Mamas & Papas Vito TT Quick guide

Vito TT
VOTT_0118_1011_V1

2
UNIVERSAL CATEGORY 9-18 Kg Y
BELTED
EN•The "Vito TT" child seat is attached to the car using its seat belt.

3
UNIVERSAL CATEGORY 9-18 Kg Y
ISOFIX & TOP TETHER
EN•The "Vito TT" child seat is attached to the car using the ISOFIX system.

OK
NO
N
NO
NO
NO
O
NO
O
UNIVERSAL CATEGORY 9-18 Kg Y BELTED

A
B
1 2
43

A
B
A
B
C
5
7 8
6

NO
NO
O
N
NO
UNIVERSAL CATEGORY 9-18 Kg Y ISOFIX & TOP TETHER

PUSH
OK
12
A
B
9
11
10

13 14
15 16

A
B
A
19 20
A
CC
B
17 18

22
24
23
21

NONO
A
B
27
OK
26
1
1
2
3
4
5
6
72
3
4
5
6
7
25
28

AB
30
32
31
A
29

B
A
B
AA
35 36
33 34

37
39 40
38

A
43 44
41 42

0409
45
46
4
3
1
2
1) BMADUO00•
2) BRIDUO00•
3) MUCI0082N
4) BSPDUO00•
Vito TT
EN• Spare parts available in different colours to be specified
when ordering.

18
EN_English In order to prevent an unsuitable (i.e. non Top Tether)
fastener being used, the car's TT fastener is generally
marked by a label bearing the following logo:
For more information and greater safety, consult your
vehicle's instruction and maintenance booklet.
Ensure the child seat is securely fastened using the Top
Tether strap. This not only guarantees utmost safety in
the event of collision, but also maximum child stability
during normal use.
Please remember that if necessary Vito TT can also
be fastened using the standard three-point seats belt
available by law on any vehicle.
IMPORTANT: TOP TETHER
Read carefully for proper use of your new Mamas
& Papas child seat: Vito TT.
Vito TT is the latest Mamas & Papas child seat for
children weighing 9-18 kg. It conforms to the European
R44/04 Directive.
Vito TT uses the ISOFIX fastening device with Top
Tether, in compliance with the most up-to-date
European Directives, as a guarantee of utmost safety
and reliability.
All recently produced vehicles are equipped by law
both with the ISOFIX fittings, placed where the backrest
meets the seat, and with the TOP TETHER connector.
This is normally located on the shelf behind the rear
seat in saloon vehicles (photo A), behind the rear seat in
hatchbacks (photo B), or in the boot in people carriers
and in SUVs / off-road vehicles (photo C):
BA C

19
Thank you for choosing a Mamas &
Papas product.
Product Characteristics
Child seat, Group 1,
“Universal” category with belts
• Approved under European standard UN/ECE R44/04 for
children weighing from 9 to 18 kg (from 1 to 4 years
approx).
• Suitable for installation on the majority of vehicle seats,
but not all.
• The car seat can be correctly installed if the vehicle's
use and maintenance manual indicates compatibility
with “Universal” Group 1 restraint systems.
• This car seat is classed as “Universal” in compliance with
stricter approval criteria than previous models that do
not have approval labels.
• The car seat can only be used in approved vehicles,
fitted with static or inertia-reel three-point safety
belts, approved under regulation UN/ECE no. 16 or
equivalent standards.
• Two-point belts and lap belts must not be used.
Child seat, Group 1, “Universal” category
with Isofix & Top Tether, class A
• Approved under European standard UN/ECE R44/04 for
children weighing from 9 to 18 kg ((from 1 to 4 years
approx).
• Suitable for installation on the majority of vehicle seats,
but not all.
• The child seat may be correctly installed if the vehicle's
instruction and maintenance booklet indicates
compatibility with "Universal", Group 1, class A, ISOFIX
car restraint systems.
• This car seat is classed as “Universal” in compliance with
stricter approval criteria than previous models that do
not have approval labels.
IMPORTANT
• “Vito TT” Group 1, must be fitted facing the
vehicle’s normal direction of travel.
• Do not fit “Vito TT” on vehicle seats that face away
or sideways with respect to the normal direction of
travel of the vehicle.
• We recommend that you always use the rear seat
on the opposite side to the driver’s seat.
• If it is fitted on the vehicle’s front seat, the car seat
should be positioned as far as possible from the
dashboard.
• The item is given a serial number.
• If you have any difficulty fitting Vito TT in your car,
lift up or remove the vehicle’s headrests.
• Do not use without the Top Tether strap. The Top
Tether strap is essential in order to guarantee
complete safety.
WARNING
• Read the instructions carefully before use and keep
them in the holder provided for future reference.
Failure to closely follow the installation instructions
for the car seat will put your child at risk.
• The assembly and installation procedures for
Vito TT must be carried out by adults.
The assembly and installation procedures must be
carried out without the child in the car seat.
• When travelling in the vehicle, never hold the child
in your arms and never put him/her anywhere but in
the seat. In the event of sudden braking, even at low
speeds, the child would be flung forward.
• Do not insert fingers into the mechanisms.
• When travelling take particular care to make sure that
luggage or other objects are not located where they
may injure the child in the car seat in the event of an
accident.
• Do not use installation methods different from those
indicated. This would result in the risk of detachment
from the vehicle’s seat.
• Ensure that the vehicle’s three-point safety belt
securing the car seat is always taut and not twisted. It
should be replaced if it undergoes significant strain due
to an accident.
• Never leave the child unattended in the car seat:

