MAKINA S7 PRO-PID User manual

User manual
MAKINA S7 PROPID
Makina Espresso Machines
Veemarkt 36D
1019 DD Amsterdam
The Netherlands
Contact us
E. [e-mail]
W. www.makinaespressomachines.com
T. 0031614577467
Company details
KVK 62515152
BTW NL253855639B01
IBAN NL63ABNA0247389293

Dear coffee lover
Thank you for buying the MAKINA S7 PROPID espresso machine. If you really care about the
pleasure of a perfect espresso, congratulations, you have made THE RIGHT CHOICE. Based on the
principle of simplicity in both thinking and decision making, we have combined the most important,
efficient and durable components and functions you need to make a perfect cup of espresso.
If you have further questions or if you require more information, please contact us or your MAKINA
authorized dealer before starting up the espresso coffee machine. Please keep the instruction manual
for future reference.
MAKINA espresso machines B.V. is not responsible for any damage caused by incorrect or
unreasonable use and maintenance. MAKINA espresso machines B.V. is not responsible for damage to
persons or objects caused by incorrect installation.
Page 2

Index
Index 3
Used symbols 4
1. Introduction 4
2. Product delivery 4
3. General advice 5
3.1 General safety notes 5
3.2 Proper use 6
4. Machine description 7
4.1 Machine parts 7
4.2 Technical data 8
4.3 Specifications 8
5. Installation 9
5.1 Preparing for installation 9
5.2 Electrical connection 10
5.3 Water supply connection 11
5.3.1 Machine in use with water tank 11
5.3.2 Machine in use with direct water connection 11
5.3.2.1 Advice for using the machine with direct water connection 12
6. First use 13
6.1 Water tank machine or machine in use with water tank 13
6.1.2 Alarms 14
6.2 Machine in use with direct water connection 14
6.2.3 Alarms 14
7. Use of the machine 15
7.1 Standard use of the installed machine with water tank 15
7.2 Standard use of the installed machine with direct water connection 15
7.3 Adjustment of the brewing pressure 16
7.4 PID display function 16
7.4.1 Programing the temperature 16
7.5 Preparing coffee 17
7.6 Dispensing of hot water 17
7.7 Dispensing steam 17
7.8 Frothing milk 18
8. Cleaning and maintenance 18
8.1 Daily 18
8.2 Weekly 19
8.3 Monthly 19
9.0 Troubleshooting 20
Page 3

Used symbols
Risk of injury
Important notices on safety for the user. Pay attention to these notices to avoid injuries.
Important
Important notice for the correct use of the machine.
1. Introduction
Please read this instruction manual carefully before using your new machine. This user manual
contains important information about the correct installation as well as safety information, operations
and maintenance of the machine.
●This handbook has the function to provide information for a correct use of the
machine and appropriate maintenance, as well as to promote the operator safety.
●Keep this handbook in a safe place for further consultation.
●The manufacturer accepts no responsibility for damage to persons or objects
caused by incorrect installation
●This handbook must always be available to the operator, and service technicians,
which must be informed on the correct use of the machine if used in a way
different from what indicated in its content, or if any possible residual risks. It has
to be stored in a dry and clean place.
●The instructions in this handbook are in no way a substitute for the safety
instructions and technical data on the machine or the packaging concerning
installation and function. This handbook is an essential part of the machine.
●For further information or additional handbooks, please contact your distributor or
the manufacturer.
●This machine needs to be operated according to the instructions supplied in the
handbook by a responsible adult operator, installation and/or service technician.
●The manufacturer is free to modify this manual without updating previous editions
except for exceptional cases.
2. Product delivery
The following is supplied as standard with the Makina S7 PROPID
●1 portafilter with 1 spout
●1 portafilter with 2 spouts
●1 filter 1 cup
●1 filter 2 cup
●1 blind filter
●1 user manual
Page 4

