MAJORITY QUADRIGA Manual

Instructions Guide
Internet Radio CD Player
Music System
QUADRIGA

2
Package contents ...........................................................................3
Overview .......................................................................................3
Getting Started ...............................................................................6
Menu Operation .............................................................................9
Internet Radio, Podcasts ...................................................................10
Spotify Connect .................................................................................10
USB Music Player ..............................................................................11
DAB+ Radio ........................................................................................12
FM Radio ...........................................................................................13
CD Player ...........................................................................................14
Bluetooth ..........................................................................................15
AUX in ................................................................................................16
RCA in ................................................................................................16
Optical in ...........................................................................................16
Sleep ..................................................................................................16
Alarm .................................................................................................17
System Settings ..............................................................................17
Equaliser ............................................................................................18
Network .............................................................................................18
Time/Date .........................................................................................19
Language ...........................................................................................19
Factory Reset .....................................................................................19
Software Update ...............................................................................19
Setup Wizard .....................................................................................19
Info ....................................................................................................19
Privacy Policy .....................................................................................20
Backlight ............................................................................................20
Troubleshooting .............................................................................20
Technical Specification ...................................................................22
Disposal .........................................................................................24
Safety .............................................................................................24
Content

3
The items enclosed in the packaging box are as follows:
Quadriga Music System
Power adaptor
Remote control
3.5mm audio cable
Telescope antenna
User manual
Front
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2.8” screen
Colour TFT display
2
CD slot
CD playback
3
Remote control
sensor
Receive remote control signal
4
EJECT button
Eject CD in CD mode
5
AUX jack
3.5mm audio input
6
Headphone jack
3.5mm headphone output
Package Contents
Overview

4
7
ON/Standby / MODE
button
Switch on/Standby the device; Enter the
mode menu
8
REWIND / PREVIOUS
button
Rewind or play previous track
9
NEXT / FAST
FORWARD button
Fast forward or play next track
10
PLAY / PAUSE
button
Play or resume track playback
11
Volume knob / OK /
SCAN button
Rotate to adjust volume or move along the
menu;
Press to OK; Press to scan in FM mode
12
STOP button
Stop playing in CD/USB mode
13
ALARM / BACK
button
Set alarm clock; Return one step under the
menu
14
FAV button
Select favorite stations ; Press and hold to
BT discoverable under BT mode
15
MENU / INFO button
Enter the menu; View the information of
the station or track
Back
16
17
18
19
20
21
16
F- connector
Plug the antenna for enhancing DAB/FM
reception
17
RCA jack
RCA audio input
18
OPTICAL IN jack
SPDIF optical audio input
19
USB port
USB drive music playback
20
ON/OFF switch
Switch on/off the device
21
DC IN
Plug for power support

5
Remote Control
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1
Device power on/off; alarm off
2
MODE
Open, close mode selection
3
MENU/INFO
Press and hold to open menu;
close menu
Display FM mode info
(Name, PTY, RT, frequency)
Display DAB mode info
(Station, track, artist etc.)
Display CD/USB mode info
(Track, artist, etc.)
4
Select previous track, hold
down to seek
5
Start playback, pause
6
EQ
Select equalizer preset
7
Move up; FM: Set frequency
8
Move left, step back
9
Confirm entry; FM: Scan;
Playing: album in full screen
10
Move right, step next
11
Move down; FM: Set frequency
12
Eject the CD
13
FOLDER DOWN
Move down the folder for CD
14
FOLDER UP
Move up the folder for CD
15
Select next track, hold down to
seek
16
Stop music playback
17
Increase volume
18
Decrease volume
19
Mute, unmute
20
Number buttons: retrieve
saved favourite station,
hold down to save station
21
Music: random and repeat
selection
22
FAV
Select favourite stations, hold
down to save favourite
Program the track of CD

