Majestic 24VFSC User manual

VENT-FREE FIREPLACE SYSTEMS
INSTALLATION AND OPERATING INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
MODELS
24VFSC
24DBXC*
32VFSC**
Natural Gas or
Propane/LPG
Manual or Milli-Volt
*Thermostat Control Only
•• Milli-Volt Only
This is an unvented gas-red heater. It
uses air (oxygen) from the room in which
it is installed. Provisions for adequate
combustion and ventilation air must be
provided. See page 9.
WARNINGS
If the information in this manual is not followed
exactly, a re or explosion may result causing
property damage, personal injury or loss of
life.
– Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any other
appliance.
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the re
department.
– Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.

2 33D4051
CONTENTS
Important Safety Information .....................................3
Product Features .......................................................5
Product Features and Specications .........................6
Getting Started ..........................................................7
General Installation Information ................................8
Location of Fireplace ..............................................16
Clearances and Height Requirements ....................17
Fireplace Framing ...................................................18
Connecting the Gas ................................................20
Checking Gas Pressure ..........................................21
Electrical Wiring (Milli-volt) ......................................22
Log Placement ........................................................24
Flame Appearance .................................................26
Installing Rock Wool and Checking Burner Flame ..27
Operating Instructions ............................................29
For Your Safety Read Before Lighting ...............29
Manual Control Lighting Instructions ................30
Thermostat Control Lighting Instructions ..........31
Milli-Volt Control Lighting Instructions ..............32
Match Lighting Instructions ...............................33
Cleaning and Servicing ...........................................34
Blower and Optional Equipment ..............................34
Illustrated Parts
Cabinet Accessories ..........................................35
DFX24C Milli-Volt, DFX24C Manual..................36
DFX32C Milli-volt, DFX32C Manual ..................39
DBX24C T-stat ..................................................40
Troubleshooting ......................................................42
Warranty .................................................. Back Cover
24VFSC and 32VFSC gas log appliances described in this manual feature the
TRIPLE PLAY BURNER SYSTEM® technology
with exclusive triple effect technology
producing a full random yellow ame, full depth ember bed and glowing logs.

33D4051 3
9. This unit complies with ANSI Z21.11.2 unvented heaters
standard.
10. Do not install the VFS Model in a bathroom or bedroom.
The DBX Model may be installed in a bedroom, but not
in a bathroom.
11. Correctinstallationoftheceramicberlogs,properloca-
tionoftheheater,andannualcleaningarenecessaryto
avoidpotentialproblemswithsooting.Sooting,resulting
from improper installation or operation, can settle on sur-
facesoutsidethereplace.Seelogplacementinstructions
for proper installation.
12. Avoidanydraftsthatalterburneramepatterns.Donot
allowfanstoblowdirectlyintoreplace.Donotplace
ablowerinsideburnareaofrebox.Ceilingfansmay
createdraftsthatalterburneramepatterns.Sootingand
improperburningwilloccur.
13. CAUTION: Candles, incense, oil lamps, etc. produce
combustionby-productsincludingsoot.Vent-freeappli-
anceswillnotlterorcleansootproducedbythesetypes
of products. In addition, the smoke and/or aromatics
(scents) may be reburnt in the vent-free appliance which
can produce odors. It is recommended to minimize the
use of candles, incense, etc. while the vent-free appliance
is in operation.
14. Anunventedgas-redheaterusesair(oxygen)fromthe
room in which it is installed. Provisions for adequate
combustion and ventilation air must be provided. See
installationguidelines.
IMPORTANT
Read these instructions carefully before installing or trying to operate a vent-free gas heater in this rebox.
IMPORTANT SAFETY INFORMATION
1. Due to high temperatures, the appliance be
locatedoutoftrafcandawayfromfurnitureand
draperies.
2. Children and adults should be alerted to the hazard
ofhighsurfacetemperatureandshouldstayaway
toavoidburnsorclothingignition.
3. Youngchildrenshouldbecarefullysupervisedwhen
they are in the same room with the appliance.
4. Donotplaceclothingorotherammablematerial
on or near the appliance.
5. Anysafetyscreenorguardremovedforservicing
anappliance, mustbereplacedpriortooperating
the heater.
6. Installationandrepairshouldbedonebyaqualied
service person.
7. Topreventmalfunctionand/orsooting,anunvented
gas heater should be cleaned before use at least
annually by a professional service person. More
frequentcleaningmayberequiredduetoexcessive
lint from carpeting, bedding material, etc. It is
imperative that control compartments, burners and
circulatingairpassagewaysbekeptclean.
8. CARBON MONOXIDE POISONING: Earlysignsof
carbonmonoxidepoisoning aresimilarto theuwith
headaches, dizziness and/or nausea. If you have these
signs,obtainfreshairimmediately.Havetheheaterser-
vicedasitmaynotbeoperatingproperly. Continued on page 4
WARNING
• Any change to this heater or its controls can be dangerous.
• Improper installation or use of the heater can cause serious injury or death from
re, burns, explosion or carbon monoxide poisoning.
• Do not allow fans to blow directly into the replace. Avoid any drafts that alter burner
ame patterns.
• Do not use a blower insert, heat exchanger insert or other accessory, not approved
for use with this heater where applicable.
INSTALLER
Please leave these instructions with the appliance.
OWNER
Please retain these instructions for future reference .

