Mahindra 2014 Scorpio S6 User manual

Owner’s Manual
S4/S6/S6+/S8/S10
_______________________________________________________________________________
Original Issue Date: August 2014
NOTE: Carefully read, understand and follow the instructions provided in this manual, and keep it in a safe place for future reference. If you have any doubt whatsoever regarding the use
or care of your vehicle, please visit your Mahindra Dealer for assistance or advice.
This Owner's Manual should be considered as an integral part of the vehicle and should remain with the vehicle.

__________________________________________________________________________________
MAHINDRA & MAHINDRA LTD., GATEWAY BUILDING, APOLLO BUNDER, MUMBAI - 400 039
www.mahindra.com
www.mahindrascorpio.com

1 INTRODUCTION AND SAFETY PRECAUTIONS . ... .. .. .. ... .. .. ... .. .. .. .. ... .. .. ... .. .. .. ... .. . 1-1
Introduction........................................................................................... 1-1
Safety Symbols ...................................................................................... 1-1
General Safety Information and Instructions .... ... .......... ... ... ... ... ....... ... ... ... 1-2
To Owner’s of a Mahindra Vehicle..... ... .......... ... ... ... ... . ... ... ... ... .......... ... .... 1-3
Audio/Infotainment Manual ... ... ... .......... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... .... 1-5
2 GENERAL ..................................................................................................... 2-1
Feature Matrix....................................................................................... 2-1
Lubricant and Capacities .......... ... .......... ... ... ... ... .......... ... .......... ... ... ... ... . . 2-4
Dimensions ........................................................................................... 2-5
Bulb Specification....... ... ... ... ... ....... ... ... .......... ... ... ... ... . ...... ... ... ....... ... ... ... 2-6
Fuses and Relays ..... ... ... ... ... .......... ... ... ....... ... ... ... ... .... ...... ... .......... ... ... .. 2-6
Flat Tire............................................................................................... 2-10
Jack Points.......................................................................................... 2-13
Technical Specifications.. .......... ... .......... ... ... ... ... .......... ... .......... ... ... ... ... 2-18
Vehicle Identification Number (VIN) . .. .. .. .. .. ... .. .. .. .. .. .. .. .. ... .. .. .. .. .. .. .. .. ... .. .. 2-20
Engine Number.................................................................................... 2-20
3 VEHICLE OVERVIEW ......... ... ... ... ... . ......... ... .......... ... ... ... ... . ... ... ... ... .......... ... .... 3-1
Front Overview....................................................................................... 3-1
Rear Overview ....................................................................................... 3-2
Instrument Panel Overview....... ... ... ....... ... ... ... ... .... ...... ... .......... ... ... ... ... . .. 3-3
4 INSTRUMENT CLUSTER OVERVIEW . ... ......... . ... ... ... ... .......... ... .......... ... ... ... ... .. 4-1
Instrument Cluster - Type 1... .......... ... ... ....... ... ... ... ... .......... ... .......... ... ... .. 4-1
Instrument Cluster - Type 2... .......... ... ... ....... ... ... ... ... .......... ... .......... ... ... .. 4-2
Warning Lamps Overview ......... ... .......... ... ... ... ... . ... ...... ... .......... ... ......... . . 4-3
Warning Lamps..................................................................................... 4-4
5 SEATS AND SEAT BELTS ........ ... ... ...... .... ... ... ... ... ....... ... ... ....... ... ... ... ... .......... . 5-1
Driver Seat............................................................................................ 5-1
Head Restraint ...................................................................................... 5-2
Second Row Bench Seat.... .... ... ... ... ... ....... ... ... .......... ... ... ... ... ....... ... ... ..... 5-3
Second Row Seat 60:40 (if equipped) . ....... ... ... ...... .... ... ... ... ... ....... ... ... ..... 5-5
Second Row Captain Seat Arrangement (if equipped) . ...... ... ... ....... ... ... ...... 5-7
Foldable Arm-Rests (if equipped).. . ... ... ... ... .......... ... ......... . ... ... ... ... ....... ... .. 5-8
Third Row Seats..................................................................................... 5-9
Seat Belts ........................................................................................... 5-10
Child Restraints ... ...... .... ... ... ... ... ....... ... ... .......... ... ... ... ... ....... ... ... ....... ... 5-14
6 SUPPLEMENTAL RESTRAINT SYSTEM (SRS) (if equipped) .. ... .......... ... .......... ... . 6-1
Introduction........................................................................................... 6-1
Airbag................................................................................................... 6-1
Airbag Deployment and Non-Deployment.. ...... ... . ... ... ... ... .......... ... .......... ... 6-5
7 LOCKS AND KEYS......................................................................................... 7-1
Locks and Keys...................................................................................... 7-1
Central Locking System (if equipped) . .. .. .. .. . .. .. .. .. .. .. .. .. .. .. .. .. .. .. . .. .. .. .. .. .. .. .. . 7-3
Anti—Lockout System (if equipped).. ... .......... ... ...... ... . ... ... ... ... ....... ... ... ...... 7-5
Remote Keyless Entry (RKE) System (if equipped)...... ... ... .......... ... ... ... .... ... 7-5
Engine Immobilizer System (if equipped) ..... ... ... .......... ... ... ... ... ....... ... ... ..... 7-9
8 FEATURES AND CONTROL.. .......... ... .......... ... ... ... ... . ......... ... .......... ... ... ... ... . ... . 8-1
Power Windows (if equipped) ...... ... ... .......... ... ... ... ... . ...... ... ... ....... ... ... ...... 8-1
Butterfly Window (Rear Quarter Window) .......... ... ... ....... ... ... ... ... . ... ...... ... 8-3
Outside Rear View Mirror (ORVM) ....... ... ... ....... ... ... ... ... .... ...... ... .......... ... . 8-4
Tip-Tap ORVM Adjustment (if equipped)..... . ... ... ... ... .......... ... ... ....... ... ... ... .. 8-5
Manual (Joystick) ORVM Adjustment (if equipped) . ... .... ... .. ... .... .... .... ... .... .. 8-5
Electric ORVM Adjustment (if equipped) . ... ... ... .......... ... ... ....... ... ... ... ... . ... .. 8-5
Interior Mirror . ... .......... ... ... ... ... . ......... ... .......... ... ... ... ... . ... ...... ... .......... ... 8-5
Exterior Lamps ...................................................................................... 8-6
Turn Signals .......................................................................................... 8-6
Table of Contents

