Magnavox MM444BT User manual

The product as repuired by IEC 60825-1 second edition 2007-03. Complies with 21 CFR 1040.10 and
1040.11 except for deviations pursuant to Laser Notice No .50, dated Jane 24,2007
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.

Welcome
Congratulations on purchasing this Flat CD Micro System. You can
now listen to your CD's, Bluetooth and FM radio.
You should have
CD Micro System Speakers
Remote control Power adaptor

Your Flat CD Micro System
CD Door Open/Close
Function
Remote
sensor
Power /
Standby
Volume
Tuning
Play/Pause
Stop LCD
Display
Headphone socket
Left speaker socket
Right speaker socket
AUX–IN
socket
DC 5V Power socket

Hanging points
Back–up batteries
(
included)
Stand FM Antenna
Hanging
points
Speaker
cables
Speaker
Stand

5
Preparing the remote control
IMPORTANT: The remote control will work within a 6m range; however, this may be
impossible if there are obstacles between the unit and the control.
If the remote control is used near other devices which generate infrared rays then it
may not operate properly and may interfere with other devices.
For first time use:
The unit has a pre-installed lithium CR2025
battery(included)Remove the protective tab to
activate the remote control battery.
To replace the remote control battery:
1. Push the switch at the side of the battery
tray towards the tray ( A ).
2. Now slide the battery tray out of the
remote control ( B ).
3. Remove the old battery.
4. Place a new CR2025 battery into the battery
tray with the correct polarity (+/-) as
indicated.
5. Slide the battery tray back into the slot in
the remote control.
Important battery information:
•
When the remote control is not used for a long time (more than a month),
remove the battery to prevent it from leaking.
•
If the batteries do leak, wipe away the leakage inside the battery compartment
and replace the batteries with new ones.
•
Do not use any batteries other than those specified.
•
Do not heat or disassemble batteries. Never throw them in fire or water.
•
Do not carry or store batteries with other metallic objects. Doing so could
cause batteries to short circuit, leak or explode.
•
Never recharge a battery unless it is a rechargeable type.

radio stations in FM condition
radio stations in FM condition

8
Fitting the back-up batteries(included)
Backup batteries prevent your CD Micro
System from losing all the saved
information in the event of a power cut. It
is recommended that you fit the batteries.
Push the catch on the battery compartment
cover in the direction of the arrow shown.
You will now be able to lift the cover off.
Slot the two AA type batteries into the
battery compartment following the
directions in the battery compartment.
Ensure the + & – on the batteries are
correctly aligned with the marks in the
battery compartment.
Slot the tabs on the top of the battery
compartment cover into the slots in the top
of the battery compartment.

8
Setting up your Flat CD Micro System
Connecting the power
Warning: Ensure your power supply voltage
corresponds to the voltage printed on the
underside of the unit.
1. Slot the jack on the power adaptor into
the power socketin the side of your Flat
CD Micro System.
2. Slot the plug on the power adaptor into a
wall socket.
3. Switch on at the plug, the unit is now in
the standby mode.
Setting up the FM aerial
Unwind the coiled FM aerial at the back of your
Flat CD Micro System.
IMPORTANT: You may need to adjust the
position of the FM aerial when tuning the radio
to receive the strongest signal.
IMPORTANT: Never leave the aerial where it
can be pulled by young children.
Connecting the speakers
First check that the speakers are on the correct
sides of the Flat CD Micro system.
The connection tabs on the sides of the
speakers must align with the slots on the sides
of the Flat CD Micro system
Unwind the cables on the backs of the
speakers.
connection
tabs
slots
Fat CD
Mini System
Speaker

Positioning your Flat CD Micro System
Separated speakers
Attached speakers Wall mounted
Separated speakers: Using this method the speakers can be separated and
placed where you want them. Youhave already completed all assembly require
see below to for how to use the stands.
Attached speakers: You can attached the speakers to the sides of the Flat CD
Micro System, see page 12.
Wall mounted: You can wall mount your Flat CD Micro System with either the
speakers attached or unattached. See page 13 on how to wall mount your Flat CD
Micro System.
Using the stands
There are stands on the backs of the two
speakers and the Flat CD Micro System.
These are used when the Flat CD Micro System
is placed on a flat surface.
To use the stands, simply pull the bottoms of
the stands out of there housings and stand the
speakers and Flat CD Micro System on a flat
level surface.
Stands

Attaching the speakers
Place a small screwdriver against the
bottom edge of the attachment tabs in the
sides of the speakers, push them upwards
and outwards until fully extended
Slot the attachment tabs on the sides of
the speakers into the slots in the sides of
the Flat CD Micro System.
Push the speakers down until the speakers
lock on to the sides of the Flat CD Micro
System.
If you want to detach the speakers, simply
push them upwards off the Flat CD Micro
System.
The attachment tabs will automatically retract
back into the sides of the speakers.

Wall mounting
WARNING: Before attempting to fit the Flat CD Micro System to the wall, if you
are in any way unsure about how or where to fit the Flat CD Micro System you
should employ a qualified person to install the Flat CD Micro System.
IMPORTANT: There are no fittings supplied with your Flat CD Micro System.
Please ensure that any fittings are correct for the wall you will be hanging your Flat
CD Micro System on. Please consult a professional for advice before drilling any
holes if you are in any doubt.
Important: These instructions
show how to hang the Flat CD
Micro System with the speakers
attached. You can also hang the
speakers impenitently from the
Flat CD Micro System. You will
need two extra fittings to do this
and will have to drill two extra
holes.
1. Mark the position on the wall
that you want the Flat CD Micro
System to be fitted to.
2. The distance between the two
mounting points is 120 mm.
Ensure the two points are level
using a spirit level ( A ).
3. Drill 2 parallel holes (the size
of the drill will depend on the
fittings you are using) in the wall.
The distance between the holes
must be 120 mm ( B ).
4. Tighten the screws into the
holes
in
the
wall.
The
screw
heads must be no larger than 8
mm and no smaller than 6 mm.
Ensure that at least 3 mm of the
screw is protruding from the wall
so that it can be inserted into the
hanging points in the back of your
Flat CD Micro System ( C ).
A
C
B
120
mm
7
m
m
3
m
m

Using your Flat CD Micro System
Basic use
Once the disk has been read,
press "play/pause “button and
CD player will start play track
one.

2

Using the BT (Bluetooth):
The first time you use the unit or pair it to a new Bluetooth Device, pair it as follows:
1. Power on the unit from standby mode and enter to BT (Bluetooth) mode as previously
instructed. “bt” will appear on the display and blink.
2. Power on the external BT Device and enter to BT searching mode. Start pairing following
on screen instructions from the external BT Device. After pairing, the “bt” on the display
will stop blinking.
3. Plays the music in the paired BT Device as usual.
4. During playback:
• Press the Button on the unit or Remote Control to pause: press again to resume normal
playback.
• Press the TUNE +/ or TUNE -/ Buttons on the unit or the Buttons on the
Remote Control to skip tracks.
Notes:
• When the external Bluetooth Device searched the unit, our model number “CM444 BT”
will appear on the display of external Bluetooth Device.
• Pairing code “0000” or “1234” may need to enter.
Normal operation after pairing:
1. Power on the external BT Device and enter to BT mode.
2. Power on the unit from standby mode and enter to BT (Bluetooth) mode as previously
instructed. “bt” will appear on the display and blink.
3. Wait a few seconds until the unit is auto paired to the external BT Device, “bt” on display
will stop blinking.
4. Plays the music in the paired BT Device as usual
