Magnavox MR41806BT User manual

MODEL: MR41806BT
PLEASE READ BEFORE OPERATING THIS EQUIPMENT.
OWNER'S MANUAL
1.8 INCH
DUAL ALARM CLOCK
with Bluetooth® Wireless Technology
Size: 148.5(W) x 210(H)mm (A5)

5
LOCATION OF CONTROLS
1. CLK/MEM/
(Clock set/Memory/BT Play-Pause) Button
2. /HR ( Skip-Search Backward/Hour set) Button
3. /MIN ( Skip-Search Forward/Minute set) Button
4. DIMMER Button
5. ALM 2/VOL- ( Alarm 2 set/Volume down) Button
6. ALM 1/VOL+ ( Alarm 1 set/Volume up) Button
7. ALM OFF/SOURCE/ ( Alarm off/Source selection/Power on-off) Button
8. SNOOZE/SLEEP Button
9. LED Display
10. AUX IN Jack
11. Battery Door
12. AC Power Cord
(1) (2) (3) (4) (5) (6) (7)
(8)
(9)
(10)
(11)
(12)

6
POWER SOURCE
Unwind the AC power cord and extend it to its full length. Insert the AC plug
into any convenient 120V 60Hz household outlet as the illustrated below:
NOTES:
This unit is equipped with a polarized AC plug which has one blade wider than the
other. This is a safety feature to reduce the likelihood of electric shock. This polarized
AC plug will only fit in a polarized AC outlet. If you find that you cannot insert this
plug into your outlet, you may have an obsolete non-polarized outlet. Please do not
try to defeat this safety feature by using a non-polarized adaptor or by filling the
wider blade to make it fit into your outlet. If this plug does not fit into your outlet,
you should contact a qualified licensed electrician to replace your obsolete outlet
If the AC power failure, this electronic clock is designed to continue operating
internally (without showing the time on the Clock Display) with two (2) AAA size
batteries (not included). Install the batteries as follows:
Open the battery door on the rearofthe unit by sliding it out and then lifting it.
Insert two (2) AAA size batteries (not included) according to the polarity
diagram inside the battery compartment. (Alkaline batteries are recommended.)
Replace the battery door.

7
BATTERY PRECAUTIONS:
Follow these precautions when using a battery in this device:
1. Use only the size and type of battery specified.
2. Be sure to follow the correct polarity when installing the battery as indicated in the
battery compartment. A reversed battery may cause damage to the device.
3. Do not mix different types of batteries together (e.g. Alkaline and Carbon-zinc) or old
batteries with fresh ones.
4. If the batteries in the device are consumed or the device is not to be used for a long
period of time, remove the batteries to prevent damage or injury from possible battery
leakage.
5. Do not try to recharge the battery not intended to be recharged; it can overheat and
rupture. (Follow battery manufacturer’s instructions.)
6. Do not dispose of battery in fire. Battery may explodes or leak.
7. Clean the battery contacts and also those of the device prior to battery installation.
OPERATION
ACTUAL TIME SETTINGS:
To set or reset the actual time at first time use:
1. Connect the unit to AC power as previous procedure. The Display will illuminate and
blink.
2. Press the /HR Button to set hour. (Make sure the PM Indicator on the display is
light if the time is PM and not light if the time is AM).
3. Press the /MIN Button to set minute.
4. When finished, press the CLK/MEM/
Button to save the settings and exit. The
display will stop blinking.

8
To set or reset the actual time at normal operation:
1. In standby mode, press and hold the CLK/MEM/
Button until the display start
blinking.
2. Press the /HR Button to set hour. (Make sure the PM Indicator on the display is
light if the time is PM and not light if the time is AM).
3. Press the /MIN Button to set minute.
4. When finished, press the CLK/MEM/
Button to save the settings and exit. The
display will stop blinking.
BT (BLUE TOOTH):
In first time use or re-pairing to a new BT Device, pairing it as
below:
1. In standby mode, press the ALM OFF/SOURCE/ Button to power on the unit.
2. Press the ALM OFF/SOURCE/ Button repeatedly until “bt” appears on the display.
The “BT.” Indicator on the display will illuminate and blink.
3. Power on the external BT Device and enter to BT searching mode. Start pairing as the
on screen instructions on the external BT Device. After paired, the “BT.” Indicator
will stop blinking. (For details pairing procedures, please refer to the user’s manual of
your BT device.).
Notes:
When the external BT Device searched the unit, our model number “MR41806BT”
will appear on the display of external BT Device.
Pairing code “0000” or “1234” may need to enter.