3. General advice
3.1 General safety notes
●Make sure that the local mains voltage corresponds with the information on the
type sticker on the inside of the espresso machine's drip tray.
●The installation of the machine is to be carried out by authorized and qualified
specialists according to the instructions in chapter 5.
●Plug the machine into a grounded socket only and do not leave it unattended.
●Unplug the machine or turn off the main switch before cleaning the machine’s
interior. Never use detergents of any kind.
●This machine is designed for the sole purpose of producing coffee, hot water and
steam for hot drinks.All other uses are incorrect and dangerous.
●This machine is designed for domestic and semi professional use.
●The machine components are made of non-toxic and long-lasting parts which are
easily accessible for cleaning and maintenance.
●The end user must be an adult, sufficiently trained to operate the appliance
properly and it must forbid the use of the appliance to children or non-responsible
persons.
●To ensure efficient and correct operation it is essential to follow the
manufacturer’s instructions concerning the periodic maintenance carried out by
an authorized technician in compliance with the local standards and laws.
●The installation technician, the user and the person incharge of maintenance are
obliged to inform the manufacturer of any defects or damages which could affect
the safety of the original installation.
●The installation technician must check the surrounding area to ensure safe and
hygienic use are guaranteed.
●The machine components’ manufacturers are responsible for the parts supplied
by them. The customer is responsible for the personal use of the equipment. Do
not expose the machine to environmental elements (sun, rain, etc.).
●When the machine is idle and not in use for an extended period of time, it should
be emptied completely and stored in an area with temperature above freezing
0°C or 32°F. This prevents any possible damage to pipes and the boiler.
●All maintenance procedures must be carried out by authorized technicians only
and all spare parts must be original.
●Any modification or forcing performed by persons not unauthorized by the
manufacturer will void all warranties on the device.
●Never bend, roll or pull the electrical supply cable.
●Never submerse the machine in water, never operate the machine with wet hands
or feet and do not operate the machine with bare feet.
●The machine has to be installed with an efficient ground system; the
manufacturer recommends a wooden platform on which the machine can stand.
●Never operate the machine without water.
●The machine must be operated with clean drinking water. Use water softeners if
the water has a high mineral content. Mineral deposits may obstruct the
machine’s water circuit which may cause damage to the machine and possibly
personal injury. The machine must operate only with drinking water.
●The machine has to be switched off whenever unattended from the operator. Tea
and coffee cups must be carefully drained before placing them over the cup-tray.
Page 5

●Please note that the surface of the machine, specially the brew group, steam
wand and the hot water wand become very hot during operation and they can
cause burns if you touch them with your hands.
●If the supply cord is damaged, it must be replaced by a service agent or similarly
qualified person, in order to avoid a hazard.
●Do not use an extension cord / power strip.
●The machine should only be used by experienced adult persons.
●The machine is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
●Children should be supervised to ensure that they do not play with the appliance.
●Keep the packaging out of the reach of children.
●Only use original spare parts.
If you have any further questions or if you require any further information, please contact us or
contact your specialized authorized MAKINA espresso machines dealer before starting up the
espresso coffee machine.
The MAKINA ESPRESSO MACHINE S7 PROPID complies with the relevant safety regulations.
Important
You must use water with a hardness of max. 4 ° dH to protect your machine against
limescale damage. If necessary, use a water softener to achieve a sufficient degree of
hardness.
A calcified machine may only be descaled by your specialized dealer because a partial
disassembly of the boiler and the tubing may be necessary to prevent the system from
being blocked by lime residues. A late descaling can cause substantial damage to the
machine.
3.2 Proper use
The MAKINA S7 PROPID is designed to be used for the preparation of coffee, hot water and steam
only. The machine is intended for domestic and semi professional use. Use of the machine other than
for the abovementioned purpose will void the warranty. The manufacturer cannot be held responsible
for damage caused by the machine and is not liable for redress.
This appliance is intended to be used in household and similar applications such as:
●Staff kitchen areas in shops and other working environments.
●Workshops.
●By clients in hotels, motels and other residential type environments.
●Bed and breakfast type environments.
Page 6

4. Machine description
4.1 Machine parts
MAKINA S7 PROPID
Image 1
1. Cup warming tray. The water tank
under the the tray)
2. Steam valve lever
3. Pump pressure gauge
4. Boiler pressure gauge
5. Steam wand
6. Control lamp red
7. On/off switch
8. Control lamp on/off green
9. Hot water valve lever
10. E61 brew group
11. Hot water wand
12. Portafilter
13. Brew lever
14. PID
15. Drip tray
16. Water connection switch button
(under the machine on the left side)
17. Water connection switch valve
Right under the machine)
18. Water tank and direct water
connection switch.
Risk of injury
Danger of injury: The following parts are hot or may become hot:
●Area around the valves
●Steam and hot water wands
●Brew group
●Portafilter
●Body (upper part and side frames)
Page 7

