Parts Breakdown 9077SL
Page 1 of 3 2/8/2008

Parts Breakdown 9077SL
Fig # Part ID Part Name Quantity
1 416972-3 CAP,9077SL 1
2 416971-5 PIN CAP,9077SL 1
3 233031-6 COMPRESSION SPRING 12, 9040L 1
4 151772-1 GEAR HOUSING CPL.,9077SL 1
5 922261-1 H.S.H. BOLT M5X40, LS1011 4
6 151776-3 GRIP CPL., 9077SL 1
7 213011-8 O RING 7, HR2511 1
8 256455-9 PIN 11,9077SL 1
9 331566-2 SLEEVE 10,9077SL 1
10 231995-8 RING SPRING 9,9077SL 1
11 253878-2 F. WASHER 10, 4301BV 1
12 226790-9 SPIRAL BEVEL GEAR ,9077SL 1
13 231994-0 LOCK SPRING 17,9077SL 1
14 231993-2 LOCK SPRING 25,9077SL 1
15 323944-0 LOCK SLEEVE,9077SL 1
16 213757-6 O RING 80,9077SL 1
17 285836-0 BEARING RETAINER 50,9077SL 1
18 211326-7 B. BEARING 2012DDW, 3612BRA 1
19 267041-1 F. WASHER 20, 9077SL 1
20 151774-7 BEARING BOX CPL., 9077SL 1
21 151778-9 SPINDLE CPL.,9077SL 1
22 922221-3 HEX BOLT M5X16, 6906 4
23 163425-0 WHEEL COVER, 9077SL 1
24 265050-4 PAN HEAD SCREW M8X25, 9046 1
25 224317-9 INNER FLANGE 89, 9040L 1
26 224509-0 LOCK NUT, 9005B 1
26 224568-4 LOCK NUT 5/8-45, 9005B 1
27 931403-6 HEX NUT M8, 406 1
28 226789-4 SPIRAL BEVEL GEAR 11,9077SL 1
29 211132-0 BALL BEARING 6301DDW, 9040L 1
30 267113-2 FLAT WASHER 12, 8412DWG 1
31 262085-6 RUBBER RING 38,9077SL 1
32 285835-2 BEARING RETAINER 47,9077SL 1
33 912222-9 C.S.H. SCREW M5X16, 2711 2
34 516796-8 ARMATURE ASS'Y 115V, 9077SL 1
35 681630-2 INSULATION WASHER 10, 9040L 1
36 253001-9 F. WASHER 10, 9077SL 1
37 211087-9 B. BEARING 6200DDW, JR3000V 1
38 416131-9 BAFFLE PLATE, 9040L 1
39 266029-8 T. SCREW FLANGE PT 5X65,JR3020 2
40 528934-0 FIELD ASS'Y 115V,9077SL 1
41 183147-6 MOTOR HOUSING SET,9077SL 1
41 183574-7 MOTOR HOUSING CPL. 9077SL 1
42 819064-1 MAKITA MARK, HM1100C 2
43 851825-3 NAME PLATE, 9077SL 1
44 643700-5 BRUSH HOLDER CAP 7-18 , HM1500B 2
45 191957-7 A.C.CARBON BR.SET,CB-204,HM1800 1
48 183117-5 HANDLE SET,9077SL 1
49 631364-7 SOFT START CIRCUIT,9077SL 1
51 651158-4 SWITCH 1362.2105,9077SL 1
51 651191-6 SWITCH, GA9040S 1
52 231402-1 COMP. SPRING 7, LS1045 1
53 416998-5 LOCK BUTTON,9077SL 1
54 687010-0 BAND, 9005B 1
55 183117-5 HANDLE SET,9077SL 1
56 911148-2 P.H. SCREW M4X25, 5057KB 4
57 265995-6 TAPPING SCREW 4X18, 4323K 2
58 687052-4 STRAIN RELIEF, HM1500B 1
59 664463-0 CORD (2X14X8 SJ), 2414B 1
60 682560-0 CORD GUARD 10, HM1202C 1
Page 2 of 3 2/8/2008

Parts Breakdown 9077SL
61 911221-8 P.H. SCREW M5X16, JR3000V 3
1,001 782412-6 LOCK NUT WRENCH 28, GA7911 1
1,002 741425-6 GRINDING WHEEL 1
5,001 810158-5 N/A 1
Page 3 of 3 2/8/2008
