Magnavox MP601 User manual

LIMITED WARRANTY
FCC STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation. The antenna(s)
used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be
co-located or operating in conjunction with any other antenna or transmitter.
INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCCWARNING:
This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful
interference unless the modifications are expressly approved in the instruction manual. Modifications not authorized by the
manufacturer may void users authority to operate this devices.

1. Do not look directly into the projector light.
2. Don’t touch the projector lens.
3. Use of this unit near fluorescent lighting may cause interference regarding
use of the remote. If the unit is displaying erratic behavior move away from
any fluorescent lighting, as it may be the cause.
3

Remove & Close The Lens Cover
Placing Your Projector
Your projector can be installed in four different configurations (see picture below):
4
Remove the lens
cover before using
Fig. 1 Fig. 2 Fig. 3 Fig. 4
Assemble the supplied
lens hood to the unit
as illustrated below:
When finished, remove
the lens hood from
the unit:
Close the lens cover
when unit not in use
Front Ceiling
Rear Ceiling
Rear Table
Front Table Front Table:
Select this location with the projector placed near
the floor in front of the screen. This is the most
common way to position the projector for quick
setup and portability.
Rear Table:
Select this location with the projector placed near
the floor behind the screen.
NOTE: A special rear projection screen is required.
Front Ceiling:
Select this location with the projector suspended
upside-down from the ceiling in front of the screen.
NOTE: A projector mount is required to install the
projector on a ceiling.
Rear Ceiling:
Select this location with the projector suspended
upside-down from the ceiling behind the screen.
NOTE: A projector mount is required to install the
projector in a ceiling.
A special rear projection screen is required.
LENS COVER
REMOVE
OK
CLOSE
LENS COVER
OK
CLOSE
LENS COVER
OK
LENS COVER
REMOVE
OK

Distance Between The Projector And Screen
Measure the distance between the projector and where you want to position
the screen. This is the projection distance.
Installing your Projector in the Ceiling
5
SCREEN SIZE
DISTANCE
Distance Screen Size
37 inch
45.7 inch
53.1 inch
59.4 inch
71.2 inch
84.6 inch
45 inch
50 inch
60 inch
72 inch
• Move the projector as close to the center of
the screen as possible.
• The light beam from the projector should be
perpendicular to the screen for a rectangular
or square image.
When installing the projector in the ceiling, please purchase a projector mount
recommended by an installation professional and follow the instructions that
come with the mount.
Before installing the projector in the ceiling, please check to make sure the
ceiling structure can support the weight of the projector and the mount. If in
doubt, please ask the advice from an installation professional.
NOTE: Projector mount and screw(s) not included

Follow below picture to adjust the vertical location.
Adjust The Focus And Keystone
6
SCREEN
PROJECTOR VERTICAL
DIMENSION
VERTICAL
DIMENSION
SCREEN
PROJECTOR
VERTICAL
DIMENSION
SCREEN
PROJECTOR
AV HDMI USB VG A
TF
AVHDMIUSBVGA
TF
Adjust this knob ( ANGLE ADJ. knob)
to fine- tune the display angle to higher.
AVHDMI
TF
KEYSTONE ADJ. KNOB
FOCUS ADJ. KNOB
Then sharpen the image
by rotating focus knob.
Follow the below picture to adjust the focus and trapezoidal screen.
Adjust the focus by turning the knob while observing the image pixels near the
center of the screen. Optimal focus is obtained when the pixels are clearly
visible. Depending on the projected screen size, the focus near the screen
edges may be less sharp than the screen center.
Keystone image is created when the projector lens is projected from above or
below the center of the screen. Keystone correction restores the distorted
image to a rectangular or square shape.

