Parts Breakdown 6910
Page 1 of 3 2/8/2008

Parts Breakdown 6910
Fig # Part ID Part Name Quantity
1 421120-1 BUMPER, 6910 1
2 156135-6 HAMMER CASE, 6910 1
3 253909-7 F. WASHER 35, 6910 1
4 231921-7 RING SPRING 22, TW1000 1
5 325587-4 ANVIL,TW1000 1
6 253182-9 F. WASHER 36, 6910 1
7 221815-4 S. GEAR, 6910 1
8 256051-3 PIN 10, 6910 2
9 212063-6 N. BEARING 1012, GA7911 2
10 221816-2 S. GEAR, 6910 2
11 325416-1 SPINDLE, 6910 1
12 216010-9 STEEL BALL 10.3, 6910 2
13 253713-4 F. WASHER 35, 6910 1
14 333112-7 RING, 6910 1
15 231211-8 COMP. SPRING 36, 6910 1
16 231212-6 COMP. SPRING 49, 6910 1
17 253712-6 F. WASHER 36, 6910 1
18 216002-8 STEEL BALL 4.8, NHP1310 32
19 325415-3 HAMMER, TW1000 1
20 211451-4 BALL BEARING 6007LLB, 6910 1
21 256040-8 PIN 5, LS1030 2
22 312739-6 BEARING HOUSING,6910 1
23 211217-2 BALL BEARING 1511LLB, 6910 1
24 241613-0 FAN 90, 6910 1
25 513282-0 ARMATURE, 6910 1
26 265343-9 HEX BOLT M5X80, 6910 2
27 413009-7 BAFFLE PLATE, 6910 1
28 528342-5 FIELD ASS'Y 115V, 6910 1
28 623252-2 FIELD, 6910 1
29 953106-2 RIVET 0-5, HM1500 4
30 815015-2 NAME PLATE, 6910 1
31 942151-2 SPRING WASHER 6, 5007NB 4
32 922382-9 H.S.H. BOLT M6X60, 6910 4
33 156136-4 MOTOR HOUSING, 6910 1
34 681002-1 INS. WASHER, 2012 2
35 911216-1 P.H. SCREW M5X14, N9501B 2
36 284016-5 REAR COVER, 6910 1
37 421075-0 RING, 6910 1
38 211066-7 B. BEARING 6200LLB, BO4552 1
39 213051-6 DUST SEAL 10, 2711 1
40 181047-4 CARBON BRUSH SET 154,5402A 1
41 643650-4 BRUSH HOLDER CAP 6.5-13.5, 5402A 2
42 341367-0 BRUSH CAP COVER, 6910 2
43 911111-5 P.H. SCREW M4X10, LS1011 2
44 682505-8 CORD GUARD, 2711 1
45 664322-8 CORD (3X16X8 SJT), 1
45 664820-2 CORD (3X14X8 SJ), GA7001L 1
46 687600-9 STRAIN RELIEF, 2711 1
47 911116-5 P.H. SCREW M4X12, 4301BV 2
48 911106-8 P.H. SCREW M4X8, NHP1310 1
49 651558-8 SWITCH 1
50 312742-7 HANDLE COVER, 6910 1
51 911146-6 P.H. SCREW M4X25, 4200H 2
400 273444-9 GRIP 37, LS1013 1
401 312743-5 N/A 1
402 923456-9 C.S.N. BOLT M8X35, HR2511 1
403 345097-5 BELT, 6910 1
404 133184-0 SOCKET 1
404 134872-2 N/A 1
405 213570-2 O RING 44, 6910-T2 1
Page 2 of 3 2/8/2008

Parts Breakdown 6910
405 213603-3 O RING 47, 6910-T1 1
406 256091-1 PIN 5.5, 6910 1
406 256284-0 PIN 5, 6910 1
407 783203-8 HEX WRENCH 5, 2708 1
408 182363-7 N/A 1
408 182363-7 N/A 1
408 182363-7 N/A 1
409 941201-0 F. WASHER 8, 5037NB 1
500 123018-5 GRIP ASSEMBLY, 6910 1
900 810146-2 N/A 1