4 33D4051
IMPORTANT SAFETY INFORMATION
This appliance may be installed in an aftermarket,
permanently located, manufactured (mobile)
home, where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases.
15. Keep room area clear and free from combustible materi-
als,gasolineandotherammablevaporsandliquids.
16. Unvented gas heaters are a supplemental zone heater.
They are not intended to be a primary heating appli-
ance.
17. Unventedgasheatersemitmoistureintothelivingarea.
Inmosthomesofaverageconstruction,thisdoesnotpose
a problem. In houses of extremely tight construction,
additional mechanical ventilation is recommended.
18. Duringmanufacturing,fabricatingandshipping,various
components of this appliance are treated with certain oils,
lmsorbondingagents.Thesechemicalsarenotharmful
butmayproduceannoyingsmokeandsmellsastheyare
burnedoffduringtheinitialoperationoftheappliance;
possiblycausingheadaches,oreyeorlungirritation.This
is a normal and temporary occurrence.
The initial break-in operation should last two to three
hours with the burner at the highest setting. Provide
maximumventilationbyopeningwindowsordoorsto
allowodorstodissipate.Anyodorsremainingafterthis
initialbreak-inperiodwillbeslightandwilldisappear
with continued use.
19. Input ratings are shown in BTU per hour and are for
elevations up to 2,000 feet. For elevations above 2,000
feet,inputratingsshouldbereduced4percentforeach
1,000 feet above sea level. Refer to the National Fuel Gas
Code.
20. Theapplianceanditsappliancemaingasvalvemustbe
disconnectedfromthegassupplypipingsystemduring
anypressuretesting ofthat systemattest pressuresin
excessof1/2psig(3.5kPa).
21. Theappliancemustbeisolatedfromthegassupplypiping
systembyclosingitsequipmentshutoffvalveduringany
pressuretestingofthegassupplypipingsystemattest
pressuresequaltoorlessthan1/2psig(3.5kPa).
22. Do not use this room heater if any part has been under
water.Immediatelycallaqualiedservicetechnicianto
inspect the room heater and to replace any part of the
controlsystemandanygascontrolwhichhasbeenunder
water.
23. Neverburnsolidfuelsinareplacewhereaunvented
room heater is installed.
24. Alwayshaveareplacescreeninplacewhentheappli-
ance is in operation, and unless other provisions for
combustion air are provided, the screen shall have an
opening(s)forinductionofcombustionair.
25. Donotllspacesaroundthereboxwithinsulationor
other materials. These spaces must be maintained to pre-
ventthereboxfromcomingincontactwithcombustible
materials.