6
Press and hold to BT
discoverable
Operating your remote control
Press and slide the back cover to open the battery compartment of the remote
control.
Insert two AAA size batteries. Make sure the (+) and (-) ends of the batteries
match the (+) and (-) ends indicated in the battery compartment.
Close the battery compartment cover.
Connection and Preparation
Connect the power adaptor to the back of device and plug it into power socket. It
starts up after switching on the device.
Connecting the network
•A broadband connection in combination with a wireless access point, router
or similar network device.
•The network device needs to support WiFi (802.11 a/b/g/n) wireless
connection.
Make sure you have setup the wireless network and you have the WEP, WPA or
WPA2 security password to activate the connection. You may also use the WPS
(WiFi Protected Setup) function for easy pairing between the network device and
the radio. Check if the light indicators on the network device are in appropriate
status.
Getting Started

7
Antenna
Plug the antenna to the F-connector. To get good reception for DAB/FM
broadcasting, always extend the antenna with its full length.
First Time Setup
When powering the device on for the first time, first you need to set language.
Selecting the menu language
Rotate the knob to select the menu language you want from the list and press OK
button to confirm.
After language be chosen, it displays information of privacy policy. Press OK
button to continue. Then a setup wizard appears for helping you setup the main
use of the device.
Select “YES” and confirm your will launch the setup wizard.
If you select “NO”, the next window will ask you choose if you want to start the
setup wizard again next time you power the device on.
Setup wizard helps you setup the main use of the device.
Setting date and time - Select “12” for 12-hour display format or “24” for 24-hour
display format. If you select the 12-hour format, the display shows “AM” in the
morning or “PM” in the afternoon after the time.
After this, the following options are available, to define if the time to be
synchronized from radios: Update from DAB, Update from FM, Update from
Network or No update
If you choose “Update from Network” you must indicate your time zone in the
next window.
Next choose “ON” for summer time, otherwise select “OFF”.
If you choose “No update”, you will have to enter the date and time manually.
“AM”/ “PM” displays only if you have chosen the 12-hour time format. Select
“AM” for the morning hours or “PM” for the afternoon hours.
Setting network - Firstly the device asks if keep network connected. If you want
to control the device in all operating modes via the app, select “YES”. If choosing
“NO”, it is not possible to control the device from the app in the (Standby, AUX IN,
FM, DAB) operating modes. Note that the power consumption in standby mode
will be higher when the network connection is kept up.
Any WiFi networks found are listed on the display, along with their names.
After selecting the network, you will be asked for choose one of the following
methods of connection:
o Push button: The device prompts you to press the connect button on the
router. It then scans for a ready Push Button Connect network and connects.

8
o Pin: The device generates an 8-digit code number which you enter into the
wireless router, access point, or an external registrar.
o Skip WPS: Enter key as for a standard encrypted network. To enter the
network’s key, use the reel or direction buttons on the remote control to move
the cursor through the characters and press OK to confirm. As each character is
selected, the key is built up near the top of the display.
There are three options accessible by tuning the navigate reel back before the
first characters –Backspace, OK and Cancel.
For more information on setting up a WPS encrypted network, see your WPS
router’s instructions.
Device attempts to connect to the selected network.
It will show connected if the setup is successful. If connecting fails, it returns to a
previous screen to try again. Once completed, press OK to quit the setup wizard.
Presets
Presets are stored in the radio and cannot be accessed from other radios. Number
of preset for each mode: IR and Podcasts share the same list of 40; Spotify 10;
DAB 40; FM 40.
To store a preset, press and hold FAV. The display shows the Save preset screen.
Select a number to save the currently playing station.
To select a preset, press FAV, then select one of the saved preset stations.
When a preset station is playing, it shows ( 1, 2 etc.) at the bottom of the
screen.
For 1-10 preset stations, there are shortcut buttons 1-10 on the remote control.
Press and hold a number button to store, or press it to select, the corresponding
number of preset. For a preset >10, it can only be stored or recalled via preset
list.
UNDOK
The device gives a feature of network remote by smartphone or tablet in iOS or
Android system. By downloading the assigned app named UNDOK, you can view
all the modes the device.
Search UNDOK from Google Play or Apple Store, and install it to your smartphone
or tablet.