4.2 Technical data
Voltage: EU 230 V
Frequency: EU 50 Hz
Power: 1,500 W  1800 W
Water tank capacity: 2.1 liter
Boiler capacity: 3.0 liter
Weight: 28 kg
Measurements: 425 mm height / 510 mm deep / 290 mm wide
4.3 Specifications
1. Quiet built-in rotary pump.Professional rotary pump ensures stable 9 bar pressure.
2. Heat exchanger.Gives the opportunity to make coffee and froth milk at the same time.
3. PID controller.Proportional Integral Derivative, full temperature control.
4. Shot timer.Perfection in each extraction.
5. Switchabletank/directwater connection.
6. Power 1800 W. Stable power supply.
7. Highqualitycopper boiler 3L.50% more capacitythan the average espresso machines.
8. Check valve. Applied to the associated hydraulic circuit and automatic overpressure discharge
system.
9. Boiler over pressure valve.
10. Full mirrorpolished high quality stainless-steel exterior.
11. Pre-infusionfunction.
12. Boiler pressure gauge.
13. Pump pressure gauge.
14. Water tank 2L.
15. Insulated boiler to save energy.
16. Lever valve technology push & go.Elegant ergonomic design.
17. Dual electronic sensors, minimum level control of internal tank via electronic card, with
automatic total blocking of all machine functions in case of missing water..
18. Indicator warning O-led lights.
19. Cool touch steam wand.
Page 8

20. Stainless steel adjustable feet
21. Ergonomic design wood portafilters.
22. Original E61 brew group.
23. Complete wood kit.
24. Quick heat. In 9 min ready to serve.
25. Soft & easy closing removable drip tray.
26. Optional water drain in the drip tray.
27. Adjustable feet height.
28. Stainless steel cup warmer.
29. Close type drip tray takes up to 1000 ml.
30. High professional performance thermal stability guarantee.
5. Installation
5.1 Preparing for installation
PLEASE READ CAREFULLY
The manufacturer has tried to foresee all possible safety devices to ensure the safety of the users.
Anyhow, different conditions of installation or of equipment moving can cause situations which cannot
be controlled or foreseen. Therefore, it’s absolutely necessary to evaluate all remaining risks and to
care about the following:
●This machine will only be safe if it is properly connected to an efficient earthing
system that meets the safety standards in force in the country where the machine
will be installed. The manufacturer declines all responsibility for accidents
resulting from non-compliance with the above standards, as incorrect installation
can lead to injuries to persons and animals, as well as problems with physical
objects. In any case, this device must always be installed on a fixed object and
the use of cable extensions or loose connections is strictly prohibited.
●Do not leave packing items such as plastic bags, styrofoam, nails, etc. around
because children or other people could get hurt.
●Any defect or discrepancy has to be notified immediately to the persons
authorized for installation and maintenance of the machine.
●Machine installation has to be performed exclusively by authorized and qualified
technicians.
●Authorized service: if the service is not complying with the instruction of the
manufacturer, or if components other than those recommended by the
manufacturer will be used for installation or maintenance of the appliance, the
conformity declaration of the product will be voided, and so the manufacturer
responsibility for arising injuries or troubles.
●Possible replacement of the supply cable, if damaged, must be performed
immediately and exclusively by service staff qualified or authorized by the
manufacturer, in order to prevent danger for persons, animals and things.
●Before connecting the appliance to a fixed water supply, check that a certificate
of conformity has been issued to confirm the suitability of the fixed water supply
for this use; if not, notify the end user and leave the device unplugged.
●Check the integrity of all components and do not install defective or damaged
parts. Ask for substitution.
Page 9