33D4051 5
Piezo
Ignition
Fireplace Screen
Control
Knob
PRODUCT FEATURES
Yourvent-freereplacemustbemountedontheoororontheoptionalreplacehearth.
OPERATION
Thisunventedgasheaterrequiresnooutsideventingandburnscleanlywithhighheatingefciency.
Thiszero-clearanceunventedgasheatercanbeinstalledagainst(orrecessedinto)anywallthatisaccessibletoagasline.
Figure 1 - Unvented Gas Heater
(Control Access Door Shown Open)
On/Off
Switch

6 33D4051
NATURAL GAS
Manual and T-Stat Pressure
Regulator Pressure Setting 4 in. w.c.
Gas Inlet Pressure: Max. 10.5 in. w.c.
Min. 5 in. w.c.
PRODUCT FEATURES and SPECIFICATIONS
IGNITION CONTROLS
Piezoignitorallowsignitionofthepilotwithouttheuseofmatchesorbatteries.
Manual control has four (4) positions:
OFF - Allgastothegaslogsisshutoffatthevalve.
IGN - Valvepositiontolight/maintainastandingpilot.
ON - ValvepositiontoturnON/OFFlogsetwithremoteswitch/thermostat.
LOW/HI - Variablepositiontocontrolameheight(heatoutput).Bothfrontandrearburnersareinoperationto
providerealisticglowandyellowame.
Thermostat control has three (3) positions:
OFF - Allgastothegaslogsisshutoffatthevalve.
IGN - Valvepositiontolight/maintainastandingpilot.
LOW/HI - Variablepositioncorrespondingtodesiredtemperature.
Continued
Model Number Type Gas Rate Number of
Burners
Max BTU/Hr Min BTU/Hr
24VFSPMC Manual 22,000 17,000 1
24VFSPVC Milli-Volt 22,000 17,000 1
32VFSPVC Milli-Volt 26,000 20,000 1
24DBXPTC T-Stat 10,000 — 1
Milli-Volt Pressure
Regulator Pressure Setting 3.5 in. w.c.
Pilot Regulator 3.5 in. w.c.
Gas Inlet Pressure: Max. 10.5 in. w.c.
Min. 5 in. w.c.
PROPANE / LPG
Note: An external regulator is required to reduce supply pressure to a maximum of 13" w. c.
T-Stat, Manual and Milli-Volt Pressure
Regulator Pressure Setting 10 in. w.c.
Gas Inlet Pressure: Maximum 13 in." w.c.
Minimum 11 in. w.c.
Model Number Type Gas Rate Number of
Burners
Max BTU/Hr Min BTU/Hr
24VFSNMC Manual 22,000 15,000 1
24VFSNVC Milli-Volt 22,000 17,000 1
32VFSNVC Milli-Volt 26,000 20,000 1
24DBXNTC T-Stat 10,000 — 1

33D4051 7
PILOT
Thegaslogheateristtedwithaspeciallydesignedsafetypilotlightwhichsensestheamountofoxygenavailableinthe
roomandshutsthegaslogheateroffiftheoxygenlevelbeginstodropbelowasatisfactorylevel.Thepilotcanonlyberelit
when adequate fresh air is available.
THERMAL GENERATOR
The milli-volt gas log pilot is tted with a milli-volt generator to provide power for remote activation.
GETTING STARTED
Make sure you have received all parts:
Checkyourpackinglisttoverifythatalllistedpartshavebeenreceived.Youshouldhavethefollowing:
 • Unventedgasheater •Two(2)90°-anglebrackets • Trimkit
 • Installation/operatinginstructions •Canopyandthree(3)screws • Two(2)anchoringscrews
 • Ceramicberlogs •Four(4)blackscrews
MillivoltcontrolledheaterdesignedtobeoperatedwithoptionaldevicesforON/OFFfunctions.
 • HandheldRemotewithreceiver • WallT-statwith20'wire
 • Wallswitchwith20'wire • HandheldThermostatRemotew/receiver
PRODUCT SPECIFICATIONS and GETTING STARTED
Carefullyinspectthecontentsforshippingdamage.Ifanypartsaremissingordamaged,immediatelyinformthedealer
from whom you purchased the appliance. Do not attempt to install any part of the appliance unless you have all parts
in good condition.
Whatyouwillneedforinstallation:
Youmusthavethefollowingitemsavailablebeforeproceedingwithinstallation:
 • Externalregulator(forpropane/LPGonly) • Manualshutoffvalve
 • Pipingwhichcomplieswithlocalcodes • Sedimenttrap
• Phillips head screwdriver • Tee joint.
 • Pipesealantapprovedforusewithpropane/LPG • Pipewrench
(Resistant to sulfur compounds)
CAUTION
• Handle the gas log burner assembly by the grate only. Do not pick the unit up by
the burners.
• Gloves are recommended when handling ceramic ber logs to prevent skin irritation
from loose bers. Logs are fragile — handle with care.
Milli-Volt control has four (4) positions:
OFF - Allgastothegaslogsisshutoffatthevalve.
IGN - Valvepositiontolight/maintainastandingpilot.
ON - ValvepositiontoturnON/OFFlogsetwithremoteswitch/thermostat.
LOW/HI - Variablepositiontocontrolameheight(heatoutput).Bothfrontandrearburnersareinoperationto
providerealisticglowandyellowame.

