SERVICE MANUAL
DVD PLAYER
MSD115
SUPPLEMENT
This service manual shows only the differences between
the model MSD115 and the original model MSD125.
All other information is described in the service manual
of the model MSD125.
TABLE OF CONTENTS
Block Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1-1
Schematic Diagrams / CBA’s and Test Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2-1
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3-1
Lead Identifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4-1
Different parts from the original model (MSD125) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5-1

1-1-1
BLOCK DIAGRAMS
System Control / Servo Block Diagram
E6151BLS
IC301
(SERVO DRIVE)
CN301
M
SLED MOTOR
M
SPINDLE MOTOR
IC101
(MICRO CONTROLLER)
+
-
+
-
+
-
+
-
+
-
+
-
+
-
SLED MOTOR DRIVE
FOCUS ACTUATOR DRIVE
SPINDLE MOTOR DRIVE
TRACKING ACTUATOR DRIVE
147
TRAY-IN SLD75
SPDL
76
TRACKING DRIVE
148
FOCUS DRIVE
66
FS(+) FS(-) TS(+) TS(-)
57
ADAC-MD
56 ADAC-MC 86 ADAC-ML
ADAC-MC
ADAC-ML
PCM-SCLK
88
AUDIO-MUTE
ADAC-MD AUDIO-MUTE
PCM-SCLK
TRAY-IN
3SP(+) 4SP(-) 5TRAY-IN 6GND 7SL(-) 8SL(+)
VREF
RESET73
RESET
IC462
1 3
+3.3V
IC202 (OP AMP)
15 16 14 13 12 11 17 18 23
6 4 5 3 1 2
25
24
27
26
81 SL-AMP
143
SP-ROT
+3.3V
146
FD-OFST
139
TD-OFST
RESET
IC461
2 1
+3.3V
TO DIGITAL SIGNAL PROCESS BLOCK DIAGRAM
TO VIDEO/ AUDIO BLOCK DIAGRAM
DRIVE CBA DVD MAIN CBA UNIT
1
2
67
5 3
13 14
12
CN1001
REMOTE
SENSOR
RM2001
AV CBA
59POWER 60OPEN/CLOSE 82
STOP
67
REMOTE
61
PLAY
CN401
OPEN/CLOSE
SW2002
POWER
SW2003
STOP
SW2004
PLAY
SW2001
23 REMOTE 22 22 PLAY 21 21 STOP 20 20
OPEN/CLOSE
19
19 POWER 18
140
SL-ADS
*1
183
I/P-SW
I/P-SW
163
1 NOTE: Either IC461 or IC462 is used for DVD MAIN CBA UNIT.

