MAJORITY D40 User manual

USER MANUAL
HOME AUDIO • CAMBRIDGE
D40

EN
2
CONTENTS
Contents ������������������������������������������������������������������������������������������������������������������������ 2
Box Contents ����������������������������������������������������������������������������������������������������������������� 3
Controls & Functions ����������������������������������������������������������������������������������������������������� 4
Setting up your Majority D40 Speakers ������������������������������������������������������������������������� 7
Basic Operation ������������������������������������������������������������������������������������������������������������� 8
Bluetooth, SD & USB Controls���������������������������������������������������������������������������������������� 9
AUX and Optical Modes����������������������������������������������������������������������������������������������� 10
Bluetooth Mode ����������������������������������������������������������������������������������������������������������� 11
USB & SD Card Mode��������������������������������������������������������������������������������������������������� 12
Connecting Headphones ��������������������������������������������������������������������������������������������� 13
Troubleshooting ���������������������������������������������������������������������������������������������������������� 14
Spec & Warranty ���������������������������������������������������������������������������������������������������������� 15
Safety Information������������������������������������������������������������������������������������������������������� 16
Register your product online for a FREE 3 year
extended warranty at: www.majority.co.uk
3YEAR
WARRANTY

EN
3
BOX CONTENTS
WHAT’S IN THE BOX
A
B C
D
E
F
A. Majority D40 Bookshelf Speakers
B. 3.5mm to 3.5mm AUX Cable
C. 3.5mm to RCA Cable
D. Instructions Guide
E. Remote Control
F. Power Adapter

EN
4
CONTROLS & FUNCTIONS
7
3
4
5
6
2
1
1. Remote Sensor 2. Speakers
FRONT VIEW
SIDE VIEW
3. Mode
4. Vol + / Next
5. Vol - / Previous
6. Headphone Jack
7. Mode indicator lights

EN
5
CONTROLS & FUNCTIONS
8
9
10
11
12
13
1415
8. Speaker connector cable
9. Speaker input
10. OPTICAL input
11. Power On/Off
12. 100--240V/50-60HZ Power
13. USB slot
14. SD Card slot
15. AUX input
BACK VIEW

EN
6
CONTROLS & FUNCTIONS
17
18
19
20
21
23
24
28
27
25
22 26
16
16. Power
17. Reset
18. Vol +
19. Play/Pause
20. Previous/Back
21. Vol -
22. Treble -
23. Bass -
24. Mode
25. Bass +
26. Treble +
27. Next
28. Mute
REMOTE CONTROL

EN
7
SETTING UP YOUR MAJORITY D40 SPEAKERS
Please note that the instructions in this manual will refer to the speaker or remote
control button number e.g (Ref.*number*) in accordance with the diagrams on pages
2-4.
Connecting and powering the unit
Using the power cord provided, plug one end into the back of the primary speaker
(Ref.12) and plug the other end into a mains socket. Switch the unit on at the back of
the primary speaker (Ref.11).
Connect the two speakers together via the speaker connector cable (Ref.8) by
plugging the connector cable into the speaker input of the primary speaker (Ref.9).
Switch on your Majority D40 Speakers
Press the ⏻button (Ref.16) or press and hold the ‘Mode’ button on the unit (Ref.3) to
switch on the speakers. Press the ⏻button (Ref.16) to switch the speakers off.
Remote Power
Remove the battery cover of the remote control. Insert 1 x AAA battery (included).
Replace battery cover.
Note: when using the remote control, ensure that you are pointing at the remote sensor
(Ref.1) otherwise the unit may not respond to keypresses.

EN
8
BASIC OPERATION
Basic controls
Volume, treble and bass can be changed on all speaker modes.
Use the 🔈+ (Ref.18)/(Ref.4) and 🔈- (Ref.21)/(Ref.5) buttons to control the volume.
Press 🔈X (Ref.28) to mute the audio.
Use the Treble- (Ref.22), Treble+ (Ref.26), Bass- (Ref.23) and Bass+ (Ref.25) to control
the bass and treble settings of the sound. Press ‘RESET’ (Ref.17) to reset the treble
and bass settings.
In Bluetooth, SD, or USB mode, use the ⏴ ⏵ (Ref.20)/(Ref.27) and -/⏮+/⏭ buttons
(press and hold (Ref.4)/(Ref.5)) to skip tracks and rewind or fast forward (see page 7).
Switching mode
When a USB, SD card or AUX cable is inserted, the unit will automatically switch to the
correct mode and begin playing audio. If necessary, select the correct mode using the
‘Mode’ button (Ref.24)/(Ref.3).
On the speaker set, Bluetooth and USB modes are indicated by a blue light. All other
modes are indicated by a red light (Ref.7).