9
For Android system
(Google Play)
For iOS system
(Apple Store)
Before using the UNDOK app, make sure the device and the smartphone / tablet
are in the same WiFi network.
Launch the app. The app initializes and scans for Internet Radio in the network.
Tap the device to make the connection.
When prompted, enter the current PIN code. The default PIN is “1234”. You can
view and edit the current PIN on the Internet Radio in the menu Select your
desired mode in the main page. You may then control the selected mode on your
smartphone / tablet and on the display of the device simultaneously.
Tap “Standby” icon to go to the standby mode. Tap “Wake up” to go to
operation mode.
Tap "Browse" to view the details. Tap to view the saved preset stations, and
tap “+” to add the playing station to the desired preset station number.
NOTE: Be aware that if another smartphone / tablet with the app in the same
network have access with the device, the original connection will be cut off.
Mode Operation

10
Internet Radio, Podcasts
Device can play thousands of radio stations and podcasts from around the world
though a broadband Internet connection. When you select Internet radio or
Podcasts mode, the device directly contacts the Frontier Smart Technologies
portal to get a list of stations or podcasts. The list menu is provided from the
portal, so it is only accessible when the device is connected to the Internet. The
contents and submenus may change from time to time.
Choose required category and search the station or podcast to listen.
Now Playing Information
While the stream is playing, the screen shows its name and description. To view
further information, press INFO.
Each time you press INFO, another set of information is displayed, cycle through
name/description, genre/location, reliability, codec/sampling rate, playback
buffer and today’s date.
Press OK to view the station album in full screen.
Presets –40 presets available, see section 3 (Presets).
Spotify Connect
Use your smartphone, tablet or computer as a remote control for Spotify. Go to
spotify.com/connect to learn how.
The Spotify Software is subject to third party licenses found here:
https://www.spotify.com/connect/third-party-licenses
Start playing Spotify on your smartphone as usual. The “devices icons” is
displayed at the bottom of the phone. Press it to display a list of the devices
available on the network.
Now select “Majority Quadriga” and the playback will take place on the radio.
A successful connection is indicated by the name of the device in green text. You

11
can use or to play the previous or next track, press and hold to rewind or
fast forward. Press to play or pause.
USB Music Player
When this menu is selected, menus are generated from the folders on the USB
device. Browse the folders with the navigation knob and BACK button, or
direction buttons on the remote control. The display shows folders and file names
(not necessarily track names).
Once you have found a track you want to play, press OK. A short press plays the
track immediately.
Note: The USB port is just for music MP3 playback, it supports no charging
functionality.
Supported USB file systems: FAT16, FAT32
The maximum device capacity: 128 GBytes
Maximum number of items (files/sub directories) in an y directory: 5000
Maximum depth of file system tree: 8 directory levels
You can use or to play the previous or next track, press and hold to rewind
or fast forward. Press to play or pause.
My playlist - Tracks are added to My playlist by browsing your available tracks
through the USB playback menu, highlight the track you wish to add, press and
hold OK to save. The playlist is preserved during standby. The device holds a
queue of up to 200 tracks in My playlist.
Clear My playlist –To clear the entire “My playlist”.
Repeat/shuffle - You can set these options to repeat tracks or play them in
random order. In order to activate Repeat or Shuffle press the corresponding
button on the remote control.
Now playing information - While a track is playing, the screen shows its track
and artist. There is also a progress bar with
figures for elapsed and total track time. At the bottom of the screen, an icon