9
Normal operation after paired：
1. Turn on the BT function of the external BT Device.
2. In Standby mode, press the ALM OFF/SOURCE/ Button to power on the unit .
3. Press the ALM OFF/SOURCE/ Button repeatedly until “bt” appears on the display.
The “BT.” Indicator on the display will illuminate and blink.
4. Wait a few seconds until the unit paired to the external BT Device automatically. (The
Indicator stop blinking).
5. Play the music on the connected BT Device as usual.
6. During playback:
Press and release the CLK/MEM/
Button to pause; press again to resume
normal playback.
Press the /HR or /MIN Button repeatedly to skip tracks.
7. To shut off, press and hold the ALM OFF/SOURCE/ Button until “OFF” appear
on the display then release the button.
RADIO:
FM Band:
1.In standby mode, press the ALM OFF/SOURCE/ Button to power on the unit.
2.Press the ALM OFF/SOURCE/ Button repeatedly until the FM Frequency (87.5 –
108) appear on the display.
3.Press and hold the /HR or /MIN Button to auto search the pervious or next
available FM station. Repeat the same procedure until the desired FM Station is
found.
4.If the reception is not good, press the /HR or /MIN Button repeatedly to fine
tune.

10
5.Adjust the volume to the desired level by pressing the ALM 2/VOL – or ALM 1/
VOL + Button.
6.When finished listening, press and hold the ALM OFF/SOURCE/ Button until
“OFF” appears on the display to shut off the radio (standby mode).
AM Band:
1. In standby mode, press the ALM OFF/SOURCE/ Button to power on the unit.
2. Press the ALM OFF/SOURCE/ Button repeatedly until the AM Frequency (520 -
1710) appear on the display.
3. Press and hold the /HR or /MIN Button to auto search the pervious or next
available AM station. Repeated the same procedures until the desired FM Station is
searched and play.
4. If the reception is not good, press the /HR or /MIN Button repeatedly to fine
tune.
5. Adjust the volume to the desired level by press the ALM 2/VOL – or ALM 1/VOL +
Button.
6. When finished listening, press and hold the ALM OFF/SOURCE/ Button until
“OFF” appear on the display to shut off the radio (standby mode).
Radio stations preset:
1. Power on the radio and receive the desired radio station as previously instructed.
2. Press and hold the CLK/MEM/ Button until "P XX" appears on the display and
blink. Press the /HR or /MIN Button repeatedly to select the program number
(P01 – P10) you want it stored to. Press the CLK/MEM/
Button again to store it.
3. Repeat the same procedures until all the desired radio stations were stored into the
program list.
4. After setting, in radio AM or FM band. Press the CLK/MEM/
Button repeatedly
to select and play the desired stored radio station.

11
Notes:
If the backup batteries are not installed when the power goes out presets may be erased.
Preset stations can only be removed by storing another station over it.
A total of 20 radio stations can be stored (10 AM / 10 FM ).
Antenna:
The unit has built-in AM/FM antennas. If reception is not clear, turn or relocate the unit to
improve the radio reception.
AUX IN
Listen to music from an external Audio Player as follows:
1. Connect the external Audio Player with a 3.5mm AUX cable (Cable not included).
2. Insert one end to the AUX IN Jack on the rear of unit.
3. Insert the other end to the Phones Jack; Line Out Jack or AUX Out Jack on the external
Audio Player.
4. Press the ALM OFF/SOURCE/ Button to power on the unit .
5. Press the ALM OFF/SOURCE/ Button repeatedly until “AUX” appear on the
display.
6. Play the music on the external Audio Player as usual.
7. Adjust the volume to the desired level by pressing the ALM 2/VOL – or ALM 1/VOL +
Button.
(Make sure the volume level of the connected external player is set to high.)