Lamps Off.............................................................................................. 8-7
Parking Lamps On. . ... ... ... ... .......... ... .......... ... ... ... ... ....... ... ... .......... ... ... ... . 8-7
Head Lamp On....................................................................................... 8-7
Head Lamp High/Low Beam.. ... .......... ... ......... . ... ... ... ... .......... ... .......... ... . 8-8
Head Lamp Flash ... ... ... ... ... . ......... ... .......... ... ...... ... . ... ... ... ... .......... ... ....... 8-8
Auto Head Lamp (if equipped)........ ... ... ... .... ...... ... ... ....... ... ... ...... .... ... ... ... . 8-8
Head Lamp Leveling System. . ... ... ... ... ....... ... ... .......... ... ... ... ... ....... ... ... ...... 8-9
Magic Lamps (if equipped) ... . ... ... ... ... ....... ... ... .......... ... ... ... ... ....... ... ... ...... 8-9
Hazard on Panic Braking....... ... ... ....... ... ... ... ... . ......... ... .......... ... ... ... ... . ... .. 8-9
Static Bending Lamps (if equipped) . ... ....... ... ... ... ... .... ...... ... ... ....... ... ... ...... 8-9
Fog Lamps (if equipped) ... ... ...... .... ... ...... .... ... ... ... .... ... ... ...... .... ... ...... .... . 8-10
Puddle Lamps (if equipped) .......... ... ... ... ... . ... ... ... ... .......... ... ...... ... . ... ... ... 8-10
Follow-Me Home (FMH) with Rain Light Sensor (RLS) (if equipped) .. ... ... .... 8-11
Follow-Me Home (FMH) Non RLS (if equipped) .. ... ... .......... ... ... ... ... . ... ... ... 8-11
Lead Me to Vehicle (LMV) (RLS & Non-RLS) (if equipped) .... ... .......... ... ..... 8-12
Hazard Warning Lamp ... ... .... ...... ... .......... ... ... ...... . ... ... ... ... .......... ... ... ... 8-12
Interior Lamps .. ... .......... ... .......... ... .......... ... ... ....... ... ... .......... ... .......... .. 8-13
Power Outlet.......... ... ... ...... . ... ... ... ... .......... ... .......... ... ... ... ... . ......... ... ..... 8-14
Windshield Wipers..... .... ... ... ... ... ....... ... ... ....... ... ... ... ... .......... ... ... ....... ... 8-16
Utility Holders ......... ... ... ... ... . ...... ... ... ....... ... ... ... ... .... ... ... ... ... ....... ... ... .... 8-19
Horn................................................................................................... 8-21
Instrument Cluster - Type 1. . ... ... ... ... .......... ... .......... ... ... ... ... . ......... ... ..... 8-22
Instrument Cluster - Type 2.. ... ... ... ... . ......... ... .......... ... ... ... ... . ... ...... ... ..... 8-23
Instrument Cluster Gauges ... ... ... ... ... ... ... .......... ... ......... ... ... ... ... .......... .. 8-24
Warning Lamps Overview ...... ... .......... ... ......... . ... ... ... ... .......... ... .......... .. 8-29
Warning Lamps in the Instrument Cluster.. ... ... ... ... .......... ... .......... ... ... ... 8-31
Voice Messaging System (VMS) (if equipped) ... .......... ... ... ... ... ....... ... ... .... 8-35
Reverse Parking Assist System (RPAS) — Type 1 (if equipped). ... ... ... ... ..... 8-38
Reverse Parking Assist System (RPAS) — Type 2 (if equipped)... ... ... ... ...... 8-42
Cruise Control (if equipped) ... ... ....... ... ... ....... ... ... ... ... .......... ... ... ....... ... ... 8-44
Micro Hybrid Stop/Start System (if equipped) .. ... ... ... .......... ... ... ....... ... ... 8-46
Radio Frequency ID (RFID) Tag .. ...... ... ... ....... ... ... ...... .... ... ... ... ... ....... ... ... 8-48
9 STEERING AND BRAKES... ... ... ... ... .... ...... ... ... ....... ... ... ...... . ... ... ... ... .......... ... ... . 9-1
Steering................................................................................................ 9-1
Tilt Steering........................................................................................... 9-2
Steering Controls - Audio Control System (if equipped)... ... ... ... ... .......... ... ... 9-2
Brakes.................................................................................................. 9-3
Anti-Lock Brake System (ABS) (if equipped)... ... ... .... ... ... ... ... ....... ... ... ......... 9-4
10 HEATING, VENTILATION AND AIR-CONDITIONING SYSTEM (HVAC).. ... ... ... ....... 10-1
Heating, Ventilation And Air-Conditioning System(HVAC) ....... ... ... ... ... . ...... 10-1
HVAC Overview.................................................................................... 10-2
Center/Side Vents... . ... ...... ... .......... ... ... ...... . ... ... ... ... .......... ... .......... ... .. 10-2
Second Row Floor Vents . .... .... .. ... .. .... .... .. ... .. .... .. ... .. .... .... .. ... .. .... .... .. ... . 10-3
HVAC Controls..................................................................................... 10-3
Automatic Climate Controller (if equipped) ... .......... ... ... ... ... . ......... ... ........ 10-4
Air Distribution Control ... ... ... ... ... ... ... ... .......... ... ... ... ... ... ... ... ... ... ... ... ... ... 10-4
Blower Speed Control......... ... ......... . ... ... ... ... ....... ... ... .......... ... ... ... ... ...... 10-5
Temperature Control. ....... ... ... .......... ... ... ... .... ...... ... ... ....... ... ... ...... .... ... . 10-5
Air Intake Mode Control .... ... ... .......... ... ... ... .......... ... ... ....... ... ... ... ... .... .... 10-6
HVAC Air Filter (Cabin Air Filter) .... .... ... ... ... .......... ... ... ....... ... ... ... ... ........ 10-7
Air-Conditioner ON ...... ... ... ... ... . ... ... ... ... ....... ... ... ...... .... ... ... ... ... ....... ... ... 10-8
Rapid Cabin Cooling.... ... ... ...... . ... ... ... ... .......... ... .......... ... ... ... ... .......... ... . 10-9
Rapid Cabin Heating ... .... .... ... .... .... .... ... .... .... .... .... ... .... .... .... ... .... ... .. ... .. 10-9
Defogging/De-misting and Defrosting...... ... ... ... ... . ...... ... ... .......... ... ...... 10-10
11 STARTING AND DRIVING THE VEHICLE .... ... ... ... ... ... ... ... ... .... ...... ... ... ....... ... ... 11-1
Safety Tips - Before Starting your Vehicle .. ... ... ... .......... ... ... ....... ... ... ... ... . 11-1
Table of Contents