12
indicates USB depending on the source. To view further information, press INFO.
Each time you press INFO, another set of information is displayed, cycling through
the information: artist, album, codec/sampling rate, playback buffer and today’s
date. Album cover from USB is unsupported.
DAB Radio
DAB mode receives DAB/DAB+ digital radio and displays information about the
station, stream and track playing.
Scanning for stations
The first time you select DAB radio mode, or if the station list is empty, the radio
automatically performs a full scan to see what stations are available. You may
also need to start a scan manually to update the list of stations for one of the
following reasons:
o Available stations change from time to time.
o If reception was not good for the original scan, this may result in an empty
or incomplete list of available stations.
o If you have poor reception of some stations, you may wish to list only
stations with good signal strength.
To start a scan manually, choose Full scan. To scan only stations with good signal
strength, select Local scan.
Once the scan is complete, the radio shows a list of available stations.
To remove stations that are listed but not unavailable, choose Prune invalid.
Turn the navigate reel to view a list of stations and press OK to select. Once
selected, the station plays and the screen show information about station, track
or show as broadcast.
Now playing information
While the stream is playing, the screen shows its name and DLS (Dynamic Label
Segment) information broadcast by the station giving real-time information such
as programme name, track title and contact details. Stereo broadcasts are
indicated with an icon at the top of the screen. To view further information, press
INFO
.

13
Each time you press INFO , another set of information is displayed, cycling
through DLS text, programme type, ensemble name/frequency, signal
strength/error rate, bite rate/codec/channels and today’s date.
Press OK to view the station album in full screen.
Presets –40 presets available, see section 3 (Presets).
Settings
Dynamic range compression (DRC)
If you are listening to music with a high dynamic range in a noisy environment,
you may wish to compress the audio dynamic range. This makes quiet sounds
louder, and loud sounds quieter. You can change DRC as off, low or high.
Station order
You can choose the order of the DAB station list to be either Alphanumeric,
Ensemble or Valid.
Ensemble lists groups of stations that are broadcast together on the same
ensemble. Valid lists valid stations first, alphanumerically, then off-air
stations.
FM Radio
FM radio mode receives analogue radio from the FM band and displays RDS
(Radio Data System) information about the station and where broadcast.
To find a station, press OK. The frequency display starts to run up as the device
scans the FM band. Alternatively, you can tune manually by turning the
NAVIGATE knob.
Now playing information
While the stream is playing, the screen shows its frequency, or if RDS information
is available, station name and any further RDS information such as programme
name, track title and contact details. If no information is available, just the
frequency is shown. Stereo broadcasts are indicated with an icon at the top of the
screen, To view further information about the broadcast, press INFO .
Each time you press INFO, another set of information is displayed, cycling through
RDS text, further RDS text (station/programme type), frequency and today’s date.
Presets –40 presets available, see section 3 (Presets).
Settings
Scan settings
By default, FM scans stop at any available station. This may result in a poor signal-

14
to-noise ratio (hiss) from weak stations. To change the scan settings to stop only
at stations with good signal strength, select Yes after choosing Strong station
only?
Audio settings
All stereo stations are reproduced in stereo. For weak stations, this may result in
a poor signal-to-noise ratio (hiss). To play weak stations in mono, select FM weak
reception: Listen in mono only and then YES.
CD Player
The smart radio can playback CD-DA (Compact Disc Digital Audio) format audio
CD-R/CD-RW discs that have been finalised* upon completion of recording. It may
fail to play some CD-R/CD-RW discs due to poor recording and wide variation in
quality of the CD-R/CD-RW disc.
*Finalising enables a CD-R/CD-RW disc to playback on audio players. A disc which
has not been finalised may have information added to it using a computer but
may not always be playable.
Insert a disc with printed side facing up into the CD slot. The disc will be loaded
automatically. The unit will check the CD type and load its track list. The display
will show 'Loading' and then 'Reading' as the information is read.
Playback
Rotate the NAVIGATE knob or /on the remote control to play the
previous or next track, press and hold the button to rewind or fast forward.
Press NAVIGATE knob or on the remote control to pause the track. Press it
again to resume.
Press to stop the track.
To take out the CD, press . Note that this device does not eject the CD if it is
not in CD mode.
Repeat/shuffle - Press REPEAT/SHUFFLE on the remote control to swap among
normal playback, repeat one, repeat all and turn on/off the function of random.
CD track programming - Stop the playback first if any track is playing.
Press FAV to program.
Set the first programming track, use /to seek the track. Press OK to
confirm and set the next programming track. Repeat the steps. When
programming is completed, press .
Press OK to start playing the programmed track(s).