1-1-2
Digital Signal Process Block Diagram
E6151BLD
C16 D18
A17 B15 E14
F12
DVD-LD 8
CD-LD 10
PD-MONI 7
FS(+) 2
FS(-) 3
TS(+) 1
TS(-) 4
CN201 CN201 CN201
IC201 (SW)
IC101 (MICRO CONTROLLER)
FS
FS(+)
CD/DVD
FS(-)
TS(+)
TS(-)
TS
DETECTOR
CD/DVD 19
Q251,Q252
CD DVD
AMP
Q253,Q254
AMP
4
1 3
6
GND(DVD-PD)
6
GND(CD-PD)
5
GND(LD)
9
RF SIGNAL PROCESS CIRCUIT
DVD/CD FORMATTER
AUDIO I/F VIDEO I/F
NTSC/PAL ENCODER
DMA BCU
INST. ROM 32BIT
CPU
DATA RAM
INTERRUPT CONTROLLER
WATCH DOG TIMER
CPU I/F
TIMER
DECODER I/F
CPU I/F
READ MEMORY
DATA RAM
DSP DECODER
I/O PROCESSOR
INST. ROM DATA RAM INST. ROM
SERIAL
GENERAL I/O INTERRUPT CONTROLLER
TIMER WATCH DOG TIMER REMOTE CONTROL
32BIT CPU
STREAM I/F
EXTERNAL MEMORY I/F
SDRAM
ECC
UMAC
114 115 116 117 132 131 134 133 129 130
126 124 125 123
83
DEBUG
BCU
INST RAM
DATA RAM
177
SPDIF
170
PCM-BCK
171
PCM-DATA
169
PCM-LRCLK
23~51
SDRAM ADDRESS(0-10)
IC103 (FLASH ROM)
FLASH ROM
29 36 38 45
~
~
DATA(VIDEO/AUDIO) SIGNAL VIDEO SIGNAL DATA(AUDIO) SIGNAL
FDQ (0-15)
~
1 9
16 25 48
~
192~212
FADR (0-19)
SDRAM DATA(0-15)
PICK-UP UNIT
TO SYSTEM CONTROL/SERVO BLOCK DIAGRAM
DVD MAIN CBA UNIT
TO VIDEO /AUDIO BLOCK DIAGRAM
IC501, IC502 (SDRAM)
SDRAM DATA(0-15)
SDRAM ADDRESS(0-10)
217 238
~
1
18
252 256
~~
2
12 39 49
~
~
20 24 27 32
~~
D/A D/A
149
158
Y(I/P)
C
VIDEO-Y(I/P)
VIDEO-C
TO VIDEO /AUDIO BLOCK DIAGRAM

1-1-3
Video / Audio Block Diagram
E6151BLV
IC601 (AUDIO DAC)
15 14 16
JK1202
JK1201
AMP
IC1201
Q1201
Q1202
+5V
(AMP)
CN601 CN1601
13 12AUDIO(L) 15 14
AUDIO(R)
14 13AUDIO(R)-MUTE
AUDIO(L)- OUT
7 6 8 4
3
2
5
AUDIO
SERIAL
PORT
SERIAL
CONTROL
PORT
4X/8X
OVERSAMPLING
DIGITAL FILTER
/FUNCTION
CONTROLLER
ENHANCED
MULTI-LEVEL
DELTA-SIGMA
MODULATOR
DAC LPF+AMP L-CH
R-CH
LPF+AMP
DAC
ZERO DETECT
1
2 67 5AUDIO(R)-
OUT
PCM-BCK SPDIF PCM-DATA PCM-LRCLK ADAC-MD ADAC-MC ADAC-ML PCM-SCLK
18 17
SPDIF
AUDIO-MUTE +3.3V
Q1204
3
WF6
WF4
WF5
AUDIO SIGNALDATA(AUDIO) SIGNAL
VIDEO SIGNAL
TO SYSTEM CONTROL /SERVO BLOCK DIAGRAM TO DIGITAL SIGNAL PROCESS BLOCK DIAGRAM
DVD MAIN CBA UNIT AV CBA
DIGITAL AUDIO OUT (COAXIAL)
SYSTEM
CLOCK
MANAGER
21
I/P-SW
I/P-SW
CN601
87VIDEO-Y(I/P)
10 9VIDEO-C
VIDEO-Y(I/P) VIDEO-C
JK1401 S-VIDEO OUT
CN1601
3 4
2
1
YC
TO DIGITAL SIGNAL PROCESS BLOCK DIAGRAM
WF1
WF2
WF3
JK1402
IC1403 (VIDEO DRIVER)
4dB AMP
2dB AMP
LPF DRIVER
2dB AMP DRIVER
4dB AMP
2dB AMP
LPF DRIVER
3 1
5 6 7
VIDEO OUT (COMPOSITE)
+5V
D2010 POWER
Q2011
D2011 DISC IN

