MAGMATIC PRISMA DRIVER 8IP User manual

User Manual
PRISMA DRIVER 8IP

©2021 MAGMATIC EFFECTS all rights reserved. Information, specifications, diagrams, images, and
instructions herein are subject to change without notice. MAGMATIC EFFECTS logo and identifying
product names and numbers herein are trademarks of MAGMATIC EFFECTS. Copyright protection
claimed includes all forms and matters of copyrightable materials and information now allowed by
statutory or judicial law or hereinafter granted. Product names used in this document may be
trademarks or registered trademarks of their respective companies and are hereby acknowledged. All
non-MAGMATIC brands and product names are trademarks or registered trademarks of their respec-
tive companies.
MAGMATIC EFFECTS and all affiliated companies hereby disclaim any and all liabilities for property,
equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic
loss associated with the use or reliance of any information contained within this document, and/or as a
result of the improper, unsafe, insufficient and negligent assembly, installation, rigging, and operation
of this product.
DOCUMENT VERSION
Due to additional product features and/or enhancements, an updated version of
this document may be available online.
Please check www.elationlighting.com for the latest revision/update of this
manual before beginning installation and/or programming.
MAGMATIC EFFECTS | 6122 S. Eastern Ave. | Los Angeles, CA. 90040
323-582-3322 | 323-832-9142 fax | www.elationlighting.com | [e-mail]
Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, The Netherlands
[phone] | [phone] fax | www.elationlighting.eu | [email protected]
Elation Professional Mexico | AC Santa Ana 30 | Parque Industrial Lerma, Lerma, Mexico 52000
[phone]
2
Date Document
Version
Software
Version
DMX Channel Mode Notes
09/27/2021 1.0 1.01 8/9/12 Channels Initial Release
11/03/2021 1.1 N/C No Change Updated Safety Guidelines

CONTENTS
3
General Information 4
Limited Warranty (USA Only) 5
Warranty Returns (USA Only) 6
Safety Guidelines 7
Maintenance Guidelines 9
Overview 10
Installation Instructions 11
System Menu 13
DMX Channel Functions and Values 17
Dimmer Modes 19
Specifications 20
Dimensional Drawings 21

INTRODUCTION
Please read and understand the instructions in this manual carefully and thoroughly before attempting
to operate this device. These instructions contain important safety and use information.
UNPACKING
Every device has been thoroughly tested and has been shipped in perfect operating condition. Care-
fully check the shipping carton for damage that may have occurred during shipping. If the carton is
damaged, carefully inspect the device for damage, and be sure all accessories necessary to install and
operate the device have arrived intact. In the event that damage has been found or parts are missing,
please contact our customer support team for further instructions. Please do not return this device to
your dealer without first contacting customer support. Please do not discard the shipping carton in the
trash. Please recycle whenever possible.
BOX CONTENTS
Twist-locking power cable (x1)
CUSTOMER SUPPORT
Contact MAGMATIC customer service for any product related service and support needs.
Also visit forums.elationlighting.com with questions, comments, or suggestions.
ELATION SERVICE USA - Monday - Friday 8:00am to 4:30pm PST
323-582-3322 | Fax [phone] | [e-mail]
ELATION SERVICE EUROPE - Monday - Friday 08:30 to 17:00 CET
Voice: [phone] | Fax: [phone] | [email protected]
REPLACEMENT PARTS: Please visit parts.elationlighting.com
GENERAL INFORMATION
THERE ARE NO USER SERVICEABLE PARTS INSIDE THIS UNIT. DO NOT ATTEMPT ANY
REPAIRS YOURSELF. DOING SO WILL VOID YOUR MANUFACTURER’S WARRANTY. DAM-
AGES RESULTING FROM MODIFICATIONS TO THIS FIXTURE AND/OR THE DISREGARD OF
SAFETY INSTRUCTIONS AND GUIDELINES IN THIS MANUAL VOID THE MANUFACTURER’S
WARRANTY AND ARE NOT SUBJECT TO ANY WARRANTY CLAIMS AND/OR REPAIRS.
IMPORTANT NOTICE!
4