Controls Of Remote
7
OK
2ABC
1/ @3D EF
4GHI 5JKL 6M NO
7PQRS 8TU V 9WXYZ
0
FLIP
MENU
EXIT
FAV/
RECALL
OK
EXIT
BATTERY DOOR
OK
Install / Replace Baery Of Remote
BATTERY PRECAUTIONS:
Follow these precautions when using a battery
in this device:
1. Use only the size and type of battery
specified.
2. Be sure to follow the correct polarity when
installing the battery as indicated in the
battery compartment. A reversed battery
may cause damage to the device.
3. Do not mix different types of batteries
together (e.g. Alkaline and Carbon-zinc) or
old batteries with fresh ones.
4. If the batteries in the device are consumed
or the device is not to be used for a long
period of time, remove the batteries to
prevent damage or injury from possible
battery leakage.
5. Do not try to recharge the battery not
intended to be recharged; it can overheat
and rupture. (Follow battery manufacturer’s
instructions.)
6. Do not dispose of battery in fire. Battery
may explode or leak.
7. Clean the battery contacts and also those
of the device prior to battery installation.

OK
1. LENS
2. ANGEL ADJ. Knob
3. VGA IN Port
4. IR Sensor
5. FOCUS ADJ. Knob
6. TRAPEZOIDAL ADJ. Knob
9. POWER Indicator
Controls Of Projector
15. EAR PHONE Jack
16. AV IN Jack
17. TF Card Slot
18. HDMI 1 & 2 Ports
19. USB Port
20. DC IN Jack
8
1
2
VGA IR
34
HDMI 2
HDMI 1 USB
AV
15 16 17 18 19 20
5
6
7
8
9
10
11
12
13
14
OK

Connect the small plug from supplied AC/DC Adaptor to the DC IN Jack
on the rear of unit then plug the AC/DC Adaptor to a wall outlet having
AC 100-240V~; 50/60Hz.
- Press the button to turn on unit, press again to turn off.
/ SOURCE - Press the button to select input source.
/ MENU - Press the button to enter projector menu.
- Press the buttons to navigate and select screen item of menu.
/ EXIT - Press the button to return to previous status or exit the menu.
- Press the buttons to fast search forward and rewind on USB / TF.
- Press the buttons to search next or previous file on USB / TF.
VOL+ / VOL - Press the buttons to select the sound level.
- Press the button to play/pause the playback of file on USB / TF card.
FLIP - Press the button to rotate / mirror projector screen
ZOOM - Press the button to select image scale.
- Press to mute the audio. Press again to resume.
9
NOTES:
• If you will not use the unit for an extended period
of time, unplug the AC/DC Adaptor from wall outlet.
• The AC/DC Adaptor is intended to be correctly
orientated in a vertical or floor mount position.
OK
AV TF CARD HDMI 1 HDMI 2
DC IN
USB
OK
AC/DC Adaptor
Power Source

Refer to the following picture to connect a set top box, a BD/DVD player or a
streaming player to the HDMI input.
1. Turn off the unit before connecting HDMI cable.
2. After connecting, press the button to turn on unit, the power indicator
power indicator will turn GREEN.
3. Press the button to select HDMI 1 or HDMI 2 and the
video from the connected device will be shown on projector screen.
4. Press the button to turn off unit power.
Follow below picture to connect AV cable and device.
1. Turn off the unit before connecting AV cable.
2. Use AV cable to connect following the below figure.
3. After connecting, press the button to turn on unit, power indicator will
turn GREEN.
4. Press the button to select AV mode and the video of AV
device will be shown on projector screen.
5. Press the button to turn off unit power.
Important Note:
If there is no sound from the internal speakers when playing media
contents from a set top box, BD/DVD or streaming players connecting to
the HDMI input, please check the set top box or the player's digital audio
settings and make sure it is set to "PCM Stereo" mode.
Connect HDMI Show The Image On Projector Screen
Connect AV Show The Image On Projector Screen
10
VIDEO CABLE LEFT CHANNEL
RIGHT CHANNEL
AV TF CAR D
HDMI 1 HDMI 2
DC IN
USB
HDMI CABLE
CABLE NOT INCLUDED
Video Player
AV TF CA RD
HDM I 1 HD MI 2
DC IN
USB
HDMI Stre aming player (n ot included)