1-1-4 E6151BLP
Power Supply Block Diagram
3
IC1006
(SHUNT REGULATOR) REG
AC1001 AC CORD F1001
1A 250V
LINE
FILTER
L1001
D1001, D1002 D1004, D1005
Q1003 Q1031
2 4 7
3 4
IC1001
ERROR VOLTAGE DET
T1001
11 12 13 15 14 16 17 18
SWITCHING
SWITCHING
CONTROL
1 2
6
BRIDGE
RECTIFIER
HOT
A V
F
HOT CIRCUIT. BE CAREFUL.
D1030
RECTIFIER
Q1016
Q1011
Q1002 CN1001
Q1004
EV+5V P-ON+9V EV+3.3V P-ON+5V
1,2
EV+1.2V
3,4,5
EV+3.3V
8,9
EV+10V
7
P-ON+5V
6
P-ON+3.3V
17
PWRCON
+1.2V
REG.
IC1002
D1006
SCHOTTKY BARRIER SCHOTTKY BARRIER
D1008
AV CBA
TO CN401
3
1
2
3
1
2
COLD
CAUTION ! Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. If Main Fuse (F1001) is blown , check to see that all components in the power supply circuit are not defective before you connect the AC plug to the AC power supply. Otherwise it may cause some components in the power supply circuit to fail.
NOTE: The voltage for parts in hot circuit is measured using hot GND as a common terminal.
"Ce symbole reprèsente un fusible à fusion rapide."
CAUTION ! For continued protection against fire hazard, replace only with the same type fuse. ATTENTION : Pour une protection continue les risqes d'Incele n'utiliser que des fusible de même type. Risk of fire-replace fuse as marked.
"This symbol means fast operating fuse."
A V
F

1-2-1 E6N_SC
SCHEMATIC DIAGRAMS / CBA’S AND TEST POINTS
Standard Notes
WARNING
Many electrical and mechanical parts in this chassis
have special characteristics. These characteristics
often pass unnoticed and the protection afforded by
them cannot necessarily be obtained by using
replacement components rated for higher voltage,
wattage, etc. Replacement parts that have these
special safety characteristics are identified in this
manual and its supplements; electrical components
having such features are identified by the mark “#” in
the schematic diagram and the parts list. Before
replacing any of these components, read the parts list
in this manual carefully. The use of substitute
replacement parts that do not have the same safety
characteristics as specified in the parts list may create
shock, fire, or other hazards.
Notes:
1. Do not use the part number shown on these
drawings for ordering. The correct part number is
shown in the parts list, and may be slightly
different or amended since these drawings were
prepared.
2. All resistance values are indicated in ohms
(K = 103, M = 106).
3. Resistor wattages are 1/4W or 1/6W unless
otherwise specified.
4. All capacitance values are indicated in µF
(P = 10-6 µF).
5. All voltages are DC voltages unless otherwise
specified.

1-2-2 E6N_SC
LIST OF CAUTION, NOTES, AND SYMBOLS USED IN THE SCHEMATIC DIAGRAMS ON
THE FOLLOWING PAGES:
1. CAUTION:
FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE
SAME TYPE FUSE.
ATTENTION: POUR UNE PROTECTION CONTINUE LES RISQES D'INCELE N'UTILISER
QUE DES FUSIBLE DE MÊME TYPE.
RISK OF FIRE-REPLACE FUSE AS MARKED.
2. CAUTION:
Fixed Voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F1001) is blown, first check to see that all components in the power supply circuit are not
defective before you connect the AC plug to the AC power supply. Otherwise it may cause some components
in the power supply circuit to fail.
3. Note:
1. Do not use the part number shown on the drawings for ordering. The correct part number is shown in the
parts list, and may be slightly different or amended since the drawings were prepared.
2. To maintain original function and reliability of repaired units, use only original replacement parts which are
listed with their part numbers in the parts list section of the service manual.
4. Voltage indications for PLAY and STOP mode on the schematics are as shown below:
5. How to read converged lines
6. Test Point Information
A V
F
This symbol means fast operating fuse.
Ce symbole represente un fusible a fusion rapide.
23
15.0
(2.5)
5.0
The same voltage for
both PLAY & STOP modes
Indicates that the voltage
is not consistent here.
PLAY mode
STOP mode
(Unit: Volt)
3
2
1
ABCD
1-B1
1-D3
AREA D3
AREA B1
1-D3
Distinction Area
Line Number
(1 to 3 digits)
Examples:
1. "1-D3" means that line number "1" goes to the line number
"1" of the area "D3".
2. "1-B1" means that line number "1" goes to the line number
"1" of the area "B1".
: Indicates a test point with a jumper wire across a hole in the PCB.
: Used to indicate a test point with a component lead on foil side.
: Used to indicate a test point with no test pin.
: Used to indicate a test point with a test pin.

