MAN Diesel & Turbo L28/32H User manual

L28/32H
Instruction Manual - Marine
Four-stroke GenSet
compliant with IMO Tier II

MAN Diesel
IndexGenSet
L28-2
Text Index Drawing No.
Engine data 500/600
Preface Description A6000
Warning Description A6001
Questionnaire Description A6002
Main particulars Description 600.00 (07H)
Introduction Description 600.01 (08H)
Safety Description 600.02 (06H)
Cross section Description 600.05 (07H)
Key for engine designation Description 600.10 (02H)
Designation of cylinders Description 600.11 (01H)
Engine rotation clockwise Description 600.12 (02H)
Code identification for instruments Description 600.20 (03H)
Introduction to planned maintenance programme Description 600.24 (02H)
Planned maintenance programme Description 600.25 (33H)
Operation data & set points Description 600.30 (50H)
Green Passport Description 600.33 (02H)
Data for pressure and tolerance Description 600.35 (16H)
Data for tightening torque Description 600.40 (18H)
Declaration of weight Description 600.45 (01H)
Ordering of spare parts Description 600.50 (06H)
How to return spare parts Description 600.51 (05H)
Service letters Description 600.55 (01H)
Conversion table Description 600.60 (01)
Basic symbol for piping Description 600.65 (01H)
Operation of engine 501/601
Operating Description 601.01 (21H)
Out of service Description 601.05 (17H)
Starting-up after out of service periods Description 601.10 (17H)
Guidelines for longterm low-load operation on HFO Description 601.15 (03H)
Guidelines regarding MAN Diesel GenSets operating on low
sulphur fuel oil Description 601.16 (02H)
Performance and condition 502/602
Engine performance and condition Description 602.01 (12H)
Evaluation of readings regarding combustion condition Description 602.02 (11H)
Condensate amount Description 602.05 (08H)
Engine performance data Working card 602-01.00 (03H)
Trouble shooting 503/603
Starting failure Description 603.01 (08H)
Faults in fuel oil system Description 603.02 (09H)
Disturbances during running Description 603.03 (08H)
Ignition in crankcase Description 603.04 (09H)
Trouble shooting guide for centrifugal by-pass filter Description 603.05 (08H)
Trouble shooting guide for turbine starter Description 603.06 (09H)
Trouble shooting guide for cooling water system Description 603.09 (08H)
Trouble shooting guide for lubricating oil cooler Description 603.10 (01H)
Media specification 504/604
Quality requirement for lube oil (SAE30) for heavy fuel oil operation
(HFO) Description 604.01 (27H)

MAN Diesel
Index GenSet
L28-2
Text Index Drawing No.
Quality requirem. for lube oil (SAE30) for operation with gas oil, diesel
oil (MGO/MDO) and biofuel Description 604.01 (26H)
Treatment and maintenance of lubricating oil Description 604.03 (11H)
Criteria for cleaning/exchange of lubricating oil Description 604.04 (17H)
Lubricating points Description 604.05 (01H)
Lubricating points Description 604.05 (02H)
Lubricating oil in base frame Description 604.06 (16H)
Specific lube oil consumption - SLOC Description 604.07 (02H)
Heavy fuel oil (HFO) specification Description 3.3.3-01
Diesel oil (MDO) specification Description 3.3.2-01
Gas oil / diesel oil (MGO) specification Description 3.3.1-01
Bio fuel specification Description 3.3.1-02
Viscosity-temperature diagram (VT diagram) Description 3.3.4-01
Fuel oil cleaning Description 604.30 (01H)
Engine cooling water specifications Description 3.3.7-01
Cooling water inspecting Description 000.07-01
Cooling water system cleaning Description 000.08-01
Water specification for fuel-water emulsions Description 3.3.10-01
Specifications for intake air (combustion air) Description 3.3.11-01
Cylinder head 505/605
Cylinder head Description 605.01 (14H)
Dismantling of cylinder head Working card 605-01.00 (01H)
Inspection of inlet valve, exhaust valve and valve guide Working card 605-01.05 (06H)
Reconditioning of valve spindle seat and valve seat ring Working card 605-01.10 (01H)
Valve rotator Working card 605-01.15 (01H)
Replacement of valve guide Working card 605-01.20 (05H)
Safety valve Working card 605-01.25 (04H)
Indicator valve Working card 605-01.26 (02H)
Replacement of sleeve for fuel injector Working card 605-01.30 (04H)
Replacement of valve seat ring Working card 605-01.35 (06H)
Mounting of cylinder head Working card 605-01.40 (06H)
Inspection of cylinder head cooling water space Working card 605-01.45 (01H)
Cylinder head Plate 60501-19H
Valve spindles and valve gear Plate 60502-31H
Safety valve and indicator valve Plate 60508-11H
Cylinder head, top cover Plate 60510-12H
Piston/connecting rod 506/606
Piston, connecting rod and cylinder liner Description 606.01 (10H)
Dismounting of piston and connecting rod Working card 606-01.00 (01H)
Separation of piston and connecting rod Working card 606-01.05 (03H)
Piston Working card 606-01.10 (09H)
Connecting rod Working card 606-01.15 (04H)
Criteria for replacement of connecting rod big-end and main bearing
shells Working card 606-01.16 (02H)
Mounting of piston and connecting rod Working card 606-01.20 (01H)
Hydraulic tightening of connecting rod screws Working card 606-01.25 (04H)
In-situ inspection of connecting rod big-end bearing Working card 606-01.30 (01H)
Inspection and honing of cylinder liner Working card 606-01.35 (08H)
Replacement of cylinder liner Working card 606-01.40 (01H)
Grinding of seal face on cylinder liner and cylinder head Working card 606-01.45 (01H)
Dismounting of piston and cylinder liner at low overhaul heights Working card 606-01.50 (01H)
Piston and connecting rod (hydraulic tightened) Plate 60601-34H
Cylinder liner Plate 60610-09H