A. Magmatic Effects hereby warrants, to the original purchaser, Magmatic products to be free of man-
ufacturing defects in material and workmanship for a period of two years (730 days) from the original
date of purchase. This warranty excludes discharge lamps and all product accessories. This warranty
shall be valid only if the product is purchased within the United States of America, including pos-
sessions and territories. It is the owner’s responsibility to establish the date and place of purchase by
acceptable evidence, at the time service is sought.
B. For warranty service, send the product only to the Magmatic Effects factory. All shipping charges
must be pre-paid. If the requested repairs or service (including parts replacement) are within the terms
of this warranty, Magmatic Effects will pay return shipping charges only to a designated point within
the United States. If any product is sent, it must be shipped in its original package and packaging mate-
rial. No accessories should be shipped with the product. If any accessories are shipped with the prod-
uct, Magmatic Effects shall have no liability what so ever for loss and/or or damage to any such acces-
sories, nor for the safe return thereof.
C. This warranty is void if the product serial number and/or labels are altered or removed; if the prod-
uct is modified in any manner which Magmatic Effects concludes, after inspection, affects the reli-
ability of the product; if the product has been repaired or serviced by anyone other than the Magmatic
Effects factory unless prior written authorization was issued to purchaser by Magmatic Effects; if the
product is damaged because not properly maintained as set forth in the product instructions, guide-
lines and/or user manual.
D. This is not a service contract, and this warranty does not include any maintenance, cleaning or peri-
odic check-up. During the periods as specified above, Magmatic Effects will replace defective parts
at its expense, and will absorb all expenses for warranty service and repair labor by reason of defects
in material or workmanship. The sole responsibility of Magmatic Effects under this warranty shall be
limited to the repair of the product, or replacement thereof, including parts, at the sole discretion of
Magmatic Effects. All products covered by this warranty were manufactured after January 1, 1990, and
bear identifying marks to that effect.
E. Magmatic Effects reserves the right to make changes in design and/or performance improvements
upon its products without any obligation to include these changes in any products theretofore manu-
factured.
F. No warranty, whether expressed or implied, is given or made with respect to any accessory supplied
with the products described above. Except to the extent prohibited by applicable law, all implied war-
ranties made by Magmatic Effects in connection with this product, including warranties of merchant-
ability or fitness, are limited in duration to the warranty periods set forth above. And no warranties,
whether expressed or implied, including warranties of merchantability or fitness, shall apply to this
product after said periods have expired. The consumer’s and/or dealer’s sole remedy shall be such
repair or replacement as is expressly provided above; and under no circumstances shall Magmatic
Effects be liable for any loss and/or damage, direct and/or consequential, arising out of the use of,
and/or the inability to use, this product.
G. This warranty is the only written warranty applicable to Magmatic Effects products and supersedes
all prior warranties and written descriptions of warranty terms and conditions heretofore published.
LIMITED WARRANTY (USA ONLY)
5

WARRANTY RETURNS (USA ONLY)
To obtain warranty service, a Return Material Authorization (RMA) number must first be obtained from
MAGMATIC. It is the Customer’s responsibility to provide product proof of purchase and serial num-
ber by acceptable evidence such as an invoice copy or an approved MAGMATIC Extended Warranty
Certificate (“EWC”) and any relevant maintenance records at the time warranty service is sought.
Failure to provide acceptable evidence of product proof of purchase or EWC and any relevant mainte-
nance records may be cause for denial of warranty service.
Products returned for warranty service must be sent without any accessories (i.e., power, data, and
safety cables, brackets, clamps, rigging hardware, frost filters, gel frames, barn doors, lenses, hoses,
nozzles, rack mounting hardware, etc.), must be boxed using the original and/or suitable packag-
ing materials (double-box and foam) that provides ample product protection for ground and/or air
freight transit, and must be shipped freight pre-paid and insured to MAGMATIC in Los Angeles, CA or
a MAGMATIC Authorized Service Center. The RMA number must be clearly written on the outside of
the return box, and a brief description of the problem and the RMA number must be documented and
included in the box.
Products returned for warranty service without an RMA number clearly marked on the outside of the
package will be refused and returned to the shipper at the Customer’s expense. Products returned for
warranty service, which are received damaged due to inadequate and/or improper packaging and/
or due to damage caused by the shipping carrier, may incur additional repair charges before warranty
service begins and/or may void this warranty. If any product accessories (included and/or optional) are
shipped with the product, MAGMATIC and/or the MAGMATIC Authorized Service Center shall have
no liability what so ever for the loss and/or damage to any such accessories, nor the safe return thereof.
If the requested warranty repairs or service (including parts replacement) are within the terms of this
warranty, MAGMATIC will pay return ground transportation shipping charges to a single designated
point within the United States.
6