EN
9
BLUETOOTH, SD & USB CONTROLS
Please note that the following controls and functions relate to Bluetooth, SD card and
USB mode only. For AUX and Optical controls and functions, please see the section
‘AUX and Optical Modes’ (page 8).
Note: in the table below, (H) = ‘Press and hold’.
Remote Speaker Function
🔈- 🔈+-/⏮ +/⏭ Volume up/down
⏴ ⏵ (H) -/⏮ +/⏭ Previous/next track
(H)⏴ ⏵ n/a Rewind/Fast forward
🔈Xn/a Mute
⏯MODE Play/Pause
TRE-/TRE+ n/a Treble up/down
BASS-/BASS+ n/a Bass up/down
MODE (H) MODE Change Mode
RESET n/a Reset Treble/Bass

EN
10
AUX AND OPTICAL MODES
Use the 3.5mm to 3.5mm AUX cable or 3.5mm to RCA cable to connect an external
AUX device to the ‘AUX’ input of the D40 speakers (Ref.15).
Switch to AUX mode
When an AUX cable is plugged in to the AUX port at the rear of the speaker (Ref.15),
the unit will automatically switch to AUX mode (indicated with a red light (Ref.7))
and make 3 short ascending beeps. If necessary, select ‘AUX’ mode using the ‘Mode’
button (Ref.24)/(Ref.3).
Optical mode
To connect the D40 speakers to an external device, use an optical cable to connect via
the OPTICAL input (Ref.10).
Press the ‘Mode’ button (Ref.24)/(Ref.3) to switch the Mode to Optical. The
corresponding mode indicator light (Ref.7) will light up red and make a short sound
when Optical mode is selected.
Controls and Functions - AUX/Optical
Note: in the table below, (H) = ‘Press and hold’.
Remote Speaker Function
🔈- 🔈+-/⏮ +/⏭ Volume up/down
🔈X ⏯MODE Mute
TRE-/TRE+ n/a Treble up/down
BASS-/BASS+ n/a Bass up/down
MODE (H) MODE Change Mode
RESET n/a Reset Treble/Bass

EN
11
To connect an external device to the D40 speakers, ensure that the speakers are
in ‘Bluetooth’ mode. Select ‘Bluetooth’ mode manually by using the ‘Mode’ button
(Ref.24)/(Ref.3) until the corresponding mode indicator light, labelled ‘AUX/BT’, (Ref.7)
lights up blue. The speakers will make a series of short ascending beeps to indicate
that Bluetooth mode is now active.
Switch Bluetooth on for your external device. Select ‘D40’ from the list of devices.
When your external device is connected, the speakers will make a short beep to
indicate successful connection. You can now play audio through the speakers. When
Bluetooth is disconnected, the speakers will sound with 5 short ascending beeps to
indicate successful disconnection.
Controls and Functions
Please see page 7.
BLUETOOTH MODE

EN
12
USB
To use USB mode, insert a USB drive into the USB port at the back of the speaker
(Ref.13). The speakers will sound with 2 short beeps to indicate that USB mode is
active, and the ‘USB/OPT’ mode indicator light (Ref.7) will light up blue. If necessary,
select ‘USB’ mode using the ‘Mode’ button (Ref.24)/(Ref.3).
SD
To use SD mode, insert a SD/TF card into the SD port at the back of the speaker
(Ref.14). The speakers will sound with 3 short beeps to indicate that SD mode is
active, and the ‘SD’ mode indicator light (Ref.7) will light up red. If necessary, select
‘SD’ mode using the ‘Mode’ button (Ref.24)/(Ref.3).
Maximum storage compatibility for USB and SD/TF cards: 64GB.
Controls and Functions
Please see page 7.
USB & SD CARD MODE

EN
13
Connect wired headphones (not included) to the headphone port of the Majority D40
speakers (Ref.6) to listen to audio through headphones.
Ensure the volume is turned down before you use the headphones.
You will now hear audio output through the headphones.
Please note that the Majority D40 is not compatible with Bluetooth headphones.
CONNECTING HEADPHONES