8 33D4051
Inplanningtheinstallationforthereplaceitisnecessarytodeterminewheretheunitistobeinstalledandwhetheroptional
accessoriesaredesired.Gassupplypipingshouldalsobeplanned.Thefollowingstepsrepresentthenormalsequenceof
installation.Eachinstallationisunique,however,andmightrequireadifferentsequence.
 1.Positionreplaceindesiredlocation.SeetheLocation of Fireplace and Clearances and Height Requirements, and
Firebox Framing sections found in this manual.
Note: Be sure all packing material has been removed from underside the unit.
2.Installcanopyandlogsperinstructionsfoundinthismanual.ThecanopyMUSTbeinstalledforsafeoperationofthe
unit.
3. Field wire main power supply to units with fan kit. See the Electrical Section found in this manual. (Electrical connec-
tionsshouldonlybeperformedbyanexperienced,licensedcertiedtradesman).
4. Install optional ON/OFF kit on units with millivolt control. See installation instruc-
tions included with the kit and also See the Electrical Wiring section found in this
manual.
 5.Plumbgasline.SeetheConnecting the Gas section found in this
manual.(Gasconnectionsshouldonlybeperformedbyanexperienced,
licensed/certiedtradesman).
 6.Completenishwallmaterialand/orsurround.
Figure 2 - Firebox Dimensions with Screen and Log Sets Removed
GENERAL INSTALLATION INFORMATION
24VFSC/24DBXC 32VFSC
A14 213/4
B131/8171/2
C117/8133/8
D9 105/8
E21 27
F47/85
G17 201/4
H1 15/8
I221/2283/4
J1 15/8
K241/232
L45/843/4
M101/212
N261/230

33D4051 9
GENERAL INSTALLATION INFORMATION
ADEQUATE COMBUSTION AND VENTILATION AIR
Thisheater shallnotbeinstalledin aconned spaceorunusuallytightconstruction unlessprovisions areprovidedfor
adequate combustion and ventilation air.
TheNationalFuelGasCodedenesaconnedspaceasaspacewhosevolumeislessthan50cubicfeetper1,000BTUper
hour(4.8m3perkw)oftheaggregateinputratingofallappliancesinstalledinthatspace.Anunconnedspaceisdened
asaspacewhosevolumeisnotlessthan50cubicfeetper1,000BTUperhour(4.8m3perkw)oftheaggregateinputrating
ofallappliancesinstalledinthatspace.Roomscommunicatingdirectlywiththespaceinwhichtheappliancesareinstalled,
throughopeningsnotfurnishedwithdoors,areconsideredapartoftheunconnedspace.
UNUSUALLY TIGHT CONSTRUCTION IS DEFINED AS CONSTRUCTION WHERE…
a) wallsandceilingsexposedtotheoutsideatmospherehaveacontinuouswatervaporretarderwitharatingof1perm(6
x1011kgper-pa-sec-m2)orlesswithopeningsgasketedorsealed,and
b) weatherstripinghasbeenaddedonopenablewindowsanddoors,and
c) caulkingorsealantareappliedtoareassuchasjointsaroundwindowsanddoorframes;betweensoleplatesanddoors;
betweenwall-ceilingjoints;betweenwallpanels;atpenetrationsforplumbing,electrical,andgaslines;andatother
openings.
CODES
Adheretoalllocalcodesor,intheirabsence,thelatesteditionofTHENATIONALFUELGASCODEANSIZ223.1or
NFPA54 which can be obtained from…
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
or
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269
WARNING
Do not install the heater
• where curtains, furniture, clothing, or other
ammable objects are less than 42" from the front
of the heater.
• in high trafc areas.
• in windy or drafty areas.

