HowtoReplaceaReplicator2XXYZEndstopCable

TheseareinstructionsforreplacingtheXYZendstopcableontheReplicator2X.Theywill
requiretheuseofthe2.5mmhexwrenchthatcamewithyourbot,severalzipties,anda
wirecutterorstrongpairofscissors.

Note:Yournewendstopcableshouldshipwiththejumpercablealreadyattached.Iftheyare
notalreadyconnected,simplyattachthelargerendofthejumpercabletotheXaxismotor
cable.YouwillalsoreceiveajumpercablefortheXYZmotorcable,whichyoushouldalso
attach.

Beforeyoustart,dothefollowing:
•Unloadandremoveanyfilament.
•TurnofftheReplicator2X.
•Removethefilamentguidetubeandspoolholder.
•UnplugpowerandUSBcables.
•RemovetherightsidepaneloftheReplicator2X.

TheXYZendstopcableconnectstotheMightyboardwithasingleconnector,butfromthere
branchesoffinthreedirections,onesectiongoingtoeachofthethreeendstops.

1.Disconnectthecablefromallthreeendstops,aswellasthemotorcablefromthe
Xaxismotor.

Unplugtheblackplasticcableconnectorfromeachendstop.TheYaxisendstopislocatedat
theupperbackleftcorneroftheReplicator2X’sinterior.TheZaxisendstopislocatedbehind
thetopsectionofthethreadedZaxisrod.TheXaxisendstopislocatedontopoftheXaxis
motor,attherightsideofthegantry.AlsounplugthemotorcablefromtheXaxismotor.

2.DetachtheXaxissectionoftheendstopandmotorcablesfromthegantry.

TheXaxissectionsoftheendstopandmotorcablesroutethroughaholeandintoaslotonthe
sideofthegantry.Pullthecableconnectorsfreeofthehole.Thenprythemetaldoweloutof
theslotatthesideofthegantryandsetitaside.Slidetheendstopandmotorcablesoutofthe
slot.

3.Detachallthreeendstopcablesectionsfromtheircableclips.

TherearetwokindsofclipsholdingthesecablesectionstotheinterioroftheReplicator2X:a
curvedmetalflapandaplasticpiecewithaholeforaziptie.Removethecablesfromtheziptie
clipusingastrongscissororwirecuttertocliptheziptie,beingverycarefulnottodamagethe

cablesthemselves.

Removejusttheendstopcablesectionsfromthemetalclips,slidingthemoutfromunderthe
clip,bendingtheclipoutofthewaynomorethanisabsolutelynecessary.Metalclipscanbe
brokenifbentbacktoofar.

Removeallthreesectionsoftheendstopcablefromtheclips.LeavetheXaxismotorcableas
is,unclippedfromtheziptiebutstillinplaceinthemetalclips.

4.FliptheReplicator2Xontoitsleftsideandremovetheelectronicsbaycover.

Thecoverissecuredwithfourbolts.Removethemwithyour2.5mmhexwrench.Setthe
boltsandcoveraside.

5.UnplugtheXYZendstopcableconnector.

WiththeReplicator2Xrestingonitsleftside,theXYZenstopcableconnectorwillbeleftof
centeronthemotherboard,directlytotherightofthewidegrayribboncableleadingtotheLCD
interface.Removetheconnectorfromthemotherboard.

6.UncliptheX,YandZaxissectionsofthecablefromtheundersideoftheReplicator
2X.

SlidetheXaxissectionofthecableoutfromundertheclipatthefrontrightcornerofthe
undersideofthebot.SlidetheYandZaxissectionsofthecableoutfromundertheclipatthe
backrightcorneroftheundersideofthebot.

7.Pullallthreesectionsofthecablethroughtotheundersideofthebot.

PulltheXaxissectionofthecablethroughtheholeatthefrontrightcorneroftheundersideof
thebot.PulltheYandZaxissectionsofthecablethroughtheholeatthebackrightcornerof
theundersideofthebot.