20
observe him/her even when he/she is sleeping.
• Never remove the child from the car seat while the
vehicle is in motion.
• Make sure that the car seat is not obstructed by any
moving parts of the vehicle’s seat or by one of the
doors.
• Adjust the height and tension of the straps, ensuring
that they are snug to the child's body without being
too tight. Check that the harness is not twisted and
that the child does not release it.
• This car seat is not designed for extended periods of sleep.
• Do not leave the car seat in vehicles exposed to the
sun. Some parts might heat up and be harmful to the
delicate skin of the child – check before placing the
child in the seat.
• Do not use the car seat without its fabric covering,
which cannot be replaced with one not approved by
the manufacturer since it is an integral part of the car
seat and the safety system.
• Do not use the car seat without the protective padding
for the shoulder straps as they are an integral part of
the car seat and the safety system.
• If you are unsure of anything, contact the manufacturer
or the retailer of this car seat.
• Do not remove the adhesive and stitched labels as this
might mean the product is no longer compliant with
standards.
• Do not use the car seat if it shows signs of breakage
or missing parts, if it is second hand, or if it has been
subjected to violent stress in an accident, because it might
have suffered extremely dangerous structural damage.
• Do not modify the product.
• For any repairs, replacement parts or information on
the product, contact the post-sales assistance service.
The relevant information is provided on the last page
of this manual.
• The car seat should always be secured in the vehicle, even
when the child is not present. In the event of sudden
braking, it could injure the occupants of the vehicle.
• Do not use this car seat after five years from the date
of production indicated on the structure. The natural
ageing of the materials may mean that it is no longer
compliant with standards.
• Do not use accessories that are not approved by the
manufacturer or by the competent authorities.
Instructions for use
UNIVERSAL CATEGORY - Belted
Fastening with seat belts
1• Place the Vito TT car seat on the vehicle’s seat, facing in
the normal direction of travel of the vehicle, as shown
in the figure. The car seat is equipped with a protective
base.
Do not remove it when fitting the car seat with the
safety belts.
2• To make it easier to pass the vehicle’s safety belts
through the back of the car seat, it is necessary to
recline the seat to the lowest position by operating the
lever, as shown in the figure.
3• Pass the vehicle’s safety belt between the frame and
the shell of the car seat.
4• The lap belt must pass through the low slots marked in
red. Fasten the belt, ensuring that it clicks into place.
5• Check that the lap belt has gone through the low slots
marked in red and tighten it.
6• Bring the backrest back to the vertical position by
pulling the handle below the seat (Fig. a) and pushing
the child seat as in figure (Fig. b).
7• To complete the securing procedure in a vehicle, use
the Steady Fix device. Open the clip and pass the
diagonal strap through it, ensuring that it is taut and
not twisted (Fig. a). Close the safety tab (Fig. b).
8• IMPORTANT: Take hold of the safety belt and pull
it upwards firmly to fit Vito TT more closely to the
seat of the vehicle (Fig. c).
Once the procedure is complete, it is possible to recline
the seat to the desired position (See Point 2).
Instructions
UNIVERSAL CATEGORY - Isofix & Top
Tether
Fastening with Isofix & Top Tether
9• Use the lever as shown in the figure to recline the seat