Connect VGA Show The Image On Projector Screen
Please refer to the following table to adjust the output signal from computer.
NOTE: In order to get the sound from the unit, please connect AV IN cable when
you connect VGA input.
PC
VGA 640x480
31.5 60
34.7 70
37.9 72
37.5 75
SVGA 800x600
31.4 50
35.1 56
37.9 60
46.6 70
48.1 72
46.9 75
XGA 1024x768
40.3 50
48.4 60
56.5 70
11
Follow below picture to connect VGA cable and device.
1. Turn off the unit before connect VGA cable.
2. Press the button to turn off power of your projector before connection.
3. After connect, press the button to turn on unit, power indicator will
turn GREEN.
4. Press the button to select VGA mode and the video of
VGA device will show on projector screen.
5. Press the button to turn off unit power.
To VGA PORT
NOTE BOOK DECK TOP
OR
COMPUTER CABLE COMPUTER CABLE
VGA IR

Follow below picture to connect audio cable and device.
1. Press the button to turn off power of your projector before connection.
2. Use audio cable to connect follow below figure.
3. After connect and turn on both units. Your projector sound from external
device now.
4. After use , turn off both units.
Important Note:
If there is no sound from the stereo audio output when playing media
contents from a set top box, BD/DVD or streaming players connecting to the
HDMI input, please check the set top box or the player's digital audio
settings and make sure it is set to "PCM Stereo" mode.
Connect Audio Output ( Aux Out / Line Out / Earphones)
Install USB Device And TF (Micro SD) Card
Follow below picture to install USB and TF card.
Turn off the unit before install USB / TF card.
12
AV CABLE
STATION AMPLIFIER
AV TF CAR D
HDMI 1 HDMI 2
DC IN
USB
TF U SB
TF
AV TF CAR D
HDMI 1 HDMI 2
DC IN
USB

1. When photo playback, press the
show on lower (figure 1).
Install USB / TF device:
1. Turn off the unit before installing USB / TF card.
connecng,
2. Install the USB device into USB port / Install the TF device into TF slot.
Using TF Card And USB Playback (Media Player)
Sub-Menu on Photo screen
Figure 1.
Sub-Menu on Music screen
Figure 2.
Sub-Menu on Movie screen
Figure 3.
13
Sub-Menu on Text screen
Figure 4.
OK
OK
OK
OK
OK
OK
OK
1. When music playback, press the
show on lower (figure 2).
OK
OK
1. When movie playback, press the
show on lower (figure 3).
OK
OK
1. When text playback, press the
show on lower (figure 4).
OK
OK
OK
NOTE:
Pause F B F F P r ev. N ex t St op R_ A l l R _ O FF
Set A Play... I n fo Slow... Step... G oto...
P aus e F B F F P r ev . N e x t Sto p R _ A l l Set A
R_OFF I n f o Goto.. .M U T E Play...
P au se Pr ev . N e x t St op R_ All
Rota... Zoom... Mov... Slid...
Zoom...
I nfo
R_ O FF Play.. .
Rota...
R
R
R
MUSIC
P r ev. . . Next... P r e v . N e x t S t o p Play... I n f o
MUSIC
OK
OK
OK

Using Bluetooth Playback Audio
14
Balance 0
Auto Volume Off
Sound Mode Standard
Bluetooth Speaker Off
Pairing is the term used when two Bluetooth devices are connected wirelessly
for the first time. This allows the devices to see each other and sets up a one to
one communication channel between both devices.
1. Press the button to turn on unit.
2. Press the / MENU button to enter the menu screen.
3. Use the button to select right side menu.
4. Use the button to select Bluetooth speaker column.
5. Press the button to select “Bluetooth Speaker On”.
6. Turn on your External Bluetooth Speaker and select to Bluetooth
pairing mode.
7. After a few seconds, near the BT logo will show the connected External
Bluetooth Speaker name in the main function page.
8. After connection is completed, the unit will sound through to External
Bluetooth speaker.
Disconnect the Bluetooth
1. Press the / MENU button to enter the menu screen.
2. Use the button to select above menu.
3. Use the button to select Bluetooth speaker column.
4. Press the button to select “Bluetooth SpeakerOff” then the bluetooth
will disconnect.
Bluetooth Connection
OK
OK