●Check and verify that the outlet power supply voltage is the same shown on the
rating-plate of the appliance.
●The customer has to protect the power outlet used to supply the appliance by
means of a safety switch system, complying with the standards and laws in
force.
●The installation of a water softener is highly recommended.
●When installing the appliance, an multi-pole main switch must be connected with
contacts with an opening distance equivalent to or higher than 3 mm, as required
by safety standards.
●The appliance must be placed over a flat and stable surface, leaving a minimum
clearance of 30 mm from walls.
Important
PLEASE READ THE INSTRUCTION CAREFULLY BEFORE INSTALLING THE MACHINE. IT IS
IMPORTANT TO FOLLOW THE CORRECT PREPARATION STEPS BEFORE INSTALLING THE
MACHINE.
Important
The installation needs to be carried out by qualified specialists according to the following
instructions and in compliance with valid laws and local regulations.
5.2 Electrical connection
●Make sure that the local mains voltage corresponds with the information on the
type sticker on the inside of the espresso machine's drip tray.
●Make sure that you use the correct power plug for your country.
●Plug the machine into a grounded socket only and do not leave it unattended.
●Do not use an extension cord or power strip.
●Do not roll or bend the power cord.
Page 10

5.3 Water supply connection
5.3.1 Machine in use with water tank
When using the machine with a water tank, please turn the valve under the machine facing the rear of
the machine (image 2. Place the switch under the machine into position 0 (image 3.
Image 2
Valve in position for operating the machine with
water tank (facing the rear of the machine)
Image 3
Turn the switch under the machine into
position 0
5.3.2 Machine in use with direct water connection
When using the machine with direct water connection, please turn the valve to the front side of the
machine (image 4. Place the switch under the machine into position 1 (image 5.
Image 5
Valve in position for operating the machine with
water tank (facing the rear of the machine)
Page 11

Image 5
Turn the switch under the machine into
position 1
Image 6
The water connecting hose is to be connected
to the water supply adapter under the machine
(image 4.
When using the machine with direct water supply, the water connection switch valve has to be turned
towards the front side of the machine (image 4. The water connection switch valve is located in the
middle part of the bottom panel (image 4. Place the switch under the machine into position “I” (image
5. Please make sure that your water tap is always open during water-connection usage so that the
machine does not run out of water.
Caution!
High water pressure can result in damage to property and machinery. Please make sure
the water pressure does not exceed 2 bar.
Important
Always use an original hose. Original hoses can be purchased from us or at your MAKINA
specialized dealer.
Make sure that the machine is on a water-resistant surface in case of water spillage or
leakage.
Make sure that the fixed water connection of your machine is connected to a potable
water supply having an operating pressure ranging between 0 and 1.5 bars. We
recommend to use a pressure regulator and a shut-off valve in case the operating
pressure exceeds 1.5 bars or frequently fluctuates. The shut-off valve should be easily
accessible, so that the water flow may be stopped at any time. Make sure that the
shut-off valve is closed or turned off when the machine is not in use to prevent any
possible water leakage.
5.3.2.1 Advice for using the machine with direct water connection
The residual water is deposed off periodically by emptying out the water drip tray. If you are using the
direct water connection function, you have the option to install a direct connection to your drainage
system. The required drip tray with drainage outlet, drainage attachment, drainage hose) are NOT
included with delivery.
Page 12

Important
●Do not leave the machine switched on or unattended when not in use.
●Make sure to close the shut off valve of the water connection and to switch off
the electric main switch or to disconnect the power plug when the machine is
not in use.
●If you will not be using the machine for an extended period of time, we
recommend emptying the machine by letting the water run out via the brew
group.
6. First use
Read the following instructions carefully prior to operating the machine
Important
Prior to starting the machine, check if:
●The steam and hot water valves are closed.
●The machine is switched off.
●The power cord is disconnected.
●The drip tray is inserted accurately.
●The machine is placed on a water-resistant surface.
Now you can continue to start up your machine.
6.1 Water tank machine or machine in use with water tank
1. Remove the cup tray. Take out the water tank and rinse it thoroughly.
2. Fill the water tank (2 liter) with fresh drinking water (preferably descaled), place it back into
the water tank guides and put the cup tray back to its position.
3. Connect the machine to an appropriate power outlet through the power supply cable.
4. Turn the power switch to position “I”. The machine is now on.
5. The green signal lamp lights up.
6. The pump will fill the boiler of the machine with fresh water.
7. As soon as the boiler is filled, the pump will stop. As soon as the fresh water falls below a
certain level in the water tank, the machine switches off and the red signal lamp turns on. To
reset to normal working conditions, turn the main switch OFF first. Refill with fresh water and
turn the main switch in position “I”. The boiler will start to refill, the red signal will turn off and
the machine will heat up automatically.
8. A large amount of water is required to fill the boiler for the first time, so the water tank will
have to be refilled with fresh water.
9. Wait until the boiler pressure gauge indicates approx. 1.01.3 bar or a temperature of 120° C
248°F has been reached.
10. Move the group lever into the upper position and dispense approx. 500 ml of water. This way,
the heat exchanger will be filled with water and the circulation of the water in the
thermosyphon system begins.
11. Move the group lever into the lower position. Refill the water tank.
12. The machine is now ready for use.
Page 13

