must not be operated with an external
timer or separate remote control system.
−Do not immerse the quadrocopter, remote control, USB
charging cable in water or other liquids. Do not place
objects filled with liquid, e.g. vases, on the quadrocopter
or the remote control.
−The quadrocopter and the remote control should not be
exposed to dripping or splashing water.
−Use an AC adapter (not supplied) only with the input
voltage (5 V ) indicated on the type label. Doing so may
result in fire or electric shock.
−The power supply unit cannot be used during
thunderstorms. Doing so may result in electric shock.

Safety
13
WARNING!
Hazard for children and persons with reduced
physical, sensory or mental abilities (such as
partially disabled, older persons with limited
physical and mental abilities) or lack of experience
and know-how (such as older children).
−These head sets may be used by children 8 years or older
and persons with reduced physical, sensory or mental
abilities or lack of experience or know-how provided they
are supervised or have been instructed on how to safely
use the quadrocopter and understand hazards resulting
therefrom. Cleaning and user maintenance must not be
carried out by children without supervision.
−This remote-controlled model is not a toy! Suitable for
persons 14 years and older. Not suitable for children under
36 months.
−Ensure that children do not push objects into the
quadrocopter.
−Do not allow children to insert objects into the
quadrocopter.
−If you suspect that your child has swallowed a battery seek
immediate medical attention.
WARNING!
Asphyxiation hazard!
Contains small parts that can be swallowed. Keep away from
small children.

Safety
14
WARNING!
Risk of explosion
If the battery is not replaced properly. Replace only by the same
or an equivalent battery type.
−Remove old or empty batteries from the remote control.
Replace all batteries in a set at the same time.
−Clean the battery contacts and the contacts in the remote
control before inserting the batteries.
−When inserting the batteries, observe the correct polarity
(+/-). Failure to observe the polarity may result in personal
injury and/or property damage.
−Never touch leaking batteries without respective
protection. If the battery acid comes into contact with the
skin, wash the area with plenty of soap and water.
−Avoid battery acid coming into contact with eyes. If the
battery acid comes into contact with eyes, rinse your eyes
with plenty of water and contact a doctor immediately.
−Remove the batteries when not using the remote control
for an extended period of time. This is to prevent damage
due to rusted or corroded batteries.
−Never throw batteries into a fire, expose batteries to fire or
other sources of heat.
−Always turn off the quadrocopter and the remote
control if you do not use the quadrocopter, clean it or if a
malfunction occurs. Remove the batteries and disconnect
all connections.
−Never expose the battery of the quadrocopter to extremely
low air pressure. An explosion may occur if flammable
liquid or gas escapes.

Safety
15
−Under no circumstances should you disassemble, destroy,
puncture or short-circuit the battery of the quadrocopter,
there is danger of explosion!
−Disposal of batteries: Old or discharged batteries must be
properly disposed of or recycled in accordance with all
applicable laws. You can obtain detailed information from
your local authority for waste.
−Follow the safety, consumption and disposal instructions
provided by the battery manufacturer.
−Before disposal, batteries and the integrated battery must
first be removed and disposed of separately from the
housing.
NOTE!
Danger of material damage!
Improper handling of the quadrocopter can damage to the
quadrocopter.
−Pay attention to the environment in which you want to
use the quadrocopter. Find a large, open and wide area
without obstacles, pay particular attention to buildings,
crowds, power lines and trees.
−Never use the quadrocopter near airports, railways or
roads. Always keep sufficient distance from hazardous and
specially protected areas.
−Do not operate your quadrocopter near radio stations,
power lines, transformer boxes or the like! These devices
can cause radio interference.
−Only use the quadrocopter outside in good weather.
Do not operate the quadrocopter in rain, storm or
thunderstorms.

Safety
16
−Find a flying area that meets the legal requirements and is
free of obstacles such as trees, houses, etc.
−For safety reasons and in order to achieve satisfactory
flight results, you must ensure a sufficiently large free
space (approx. 6 x 5 x 2.5 m) for indoor use. The room
must be free of obstacles (lamps, loose objects, etc.). In
addition, there should be no airflow.
−Do not fly in an environment above +45 °C and below
10 °C.
−Do not expose the quadrocopter to direct sunlight, high
humidity or dust.
−Do not drop or crash the quadrocopter from great heights.
This can affect the flight characteristics and the lifespan of
the quadrocopter.
−Be aware that some parts on the quadrocopter may
become hot.
−Keep the quadrocopter and accessories away from open
fire and hot surfaces.
−Do not place open fire sources, such as lit candles, on or
near the quadrocopter or the remote control.
−Do not bring the USB charging cable into contact with hot
parts.
−Never immerse the quadrocopter in water or use a steam
cleaner to clean it. Otherwise the quadrocopter may be
damaged.
−Do not use the quadrocopter if the plastic or metal parts
of the unit have splits or cracks or are misshapen. Replace
damaged parts only with fitting original spare parts.
−Damage to the quadrocopter, the camera, the remote
control or the accessories caused by external influences
such as impacts, falls or anything else is not covered by
the warranty and are chargeable.

Safety
17
−Please inform yourself about the current legal situation in
your country regarding the use of the quadrocopter you
have purchased.
NOTE!
Caution!
On some countries it is mandatory to take out a special model
owner liability insurance for the operation of a quadrocopter.
Information on this can be obtained from the model sports
associations or from an insurance company.
A mains adapter is not included.

Start
18
Start
Packaging contents
WARNING!
Asphyxiation hazard!
Keep plastic film and bags away from infants and young
children.
NOTE!
Danger of damage!
If the packaging is opened carelessly with a sharp knife or
other pointed objects, the product can be damaged.
−Please open the packaging carefully
1. Check whether the delivery is complete
(see Fig. A on page 3).
2. Remove the quadrocopter 1from its packaging and
check whether the unit or parts are damaged. If this is the
case, do not use the quadrocopter 1. Contact the service
address of the manufacturer listed on the warranty card.

Preparing the quadrocopter
19
Preparing the quadrocopter
Inserting the batteries in the remote
control
To insert batteries 3into the remote control 2, first open
the remote control 2. The battery compartment is located
on the back of the remote control 25 . Now open the battery
compartment cover by first unscrewing the screw with the
screwdriver 9, then pulling the clamp on the top slightly
inwards and then lifting off the cover.
First remove any existing batteries from the battery
compartment. Insert 3 fully charged batteries 3. When
inserting batteries 3make sure they have the correct
polarity, which is marked for each battery in the battery
compartment 25 .
Close battery compartment 25 again with protective cover.

Preparing the quadrocopter
20
−You can also use rechargeable batteries
of the same specification at 2000 mAh or
higher instead of LR6 (AA) batteries. We
recommend NiMh batteries with low self-
discharge (not supplied).
−Check your batteries regularly. old or empty
batteries must be replaced.
−If you do not intend to use the remote
control for an extended period of time,
remove the batteries to prevent them from
leaking.
NOTE!
Note for adult guardians:
Check that the quadrocopter is assembled as instructed. The
installation must always be carried out under the supervision
of an adult .