EN
14
Observation Potential Cause/Solution
No power/function
Check whether the power is switched on or off
at the wall.
Check that the power adaptor is properly
connected to the power outlet.
No sound
Check whether unit is set to MUTE.
Check whether MODE is correctly selected.
Turn up the volume on the speakers or on your
external device.
Check that cables are properly installed.
Function disturbance Switch off and unplug the unit. Leave it for 2
minutes and switch it on again.
Bluetooth not connecting
Ensure that you are on Bluetooth mode on the
speaker and the Bluetooth on your device is
switched on. Select the Bluetooth device ‘D40’
and you should now be able to play audio.
TROUBLESHOOTING
SUPPORT
If you require further assistance with your new soundbar, please contact our support
team on the Majority website: www�majority�co�uk/support

EN
15
SPEC & WARRANTY
SPECIFICATION
Power Supply 100-240V/50-60Hz
Mode:
Bluetooth
3.5mm AUX-in
USB reader
SD reader
Power consumption 0.5W (standby mode)
Dimensions 223 x 137 x 179 mm
Weight 3.80 kg
Speakers 2*4” full range + 2 * 1” tweeter
Bluetooth Version 5.0
Bluetooth range up to 10 meters
Compatible le types MP3, WMA, FLAC, MAV, APE
Maximum compatible USB/SD
storage 64GB
WARRANTY
All products come with a standard 12 month warranty. All items must be registered
on www�majority�co�uk for the warranty to be valid. Once on the web page, use the
menu to nd “Register Your Product”. You will also be given the chance to extend your
warranty for an additional 24 months, free of charge.

EN
16
1� Read these instructions�
2. Keep these instructions. Instructions are also availa-
ble for download at www.majority.co.uk
3. Heed all Warnings
4. Follow all instructions
5. Do not clean the apparatus near or with water
6. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions
7. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
8. Protect the power from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
9. Only use attachments/accessories specied by the
manufacturer.
10. Unplug this apparatus during light storms or when
unused for long periods of time.
11. Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in a way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been
exposed to the rain or moisture, does not operate
normally or has been dropped.
12. No naked ame sources, such as lit candles, should
be placed on the apparatus.
13. Dispose of used electrical products and batteries
safely according to your local authority and
regulations.
ADDITIONAL WARNINGS
The apparatus shall not be exposed to dripping or splash-
ing and no objects lled with liquid, such as vases, shall
be places on the apparatus.
Main plug is used to disconnect device and it should
remain readily operable during intended use. In order to
disconnect the apparatus from the main mains complete-
ly, the mains plug should be disconnected from the main
socket outlet completely.
Battery shall not be exposed to excessive heat such as
sunshine, re or the like.
RECYCLING ELECTRICAL PRODUCTS
You should now recycle your waste electrical
goods and in doing so help the environment.
This symbol means an electrical product should
not be disposed of with normal household waste.
Please ensure it is taken to a suitable facility for disposal
when nished with.
IMPORTANT: Please read all instructions carefully before
use and keep for future reference.
Risk of electric shock.
Do not open
Read all instructions carefully before use
and keep for future reference
When servicing, use only identical
replacement parts
ATTENTION
RISQUE D’ELECTROCUTION
NE PAS OUVRIR !
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN !
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN !
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
!
!
!
IMPORTANT: Please read all instructions carefully before use and
keep for future reference
!
SAFETY INFORMATION




HOME AUDIO • CAMBRIDGE
WWW.MAJORITY.CO.UK
Other manuals for D40
1
Table of contents
Other MAJORITY Stereo System manuals

MAJORITY
MAJORITY Fitzwilliam 3 Manual

MAJORITY
MAJORITY OAKINGTON Manual

MAJORITY
MAJORITY SCAFELL PIKE SKP-BAR-BLK Manual

MAJORITY
MAJORITY Humboldt Manual

MAJORITY
MAJORITY QUADRIGA Manual

MAJORITY
MAJORITY HNT-CDAB-BLK User manual

MAJORITY
MAJORITY HUNTINGDON Manual

MAJORITY
MAJORITY CASTLE CB3A-CDAB-WHT Manual

MAJORITY
MAJORITY Castle CB3A-CDAB-BLK Manual

MAJORITY
MAJORITY HOMERTON 2 User manual