Ignition Switch... ....... ... ... ...... .... ... ... ... ... ....... ... ... .......... ... ... ... .......... ... ... 11-1
Starting the Engine... ... ... ...... .... ... ... ... ... ....... ... ... .......... ... ... ... .......... ... ... 11-2
Engine Idling... ... ...... . ... ... ... ... .......... ... ... ....... ... ... ... ... .......... ... .......... ... ... 11-3
Stopping the Engine.. ....... ... ... ... ... .... ...... ... ... ....... ... ... ...... . ... ... ... ... ......... 11-3
Manual Transmission ...... ... ... ... ... .... ...... ... ... ....... ... ... ...... . ... ... ... ... ......... 11-4
Driving Your Vehicle .......... ... ... ... ... . ...... ... ... .......... ... ...... .... ... ... ... ... ....... 11-5
Four Wheel Drive (4WD) System (if equipped) ........ ... ... ... .... ...... ... ... ....... 11-8
Fuel ..................................................................................................11-11
Tips for Better Fuel Economy. .... ... ...... ... . ... ... ... ... .......... ... .......... ... ... ... . 11-12
How to Calculate Fuel Efficiency (Mileage)...... ... ... ... ... .... ...... ... .......... ... . 11-13
12 WHEELS AND TYRES ...... ... ... ...... .... ... ... ... ... ....... ... ... .......... ... ... ... .......... ... ... 12-1
Tyre Information .. ... ... ... .......... ... ... ....... ... ... ... ... .... ...... ... .......... ... ... ...... . 12-1
Tyre Rating.......................................................................................... 12-1
Tyre Label (Vehicle Placard) .... . ... ... ... ... .......... ... ......... . ... ... ... ... ....... ... ... . 12-2
Tyre Pressure... ... ... .......... ... ... ... ... ....... ... ... .......... ... ... ... .... ...... ... ... ....... 12-2
Tyre Rotation Recommendations...... ... ...... ... . ... ... ... ... ....... ... ... .......... ... .. 12-6
Tyre Pressure Monitoring System (TPMS) (if equipped) ....... ... ... ... ... ........ 12-7
Snow Chains......................................................................................12-15
Changing a Flat Tyre......... ... ... ... ... . ......... ... .......... ... ... ... ... . ... ... ... ... ...... 12-16
Wheel Tightness . .. ... . ... .. .. .. .. .. .. .. .. .. .. .. .. ... .. .. .. .. .. .. .. .. .. .. .. .. ... .. .. .. .. .. .. .. .. 12-16
13 EMERGENCIES. ... ... .......... ... ... ....... ... ... ... ... .... ...... ... ... ....... ... ... ...... . ... ... ... ... .. 13-1
Hazard Warning Flashers . ... .. .. .. ... .. .. ... .. .. .. ... .. .. .. ... .. .. ... .. .. .. ... .. .. .... .. .. ... 13-1
Vehicle Does not Start - Checks ... ... ... ... . ... ...... ... .......... ... ......... . ... ... ... ... . 13-1
Vehicle Overheating... ... ... ....... ... ... ... ... .... ... ... ... ... ....... ... ... ....... ... ... ... ... .. 13-2
Jump Starting. .......... ... ... ....... ... ... ... ... .... ...... ... ... ....... ... ... ...... . ... ... ... ... .. 13-3
Towing................................................................................................ 13-6
Limp Home Mode .. .......... ... ... ... ... . ... ... ... ... .......... ... ... ....... ... ... ... ... ........ 13-7
14 MAINTENANCE.. ... ... ... ... .......... ... .......... ... ... ... ... . ......... ... .......... ... ... ... ... . ... ... 14-1
General Owners Information. ... ... .......... ... ... ... ... ....... ... ... .......... ... ... ... .... . 14-1
Suggestions for Obtaining Service for your Vehicle .. .......... ... ... ....... ... ... ... 14-1
Need Assistance? . .. .. .. .. .. .. .. .. .. ... . ... .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ... .. .. . 14-2
Warranty Information.. ... ... .......... ... ... ....... ... ... ... ... .... ... ... ... ... ....... ... ... ... 14-2
Protect your Warranty ... ... ......... . ... ... ... ... .......... ... .......... ... ... ... ... . ...... ... 14-2
Maintenance Interval.. ... ... ... ....... ... ... .......... ... ... ... ... ....... ... ... ....... ... ... ... . 14-2
Vehicle Self Maintenance - General Precautions.......... ... ...... ... . ... ... ... ... ... 14-3
Opening/Closing the Hood... ... ... ...... .... ... ... ... ... ....... ... ... .......... ... ... ... ..... 14-3
Identifying Components in the Engine Compartment . .. .. .. .. .. .. .. . ... .. . .. ... .. . .. 14-5
General Maintenance ... ... ... ...... .... ... ... ... ... ....... ... ... .......... ... ... ... .......... .. 14-6
In the Engine Compartment. ... ... .... ...... ... ... ....... ... ... ...... .... ... ... ... .......... .. 14-6
Maintenance - Inside the Vehicle.... ... ... ... ... ....... ... ... .......... ... ... ... .......... 14-12
Maintenance - Outside the Vehicle ... ... ....... ... ... .......... ... ... ... ... ....... ... ... . 14-12
Battery.............................................................................................. 14-12
Appearance Care and Protection .... ... . ...... ... ... .......... ... ...... ... . ... ... ... ... . 14-14
Air Conditioning System Maintenance . ... .... ... .... .... ... .... ... .... .... .... .... ... .. 14-17
Vehicle Storage... .......... ... ... ....... ... ... ... ... .... ...... ... ... ....... ... ... ...... . ... ... .. 14-17
Winter Care......................................................................................14-17
Bulb Replacement......... ... ... ....... ... ... ... ... .......... ... ... ....... ... ... ... ... . ... ..... 14-18
Scheduled Maintenance ........ ... ......... . ... ... ... ... .......... ... .......... ... ... ... ... . 14-19
Maintenance Schedule Chart ... ... ....... ... ... ... ... .......... ... ... ....... ... ... ... ... . . 14-20
Table of Contents