15
MP3 / WMA CD
The radio is able to play CD-R and CD-RW discs containing MP3 and WMA files. It
is assumed in this section that a file is equivalent to a CD track.
It allows skipping folder by pressing FOLDER UP or FOLDER DOWN on the remote
control. The first file of the next or previous folder will be played.
An MP3 / WMA CD may not contain more than 512 files and not more than 99
folders. MP3 and WMA files should be created with an audio sample rate of
44.1kHz (this is normal for files created from CD audio content).
MP3 and WMA data rates up to 320 kilobits per second are supported. WMA
lossless files are not supported. The unit will not play files which include digital
rights management (DRM) protection.
When burning CD-R and CD-RW discs with audio files, various problems may arise
which could lead to problems with playback. Typically such problems are caused
by poor CD writing or audio encoding software, or by the hardware settings of the
PC's CD writer, or by the CD being used. Should such problems arise, contact the
customer services of your CD writer or software manufacturer or look in their
product documentation for relevant information. When you are making audio
CDs, take care to observe all legal guidelines and ensure that the copyright of
third parties is not infringed.
Bluetooth
In Bluetooth mode, the radio enters the pairing mode automatically.
You can turn on the Bluetooth of your Bluetooth device and search the radio
Majority Quadriga to pairing. When it is waiting for pairing, there is a blinking
Bluetooth icon at the bottom. If the pairing is successful, the Bluetooth icon
becomes steady.
Control the music playback from your Bluetooth device.
To disconnect from the radio, press and hold PRESET/BT PAIR, or go to the menu
and choose BT disconnect.

16
Aux in
Aux in mode plays audio from an external source such as an MP3 player.
To play audio with Aux in mode.
Turn the volume low on both the radio and, if adjustable, the audio source
device.
Connect the external audio source to the Aux in 3.5mm stereo socket.
Adjust the volume of the radio (and, if necessary, the audio source device) as
required.
RCA in
RCA in mode plays audio from an external source.
To play audio with RCA in mode.
Turn the volume low on both the radio and, if adjustable, the audio source
device.
Connect the external audio source to the RCA L-R audio socket.
Adjust the volume of the radio (and, if necessary, the audio source device) as
required.
Optical in
Optical in mode plays audio from an external source.
To play audio with Optical in mode.
Turn the volume low on both the radio and, if adjustable, the audio source
device.
Connect the external audio source to the SPDIF socket.
Adjust the volume of the radio (and, if necessary, the audio source device) as
required.
Sleep
To set the sleep timer, select Sleep under Main menu or press SLEEP button on
the remote control. Choose from Sleep OFF, 15 30,45,60, 90 or 120 minutes. The
radio will count and turn off after you select a sleep time.

17
Alarm
There are two versatile wake-up alarms with snooze facility, and a sleep function
to turn the system off after a set period. Each alarm can be set to start in a
particular mode.
Select Alarms under Main menu to set or change an alarm.
Select the alarm number (1 or 2) then configure the following parameters:
o Enable: on/off,
o Frequency: Daily, Once, Weekends or Weekdays,
o Time,
o Mode: Buzzer, Internet Radio, DAB or FM,
o Preset: Last listened or Preset 1-40
o Volume
To activate the new settings, scroll down and select Save.
The screen shows active alarms with an icon at the bottom left.
At the set time, the alarm will sound. To temporarily silence, press any buttons
except STANDBY. You can change the snooze period. The radio returns to standby
for the set period, with the silenced alarm icon flashing.
Press STANDBY to turn off the alarm.
On the playing screen of any modes, press and hold MENU / INFO on the unit or
press MENU on the remote control, choose System settings to continue.
System Settings

