Magnavox MDV 530 VR Operating manual

There are many ways to connect your new DVD/VCR to yourTelevision and other equipment.This
Quick-Use Guide shows the easiest, most common connection between the DVD/VCR and a TV.
Higher quality connections are explained in the owner’s manual and will provide better sound or
picture if your TV and/or audio system is compatible.
ANT-IN
ANT-OUT
DVD/VCR VCR
AUDIO OUT AUDIO IN
LL
RR
VIDEO OUT VIDEO IN COAXIAL
DVD
S-VIDEO
OUT COMPONENT VIDEO OUT
Y
LC
R
AUDIO
OUT DIGITAL AUDIO OUT
C
B
R
4
REAR OFTV
(EXAMPLE ONLY)
ANTENNA IN
IN OUT
RF COAXIAL CABLE
CABLE
TV SIGNAL
ANTENNA or
CABLE TV SIGNAL
CABLE BOX OR
2
3
1Disconnect all equipment from the power outlets. Connect the equipment to the power outlets
only after you have finished hooking up everything. Never make or change connections with equipment
connected to the power outlet.
2If you do not have a Cable Box, simply connect your Antenna or CableTV signal directly to the
ANT-IN jack on the rear of the DVD/VCR.
If you do have a Cable Box (or Satellite Receiver), first connect the CableTV (or Satellite) signal
to the IN jack on the Cable Box/Satellite Receiver. Then, use an RF coaxial cable (like the one
supplied) to connect the OUT jack of the Cable Box/Satellite Receiver to the ANT-IN jack on
the DVD/VCR.
3Connect the supplied black RF coaxial cable to the DVD/VCR’s ANT-OUT jack and to yourTV’s
ANTENNA IN jack. The TV’s ANTENNA IN jack could be labelled 75-ohm,TV IN, or RF IN. Check your
TV manual for details.
4Plug the power cords of the DVD/VCR and the TV into an active power outlet.
5Turn on the TV power. Set theTV to channel 3. (If you cannot use channel 3 at your TV, you can
use channel 4 instead. However, you must set the DVD/VCR’s output channel to 4. See the accompanying
DVD/VCR owner’s manual for details.)
6Press the STANDBY-ON 2button on the DVD/VCR or its remote to turn on the DVD/VCR.
The first time you turn on the DVD/VCR, you should complete the VCR setup. See the other
side of this Quick-Use Guide for details.
Quick-Use Guide
Quick-Use Guide
530VR qug2 19/03/2003 2:49 PM Page 1

Playing a Disc
1With the TV and DVD/VCR on, press the DVD
button to put the DVD/VCR in DVD mode.
2Press OPEN/CLOSE /to open the disc tray. Put
a Disc in the tray with the label facing up and the
shiny side facing down.
Press OPEN/CLOSE /again to close the tray.
3Playback may start automatically. If not, press
PLAY B.If a DVD Disc menu appears, use the 1 234,
OK, or Number buttons to select features or start
playback. Follow the instructions in the menu.
4To stop playing the Disc, press STOP 9.
MDV530VR / 8239 300 26712
H9460UD/0VMN03997*****
Setting Up the VCR the First Time
1Turn on the TV and set it to channel 3.
2PressVCR, then press STANBDY-ON 2to turn
on the DVD/VCR. This display will appear.
3Press 3or 4to select English, French, or Spanish
as the language for VCR displays. Then, press 2.
4The AUTO SET UP message will appear. Press 2to set
up TV channels for the VCR. When setup is
complete, the lowest TV channel will appear on the TV.
AUTO SET UP
LANGUAGE SELECT
2 ENGLISH [ON]
FRANCAIS
ESPANOL
Playable Discs
The DVD Player of the DVD/VCR will play the following Discs.
DVDs must have a Region Code of ALL regions or Region 1.
DVDs must be recorded in the NTSC Color System.
1
ALL
Recordable
ReWritable
TIMER SET
STANDBY-ON
Turn on
the TV to
channel 3.
Quick-Use Guide (cont’
Quick-Use Guide (cont’d) d)
3-4
2
TIMER SET
STANDBY-ON
4
STOP PLAY
OPEN
CLOSE
DVD VCR
OUTPUT
TIMER
REC REC RECORD STOP/EJECT PLAY VIDEO AUDIOL AUDIO R
STANDBY-ON
1
2
1
3
530VR qug2 19/03/2003 2:49 PM Page 2