© Copyright Mahindra & Mahindra Ltd. 082014 1-1
1 INTRODUCTION AND SAFETY PRECAUTIONS
1.1 Introduction
Dear Customer,
Congratulations on purchasing Mahindra SCORPIO. Your vehicle has been designed
to provide years of safe and dependable service, as long as it is used and maintained
in accordance with the instructions provided in this manual.
All persons who will use and/or maintain this vehicle must read, understand and
follow all warnings and instructions provided in this manual. This Owner's Manual
should be considered an integral part of the vehicle and should remain with the
vehicle. However, nothing in this manual, and none of the safety devices installed in
the vehicle, are a substitute for careful operation and common sense. Always make
sure that your vehicle is in optimum working order, and take note of the road and
weather conditions under which you are using your vehicle.
If you have any questions concerning the proper use or maintenance of your vehicle,
please call your Authorized Mahindra Dealer. A list of dealers can be found in the
Dealer Directory Supplement.
Alternatively you can contact Mahindra at,
• 1800-209-6006 (Toll free)
• [email protected]
We extend our best wishes for safe and pleasurable motoring.
Sincerely,
MAHINDRA & MAHINDRA LTD.
Servicing and Summary Data
• For all issues concerning the vehicle and for any need of spare parts, contact only
the Authorized Mahindra network
• We recommend you always use genuine Mahindra spare parts when performing
repairs on the vehicle
• We suggest that you record the vehicle data in the Warranty Information &
Maintenance Guide for future references
1.2 Safety Symbols
Carefully read, understand and follow the safety symbols/ instructions given in this
manual.
Legend of the Symbols
To emphasize information and procedures regarding safety, use, maintenance, etc.
the following symbols are used throughout the manual.
DANGER indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury and/or property damage.
INTRODUCTION AND SAFETY PRECAUTIONS