SAFETY GUIDELINES
This fixture is a sophisticated piece of electronic equipment. To guarantee smooth operation, it is
important to follow all instructions and guidelines in this manual. Magmatic Effects is not responsible
for injury and/or damages resulting from the misuse of this fixture due to the disregard of the informa-
tion printed in this manual. Only qualified and/or certified personnel should perform installation of this
fixture and only the original rigging parts included with this fixture should be used for installation. Any
modifications to the fixture and/or the included mounting hardware will void the original manufac-
turer’s warranty and increase the risk of damage and/or personal injury.
PROTECTION CLASS 1 - MUST BE PROPERLY GROUNDED.
THERE ARE NO USER SERVICEABLE PARTS INSIDE THIS UNIT. DO
NOT ATTEMPT ANY REPAIRS YOURSELF. DOING SO WILL VOID
YOUR MANUFACTURER’S WARRANTY. DAMAGES RESULTING FROM
MODIFICATIONS TO THIS DEVICE AND/OR THE DISREGARD OF
SAFETY INSTRUCTIONS AND GUIDELINES IN THIS MANUAL VOID THE
MANUFACTURER’S WARRANTY AND ARE NOT SUBJECT TO ANY WARRANTY
CLAIMS AND/OR REPAIRS.
DO NOT PLUG THIS UNIT INTO A DIMMER PACK
NEVER OPEN WHILE IN USE!
UNPLUG POWER BEFORE SERVICING!
NEVER TOUCH DURING OPERATION, AS SURFACE OF DEVICE MAY BE HOT!
KEEP FLAMMABLE MATERIALS AWAY FROM DEVICE!
7
FIXTURE IS DUST TIGHT AND PROTECTED AGAINST WATER JETS FROM ANY
DIRECTION.
IP65

• DO NOT TOUCH the driver housing during operation. Turn OFF the power and allow
approximately 15 minutes for the driver to cool down before servicing.
• DO NOT shake driver, and avoid brute force when installing and/or operating.
• DO NOT operate driver if the power cord is frayed, crimped, damaged and/or if any of
the power cord connectors are damaged and do not insert into their sockets securely
and with ease. NEVER force a power cord connector into a socket. If the power cord or
any of its connectors are damaged, replace it immediately with a new one of the same
power rating.
• DO NOT block any air ventilation slots.
• All fan and air inlets must remain clean and free of dust and debris.
• Always disconnect driver from main power source before performing any type of ser-
vice and/or cleaning procedure. Only handle the power cord by the plug end, and
NEVER pull out the plug by tugging the wire portion of the cord.
• Consistent operational breaks will ensure driver will function properly for many years.
• ONLY use the original packaging and materials to transport the driver for service.
SAFETY GUIDELINES
8

MAINTENANCE GUIDELINES
9
DISCONNECT POWER BEFORE PERFORMING ANY
MAINTENANCE!
CLEANING
Frequent cleaning is recommended to ensure proper function and an extended life. The
frequency of cleaning depends on the environment in which the driver operates: damp,
smoky, or particularly dirty environments can cause greater accumulation of dirt on the
driver. Clean the external surface periodically with a soft cloth to avoid dirt/debris accu-
mulation.
NEVER use alcohol, solvents, or ammonia-based cleaners.
MAINTENANCE
Regular inspections are recommended to ensure proper function and extended life.
There are no user serviceable parts inside this driver, please refer all other service issues
to an authorized MAGMATIC service technician. Should you need any spare parts, please
order genuine parts from your local MAGMATIC dealer.
Please refer to the following points during routine inspections:
• A detailed electrical check by an approved electrical engineer every three months, to
make sure the circuit contacts are in good condition in order to prevent overheating.
• Be sure all screws and fasteners are securely tightened at all times. Loose screws may
fall out during normal operation, resulting in damage or injury as larger parts could fall.
• Check for any deformations on the housing, rigging hardware, and rigging points (ceil-
ing, suspension, trussing). Deformations in the housing could allow for dust or liquids
to enter into the driver. Damaged rigging points or unsecured rigging could cause the
driver to fall and seriously injure a person(s).
• Electric power supply cables must not show any damage, material fatigue, or sediments.
NEVER remove the ground prong from the power cable.