1-2-3
DVD Main 1/3 Schematic Diagram
E6151SCD1
DVD MAIN 1/3
Ref No. Position
IC201 C-1
IC202 D-4
IC301 D-3
IC461 F-1
IC462 E-1
Q251 C-2
Q252 B-2
Q253 C-2
Q254 B-2
CN201 A-3
CN301 A-1
CN401 F-3
CONNECTORS
ICS
TRANSISTORS
1 NOTE:
Either IC461 or IC462 is used for DVD MAIN CBA UNIT.

1-2-4
DVD Main 2/3 Schematic Diagram
E6151SCD2

1-2-5
IC101 Voltage Chart
PIN.NO PLAY STOP PIN.NO PLAY STOP PIN.NO PLAY STOP PIN.NO PLAY STOP
1 ~ ~ 33 ~ ~ 65 ----- ----- 97 ----- -----
2 ~ ~ 343.43.4663.43.5983.43.4
3 0 0 35 0 0 673.23.2990.90.8
4 ~ ~ 36 ~ ~ 68 ----- ----- 100 0 0
5 ~ ~ 37 ~ ~ 69 3.4 3.4 101 2.4 2.4
6 3.4 3.4 38 0.4 0.3 70 3.4 3.4 102 2.2 2.2
7 ~ ~ 39 ~ ~ 71 ----- ----- 103 1.9 1.9
8 ~ ~ 40 ~ ~ 72 1.4 2.7 104 0.4 0.3
9 0 0 41 ~ ~ 73 3.5 3.5 105 0 0
10 ~ ~ 42 ~ ~ 74 0 0 106 1.7 1.7
11 ~ ~ 43 ~ ~ 75 1.7 1.8 107 3.4 3.4
12 3.4 3.4 44 1.3 1.3 76 2.3 1.8 108 ----- -----
13 ~ ~ 45 ~ ~ 77 ----- ----- 109 ----- -----
14 ~ ~ 46 ~ ~ 78 ----- ----- 110 1.9 1.9
15 ~ ~ 47 ~ ~ 79 ----- ----- 111 1.9 1.9
16 0 0 48 3.4 3.4 80 3.4 0 112 1.7 1.7
17 ~ ~ 49 0 0 81 0.1 0.1 113 1.7 1.7
18 ~ ~ 50 ~ ~ 82 2.8 2.8 114 1.7 1.7
19 3.4 3.4 51 ~ ~ 83 0.1 0.1 115 1.7 1.7
20 0 0 52 0.8 0.8 84 3.4 3.4 116 1.7 1.7
21 ----- ----- 53 ----- ----- 85 0.1 0.1 117 1.7 1.7
22 3.4 3.4 54 ----- ----- 86 3.6 3.4 118 3.4 3.4
23 ~ ~ 55 ----- ----- 87 0 0 119 2.0 2.0
24 ~ ~ 56 3.4 3.4 88 3.5 0.1 120 1.7 1.7
25 ~ ~ 57 3.5 3.5 89 1.3 1.3 121 1.5 1.5
26 1.3 1.3 58 3.4 3.4 90 ----- ----- 122 0 0
27 ~ ~ 59 3.4 3.4 91 ----- ----- 123 0.3 0.1
28 3.4 3.4 60 3.4 3.4 92 ----- ----- 124 1.1 0.1
29 0 0 61 3.5 3.5 93 0 0 125 0.3 0.1
30 ~ ~ 62 3.4 3.4 94 ----- ----- 126 0.1 0.1
31 ~ ~ 63 0 0 95 ----- ----- 127 2.3 2.3
