Mammoth Tents Pro+ 240HC User manual

Two Person Assembly
Assembly Instructions
Close tent zip top to bottom as shown.
Fit equipment hanger ends to poles.
Position equipment hangers as required.
Close tent zip
starting top right as shown.
Step 5
Step 6
Equipment Hangers
Upper Equipment Hanger
Lower Equipment Hanger
Blue Pole
x9
Parts List
3-Way
Corner
x8
Equipment
Hanger Ends
x16
Yellow Pole
x28
Support Pole
Rubber Foot
x1
Support Pole
Rubber Top
x1
Straight Pole Connectors x2 Centre Securing Ring x1
4-Way
Join
x8
Black Pole
x9
Assembly Guide
Pro 240HC, 300HC
Mammoth
Equipment
Hanger End
Pro 240HC 300HC
mammothtents.nl
+
+

Organise poles and connectors into their colours and groups.
Unzip and lay out tent.
Locate floor section and lay flat with edge sections vertical.
Assemble floor poles and 3-way corners and 4-way Joins as shown.
Fit support pole.
Lift tent over roof as shown.
Step 1
Step 2
Step 3
Step 4
3-Way Corner
4-Way Join
3-Way Corner
4-Way Join
ring
Straight Pole
Connectors
Centre
Securing Ring
Insert ceiling poles into 3-way corners and 4-Way joins.
Fit centre securing ring over pole before fitting to 4-way join.
Fit centre ceiling poles into straight pole connectors.
Support Pole
Rubber Ends
Insert lower wall poles (chamfered end) into 3-way corners and 4-way Join.
Insert upper wall poles (shrunk end) into lower poles.
Fit 3-way corners and 4-way joins on top.