1-2 © Copyright Mahindra & Mahindra Ltd. 082014
NOTICE indicates important information relevant to the vehicle, the vehicle's use
or to sections of this manual to which particular attention must be paid for
optimum use of the vehicle.
If you see this symbol, it indicates “no”, “do not,” “do not do this,” or “never”.
1.3 General Safety Information and Instructions
Failure to follow the warnings and instructions provided in this manual could
result in failure of the vehicle, an accident and/or serious personal injury.
1. Carefully read, understand and follow the warnings and instructions given in
this manual. This manual is an essential part of the product. Keep it in the
vehicle glove box for future reference
2. Spare bulbs and first aid kit are placed in the glove box of the vehicle. Ensure
they are not taken out of the vehicle at any point of time.
3. Please note that throughout this manual, reference is made that “an accident”
could occur. An accident could cause you or a bystander to sustain severe
personal injury, or result in property damage
4. Never use a mobile phone, personal music device or pager while driving. This
may take your focus off the road and lead to accidents
5. Please be advised that many service and repair tasks require specialized
knowledge, tools and experience. General mechanical aptitude may not be
sufficient to properly service or repair your vehicle. If you have any doubt
whatsoever regarding your ability to properly service or repair your vehicle,
please contact your Authorized Mahindra Dealer or a qualified technician
6. A person with a pacemaker should never contact the engine control unit or its
cables to injectors, as this system carries high voltage which may adversely
affect the functioning of the pacemaker
7. Inspect the seat belt system periodically, checking for cuts, frays or wear in the
seat belt webbing, or loose buckles, retractors, anchors or other loose parts.
Damaged parts must be replaced immediately
8. Always start and operate the engine in a well-ventilated area. If in an enclosed
area, vent the exhaust to the outside. Do not modify or tamper with the
exhaust system
9. Examine tires for excessive tread wear and uneven wear patterns. Check for
stones, nails, glass or other objects lodged in the tread and check sidewalls
for any cuts, cracks or other signs of wear. Replace as necessary
10. Always maintain the safety labels affixed to your vehicle in a good legible
condition
11. All signal lamps, buzzers, shields, guards and other protective safety devices
must always remain in place and in good, proper working condition
12. The life span of Mahindra products depend on many factors. Improper use,
abuse or harsh use in general may compromise the integrity of the vehicle and
significantly reduce its life span. The vehicle is also subject to wear over a
period of time. Please have your vehicle regularly inspected by an Authorized
Mahindra Dealer or a qualified mechanic. If the inspection reveals any damage
or excessive wear, immediately replace or have the component serviced
13. We recommend that you use only genuine parts supplied by Mahindra. The
use of non-Mahindra parts will not be covered by warranty
14. The vehicle can be used only as a passenger vehicle. Any other use is
improper, and may result in voiding the warranty
15. Never crawl under or be in close proximity to the vehicle when it is lifted off the
ground (by a jack), unless the vehicle is properly supported with jack stands,
wheel chocks and other appropriate safety devices
INTRODUCTION AND SAFETY PRECAUTIONS

© Copyright Mahindra & Mahindra Ltd. 082014 1-3
16. Never attempt any repairs or adjustments to any component while the vehicle
is in motion. Always switch off the engine, and wait for the engine to come to a
complete stop before performing any repairs or adjustments
17. The vehicle identification plates are the only legal identification reference,
hence it is necessary to keep them in good condition. Never modify data on
the plates or remove them. The customer is responsible for any possible
tampering with the plates, which will immediately void the warranty
18. Do not attempt sharp turns, abrupt maneuvers, or other unsafe driving
actions that can cause loss of vehicle control. When the vehicle is fully loaded,
drive at a slow speed, especially when turning. Note that the center of gravity
of the vehicle increases as the vehicle is fully loaded on the roof carrier
19. Do not wash the engine or engine compartment with pressurized water
1.4 To Owner’s of a Mahindra Vehicle
When first driving the vehicle after long periods of non-use, you may experience a
temporary drive disturbance. This is a characteristic of the tires and should be no
reason for concern. The condition should correct itself within 5-15 kms. of driving. If
the disturbance persists, have the tires checked by an Authorized Mahindra Dealer.
Driving and Alcohol
Your driving ability can be seriously impaired by alcohol even if the blood alcohol level
is far below the legal minimum. Drunken driving is one of the most frequent causes
of accidents.
Never drink and drive. Drinking and driving will lead to an accident resulting in
serious personal injury.
Driving and Drugs/Medication
Your driving ability can be seriously impaired through the use of prescription or non-
prescription drugs or medication (even cough syrup). If you are taking any sort of
drug or medication, be sure that it will not affect your driving ability.
Mobile Phone Warning
Use of electrical devices such as mobile phones, computers, portable radios or other
by the driver while driving is dangerous. Dialing a number on a mobile phone while
driving also ties up the driver's hands. Use of these services will cause the driver to
be distracted and may lead to a serious accident. If a passenger is unable to use the
device, pull off the road to a safe area before use. If use of a mobile phone is
necessary despite this warning, use a hands free system to at least leave the hands
free to drive the vehicle. Never use a mobile phone or other electrical devices while
the vehicle is moving.
Please comply with the legal regulations concerning the use of communication
equipment in vehicles in your country.
Driving Long Distances
When you are driving over long distances, follow these tips so that you have a safe
journey;
• Lack of sleep or fatigue may impact your ability to drive safely
• Exercise your eyes by shifting the focus of your eyes to different parts of the road
• Use stimulating beverages such as coffee or tea
• Relax and stay calm
Protecting Our Environment
Every one of us should play our part in protecting our environment. Judicious vehicle
usage and disposing hazardous waste (including cleaning and lubrication fluids) are
important steps towards this initiative.
INTRODUCTION AND SAFETY PRECAUTIONS