10 33D4051
GENERAL INSTALLATION INFORMATION
Figure 3 - Sample Room for Determining the Maximum Heater Rating
WARNING
If the area in which the heater may be operated is smaller than that dened as an
unconned space or if the building is of unusually tight construction, provide adequate
combustion and ventilation air by one of the methods described in the National Fuel
Gas Code, ANSI Z223.1, 1992, Section 5.3 or applicable local codes.
Thefollowingformulacanbeusedtodeterminethemaximumheaterratingperthedenitionofunconnedspace:
BTU/Hr =
(L1 + L2) Ft x (W) Ft x (H) Ft. x1000 BTU/Hr
50
Considertwoconnectingroomswithanopenareabetween,withthefollowingdimensions:
L1= 151/2Ft.,L2=12Ft.,W=12Ft.,H=8Ft.
BTU/Hr = (151/2 + 12) x (12) x (8) x1000=52800 BTU/Hr
50
If there were a door between the two rooms the calculation would be based only on the room with the heater.
BTU/Hr = (151/2) x (12) x (8) x1000=29760 BTU/Hr
50

33D4051 11
GENERAL INSTALLATION INFORMATION
INSTALLING OPTIONAL FIREBRICK PANELS
1. Removeoptionalrebrickpanelsfrompackaging.ChecktoSeethatyouhavethefollowing:
•3rebrickpanels •two(2)retainerbrackets •two(2)blackscrews
 Ifanypartorpartsaremissing,contactdealerwhereyouboughtreplace.
2. Turnoffreplaceandallowtocool.
3. Remove replace screen (See Figure 14, page 14) andlogs.
4. Place rear rebrick panel on back wall of rebox. Set bottom of panel behind the bracket tabs of the grate. See
Figure 4.
5. Placeoneofthesiderebrickpanelsincabinet.Lineuptheholeintheretainerclipwiththeholeinsidetherebox.
UsingPhillipsscrewdriver,attachtheretainerbrackettoinsideofrebox.See Figure 5.
6. Repeatstepvefortheotherrebricksidepanel.
Figure 4 - Installing Back Firebrick Panel
Figure 5 - Installing Side Firebrick Panel
Bracket
Tabs
Rear
Firebrick
Panel
Retainer
Clip
Side Firebrick
Panel Screw
Hole

12 33D4051
GENERAL INSTALLATION INFORMATION
BLACK TRIM INSTALLATION (24VFSC/24DBXC)
1. Remove black trim from protective packaging. Remove four (4) black screws and 2 (two) 90°-angle trim
brackets from owner’s manual packaging.
2. Lay trim on oor and match corners of side trims to top trim (See Figure 6).
3. Useone90°-angletrimbrackettojointhecornerofonepieceofsidetrimtothecornerofthetoptrimpiece(See Figure
6). A rubber hammer or handle of a claw hammer will help secure the corners.
4. Repeat for other side.
NOTE: If you do not attach the trim at the correct corners, use a hammer and screwdriver to tap on
the one end of the 90°-angle bracket. This will separate the two pieces of trim (See Figure 8).
5. Placeassembledblacktrimonfrontofheater.Usingfour(4)blackscrews,secureblacktrimtosidesofheater(See
Figure 8).
Figure 6 - Matching and Joining Corners of Black
Trim with 90°-angle Trim Brackets
Figure 7 - Removing the 90°-angled Trim Bracket
Figure 8 - Attaching Assembled Black
Trim to Heater
Matched Corners
90°-angle Trim Brackets
Assembled
Black Trim
Black Screw
Holes for Black
Screws
Side Trim
Top Trim
90°-angle Trim Bracket