TheXYZendstopcableisnolongerattachedtoanypartoftheReplicator2X.Discardit.

8.PlugthenewXYZendstopcableintothemotherboard.

9.RoutetheXaxissectionoftheendstopcabletothefrontrightcornerofthebot.

Pushthecableconnectorintothebodyofthebotthroughtheholeinthecornerofthebottom
panel.Slidethecableunderneaththenearbymetalclip.

10.RoutetheYandZaxissectionsoftheendstopcabletothebackrightcornerofthe

bot.

Pushthecableconnectorsintothebodyofthebotthroughtheholeinthecornerofthebottom
panel.Slidethecablesunderneaththenearbymetalclip.

11.TurntheReplicator2Xuprightagain.

12.AttachthejumpercabletotheXaxismotorcable.

Yourmotorcableshouldbehangingfromametalclip.Attachthemaleendofthejumpercable
tothemotorcable.

13.AttachthejumpercableendsofthenewXAxisendstopandmotorcablesectionsto
theframeandgantry.

FindtheXaxissectionsofbothcables,withthejumpercablesattached,insidethefrontright
corneroftheReplicator2X.Routethecablesupthroughthecableclips.Slidethecablesinto
theslotatthesideofthegantrysothatitroutesfrombacktofront.

14.PluginthejumpercableendoftheXaxissectionoftheendstopcable.

Pushthecableconnectoronthejumpercablethroughtherectangularholeinthesideofthe
gantryandplugitintotheendstop.

15.PluginthejumpercableendoftheXaxismotorcabletotheXaxismotor.

Pushthecableconnectoronthejumpercablethroughtherectangularholeinthesideofthe
gantryandplugitintothebottomoftheXaxismotor.

16.MaximizeslackontheXaxissectionsofthecables.

GentlytugontheXaxissectionsofthecableswheretheyexitsthegantryslottowardtheback
ofyourbox.Makesurethereisnoexcesscablebetweenthegantryslotandtheendstop/motor.
Thenreturnthemetaldoweltothegantryslot.Makesuretheslitinthesideofthedowelfaces
out,awayfromthecablesintheslot,andpushthedowelintoplacewithahexwrench.

17.RoutetheYandZaxissectionsofthecablethroughtheircableclips.

FindtheYandZaxissectionsofthecableatthebackrightcorneroftheReplicator2X.Route
thecablesupthroughthecableclipsinthebackrightcorner.

18.PlugtheZaxisendstopcableconnectorintotheZaxisendstop.


TheZaxisendstopistheonelocateddirectlybehindthethreadedZaxisrodbehindyoubuild
platform.

19.PlugtheYaxisendstopcableconnectorintotheYAxisendstop.

TheYaxisendstopistheonelocatedinthebackleftcornerofyourReplicator2X.Togetthe
cableconnectorthere,routeitbehindthethreeZaxisrodsandunderthemetalcableclipnext
totheendstop.

20.Addnewziptiestotheplasticclips.

TherearethreeziptieholderclipsinthetopofthetheReplicator2X’sframe.Toattachcables
toaziptieholderclip,dothefollowing:

Takeathinziptieandbendacentimeterortwooftheendintoasharp,fishhookshape.Poke
theendofthehookthroughtheholeintheziptieholder.Tightentheziptiearoundthecableor
cablesenoughthatitholdsthemstill,butnotsomuchthatitcouldharmthecables.

TheziptieholderclipattheupperrightsideshouldholdtheXaxissectionsofboththemotor
andendstopcables.TheziptieholderclipatthebacktowardstherightsideshouldholdtheY
andZaxissectionsoftheendstopcables.Theziptieholderclipatthebackbytheleftcorner
shouldholdonlytheYaxissectionoftheendstopcable.

Thispartreplacementisnowcomplete!ReturntherightsidepaneltotheReplicator2X,plugin
yourbot,andtryoutyournewendstopcable.