1-4 © Copyright Mahindra & Mahindra Ltd. 082014
Mahindra vehicles conform to existing emission norms (standards). Adhering to the
periodical maintenance schedule and using Mahindra genuine parts will help retain
emission performance of the vehicle and is a pre-requisite to emissions warranty
coverage.
Servicing
If you have any questions concerning the proper use or maintenance of your vehicle,
please call your Authorized Mahindra Dealer. A list of dealers can be found in the
Dealer Directory Supplement or on the Internet.
Alternatively you can contact Mahindra on 1800-209-6006 /
[email protected].
Hazardous Material
Certain components of this vehicle such as seat belt pre-tensioner, airbag and
vehicle battery may contain hazardous material. Special handling may be required for
service or vehicle end-of-life disposal.
Running-in
Driving smoothly during the first 1000 km will help prevent premature failures and
abnormal system wear, improving the life of drivetrain and vehicle components.
A new engine may consume more oil during the first 1,000 km of running. This
should be considered as a normal part of break-in and not interpreted as any
problem with the engine.
Protection from Electronics
To ensure optimum vehicle performance and passenger safety, your Mahindra
vehicle is equipped with sophisticated modern electronics and controls. Do not install
any communication devices, electronic gadgets or radar detection devices, without
express written consent from Mahindra.
An improperly installed/adjusted two-way radio can adversely affect electronic
systems.
Mahindra Genuine Parts
Mahindra uses high quality parts for building vehicles.
In the event that any parts need replacement, we recommend that you use only
Mahindra genuine parts.
In order to safeguard the theft protection system of the vehicle, Mahindra will
not supply EMS ECU, vehicle keys and the immobilizer as a set for any vehicle.
Non-Mahindra parts may harm vehicle performance and will not be covered by your
Mahindra warranty.
To avoid counterfeit parts and to protect our brand image, Mahindra genuine parts
are packed in a branded carton. Look for the ‘Mahindra Genuine Parts’ logo.
Any unauthorized modifications or alterations to this vehicle or failure to use
appropriate specification and quality spare parts could seriously affect vehicle
road worthiness and safety leading to an accident, resulting in serious injury
Mahindra Genuine Accessories
A wide selection of quality accessories is available through your Authorized Mahindra
Dealership. These accessories have been specifically engineered to allow you to
personalize your vehicle to suit your requirements and compliment its style and
aerodynamic appearance.
Each accessory is made from high quality materials and meets Mahindra's rigid
engineering and safety specifications. Every Mahindra accessory installed according
INTRODUCTION AND SAFETY PRECAUTIONS

© Copyright Mahindra & Mahindra Ltd. 082014 1-5
to the Mahindra installation provisions comes with the respective accessory
warranty.
Consult your Authorized Mahindra Dealer for detailed information about accessories
available for your specific model variant.
For maximum vehicle performance and safety considerations always keep the
following information in mind.
• When adding accessories, equipment, passengers and luggage to your
vehicle, do not exceed the total weight capacity of the vehicle or of the front
and rear axle. Consult Mahindra authorized dealer for specific weight
information.
• Bull bars and nudge guards are not recommended for variants with an
airbag.
• Accessories causing any change in vehicle specifications like wheel rims, bull
bars, etc., may affect the performance of safety systems.
• Mobile communication systems such as two way radios, telephones and
theft alarms that are equipped with radio transmitters and installed in your
vehicle should comply with the local regulations and should be installed only
by a your Authorized Mahindra Dealer
Vehicle Safety
When leaving your vehicle unoccupied;
• Always remove the ignition key when you park the vehicle
• Close all the windows completely and lock all the doors
• Do not leave any valuables in your vehicle. If you must leave something in your
vehicle, hide it and securely lock all the doors
1.5 Audio/Infotainment Manual
Please refer the Audio/Infotainment manual available in the manual pouch for
details regarding;
• Audio/Video functions
• Bluetooth functions
• Navigation (if equipped)
• Map upgradation details
To upgrade the maps in your navigation system (if equipped), please refer the
Infotainment manual.
INTRODUCTION AND SAFETY PRECAUTIONS