32 ~ ~ 64 0 0 96 ----- ----- 128 1.7 1.7
PIN.NO PLAY STOP PIN.NO PLAY STOP PIN.NO PLAY STOP PIN.NO PLAY STOP
129 2.3 2.3 161 3.4 3.4 193 ~ ~ 225 3.4 3.4
130 2.3 2.3 162 0 0 194 ~ ~ 226 ~ ~
131 2.3 2.3 163 1.8 1.8 195 ~ ~ 227 ~ ~
132 2.4 2.3 164 0 0 196 3.4 3.4 228 ~ ~
133 2.4 2.4 165 1.7 1.8 197 ~ ~ 229 0 0
134 2.4 2.4 166 1.7 1.7 198 ~ ~ 230 ~ ~
135 2.3 2.3 167 3.4 3.4 199 ~ ~ 231 3.4 3.4
136 2.3 2.3 168 0 0 200 ~ ~ 232 1.3 1.6
137 2.3 2.3 169 1.8 1.8 201 0 0 233 ~ ~
138 2.3 2.3 170 1.7 1.7 202 3.4 3.4 234 1.9 2.3
139 1.7 1.7 171 1.3 0.1 203 ~ ~ 235 0 0
140 1.7 1.7 172 1.3 1.3 204 ~ ~ 236 1.3 1.3
141 3.4 3.4 173 0 0 205 0 0 237 ----- -----
142 1.3 1.3 174 ----- ----- 206 ~ ~ 238 ~ ~
143 2.1 1.7 175 ----- ----- 207 ~ ~ 239 3.4 3.4
144 2.2 2.2 176 ----- ----- 208 ~ ~ 240 3.4 3.3
145 0 0 177 1.8 1.7 209 3.4 3.4 241 1.9 1.9
146 1.7 1.7 178 3.4 3.5 210 ~ ~ 242 0 0
147 1.8 1.7 179 0 0 211 ~ ~ 243 1.9 1.9
148 1.7 1.7 180 ----- ----- 212 ~ ~ 244 3.4 3.3
149 0.6 0.5 181 ----- ----- 213 0 0 245 3.4 3.4
150 3.4 3.4 182 ----- ----- 214 ~ ~ 246 3.4 3.4
151 ----- ----- 183 3.4 3.4 215 ~ ~ 247 0 0
152 ----- ----- 184 ----- ----- 216 3.4 3.4 248 3.3 3.4
153 1.4 1.3 185 ----- ----- 217 ~ ~ 249 3.2 3.0
154 1.4 1.3 186 ----- ----- 218 0 0 250 0 0
155 2.4 2.4 187 ----- ----- 219 1.3 1.3 251 3.2 3.0
156 ----- ----- 188 ----- ----- 220 ~ ~ 252 ~ ~
157 0 0 189 ----- ----- 221 ~ ~ 253 0 0
158 0.9 0.9 190 3.4 3.5 222 0 0 254 ~ ~
159 3.4 3.4 191 0 0 223 ~ ~ 255 3.4 3.4
160 0 0 192 ~ ~ 224 ~ ~ 256 ~ ~
~ : Voltage is not consistent ----- : Not used Unit : Volts

1-2-6
DVD Main 3/3 Schematic Diagram
E6151SCD3
DVD MAIN 3/3
Ref No. Position
IC103 N-3
IC501 O-4
IC502 Q-4
IC601 O-1
CN601 R-2
ICS
CONNECTOR