6.1.2 Alarms
If the red signal lamp lights up, this means that the water tank is empty if the machine is in use with a
water tank connection. All machine functions will be automatically blocked by an internal electronic
device to prevent damage of the heating element. To reset normal working conditions, take the
following actions:
1. Turn off the main switch.
2. Make sure that the switch under the machine is placed in position “0”.
3. Fill the water tank.
4. Turn on the main switch.
6.2 Machine in use with direct water connection
1. First of all, make sure that the machine is connected to the direct water supply adapter and
connected to water supply connection (water tap). Make sure that your water tap is always
open during usage so that the machine does not run out of water.
2. Connect the machine to an appropriate power outlet through the power supply cable.
3. Turn the power switch to “I”. The machine is now on.
4. The green signal lamp lights up. The pump begins to fill the boiler of the machine with fresh
water.
5. As soon as the boiler has filled, no more pump noise will be heard, the machine will heat up
automatically.
6. Wait until the boiler pressure gauge indicates approx. 1.01.3 bar or a temperature of 120° C
248°F has been reached.
7. Move the group lever into the upper position and dispense approx. 500 ml of water. This way,
the heat exchanger will be filled with water and the circulation of the water in the
thermosiphon system begins.
8. Move the group lever into the lower position.
9. The machine is now ready for use.
6.2.3 Alarms
If the red signal lamp lights up, this means that the direct water connection supply is switched off. All
machine functions will be automatically blocked by an internal electronic device to prevent damage of
the heating element. To reset normal working conditions, take the following actions
1. Turn the main switch off first.
2. Make sure that the switch under the machine is placed on position “I”.
3. Then open the direct water connection.
4. Then switch the machine on.
Page 14

7. Use of the machine
Important
Please note that the portafilter, drip tray and water tank are not suitable for the
dishwasher.
7.1 Standard use of the installed machine with water tank
The switched off machine is put into operation as follows:
1. Make sure that there is enough water in the water tank.
2. Turn the power switch to position “I”. The machine is now on.
3. Wait until the boiler pressure gauge indicates approx. 1.01.3 bar or a temperature of 120° C
248°F has been reached.
4. Fill the portafilter with ground coffee (suitable for espresso).
5. Insert the portafilter into the brew group, pull-up the brew group lever and wait for coffee to
flow until reaching the requested quantity.
6. Push the brew group lever completely down to its original position.
Important
Before preparing the first coffee, please rinse the machine by extracting about 23 water
tank fillings from the brew group and the hot water wand. When the machine is switched
off, more hot water can be dispensed.
Risk of injury
All refill and cleaning procedures must be carried out with a machine disconnected from
the power source. The manufacturer accepts no liability for injury and damage to persons
or property caused by incorrect installation and/or use of the machine.
7.2 Standard use of the installed machine with direct water connection
The switched off machine is put into operation as follows:
1. Make sure that your water tap is always open during usage so that the machine does not run
out of water.
2. Make sure that there is enough pressure in the direct water supply connection.
3. Turn the power switch to position “I”. The machine is now on.
4. Wait until the boiler pressure gauge indicates approx. 1.01.3 bar or a temperature of 120° C
248°F has been reached.
5. Fill the portafilter with ground coffee (suitable for espresso).
6. Insert the portafilter into the brew group, pull-up the brew group lever and wait for coffee to
flow until reaching the requested quantity.
7. Push the brew group lever completely down to its original position.
Page 15