© Copyright Mahindra & Mahindra Ltd. 082014 2-1
2 GENERAL
2.1 Feature Matrix
In view of our policy of continuously improving our products, we reserve the
right to alter specifications, designs or features without prior notice and
without liability.
We recommend you contact the nearest Authorised Mahindra Dealer for the
2latest features applicable to your vehicle.
Feature S4 S6/S6+ S8 S10
Technology
Micro Hybrid Technology ü
Tyre-tronics ü
Reverse Parking Assist ü ü
Auto Wipe & Auto Head lamp ü
Digital Immobiliser ü ü ü ü
Voice Assist System ü ü ü
Remote Locking/Unlocking ü ü ü
Infotainment Basic Audio Touchscreen with
Navigation & BT
Safety
Dual Airbags Optional Driver Airbag ü ü
Anti-Lock Braking System (ABS) with EBD Optional ü ü
Collapsible Steering Column ü ü ü ü
Tubeless Tyres ü ü ü ü
Smart Window (Anti-pinch Driver Side only) ü
Style
Alloy Wheels ü ü
GENERAL

2-2 © Copyright Mahindra & Mahindra Ltd. 082014
Feature S4 S6/S6+ S8 S10
Roof—top Ski Racks ü ü ü
Spoiler ü ü ü
Wheel Caps ü
Front Fog Lamps ü ü
Side Cladding Unpainted Body Coloured Body Coloured Body Coloured
Comfort
Tiltable Steering ü ü ü ü
HVAC with Rear Vents ü ü ü Automatic Climate
Control
Individual Armrest for Driver & Co-driver Seats ü ü
Centre Armrest for 2nd row 60-40 Seat only ü ü
Driver Seat Height Adjust ü
ORVM Manual Adjustable Electric
Convenience
Power Steering ü ü ü ü
Power Windows ü ü ü ü
Central Locking Manual Remote Remote Remote
Power Socket Front & Middle Rows
Rear Wipe & Wash ü ü ü
Rear Demister ü ü ü
Head lamps Twin chamber Twin chamber Projector lamps Projector with static
bending lamps
Lead-me-to-Vehicle ü ü ü
Follow-me-Home Head lamps ü ü ü
Puddle Lamps ü
GENERAL

© Copyright Mahindra & Mahindra Ltd. 082014 2-3
Feature S4 S6/S6+ S8 S10
Cruise Control ü
Steering Mounted Audio Controls ü
GENERAL

2-4 © Copyright Mahindra & Mahindra Ltd. 082014
2.2 Lubricant and Capacities
System Lubricant Capacity Specification Remarks
Engine Oil MAHINDRA “MAXIMILE FEO”
NEW GENERATION GENUINE ENGINE FLUID 6.0 liters Special Engine
Fluid
For other than specified brand, the oil change interval has to be reduced to 10,000
kms if the oil meets minimum of API CH-4 SAE 15W-40 specification
Engine Oil Filter MAHINDRA “MAXIMILE UNIVERSE”
GENUINE OIL FILTER —Recommend to use only the genuine filter for better engine protection and lubricant life
Engine Cooling MAHINDRA “MAXIMILE ULTRA COOL”
(READY TO USE COOLANT. NO NEED TO MIX WATER) ~7.5 liters
Brand specific. Don’t use other coolants / water for top up. In case of emergency, coolant meeting JIS
K-2234 specification should be used (30% concentration diluted with distilled water) and coolant
change period to be reduced as 30,000 kms
Manual Transmission MAHINDRA “MAXIMILE SYNTEC F2”
NEW GENERATION GENUINE TRANSMISSION OIL 2.25 liters
Special Manual
Transmission
Fluid
If Maximile GO Synchro 80W-90 is used, the oil change interval to be reduced to
40,000 kms. For other than Maximile brand, the oil change interval to be reduced to
20,000 kms if oil meets minimum of API GL-4 SAE 80W-90 specification
Rear Axle MAHINDRA “MAXIMILE ELITE”
NEW GENERATION GENUINE DIFFERENTIAL OIL
2.1 liters Special
Differential Fluid
For other than Maximile brand, the oil change interval has to be reduced to 20,000
kms if the oil meets minimum of API GL-5 SAE 80W-90 specification
Front Axle (4WD only) 1.2 liters
Power Steering SHELL “SPIRAX S3 ATF MD3” / CALTEX
“TEXAMATIC 1888" 0.8 liters Brand Specific and no other brand should be used
Brake and Clutch MAHINDRA “MAXIMILE DOT 4” 0.9 liters In emergency situations, brake fluid meeting SAE J1703; FMVSS No.116 DOT 4 or IS 8654 Type-2
specification and change at 30,000 km or 2 years whichever earlier
Wheel Hub (Grease) MAHINDRA “MAXIMILE LCG”
GENUINE WB GREASE As Req. Advise to use only the genuine grease for better life and protection. In emergency Lithium Complex
grease meeting NLGI 2 / 3 specification can be used
Recommended Fuel
Diesel conforming to Indian standard IS
1460; 2010 BS IV / BS III specification or
equivalent. 60 liters —
GENERAL