33D4051 13
GENERAL INSTALLATION INFORMATION
45°-angled
Corners
Back of Trim
Assembly
Top Trim Piece
Side Trim Pieces
90°-angled
Shim
90°-angled
Bracket
Outside Corner Slot
Outside
Corner Slot
Bracket
Screws
BLACK TRIM INSTALLATION (32VFSC)
1. Removetrimfromprotectivepackaging.Becarefulnot
toscratchthetrim.Removetwo(2)90°-angledmounting
bracketsandtwo(2)90°-angledshims.
2. Laytrimfacedownontheoor.Lineupthe45°-angled
cornersofthetoptrimwiththe45°-angledcornersofthe
side trims.
Note: Both ends of the top piece of trim are
mitered. See Figure 9.
3. Slideone(1)90°-angledbracket(withattachedscrews)
andone(1)90°-angledshimintheoutsidecornerslot
where the top and side trims meet. See Figure 10.
4. Holdthecorners together securely.Tighten screws on
bracketwithatheadscrewdriver.Makesurethecorners
areushandtherearenospaces.Do not over tighten
screws. See Figure 11.
5. Repeat for other side trim.
6. Slide assembled trim over the top and down the sides of
thereplace.Flushtrimwithfrontofreplaceasshown
in Figure 12.
7. Alignholesinassembledtrimwithholesinsideofre-
place.UsingaPhillipsscrewdriver,attachtrimwithfour
(4)screws provided—twoforeach sideof replace.
Tightensnuggly.See Figure 13.
Figure 10 - Securing Corners Together
Figure 11 - Making Sure Corners Are Flush
Assembled Trim
No Spaces
where
Corners Join
Figure 13 - Securing Trim to Heater with Four (4)
Screws Provided
Screws
Screw
Screw
Figure 12 - Sliding Assembled Trim Over the Top
of the Heater
Figure 9 - Lining Up Corners of Trim Kit
Trim Flushed
with Front of
Fireplace
Holes

14 33D4051
REMOVING SCREEN
1. Remove bottom louver. See Figure 14.
2. Removingreplacescreenframepanelbypushingscreenframepanelupandout.See Figure 14.
GENERAL INSTALLATION INFORMATION
Figure 15 - Canopy Installation
INSTALLING CANOPY
1. Push louvers up and out to remove top louver assembly.
2. Aligntheblackcanopywiththeholesinthetopframeassembly.See Figure 15.
3. Installthe three(3)screws(inowner’smanual packaging)whichattachthecanopytothe topframe assembly.See
Figure 15.
4. Tightenallscrews.Makesurethecanopyislevelandsecure.Installtoplouverassembly.
Figure 14 - Removing Fireplace Screen Frame Panel
NOTE: Fireplace screen must be removed to access log box and to install canopy.
Canopy
Fireplace
Screen
Canopy
Screws
WARNING
Do not operate the unit without the
screen frame panel and canopy
installed.
Louver

33D4051 15
GENERAL INSTALLATION INFORMATION
SECURING HEATER TO FLOOR OR HEARTH
Note: Clearance requirements as detailed in “CLEARANCES and HEIGHT REQUIREMENTS” section on
page 17 of this manual, must be met before securing the heater in place.
Topreventmovement,theheatermustbesecuredtotheoororhearth.
1. Open the control access door and remove the screen.
2. Removecartoncontainingthefour-logset.
3. To remove the grate and base assembly, take out two (2) screws as shown in Figure 16.
4. Liftgrateandbaseassemblyoutoftherebox.
5. Securethereboxwithtwoanchoringscrews(3/16"x11/4"length)suppliedwiththereplacesystem.See Figure 17.
Note: If the unit is mounted on carpeting, tile or combustible material without the hearth, a metal or wooden
base covering the entire width and depth of the base must be installed.
Figure 16 - Removing Grate Figure 17 - Securing Heater to Floor or
Hearth
Grate
Screws
3/16" x 1 1/4"
Anchor Screws