1-2-7
AV 1/2 Schematic Diagram
E6151SCAV1
AV 1/2
Ref No. Position
IC1001 B-2
IC1002 D-4
IC1006 C-2
Q1002 D-3
Q1003 B-2
Q1004 D-3
Q1011 D-2
Q1016 E-2
Q1031 B-3
Q2011 D-1
CN1001 F-4
ICS
TRANSISTORS
CONNECTOR
CAUTION !
Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F1001) is blown , check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
"Ce symbole reprèsente un fusible à fusion rapide."
CAUTION !
For continued protection against fire hazard,
replace only with the same type fuse.
ATTENTION : Pour une protection continue les risqes
d'Incele n'utiliser que des fusible de même type.
Risk of fire-replace fuse as marked.
"This symbol means fast operating fuse."
A V
F

1-2-8
AV 2/2 Schematic Diagram
E6151SCAV2
AV 2/2
Ref No. Position
IC1201 H-1
IC1403 I-4
Q1201 J-1
Q1202 J-1
Q1204 I-1
Q1351 K-4
Q1352 H-2
CN1601 G-3
ICS
TRANSISTORS
CONNECTOR

1-2-9 BE6160F01014
AV CBA Top View
CAUTION !
Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F1001) is blown , check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
"Ce symbole reprèsente un fusible à fusion rapide."
CAUTION !
For continued protection against fire hazard,
replace only with the same type fuse.
ATTENTION : Pour une protection continue les risqes
d'Incele n'utiliser que des fusible de même type.
Risk of fire-replace fuse as marked.
"This symbol means fast operating fuse."
A V
F

1-2-10
WF2
PIN 9 OF
CN1601
WF1
PIN 7 OF
CN1601
WF3
C1402
PLUS LEAD
WF4
PIN 12 OF
CN1601
WF5
PIN 14 OF
CN1601
WF6
PIN 17 OF
CN1601
CAUTION !
Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F1001) is blown , check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
"Ce symbole reprèsente un fusible à fusion rapide."
CAUTION !
For continued protection against fire hazard,
replace only with the same type fuse.
ATTENTION : Pour une protection continue les risqes
d'Incele n'utiliser que des fusible de même type.
Risk of fire-replace fuse as marked.
"This symbol means fast operating fuse."
A V
F
AV CBA Bottom View
BE6160F01014
AV CBA
Ref No. Position
IC1001 D-3
IC1002 C-2
IC1006 D-3
IC1201 D-1
IC1403 D-2
Q1002 B-1
Q1003 D-3
Q1004 B-1
Q1011 C-1
Q1016 C-1
Q1031 E-3
Q1201 E-1
Q1202 E-1
Q1204 D-1
Q1351 E-1
Q1352 C-1
Q2011 A-1
CN1001 B-1
CN1601 D-1
ICS
TRANSISTORS
CONNECTORS

WIRING DIAGRAM
E6151WI
1-3-1
CN201CN301
TRAY-IN
EV+1.2V 21
EV+1.2V 32
EV+3.3V 54
EV+3.3V 65
P-ON+3.3V 76
P-ON+5V 87
EV+10V 98
EV+10V 109
GND 1110
GND 1211
GND 1312
GND 1413
GND 1514
GND 1615
GND 1716
PWRCON 1817
POWER 1918
OPEN/CLOSE 2019
STOP 2120
PLAY 2221
REMOTE 2322
CN401
CN1001
AC CORD
EV+3.3V 43
FS TS
DETECTOR
7 9 11 2 3 6 5
M
SLED MOTOR
M
SPINDLE MOTOR
4
AV CBA
DVD MAIN CBA UNIT
(CN1001 is soldered directly to the PCB.)
DRIVE CBA PICK UP UNIT SP(+) 3
SP(-) 4
TRAY-IN 5
GND 6
SL(-) 7
SL(+) 8
FS(-) 3
TS(-) 4
GND(CD-PD) 5
GND(DVD-PD) 6
PD-MONI 7
DVD-LD 8
TS(+) 1
FS(+) 2
GND 11
F 12
VREF 13
E 14
B 15
C 16
GND(LD) 9
CD-LD 10
A 17
D 18
CD/DVD 19
P-ON+5V 20
VIDEO-C 109
GND 98
VIDEO-Y(I/P) 87
CN601
CN1601
AUDIO(R) 1514
AUDIO-GND 1110
AUDIO-GND 1211
AUDIO(L) 1312
AUDIO(R)-MUTE 1413
(CN1601 is soldered directly to the PCB.)
AUDIO+5V 1615
AUDIO+5V 1716
SPDIF 1817
GND 76
NU 65
GND 54
NU 43
NU 32
I/P-SW 21
AUDIO(L)- OUT
AUDIO(R)- OUT
VIDEO OUT (COMPOSITE)
DIGITAL AUDIO OUT (COAXIAL)
S-VIDEO OUT
DVD MECHANISM