© Copyright Mahindra & Mahindra Ltd. 082014 2-5
2.3 Dimensions
2.3.1 Front View
1520
W12B01
2.3.2 Rear View
1500
W12B02
2.3.3 Side View
2680
4430
1975
4456
2680
1995
W12B03
DIMENSION & WEIGHTS mm
Wheel Base 2680 mm
Overall Length 4456 mm
Overall Width 1820 mm (excluding
outside mirrors)
Overall Height 1948 without ski rack
1995 with ski rack
Track Width (Front) 1520 mm
Track Width (Rear) 1500 mm
Maximum GVW 2510 (2WD)
2610 (4WD)
The specifications are for reference only. Subject to change without prior notice
GENERAL

2-6 © Copyright Mahindra & Mahindra Ltd. 082014
2.4 Bulb Specification
Lamp Bulb Wattage No. of Bulbs per Vehicle
Head Lamp - Low Beam H7 55W 2
Head Lamp - High Beam H7 55W 2
Front Turn Signal Lamp 21W 2
Side Turn Signal Lamp (Fender) 5W 2
Static Bending Lamp H1 55W 2
Front Position Lamp LED* / 5W LED* / 2
High Mount Stop Lamp LED* / 10W LED* / 2
Brake Lamp LED* LED*
Rear Turn Signal Lamp 16W 2
Rear Position Lamp LED* LED*
Reversing Lamp 16W 2
Front Fog Lamp * 35W 2
Rear License Plate Lamp 5W 2
Interior Lamps Bulb 10W 1
Puddle Lamps LED* LED*
* select models only, subject to LED serviceability
2.5 Fuses and Relays
A fuse is the most common electric protection device. The fuse is placed in an
electrical circuit, so that when current flow exceeds the rating of the circuit/fuse, it
blows off. The element in the fuse melts, opening the circuit and preventing other
components of the circuit from being damaged by the over current. The size of the
metal fuse element determines the rating. Once a fuse blows off, it must be replaced
with a new one.
Switch the ignition and all electrical equipment OFF before touching or attempting to
change a fuse.
Replacement fuse must be with the same rating as the one you have removed.
You can identify a blown fuse by a break in the filament. All fuses except high
current fuses are press fit.
Never touch fuses with bare hands. Always use a fuse puller to remove and
refit the fuses. The fuse puller is available in the IP fuse box.
Be careful while removing the relay, do not shake or apply excessive force to
avoid damage to relay terminal.
W12B05
Three fuse boxes in the vehicle;
• Battery Mounted Fuse Box
• Engine Compartment Fuse Box
• Instrument Panel Fuse Box
GENERAL

© Copyright Mahindra & Mahindra Ltd. 082014 2-7
2.5.1 Engine Compartment Fuse Box
W12B31
W12B06
The engine compartment fuse box is located adjacent to vehicle battery. Follow the
below steps to remove the fuse cover;
• Slightly press/nudge the fuse cover towards the vehicle LHS and remove the left
snap lock
• Further, push top cover towards vehicle RHS and remove/pull the cover
completely
W12B07
SPARE
FUSE
CAB BATT-2
60A
ABS
MOTOR
40A
EMS MAIN
RELAY I / P
30 A
STARTER
SOLENOI D
60 A
EC MI NI
FUSE B+
60 A
FUEL
PUMP
RELAY
GNS
RELAY
SPARE
HORN 15A
A/C RELAY/ GNS
10A
CBSB/WIF/ ES S
5A
SPARE
EGR/FMU/BPA
15A
FRONT F OG LAMP
15A
EMS BATT- 2
10A
LOWBEAM
15A
EMS BATT- 1
10A
HIGH BEAM 15A
SPARE
HFM 10A
AC COMP
CLUTCH 15A
BRAKE S WI TCH
15A
ABS/CONDENSOR
FAN 30 A
CONDENSOR
FAN
RELAY
STARTER
RELAY
COOLING
FANHIGH
RELAY
COOLING
FANLOW
RELAY
HORN
RELAY
HIGH
RELAY
LOW
RELAY
FOG
RELAY
AC
COMP
RELAY
SPARE
RELAY
SPARE
RELAY GNS
RELAY
CAB BATT-1
60A
CAB BATT- 3
60A
SPARE
FUSE
SPARE
FUSE
SPARE
FUSE
SPARE
FUSE
SPARE
FUSE
SPARE
FUSE
ECU/
SPARE
RELAY
ECU/
SPARE
RELAY
BEAM LAMP
BEAM
1 2 3 4 5 6 7 4546
4443
3738
3940
33
4142
3231
1516171819202122
3029282726252423
34
3536
8 9 1011121314
W12B34
Fuse No Fuse Rating Circuit
1 60A Battery — 3
2 40A ABS
3 60A Starter Solenoid
4 30A EMS Relay
5Spare Fuse
6Spare Fuse
7Spare Fuse
8 60A Battery — 1
GENERAL
