Parts Breakdown 9005B
Page 1 of 3 2/8/2008

Parts Breakdown 9005B
Fig # Part ID Part Name Quantity
1 266041-8 TAPPING SCREW, FLANGE 5X25, 5177B 4
1 911241-2 P.H. SCREW M5X25, 9005B 4
2 341680-6 TOOL REST, 9005B,T1 1
3 156735-2 GEAR HOUSING, 9005B,T1 1
3 159710-7 GEAR HOUSING,9005B,T2 1
7 181737-9 BEVEL GEAR SET,9005B 1
8 211061-7 B. BEARING 6000LLB, 6222DWE 1
8 211088-7 BALL BEARING 6000DDW, 9005B 1
9 341681-4 PLATE, 9005B 1
10 254002-0 WOODRUFF KEY 3, 9217SPC 1
11 241517-6 FAN 70, 9005B 1
12 516091-6 ARMATURE ASSEMBLY,9005B 1
13 681613-2 INS. WASHER, JN3200 1
14 210005-4 BALL BEARING 608DDW, 9031 1
14 211033-2 B. BEARING 608LB, 5091D 1
15 522516-0 FIELD, 9005B 1
16 687010-0 BAND, 9005B 1
17 263014-2 RUBBER PIN 4, 9217SPC 1
18 266029-8 T. SCREW FLANGE PT 5X65,JR3020 2
18 911290-9 P.H. SCREW M5X65, 2711 2
19 263002-9 RUBBER PIN 4, HR2400 1
20 961052-5 RETAINING RING S-12, 9218PBL 1
21 181737-9 BEVEL GEAR SET,9005B 1
22 962151-6 RETAINING RING R-32, 9005B 1
23 211106-1 B. BEARING 6201LLB, 5007NB 1
23 211129-9 BALL BEARING 6201DDW, N9501B 1
24 253824-5 F. WASHER 21, 9005B,T1 1
24 267126-3 FLAT WASHER 22, 6913D 1
25 443051-4 FELT RING 20, 9005B 1
26 254002-0 WOODRUFF KEY 3, 9217SPC 1
27 321336-7 SPINDLE, 9005B 1
28 251259-4 P.H. SCREW M5X16, 9505BH 1
30 315282-4 HOUSING W/O BEARING, 9005B 1
31 266034-5 TAPPING SCREW 4X16, 9524NB 4
31 266148-0 H.S.H. BOLT M4X14, 9005B 4
31 911121-2 P.H. SCREW M4X14, 9217SPC 4
32 133498-7 5 WHEEL COVER 1
32 135040-0 WHEEL COVER ASSEMBLY, 9005B 1
33 224361-6 INNER FLANGE 82, 9505BH 1
33 224368-2 INNER FLANGE 45, 9561CV 1
33 224378-9 INNER FLANGE 45 1
34 224509-0 LOCK NUT, 9005B 1
34 224566-8 LOCK NUT 5/8-45, 9561CV 1
34 224568-4 LOCK NUT 5/8-45, 9005B 1
36 854116-1 NAME PLATE, 9005B 1
37 153455-9 MOTOR HOUSING COMPLETE,9005B 1
37 153548-2 MOTOR HOUSING CPL,9005B 1
37 153548-2 MOTOR HOUSING CPL,9005B 1
37 153548-2 MOTOR HOUSING CPL,9005B 1
37 156734-4 MOTOR HOUSING, JN3200 1
38 191945-4 CARBON BRUSH CB-124, 9045B 1
39 643600-9 BRUSH CAP 6-10, 9005B 2
40 651128-3 SWITCH, 9005B 1
42 911248-8 P.H. SCREW M5X28, HM1500 2
42 266041-8 TAPPING SCREW, FLANGE 5X25, 5177B 2
43 911143-2 P.H. SCREW M4X22, 6211D 3
44 182418-8 HANDLE SET, 9005B 1
44 182853-0 HANDLE SET, 9005B 1
44 182853-0 HANDLE SET, 9005B 1
46 265941-9 TAPPING SCREW M4X18, N1900B 2
Page 2 of 3 2/8/2008

Parts Breakdown 9005B
46 265995-6 TAPPING SCREW 4X18, 4323K 2
47 687063-9 STRAIN RELIEF, 4323K 1
48 664064-4 CORD (2X18X8 SJ), HR2400 1
49 682503-2 CORD GUARD 8-90, 9005B 1
49 682572-3 CORD GUARD, 6304LR 1
50 911248-8 P.H. SCREW M5X28, HM1500 2
50 266041-8 TAPPING SCREW, FLANGE 5X25, 5177B 2
51 411876-4 BAFFLE PLATE, JN3200 1
52 182853-0 HANDLE SET, 9005B 1
52 182853-0 HANDLE SET, 9005B 1
52 182418-8 HANDLE SET, 9005B 1
400 152492-0 GRIP 36 COMP. 9005B-T2 1
401 794046-3 DEPRESS CENTER WHEEL, 9505BH 1
402 782412-6 LOCK NUT WRENCH 28, GA7911 1
902 261039-0 URETHANE WASHER 14,9005B 3
903 687051-6 STRAIN RELIEF, NHP1310 1
904 819001-5 MAKITA LABEL, 9015A 1
905 810155-1 N/A 1
Page 3 of 3 2/8/2008