1-4-1 E6151LE
LEAD IDENTIFICATIONS
123
E C B E C B
GDS
85
4
1
85
4
1
MM1636XWRE
1: R
2: A
3: K
123
1
2
4
3
1: A
2: K
3: E
4: C
1: GND
2: Vout
3: Vin
Note:
A: Anode
K: Cathode
E: Emitter
C: Collector
B: Base
R: Reference
G: Gate
D: Drain
S: Source
KIA4558P
KTA1266-Y-AT/P
KTC3203-Y-AT/P
KTA1267Y-AT/P
KTC3199-GR-AT/P
KTC3199(Y)
LTV-817B-F
KIA431-AT
2SK3498(T6L1FUNANQ)+C177
LD1117SC-R

1-5-1 E6151PL
Different parts from the original model (MSD125)
Ref. No. Description Part No.
MECHANICAL PARTS
A1X FRONT ASSEMBLY E6151UD 1VM321787
A15 CHASSIS ASSY E6163UD 1VM321747
A21#MODEL NO LABEL E6151UD ----------
S1 GIFT BOX CARTON E6151UD 1VM321788
X10#OWNERS MANUAL E6151UD 1VMN21627
ELECTRICAL PARTS
DVD MAIN CBA UNIT N79F7JUP
AV CBA 1VSA12740
C1003 ELECTROLYTIC CAPACITOR ZT250TA2R2M6BB CA2E2R2DYG02
C1050 CAP ALUMINUM ELECTOLYTIC 220µF/6.3V M CE0KMASDL221
C1403 CHIP CERAMIC CAP.(1608) B K 0.33µF/10V CHD1AK30B334
C1421 Not Used
C1423 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1441 Not Used
C1442 Not Used
C1443 CAP ALUMINUM ELECTOLYTIC 1000µF/6.3V M CE0KMASDL102
C1461 Not Used
C1462 Not Used
C1481 Not Used
C1482 Not Used
C1531 Not Used
C1532 Not Used
C1533 Not Used
C1535 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1536 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMASSL220
C1537 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
IC1402 Not Used
IC1403 DRIVER FOR DVD MM1636XWRE QSZBA0TMM108
L1007 CHOKE COIL 22µH-K LLBD00PKV021
L1008 CHOKE COIL 22µH-K LLBD00PKV021
L1009 CHOKE COIL 22µH-K LLBD00PKV021
L1011 Not Used
Q1004 TRANSISTOR KTC3199(Y) NQSY0KTC3199
R1023 CHIP RES.(1608) 1/10W F 2.2k ΩRRXAFR5Z0222
R1073 METAL RES. 2W J 27kk ΩRN02270ZU001
R1076 CHIP RES.(1608) 1/16W F 1kk ΩRRXAFR5Z0102
R1403 CHIP RES. 1/10W F 160k ΩRRXAFR5Z0161
R1421 Not Used
R1423 CHIP RES. 1/10W F 160k ΩRRXAFR5Z0161
R1441 Not Used
R1443 Not Used
R1461 Not Used
R1462 Not Used
R1481 Not Used
R1482 Not Used
R1523 Not Used
JK1201 PIN JACK 2P MSD-242V-01 NI FE LF JXRL020LY123
JK1402 1PIN JACK(YELLOW) MSP-251V-02 NI JXRL010LY117

MSD115
E6151UD
2005-09-15