18
Equaliser
Several preset EQ modes are available: Normal, Flat, Jazz, Rock, Movie, Classic,
Pop and News.
Also a user-defined setting is available; create your own EQ with custom bass,
treble settings.
Network
Network wizard - Enter to search AP SSID, then input the WEP / WPA key or
choose Push Button/Pin/Skip WPS to connect to the wireless network.
PBC WLAN setup - Push Button Configuration, it is to connect the AP that
supports WPS (Wi-Fi Protected Setup).
View settings -View the information of current connected network: Active
connection, MAC address, WLAN region, DHCP, SSID, IP address, Subnet mask,
Gateway address, Primary DNS and Secondary DNS.
Manual settings - Choose wired or wireless network connection and enable or
disable DHCP (Dynamic Host Configuration Protocol).
NetRemote PIN Setup - Here you can view and edit the NetRemote PIN. The
default NetRemote PIN is: 1234. The NetRemote PIN is required when you want
to connect a smartphone or Tablet PC to your radio.
Network profile - The smart radio remembers the last four wireless networks it
has connected to, and automatically tries to connect to whichever one of them it
can find.
From here you can see the list of registered networks. You can delete unwanted
networks by pressing OK button and then choosing “YES” to confirm delete.
Clear network settings -Select “YES” to clear all the current network settings.
Select “NO” to cancel.
Keep network connected - If you choose to keep network connected the WiFi will
not disconnect even in standby mode. This option allows the device to be ready
for UNDOK (Details can be found on Section 3) connection in any operating
modes.

19
Time/Date
Set the time manually or auto update, time format, time zone and daylight.
Details can be referred to Setting date and time under to Section 3 (First Time
Setup).
Language
The default language is English. Change it as your preference. There are 13
languages available - English, Dansk, Deutsch, Español, Français, Italiano,
Nederlands, Norsk, Polski, Português, Suomi, Svenska, Türkçe
Factory Reset
A factory reset resets all user settings to default values, so that time and date,
network configuration and presets will be lost.
Software Update
Auto-check setting - This option automatically checks for new updates from time
to time. Automatic updating is enabled by default. To disable it, select “NO”. To
enable it again, select “YES”.
Check now - Search for available updates immediately.
If newer available software is detected, you will be asked if you want to go ahead
with an update. If you agree, the new software is then downloaded and installed.
After a software upgrade, all user settings are maintained.
NOTE: Before starting a software upgrade, ensure that the radio is plugged into a
stable main power connection. Disconnecting power during an upgrade may
permanently damage the unit.
Setup Wizard
With this function, you can start the setup wizard at any time. Any parameters or
stations entered already are not deleted. For more information, please read the
Section 3 (First-time setup).
Info
Enter Info to view the firmware version and the radio ID.

20
Privacy Policy
View the information of Privacy Policy. Please read the data protection
regulations listed there or go to this website: www.frontiersmart.com/privacy
Backlight
You may change the backlight of each environment (power on or standby) to
High, Medium or Low. And adjust the timeout duration which the radio turns to
standby backlight level when it has not been controlled.
Error
Remedy
The device does not
switch on or turned off
suddenly.
1. Check if the power adaptor is connected properly.
2. The device may malfunction when used in areas
with strong radio interference. The device will work
properly again once there is no more interference.
No Power
Ensure that the power adaptor plug of the unit is
connected properly.
No Sound or lower sound
1.Tune on the sound as it may be muted.
2.Increase the volume.
No network connection
can be established.
1. Check the WLAN function.
2. Try to set an IP address at the device.
3. Activate the DHCP function on the router and
make the connection again at the device.
4. A firewall is activated on the network –set the
respective program in such a way that access is
possible.
5. Reboot the router.
WiFi connection cannot
be established.
1. Check the availability of WLAN network on the
router.
2. Place the device closer to the router.
3. Make sure the password is correct.
No station is found.
1. Check the network as well as the access point and
firewall.
2. The station may not be available currently, try
again later.
Troubleshooting