OVERVIEW
10

INSTALLATION INSTRUCTIONS
11
FLAMMABLE MATERIAL WARNING
Keep driver a minimum of 5.0 feet (1.5m) away from flammable materials and/or pyrotech-
nics.
ELECTRICAL CONNECTIONS
A qualified electrician should be used for all electrical connections and/or installations.
DO NOT INSTALL THE DRIVER IF YOU ARE NOT QUALIFIED TO DO SO!
Driver MUST be installed following all local, national, and country commercial electrical and construc-
tion codes and regulations.
Before rigging/mounting a single device or multiple interconnected devices for custom matrix designs
to any metal truss/structure or placing the device(s) on any surface, a professional equipment installer
MUST be consulted to determine if the metal truss/structure or surface is properly certified to safely
hold the combined weight of the device(s), clamps, cables, and accessories.
Ambient operating temperature range is from -4°F (-20°C) to 122°F (50°C).
Do not operate this device when ambient temperature falls outside this range.
Device(s) should be installed in areas outside walking paths, seating areas, or away from areas were
unauthorized personnel might reach the device(s) by hand.

INSTALLATION INSTRUCTIONS
MOUNTING
The driver may be secured to a surface or mounting rail by using the four (4) mounting points located
on the integrated mounting brackets on either side of the driver.
CONNECTIONS
This driver features eight (8) 4-pin locking output sockets, each of which can accommodate a connec-
tion to a single Magmatic Prisma Mini series lighting fixture.
This driver is suitable for use with the following Magmatic lighting fixtures:
• Prisma Mini BAR 20
• Prisma Mini PAR 20
• Prisma Mini PAR 45
Each output socket features a waterproof cap, which must be fitted in place over the socket when not
in use in order to maintain the device’s IP65 rating.
12

SYSTEM MENU
13
The fixture includes an easy to navigate system menu. The control panel (see image below) located
on the fixture provides access to the main system menu, where all necessary system adjustments can
be made. During normal operation, pressing MODE button once will access the fixture’s main menu.
Once in the main menu you can navigate through the different functions and access the sub-menus
with the UP and DOWN buttons. Once you reach a field that requires adjusting, press the ENTER
button to activate that field and use the UP and DOWN buttons to adjust the field. Pressing the
ENTER button once more will confirm your setting. You may exit the main menu at any time without
making any adjustments by pressing the MODE button.
The display screen will automatically time out after an extended period of inactivity. To unlock the dis-
play screen, simply press and hold the MODE until the display screen unlocks.

SYSTEM MENU
14
Magmatic Prisma Driver 8IP System Menu
Default settings shown in bold
Supports Software Versions: 1.01
ADDRESS Address XXX 001 - 504
USER MODE
Basic
Standard
Extended
FUNCTION
Status Lost DMX Black
Hold
LCD Set
Display On / Off 30-second screen
time-out
Key Lock On1 / On / Off Lock screen keys
Flash On / Off
Display screen will
flash when DMX
connection is
absent
Invert Off / On Flip screen display
Dim Mode
Standard
Stage
TV
Architec
Theatre
Stage2
0.0s
0.1s
0.2s
0.3s
0.4s
0.5s
0.6s
0.7s
0.8s
0.9s
1.0s
1.5s
CONTINUED ON NEXT PAGE

SYSTEM MENU
15
Magmatic Prisma Driver 8IP System Menu
Default settings shown in bold
Supports Software Versions: 1.01
FUNCTION
(continued)
Dim Mode
(continued)
2.0s
3.0s
4.0s
5.0s
6.0s
7.0s
8.0s
9.0s
10.0s
Disp Set
ADDR
Disp CH
Secondry Secondary mode
Dim Curve
Linear
Square
Inv. Squa
S Curve
Frequen
900 Hz
1000 Hz
1100 Hz
1200 Hz
1300 Hz
1400 Hz
1500 Hz
2500 Hz
4000 Hz
5000 Hz
10 kHz
15 kHz
20 kHz
25 kHz
CONTINUED ON NEXT PAGE