16 33D4051
LOCATION OF FIREPLACE
Carefullyselectthebestlocationfor installationofyour unventedreplace.Thefollowingfactorsshouldbetakeninto
consideration.
• Clearancetosidewall,ceiling,woodworkandwindoworothercombustibles.SeeClearances and Height Requirements
section on page 17. Minimum clearances to combustibles must be maintained.
• Locationmustnotbeaffectedbydraftscausedbykitchenexhaustfans,ceilingfans,returnairregistersforforcedair
furnaces/air conditioners, windows or doors.
• Installation must provide adequate ventilation and combustion air.
• DO NOT INSTALL THE VFS MODEL IN A BEDROOM OR BATHROOM.
THE DBX MODEL MAY BE INSTALLED IN A BEDROOM, BUT NOT IN A BATHROOM.
• Locationshouldbeoutofhightrafcareasandawayfromfurnitureanddraperiesduetoheatfromrebox.
• Neverobstructthefrontopeningoftheunventedreplaceorrestricttheowofcombustionandventilationair.
• Minimizemodicationstoexistingconstruction.See Figure 18 belowforlocationsuggestions.
• Donotinstallinthevicinitywheregasolineorotherammableliquidsmaybestored.Theunventedreboxmustbe
kept clear and free from the combustible materials.
Figure 18 - Suggested Locations

33D4051 17
9"
Minimum
42"
Minimum
9"
Minimum
12"
2 1/2"
10"
19"
CLEARANCES and HEIGHT REQUIREMENTS
Figure 20 - Minimum Mantel Clearances
Canopy
Ensure that minimum clearances shown in Figures 14 and 15 aremaintained.Leftandrightclearancesaredeterminedwhen
facingthefrontoftherebox.
Follow these instructions carefully to ensure safe installation. Failure to follow these requirements may create a re
hazard.
1. Sidewall Clearances — The clearance from the inside of the appliance to any combustible adjacent wall should not
be less than 9" for the 24DBXC/24VFSC and 32VFSC. See Figure 19.
2. Ceiling Clearance —Theceilingmustbeatleast42"fromthetopofthereboxopening.See Figures 19 and 20.
3. Back Wall Clearance —Theappliancemaybeplacedagainstacombustiblebackwall.
4. Floor Clearance —Thereplacemaynotbeinstalledontoanycombustibleooringmaterial,suchascarpeting,vinyl
or tile without the hearth or a min. 22 Ga (0.030") metal or a minimum 1/2"woodenbasecoveringtheentirewidthand
depth of the base. Combustible material must be installed at least 1" away from the front face of the unit.
5. Mantel clearances — The canopy supplied with the unit must be installed. If a combustible mantel is installed. It
must meet the clearance requirements detailed in Figure 20.
Figure 19 - Clearances and Height Requirements for
24VFSC/24DBXC/VFS32
WARNING
The dimensions shown in Figures 19 and 20 are minimum clearances to maintain in
installing this heater. Left and right clearances are determined when facing the front
of the heater.
Follow these instructions carefully to ensure safe installation. Failure to follow
instructions exactly can create a re hazard.

