ELF50CW
50Watt LED Floodlight
INSTRUCTION MANUAL
Attention: Please read the following instructions carefully to ensure that installation will be
carried out in the right way .These instructions should be properly preserved for future
reference.
Product Overview:
IP65 LED ELF50CW floodlight have a 50 Watt high power LED Chip capable of producing
2500Lm designed as a replacement of traditional floodlights. The glass cover is 4mm
strengthen clear glass which is fully waterproof and resistant to all environmental factors. The
lighting source inside is made up from single or multiple high power LED's, which in turn are
directly connected with the aluminium shell. The design ensures very low heat emissions and
has a much longer lifespan. The ELF50CW offer a cool and pure light for improved visibility.
ELF50CW LED Floodlights are widely used in and around tunnels, gas stations, airports, large
stores, billboards, railway stations, public areas, industrial areas, indoor parking places and
domestic use.
Features:
Die-cast aluminium body:
Durable material for lighting purposes.
Resistant to rust and other harmful elements.
Aluminum provides a good heating facility for thermal applications and to ensure a longer
lifespan.
Super bright illumination.
Easy Installation:
Perfect for indoor and outdoor use.
Easy to install and cost efficient.
Environmentally friendly.
Bracket can be mounted vertically or horizontally.
Adjustable stand lets you point out the light at different angles, perfect for garden or
swimming pool areas.
Specifications:
Type
Rated Power
Tempered Glass
Weight
Maximum
projected area
Dimensions
Remark
ELF50CW
50W（1x50W）
280x228x4mm
4.0Kg
0.06M2
287x256x157mm
Electric shock protection class:Ⅰ
External light protection class:
IP65
Lamp socket size: LED
Rated voltage:220-240V~ 50Hz
Max height：<3M
Universal for operating position
IEC 60598-2-5 and/or EN 605982--5
Power source: 100VAC~240VAC
Housing : Die-casting aluminium
IP65
Luminous flux : 2 500 lumens
Frequency : 50Hz
Power : 50W
Beam angle: 120°
Max height: 3m
Safety instructions:
1. Before mounting and maintenance please make sure that the electrical supply has been
switched off to avoid electric shock.
2. The light must be earthed.
3. The power cord must be H05RN-F 3x 1.0 mm ² cable waterproof.
4. Replace the cracked protection glass immediately and use only original parts to substitute.
5. Connect the yellow/green conductor of the connection supply cable with the connection
block, marked with the earthings symbol. Mount the other wires into the connector
block .see mark N and L
6．Before the maintenance work takes place, the power should be switched off. The
maintaining should be done only by a qualified electrician.
7. The light is only suitable for fixed mounting.
Maintenance:
CAUTION: The light source of lamp can’t be replaced, please replace a whole new lamp if the
light source broken.
MAJOR TECH (PTY) LTD
Head Office:
Cnr Rover & Jaguar Roads, Rustivia Ext 3,
Elandsfontein.
P O Box 888 Isando, 1600 South Africa
Tel: +27 11 822 1551 Fax: +27 11 822 1411
Website: www.major-tech.com
This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent
possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used device, please use the return andcollection systems or contact
the retailer where the product was purchased. They can take this product for environmental safe recycling.