Important
Before preparing the first coffee, please rinse the machine by extracting about 35 water
tank fillings from the brew group and the hot water wand. When the machine is switched
off, more hot water can be dispensed.
Important
If you use large quantities of hot water through a water valve, please wait for the filled
water to reach the desired temperature.
7.3 Adjustment of the brewing pressure
Important
The brewing pressure of the machine can be adjusted manually by opening the machine
and adjusting the screw on the rotary pump. This adjustment must be carried out by
expert specialists.
7.4 PID display function
The PID control allows you to program the boiler temperature inside the boiler, so you can modify the
extraction temperature of the coffee from the brew group.
We recommend a temperature setting on the PID of 120°C at about 1.2 bar, which corresponds to an
outlet temperature of about 91°C. If the temperature is set lower, there will not be enough pressure to
froth milk.
7.4.1 Programing the temperature
Image 7
1. Turn the machine on.
2. To change the boiler temperature, keep the left key A pressed until the display reads PrG.
Then immediately press key B (image 7.
3. Press button A or B to increase or decrease the temperature (figure 7. After 3 seconds it will
remember the temperature you have set.
Page 16

7.5 Preparing coffee
Use the portafilter with 1 spout and the corresponding filter 1 cup for the preparation of 1 cup.
Use the portafilter with 2 spouts and the big filter 2 cups for the preparation of 2 cups.
1. Fill the basket with fresh espresso grounds. The reference line inside the filter basket can help
you find the right amount of coffee (image 8.
2. Press the ground coffee with the tamper.
3. Insert filter holder into the brew group.
4. Place an empty espresso cup/cups below the filter holder spout.
5. Pull the group lever up and wait for the coffee to flow from the spouts until the desired
amount is reached.
6. Push the group lever completely down to its original position.
7. When brewing is complete, remove the portafilter and discard coffee grounds.
Image 8
Reference line for the
desired ground coffee
in your basket
Important
Do not leave the lever in intermediate position to prevent malfunction of the brew group.
7.6 Dispensing of hot water
1. To deliver water into a jug, pot or cup, push down the hot water valve lever until reaching the
desired amount of water.
2. Put the hot water valve lever to its original position.
Risk of injury
Ensure that the hot water nozzle of the dispenser is placed into the water container in
order to avoid injuries due to hot water spray or spillage.
7.7 Dispensing steam
The Makina espresso machine S7 PROPID is able to provide large amounts of steam. Thanks to the
generic 3 liter copper boiler and the powerful 1800 W heating element. The Makina S7 PROPID is a
semi professional espresso coffee machine. It can prepare frothed milk within seconds. However,
frothing milk needs some practice. Try to not boil the milk, if you do the milk will not froth.
Page 17

7.8 Frothing milk
1. Push down the steam valve lever for a couple of seconds to release the condensation water in
the steam wand. Push the steam valve lever to its original position.
2. Position the nozzle (at the end of the steam pipe) of the steam wand into the milk pitcher. You
can decide the amount of milk up on your need (one cup or two cups).
3. Push down the steam valve lever, heat and froth the milk or the liquid.
4. When the desired temperature/milk froth is reached, put the steam valve lever back to its
original position. Clean the nozzle from the milk by wiping the nozzle with clean, non-abrasive
damp cloth.
Risk of injury
Keep the nozzle of steam wand always under the surface of the milk or the liquid during
the heating and or frothing process.
Risk of injury
Both the steam valve wand and hot water valve wand become very hot during using
them. Don’t touch them with your hands without protection.
8. Cleaning and maintenance
Cleaning the machine is not the most fun thing to do. Cleaning the machine is very important to the
performance, life and safety of your machine.
8.1 Daily
1. Clean the nozzle of the steam pipe from the milk residue daily by wiping the nozzle with clean,
non-abrasive damp cloth.
2. Clean the portafilter, filters, drip tray and water tank with water and food safe detergent.
3. When the machine is turned off and cold you can clean the body of the machine. We do not
recommend using any of the commercial stainless-steel cleaners.
4. Backflush the machine group head every day with water only (without espresso machine
detergent).
If the steam nozzle gets blocked with dry milk use a paperclip to unclog them. You can also unscrew
the nozzle and clean it with water.
Caution!
Be careful of the hot water spray while cleaning the brew group.
Important
Please note that the portafilters, drip tray and water tank are not suitable for the
dishwasher.
Page 18

