MAKAYLA MD305 User manual

Dehumidifier Instruction Manual
MD305
Please read this manual carefully before use and keep it for future reference.

Contents
Product Description
Product Description.................................................................................1
Structure......................................................................................................2
Specification...............................................................................................2
Instructions.................................................................................................3
Maintenance...............................................................................................4
Safety Instructions....................................................................................4
Cautions.......................................................................................................5
Warranty.......................................................................................................6
This sleek dehumidifier is designed for compact and portable use.
Apart from having the advantage of energy-saving and being
environment-friendly. This product is equipped with 7-colored LED
lights and with excellent performance on dehumidification.
By inhaling the moisture in the air through the fan, the machine
removes water vapor from the air and discharges dry, fresh air out of
the machine that aims to get rid of the mold from humid environments,
which greatly creates comfortable and healthy living conditions.
Ideal for home, office, and any small space.

Structure
Specification
Instructions
1. When the dehumidifier is plugged in, press the ON/OFF switch (1),
the machine starts to work, the Power Indicator(2), LED Lights (10) and
Gear indicator (5) lights up at the same time, and the LED light changes
color alternately. The airflow is discharged from the Air Outlet (6).
1ON/OFF Switch 6Air Outlet 11 DC Port 14 Water Tank
2Power Indicatior 7Handle 12 Adaptor 15 Tank Cover
3Lighting Switch 8Removable Dust Mesh and Grille
4Gear Shift 9Air Inlet
10 LED lights(inside)
5Gear Indicator
13 Cable
Cooling element: Peltier module
Power adapter: 15V DC 4A
Water tank capacity: 1650ML
Capacity: Approximately 750ml per day
at 30℃，80%RH
Fan: 80mm*80mm DC Brushless motor
Power consumption: 60W
Product dimension: 6.9*6.9*12.5ins.
Water level detector: Automatic switch off
with“Red”lights will be on LED Indicator
when water tank is full
1
2
5
43
6
8
9
7
12
13
10
15
14
11

2. After powering on, press the Lighting Switch (3) and the color will be
fixed to your desired one. Press the switch again, the lights are turned off.
3. After powering on, the fan runs at high speed by default. Press the Gear
Shift (4) for low speed, the gear indicator is off at the same time.
4. When the water tank is not installed or the tank is full, the product will
not work and the light of the water tank will be red.
5. When the water tank is full of condensed water, the floating ball will be
lifted, the machine will be disconnected, and the indicator light will be red.
Please pour out the water.
6. Please turn off the machine before pouring water, then take the water tank
out. After emptying the water, if you need to clean the inside of the water tank,
just open the water tank cover and clean it. After cleaning,
put the water tank back to the correct position in the machine.
7. When water splashes on the machine, be sure to wipe the water dry with
a dry cloth to avoid short circuits caused by water droplets.
8. If you need to continue to dehumidify, just restart the machine.
Pic.1
Pic.3 Pic.4 Pic.5
Pic.2

Maintenance
SAFETY INSTRUCTIONS
This dehumidifier was made of safe and environmental protection
materials, it has been certified and complied with the requirement
of sale region's related regulations or laws.
Important: Please read the Cautions Notice before using the device.
Basic precautions should always be followed to reduce the risk of fire,
electrical shock, and injury to persons, or damage to the product.
1. Wipe the machine body with neutral detergent and wash the tank
directly with water to ensure the service life of the machine.
2. Once the machine has been cleaned, wipe to dry with a soft and
dry cloth.
3. After being cleaned and dried, return it to the box for storage
Please make sure the product is powered off before maintenance.
WHY IS IT UNDERPERFORMING? (remove water from the tank)
·Is the door or window open? (Please close the doors and windows.)
·Is there any obstacle blocking the air inlet/outlet?
·Is there any other equipment releasing steam indoors?
·Is the indoor temperature too low?
（The dehumidification capacity can be affected in a low temperature
and low humidity environment. If the indoor temperature is lower
than 8℃/46.4°F, the effects of dehumidification are not obvious).

Cautions
1. Before use, please check the applied voltage matches with the adapter
label.
2. DO NOT turn on the machine if the wire is damaged, contact the
customer service for help.
3. Keep away from any obstacles to avoid block-up of the air inlet or outlet.
4. DO NOT use in an inflammable or explosive environment which is above
40℃/104°F.Ideal operation environment: Temp: 8℃ -40℃ (46.4°F-104°F).
5. Please switch off and unplug the machine if not in use.
6. DO NOT twist or pull the wire.
7. DO NOT use the dehumidifier on uneven surfaces
8. DO NOT cover the machine to avoid overheating.
9. DO NOT use the dehumidifier in conditions of low temperature,
dusty or a volatile place with acid, alkali, or oil.
10. DO NOT touch the plug with wet hands in case of electric shock.
11. DO NOT put any object into the dehumidifier while it's working.
12. This appliance can be used by children aged 8 years old and above
and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
13. Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.

Warranty
14. Machine surface can be cleaned by soft cloth with neutral detergent
instead of petroleum, alcohol, and other organic agents.
15. DO NOT use an unmatched adaptor.
16. DO NOT disassemble the product or any component by yourself.
17. It is normal that the adapter will heat up (no more than 80 °C or 176°F)
during operation.
We appreciate your feedback and will do our best to guarantee your
satisfaction.
Within 1 year after your purchase, shall the product be defective, we will
provide a refund or resend you a new one. Please email us with your order
number or contact the seller on Amazon. Your inquiries will be taken care of
as soon as possible.
This warranty does not cover normal wear of product and damage caused
by the misconduct of buyers.
This warranty only covers orders from the authorized Amazon Store and
our official website. We are not responsible for any purchases from other
distribution channels.