Using Projector Menu (Main Menu)
Press button to enter projector menu.
This Picture menu is shown on right upper of
view screen.
15
Color Temperature
Customer define Parameter
RED 0-100
GREEN 0-100
BLUE 0-100
Picture Mode
Customer define Parameter
Contrast 0-100
Brightness 0-100
Color 0-100
Sharpness 0-100
Aspect Ratio
4:3 The signal in a 4:3 aspect ratio projection image
16:9 The signal in a 16:9 aspect ratio projection image
Use to select different picture effect to Standard /
Soft / User / Vidid. Use or to select
Contrast / Brightness / Color / Sharpness digit If chose
User item. Follow below figure.
Use buttons to select different color temperature
to Cool / Medium / Warm / User. Use or to
select Red / Green / Blue digit If chose User item.
Follow below figure.
Use buttons to select screen ratio AUTO / 4:3 /
16:9. Follow below figure.
Use buttons to select Off / Low / Middle / High
/ Default.
Use buttons to select 75% - 100%.
USE TO SELECT
USE TO SELECT
USE TO SELECT
USE TO SELECT
PRESS OK
PRESS OK
PRESS OK
PRESS OK
Picture Mode Standard
Color Temperature Medium
Aspect Ratio Auto
USE TO SELECT
PRESS OK
PRESS OK
Noise Reduction Middle
Reduce Display 100%
Picture Mode Standard
Color Temperature
Aspect Ratio Auto
Noise Reduction
PC Setting
Reduce Display 100%

Use to select different sound effect Standard /
Music / Movie / Sports / User.
Use or to select Treble and Bass digit if
chose User item. Follow below figure to set digit.
Use buttons to select Balance level to -50 to +50.
To select On / Off.
To select On / Off.
Press button to enter projector menu, press buttons to select
SOUND menu.
Using Projector Menu (Sound Menu)
16
Sound Mode - User Parameter
001-0elberT
001-0ssaB
This SOUND menu showed on right upper of view screen.
Sound Mode Standard
Balance 0
Auto Volume Off
ffOrekaepShtooteulB
USE TO SELECT
PRESS OK
PRESS OK
USE TO SELECT
PRESS OK
PRESS OK
Balance 0
Auto Volume Off
Bluetooth Speaker Off
Sound Mode Standard
USE TO SELECT
USE TO SELECT

Use button to select different language. Follow
below figure.
Use buttons to select Y or N. If choose “Y” that
your unit will go to factory default setting.
To select different project direction
Normal / left-right mirror / up-down mirror / left-right and
up-down mirror.
To select 5S, 10S, 15S, 20S, 25S, 30S, Never.
For service center use only.
Using Projector Menu (Opon Menu)
17
Czech English French Hungarian Polish Romanian Slovak
Danish Spanish Croatian Dutch Portuguese Serbian Simplified
Chinese
German Greek Italian Norwegian Romanian Finnish
Press button to enter projector menu, press buttons to select
OPTION menu.
This OPTION menu showed on right upper of
view screen.
OSD Languag hsailgnEe
Restore Factory Default
Rotate 0
OSD Duration 30 S
Software Update(USB)
Restore Factory Default
OSD Language English
USE TO SELECT
USE TO SELECT
PRESS OK
PRESS OK
USE TO SELECT
PRESS OK
Rotate 0
USE TO SELECT
PRESS OK
OSD Duration 30 S
USE TO SELECT
PRESS OK
Software Update(USB)
OK
OK

General Specification
Package Includes
1x Owner’s Manual
1 x AC/DC Adaptor (Input: AC 100-240V~, 50/60Hz, 0.8A; Output: DC 12V, 2.5A, )
1
1 x Lens Cover
1 x Lens Hood
x Remote Control (Uses 2 x “AAA” Batteries, not included)
18
Bluetooth Version
Light Source Type
Brightness Level
Display Native Resolution
HDMI Input Supported
Video Resolution
Power Consumption
Power Souce
Display Color
4.1
LED
2000 lumens
800 x 480 RGB
1080p , 1080i , 720p, 576i , 480p, and 480i
30W Maximum
DC 12V , 2.5A,
16.7M
Projection Size 37-100 inch
Input Ports AV/ VGA / HDMI X 2
USB Port
TF (Micro SD) Card
Support USB device up to 32GB
Support formats: Mpeg1, Mpeg2, Mpeg4, mp3, Jpeg
Support TF (Micro SD) card up to 32GB
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT TO CHANGE WITHOUT NOTICE
Support formats: Mpeg1, Mpeg2, Mpeg4, mp3, Jpeg
