Mammoth Tents Elite 240L User manual

Elite 240L
mammothtents.nl
Two Person Assembly Recommended
Assembly Instructions
Insert pole into connector
(ensure poles are fully inserted)
Lock poles into connecters
by rotating left or right
Equipment Hangers
Upper Equipment Hanger
Lower Equipment Hanger
Parts List
Green Pole
x16
Straight
Connector
x8
3-Way
Corner
x8
Equipment
Hanger Ends
x8
3-Way
T Piece
x10
Yellow pole
x12
Red Pole
x11
Rotate locking
mechanism until it clicks Insert pole into connector
(ensure poles are fully inserted)
If unable to Insert pole
CLICK!
NOTE
Connect wall panel zip to the roof
and base zips (under Velcro flaps).
Step 5
Zip the wall panel to the roof and base.
Step 6

Lay out base ensuring Velcro flap is in front right corner.
Assemble floor poles, 3-way corners and 3-way T pieces as shown.
3-Way Corner
Velcro Flap
Step 1
3-Way T Piece
Insert lower wall poles into 3-way corners and 3-way T pieces.
Fit straight connectors.
Insert upper wall poles into straight connectors.
Fit 3-way corners and 3-way T pieces on top.
3-Way Corner
Straight Connector
Step 2
3-Way T Piece
Insert ceiling poles into 3-way corners and 3-way T pieces.
Fit equipment hanger ends to poles. Position equipment hangers as required.
Equipment
Hanger End
Step 3
3-Way T Piece
Fit roof ensuring Velcro
flap is in front right corner.
Step 4
Velcro Flap