SYSTEM MENU
16
Magmatic Prisma Driver 8IP System Menu
Default settings shown in bold
Supports Software Versions: 1.01
FUNCTION
(continued)
Primary On / Off Set device as Pri-
mary
DFSE On / Off Restory factory
default settings
INFO
TimeInfo
Current Current fixture run
time (hours)
Total Total fixture run
time (hours)
Last Clear fixture run
time
Password “050” or “060”
Clear On / Off
Model Inf PD8IP
Software V1.01
TEST
ManCtrl
Led1 000 - 255
Led2 000 - 255
Led3 000 - 255
Led4 000 - 255
Led5 000 - 255
Led6 000 - 255
Led7 000 - 255
Led8 000 - 255
Dimmer 000 - 255
Strobe 000 - 255
Calibrat Password
Led1 050 - 255
Led2 050 - 255
Led3 050 - 255
Led4 050 - 255
Led5 050 - 255
Led6 050 - 255
Led7 050 - 255
Led8 050 - 255

DMX CHANNEL FUNCTIONS & VALUES
Magmatic Prisma Driver 8IP: DMX Channels / Functions
Supports Software Versions: 1.01
CHANNEL DMX VALUE FUNCTION
8-CH 9-CH 12-CH Ext
1 1 1 000 - 255 LED Signal Output 1
2 2 2 000 - 255 LED Signal Output 2
3 3 3 000 - 255 LED Signal Output 3
4 4 4 000 - 255 LED Signal Output 4
5 5 5 000 - 255 LED Signal Output 5
6 6 6 000 - 255 LED Signal Output 6
7 7 7 000 - 255 LED Signal Output 7
8 8 8 000 - 255 LED Signal Output 8
9 000 - 255 Master Dimmer
10 000 - 255 Dimmer Fine
11
Strobe
000 - 031 Closed
032 - 063 Open
064 - 095 Strobe, slow to fast
096 - 127 Open
128 - 159 Pulse, slow to fast
160 - 191 Open
192 - 223 Random Strobe, slow to fast
224 - 255 Open
9 12
Dim Mode
000 - 020 Standard
021 - 040 Stage
041 - 060 TV
061 - 080 Architectural
081 - 100 Theatre
101 - 120 Stage 2
Dimmer Delay Time
121 0.0 s
122 0.1 s
123 0.2 s
CONTINUED ON NEXT PAGE
17

DMX CHANNEL FUNCTIONS & VALUES
Magmatic Prisma Driver 8IP: DMX Channels / Functions
Supports Software Versions: 1.01
CHANNEL DMX VALUE FUNCTION
8-CH 9-CH 12-CH Ext
9 12
Dimmer Delay Time (continued)
124 0.3 s
125 0.4 s
126 0.5 s
127 0.6 s
128 0.7 s
129 0.8 s
130 0.9 s
131 1.0 s
132 1.5 s
133 2.0 s
134 3.0 s
135 4.0 s
136 5.0 s
137 6.0 s
138 7.0 s
139 8.0 s
140 9.0 s
141 10.0 s
132 - 255 Default (0.1 s)
18

DIMMER MODES
Select desired DIMMER MODE (Standard, Stage, TV, Architectural, Theatre, Stage2).
19

20
SPECIFICATIONS
CONSTRUCTION
Rugged IP65 Housing
Easy Keyhole Slots for Wall/Surface Mounting
CONTROL
Multiple DMX Channel Modes
Onboard 4 Button Touch Control Panel
DMX-512 and RDM Protocol Support
CONNECTIONS
8x 4pin locking output sockets (8 PRISMA MINI fixtures max)
Locking 5pin XLR Connector In/Out
IP65 Locking Power Connector In/Out
With Wired Digital Communication Network
SIZE / WEIGHT
Length: 4.05 in. (102.9mm)
Width: 10.4 in. (264.3mm)
Height: 8.74 in. (221.9mm)
Weight: 8.05 lbs. (3.65 kg)
ELECTRICAL
AC90-240V, 50-60Hz
48VDC 8.3A
167W Max Power Consumption
THERMAL
Maximum Temperature (Ambient): 113° F (45° C)
Minimum Temperature (Ambient): 14° F (-10° C)
APPROVALS / RATINGS
CE | cETLus *Pending | IP65
Specifications and improvements in the design of this unit and this manual are subject to change without any prior
written notice.
