Magnescale LY71 User manual

LY71 Change of display resolution (polarity) 1/3
With the display , press key once
The display will be . (Selection of input axis)
Press key to select a condition.
When you have made your selection, press key to save your settings.
To finish the basic settings, follow steps ②and ③below.
Ver.1 (2021.1) CS&S
LY71
Initial
setup
Item No option BCD unit
(LZ71-B)
BCD unit (LZ71-B)
Comparator unit (LZ71-KR)
Comparator unit
(LZ71-KR)
1-axis input 2-axes
input
2-axes
input
1-axis
input
2-axes
input
2-axes
input
1-axis input 1-axis input 2-axes input
Basic
settings
Addition /
subtraction
function
Not used Not used use Not
used
Not used use Not used Not used use
Advanced
Settings
Display
resolution
A axis A axis
B axis
A axis A axis A axis
B axis
A axis A axis A axis A axis
Combination with optional unit and settings items
Power ON
Basic settings ⇒Input axis ⇒Change
Input axis selection
(addition / subtraction function)
Input 1
Input 1 +Input 2
Input 1 – Input 2
-Input 1 +input 2
-(Input 1 + Input 2)
Input 1, input 2 (independent)
NOTE: When using comperate unit, 2-axis
independent display is not possible.
LY71 Change of display resolution (polarity)
* If you do not know the output resolution of the measurement unit, refer to the separate "Initial setup manual".
Purpose of change Operation Explanation
Change the polarity for the input axis
using the 2-axes addition / subtraction
function in the input axis selection
Change the input axis choices in the basic
settings
Change the measurement unit resolution Change the length measurement unit resolution in
the basic settings. And check the display
resolution in the detailed settings.
Change the display resolution Change the display resolution in the detailed
settings
Change the display polarity
(Counting direction is reversed)
Change the display resolution in the detailed
settings
Advanced Settings ⇒Display resolution ⇒Change
The operation method for changing the display resolution differs depending on the purpose and conditions of the change.
Select the purpose and conditions to be changed from the table below and perform the operation.
Basic settings ⇒Measurement unit resolution ⇒Change
Basic settings ⇒Input axis ⇒Change
Advanced Settings ⇒Display resolution ⇒Change polarity
Set to basic settings mode.
Turn key “ON” while the AC adapter is energized.
Press and hold key for 3 seconds after the lamp changes from blinking to off.
①
About 2 sec
Press key once to automatically switch to advanced settings mode.
The display will be .
Press key, the display becomes the normal display.
③
④
Switch from basic settings to normal count mode.
Press key once and the display will change to .
Press key once and the display will change to .
②

LY71 Change of display resolution (polarity) 2/3
Press key once while the display is .
The display will be (measurement unit resolution).
Basic settings ⇒Measurement unit resolution ⇒Change
Input 1
Input 2
Display example when inputting 2 axes
Press key to check the current measurement unit resolution.
LY71
Set to basic settings mode.
Turn key “ON” while the AC adapter is energized.
Press and hold key for 3 seconds after the lamp changes from blinking to off.
①
Power ON About 2 sec
②
③
Press key of the axis you want to change and select
the measurement unit resolution.
When you have made your selection, press key to save your settings.
④
Press key once to automatically switch to advanced settings mode.
The display will be .
Press key, the display becomes the normal display.
⑤
⑥
Switch from basic settings to normal count mode.
Press key once and the display will change to .
Press key once and the display will change to .
Standard Expansion
Extended key
Selection of measurement
unit resolution

LY71 Change of display resolution (polarity) 3/3
Set to advanced settings mode.
Press key in normal count mode
The display will be .
Press key once to display .
Advanced Settings ⇒Display resolution ⇒Change polarity
Advanced Settings ⇒Display resolution ⇒Change
Before After
Change polarity
Example of changing the polarity of the display in the middle row
Press key once to get the display resolution of each axis.
Press key for the axis for which you want to change the polarity,
and then press key.
When you have made your selection, press key to save your settings.
Press key to return to the normal counting state.
②
①
Set to advanced settings mode.
Press key in normal count mode
The display will be .
Press key once to display .
①
Press key once to display the display resolution of each axis.
Press key of the axis you want to change and select the resolution.
When you have made your selection, press key to save your settings.
Press key to return to the normal counting state.
②
Angle display
Length display
NOTE 1: Selection of a value smaller than the basic settings measurement unit
resolution is not displayed.
NOTE 2: The angle display can be set when the angle resolution is selected in
the basic settings.
NOTE 1 NOTE 2
Selection of display resolution
Expansion
Extended key
