Makita 6016D Manual

6016D
10mm Cordless Drills
Model Battery
Keyed 3Hr No
N/A N/A N/A NoKeyless
1Hr Yes
N/A N/A N/A NoKeyless
1Hr Yes
Motor DC 7.2V magnet motor
Battery
6016D
6017D
H:600rpm L:200rpm
No load speed
6018D
Chuck capacity
Steel
10mm(3/8")
Wood
15.4mm(5/8")
Capacities
Wood screw
H
L
6016D
6017D
6018D
The standard equipment for the tools shown may differ from country to country.
These 7.2V cordless drills are redesigned versions
of existing Model 6012D, 6015D,6172D and their brief
benefits are;
*Easy operation
by ergonomic design for easily pushing the axis of drilling
*Very quiet
*Equipped with electric brake
Speed
control Drill chuck Fast charger
Plastic
Carrying
case
Charging
time
6016 DW
6017 D
6017 DW
6018 D
6018 DW
2 speeds
(H&L)
2 speeds
(H&L)
+
variable
speed
Battery
7000
Battery
7000
Battery
7000
DC 7020
DC 9700
or DC 7100
DC 9700
or DC 7100
Max.fastening
torque
Net weight
(including
battery)
Battery7000(Ni-Cd,7.2V,1.3Ah)
H:0-600rpm L:0-200rpm
1.0-10mm(1/32-3/8")
5.1mm(13/64")X35mm(1-3/8")
Approx.40Kgf-cm(35in-lbs)
Approx.120Kgf-cm(104in-lbs)
1.0Kg(2.2lbs)
1.0Kg(2.2lbs)
1.1Kg(2.4lbs)
<Note>L: Low speed H:High speed
Specifications
CONCEPTION AND MAIN APPLICATIONS
Models No.
New Tool
TECHNICAL INFORMATION
Description
244(9.5/8")
221(8.3/4")
56(2-3/16")
251(9.7/8")
213(8.3/8")
56(2.3/16")

2 speeds by gear change (slide-button)
Ergonomic design
for easilly pushing axis of drilling
Bit holder
Bits can be held
at both right and left sides.
Chuck key holder
Charging time : 3Hr
by Fast Charger DC7020 with Charging Base
Charging Base DC7020
2 speeds by gear change (slide-button)
Keyless chuck
Ergonomic design
for easilly pushing axis of drilling
Bit holder
Bits can be held
at both right and left sides.
Charging time : 1Hr
by Fast Charger DC9700 or DC7100
Very quiet
6017D/6018D : 67dB (total noise of eight 6017D/6018D' s=noise of one 6015D/6172D)
6015D/6172D : 76dB
Very quiet
6016D : 67dB (total noise of eight 6016D' s=noise of one 6012D)
6012D : 76dB
(1)6016D
(2)6017D,6018D

6016DW 6017D 6017DW 6018D 6018DW
Yes
Battery Cover Yes No Yes No Yes
Chuck Key Yes No
Chaging Base Yes No
Plastic Carrying Case No Yes No Yes
See the attached sheets for more information
(1) Cautions in disassembling
To replace the gear assembly, first disassemble the drill chuck.(To disassemble only the housing, its no need to
disassemble the chuck.)
Use care not to miss the compression spring 4 inside the speed change lever since it can be easily jumped out
when disassembling.
+- Bit2-45 (2 pcs.)
Drill Bit 1.5,2,3,4,5,6
Drill Bit for wood 9,12,15
Philips Bit l-65, 2-45,2-65,2-82,2-110, 2-150,2-250,3-45,3-65,3-110
Slotted Bit 5-45,5-82,6-70,6.35-45,8-40,8-70
Foam Polishing Pad 125
Rubber Pad Assembly
Wool Bonnet 100
Fast Charger DC7100, DC9700, DC1201, DC1209
Automotive charger DC7112
Standard equipment
Optional accessories
Features and benefits
Repair
Speed change lever
Compression spring 4
Figure 1

(2) Cautions in assembling
(d) Assembling of drill chuck
1) Fasten the chuck into the spindle and body face .
2) Mount the hexagon rod on the chuck and use the vice to fix the hexagon rod.
3) Set to the normal rotation and low speed. Use the full charged battery.
4) Insert the switch and fasten the chuck while securely holding the handle.
*Weakly holding the handle may let you turned around when motor locking.
5) Widen the claw of chuck at maximum and fasten the pan head screw for holding the chuck.
*The left hand thread is used for pan head screw.
(c) Assembling on the housing
1) To assemble the one body of gear assembly and motor etc. on the housing L, place the speed change lever
at the position as shown on the figure 4.
2) Use care that the compression spring 4 may not be jumped out in assembling on the housing.
(b) Mounting of speed change lever
1) Mount the compression spring 4 on the speed change lever.
2) Mount the speed change lever on the protrusion of the change lever as shown on the figure 3 while using
care so that the compression spring 4 may not be jumped out.
(a) Assembling of motor and gear assembly
*Since the motor bracket is mounted on the gear assembly for
repair, turn counterclockwise(viewed from motor bracket
side) the motor bracket beforehand to disconnect it from the
gear assembly.
1) Screw the motor bracket into the motor.
2) Turn clockwise(viewed from motor bracket side) the motor
assembling parts(shown in 1)to mount them on the gear
assembly. At this time assemble in a way that the red mark
on the motor edge is placed on the change lever side of the
gear assembly.
Red mark
Turning direction in assembling
Motor bracket
Gear assembly
Motor
Compression spring 4
Speed
change
lever
Motor
Protrusion of the change lever
Gear assembly
Inner side of
housing L
Figure 4
The speed change lever should
be positioned at either side
Figure 3
Figure 2

Terminal Switch
Red
Black
Red mark
DC motor
T+
T-
Circuit drawing