18 33D4051
H
G
D
F
E
A
C
C
G
A1/2" or 5/8"
B
A
1
/ 2 " or
5
/ 8 "
C
A
G
24VFSC 24DBXC 32VFSC
A243/4243/4321/2
B263/4263/4301/4
C14 14 213/4
D101/2101/2141/2
E421/2421/2533/4
F21 21 263/4
G101/2101/2121/4
H30 30 38
FIREPLACE FRAMING
Ifunitistobe“builtin”,replaceframingcanbebuiltbeforeoraftertheapplianceissetinplace.BE SURE THAT ALL
PACKING MATERIAL HAS BEEN REMOVED FROM THE UNDERSIDE OF THE UNIT PRIOR TO SETTING
THE FIREBOX IN PLACE. ConstructreplaceframingfollowingFigures 21 through 24. See Figure 2 on page 8 for
replacedimensions.Theframingheadersmayrestdirectlyontopoftherebox.
Thereplacemaybeinstalleddirectlyonacombustibleoororaraisedplatformofanappropriateheight.Donotplace
replaceoncarpeting,vinyl,tileorothersoftoorcoverings.Itmay,however,beplacedonatwood,plywood,particle
boardorotherhardsurfaces.Besurereplacerestsonasolidcontinuousoororplatformwithappropriateframingfor
supportandsothatnocoldaircanenterfromundertherebox.
Anchorreplacetothesideframingmembersusingnailinganges.
Figure 21 - Corner Installation
Figure 22 - Inside Chase Installation
Figure 24 - Recessed Installation
Figure 23 - Stud Location
Unnished/rough
framing surface
Unnished/rough
framing surface
Unnished/rough
framing surface
5/8" or equivalent
clearance for
drywall/nishing
materials
5/8" or
equivalent
clearance
for drywall/
nishing
materials

33D4051 19
H
J
Nail Sides
Through Nailing
Flanges
1. Bendoutthenailingangeslocatedoneachsideoftherebox.
 2. Slidethereboxintopreparedframingorpositionreboxinitsnalpositionandframelater.
 3. Levelthereboxbycheckingthetopedgeoftherebox.Shimifnecessary.
 4. Anchorreboxtothesideframingmembersusing8dnailsorothersuitablefasteners.See Figure 26.
5. The canopy must be installed for safe operation of the heater. See page 14 for canopy installation details.
Whennishingacustomcabinet,mantel,orotherbuilt-inenclosure,
theopeningsizetoaccommodatethereplacewithtriminstalledis
as follows:
FIREPLACE FRAMING
24VFSC w/ trim 24DBXC w/ trim 32VFSC w/trim
H25 " 25" 3213/16 "
J263/4 "263/4 "311/4 "
Figure 25 - Custom Cabinet
Figure 26 - Location of Nailing Flanges
WARNING
The replace must be installed giving full
consideration to the clearance and height
requirements identied in this manual.

20 33D4051
Pipe Coupling
To Heater
Valve
3"
Minimum
CAUTION
CONNECTING THE GAS
NOTICE: A qualied gas appliance installer must connect the heater to the gas supply. Consult all local
codes.
IMPORTANT: Loosenthepipeadapterontheextubebeforeinstallingtothesystempiping.
CHECK GAS TYPE: Thegassupplymustbethesameasstatedontheheater’sratingplate.Ifthegassupplyisdifferent,
DO NOT INSTALL THE HEATER. Contact your dealer for the correct model.
Always use an external regulator for all propane/LPG heaters only,toreducethesupplytankpressuretoamaximum
of13"w.c.Thisisinadditiontotheinternalregulatorintheheatervalve.
Manual Shutoff
Valve
Pipe
Tee Joint
Sediment Trap Pipe Nipple
Cap
Stainless
Flexible Tube
Figure 27 - Gas Connection
CAUTION
Use new black iron pipe, steel pipe, copper tubing or internally tinned copper tubing.
Internally tinned copper tubing can only be used per National Fuel Code, section 2.6.3,
providing gas meets sulde limits, and where permitted by local codes. Gas piping
system must be sized to provide minimum inlet pressure (listed on Data Plate) at the
maximum ow rate (BTU/Hr). Undue pressure loss will occur if the pipe is too small.
A manual shutoff valve must be installed upstream of the appliance. Union tee and
plugged 1/8" NPT pressure tapping point should be installed upstream of the appliance.
See Figure 27.
A sediment trap should be installed upstream to prevent moisture and contaminants
from passing through the pipe to appliance controls and burners. Failure to do so
could prevent the appliance from operating reliably. See Figure 27.