12
8. When no longer in use, press and hold the ALM OFF/SOURCE/ Button until
“OFF” appear on the display to shut off the unit (standby mode).
ALARM:
Alarm 1 setting:
1. Make sure the unit is in standby mode before setting.
2. Press and hold the ALM 1/VOL + Button until alarm 1 time appears on the display and
blinks. (One of AL 1 Indicator will light).
3. Press the /HR Button to set hour. (Make sure the PM Indicator on the display is
lit if the alarm 1 time is PM and not lit if the alarm 1 time is AM).
4. Press the /MIN Button to set minute.
5. Press the ALM 1/VOL + Button again to save the settings and exit. The display will
stop blinking.
6. Press the ALM 1/VOL + Button repeatedly to set or reset the weak up mode to Buzz
(ALARM 1 Indicator will light) or Radio (RADIO Indicator under ALARM 1 Indicator
will light) or turn it off (Both indicators will not light).
Alarm 2 setting:
Same as the settings of Alarm 1. But, press the ALM 2/VOL - Button instead of ALM
1/VOL +Button.
Important:
If radio was selected as weak up mode, received the desired radio station as previous
procedure before activate alarm. Otherwise, when alarm goes off, no sound output from the
speaker or sound weak.

13
Shut off alarm:
When alarm goes off, press the ALM OFF/SOURCE/ Button to turn off alarm, the
alarm will be reset for next day. (The correspondence alarm indicator will keep
illuminate).
To turn off the alarm completely (not reset for next day). Press the ALM 1/VOL +
and/or ALM 2/VOL - Button repeatedly until all the alarm indicators not light.
SNOOZE:
The alarm can be temporarily turned off manually by pressing the SNOOZE/SLEEP Button.
After pressing the button the alarm will stop sounding, the correspondence alarm indicator
will blink and the alarm will turn back on automatically nine (9) minutes later. This feature
can be repeated until the ALM OFF/SOURCE/ Button was pressed (The correspondence
alarm indicator will stop blinking and the alarm will reset for next day).
SLEEP TIMER:
In BT (Blue Tooth), Radio or Aux (in) mode, press the SNOOZE/SLEEP Button to activate
the sleep function, sleeptimer will appear on the display. Press the SNOOZE/SLEEP Button
repeatedly to set the sleep timer to 10 – 90 minutes as desire. To turn off the sleep timer
before the time is up, press theSNOOZE/SLEEP Button repeatedly until “OFF” appear on the
display.
DIMMER:
Press the DIMMER Button repeatedly to set the brightness level of the display as desired.

14
TROUBLE SHOOTING GUIDE
Symptom Possible Cause Solution
Power
No power
Plug from AC Power Cord had
not inserted to AC wall outlet.
Insert the plug to wall outlet having
AC 120V~, 60 Hz.
Radio
Noise or sound
distorted on radio
broadcasts
Station not tuned properly. Retune the radio station.
The location not good for radio
reception.
Turn or relocation the unit.
Volume at minimum.
Increase Volume level by press the
ALM 1/VOL + Button.
BT
BT not functioning
The BT Device had not paired to
the unit.
Paired the BT Device to the unit as
page 8-9
Sound weak or
distortion
The BT Device too far from the
unit.
Place the BT Device close to the
unit.

15
GENERAL SPECIFICATIONS
Power Source: AC 120V~, 60 Hz, 5W
Clock back up: DC 3V, 2 x AAA size batteries; Not included
Audio Power: 1 Watts
Impendence of Speakers: 8 Ohm; 2W
Radio Band Coverage: AM 520 - 1710 kHz
FM 87.5 - 108 MHz
BT Version: 2.0
BT Effective Range: 32 feet in open area
ACCESSORY
1 x User’s Manual
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT
NOTICE