Warning: before performing tests and maintenanceand replacing parts.
DISCONNECT THE MACHINE FROM THE MAINS.
8.2 Weekly
Backlash the machine every day (without espresso machine detergent), the group and shower plate
must be cleaned every day, ONCE a week use a detergent in the blind filter:
1. Put a half teaspoon of special espresso machine detergent in the blind filter and then insert it
into the brew group.
2. Pull-up the group brew lever and wait about 20 seconds. Put the lever down to its original
position (completely down until it stops).
3. Repeat this operation at least 57 times.
4. Empty the blind filter and repeat the same operation without detergent 5 times (with water
until). Repeat until the water runs clear.
5. Remove blind filter and replace it with the regular filter. Finally prepare one coffee to remove
residual detergent taste.
8.3 Monthly
Please refresh the boiler water once every month by extracting hot water from the hot water wand.
Important
The machine can only be dismantled by an authorizedtechnician.
A calcified machine may only be descaled by your specialized dealer because a partial
disassembly of the boiler and the tubing may be necessary to prevent the system from
being blocked by lime residues. A late descaling can cause substantial damage to the
machine.
Risk of injury
Be careful of the hot water spray while cleaning the brew group.
Important
Never use abrasive or chloric detergents!
Caution!
If you clean the brew group too often with cleaner, it may start squeaking. Do not clean it
too often with cleaner, you will degrease all the moving parts and they will wear out
quickly. It s better if you clean the brew group from time to time without detergent.
Page 19

9.0 Troubleshooting
Trouble
Cause
Solution
The appliance doesn’t switch ON
1. Mains switch is OFF
2. Machine switch is OFF
3. Wrong connection to mains
1. Set mains switch ON
2. Set machine switch in pos. ON
3. Contact service for check
Missing coffee delivery from
groupusing water tank
1. Water tank emptyor there is not enough water
in the water tank
2. Water tank is not fixed properly
3. Machine in use with water tank connection, but
switch in position “1” (=position direct water
connection). Machine does not take in water.
4. Vale in position for operating the machine with
direct water connection (facing the front of the
machine)
1. Refill water tank
2. Fix the water tank properly
3. Switch to position “0” (=position
water tank connection)
4. Turn the valve in position for
operating the machine with a water
tank (facing the rear of the machine)
Missing coffee delivery from
groupusing direct water
connection
1. Valve of the direct water connection is shut off.
2. Machine in use with direct water connection,
but switch in position “0” (=position water tank).
Machine does not take in water
3. Vale in position for operating the machine with
water tank (facing the rear of the machine)
1. Open the direct water connection
valve
2. Switch to position “1” (=position
direct water connection)
3. Turn the valve in position for
operating the machine with direct
water connection (facing the front
of the machine)
The machine does not stop
working when there is no water in
the tank and takes in air.
Machine in use with a water tank, but switch in
position “I” (= position direct water connection)
Switch to position “0” (=position
water tank connection)
Coffee dregs are wet
1. Coffee grinding is too fine
2. Group is still cold
3. Group valve doesn’t work
properly
1. Adjust grinding degree
2. Wait for appliance to get warm
3. Clean group exhaust system
Coffee delivery is too slow
1. Coffee grinding is too fine
2. Filter holder is dirty
3. Group is clogged
4. Injector or valve are partiallyclogged
1. Adjust grinding degree
2. Replace filter and clean filter
holdermore frequently
3. Contact service
4. Replace injector or valve
Coffee delivery is too fast
1. Coffee grinding is too gross
1. Adjust grinding degree
Delivered coffee is cold
1. Heat-exchangers or heating
element coated with limestone
2. Pressure-switch contacts are
oxidised
3. Defective electrical connections
4. Heating element is burned
1. Contact service for overhauling
2. Clean pressure-switch contacts
3. Contact service to check the
connections
4. Replace heating element
Little or no crema on the top of
the coffee
1. The grind is not fine enough.
2. The coffee is too old
3. There is too much chlorine in the water
4. The amount of ground coffee is not enough
5. The shower screen is dirty
1. Use a finer grind
2. Tamp the ground coffee more
firmly
Page 20