MAN Diesel
IndexGenSet
L28-2
Text Index Drawing No.
Camshaft 507/607
Camshaft and camshaft drive Description 607.01 (05H)
Camshaft and camshaft drive Working card 607-01.00 (01H)
Inspection and replacement of camshaft bearing Working card 607-01.05 (01H)
Adjustment of camshaft for valve and injection timing Working card 607-01.20 (04H)
Intermediate wheel Plate 60701-06H
Camshaft and camshaft bearing Plate 60705-22H
Operating gear 508/608
Operating gear for valves and fuel injection pumps Description 608.01 (12H)
Inspection of valve roller guides Working card 608-01.00 (01H)
Inspection of fuel injection pump roller guide Working card 608-01.05 (01H)
Control and adjustment of valve clearance Working card 608-01.10 (01H)
Roller guide and push rods Plate 60801-17H
Control/safety 509/609
Control and safety system Description 609.01 (20H)
Instruments and automatics Description 609.05 (11H)
Lambda controller Description 609.10 (15H)
Starting box Description 609.35 (06H)
Converter for engine- and turbocharger RPM signal Description 609.40 (01H)
Functional test and adjustment of safety, alarm and monitoring
equipment Working card 609-01.00 (01H)
Functional test and adjustment of overspeed trip Working card 609-01.05 (01H)
Adjustment and test of ON/OFF pressostate Working card 609-05.00 (02H)
Adjustment and test of ON/OFF thermostate Working card 609-05.01 (02H)
Function and test of level switch (LAL 25) Working card 609-05.02 (02H)
Adjustment and test of analogous transmitter Working card 609-05.03 (02H)
Adjustment and test of analogous temperature transmitter Working card 609-05.04 (02H)
Adjustment of lambda controller Working card 609-10.00 (16H)
Governor and governor drive Plate 60901-13H
Governor and governor drive Plate 60901-14H
Governor and governor drive Plate 60901-15H
Regulating mechanism Plate 60902-18H
Overspeed device Plate 60903-38H
Instrument panel Plate 60905-20H
Instrument panel Plate 60905-27H
Instrument panel Plate 60905-32H
Thermometer Plate 60907-19H
Pressostate, thermostate, diff. pressostate and pressure transmitter Plate 60907-02H
Prelubricating oil alarm (LAL 25) Plate 60919-01H
Level switch in oil sump (LAL/LAH 28) Plate 60920-01H
Local starting box - No 1 Plate 60935-13H
Local starting box - No 1 Plate 60935-16H
Local starting box - No 2 Plate 60935-14H
Local starting box - No 2 (incl. high lub. oil temp.) Plate 60935-15H
Engine control box Plate 60936-08H
Termnal box Plate 60936-07H
Converter Plate 60956-01
Crankshaft 510/610
Crankshaft and main bearings Description 610.01 (12H)
Checking of main bearings alignment (deflection), hydraulic
tigthened connecting rod Working card 610-01.00 (10H)

MAN Diesel
Index GenSet
L28-2
Text Index Drawing No.
Inspection of main bearing shells Working card 610-01.05 (05H)
Inspection of guide bearing shells Working card 610-01.10 (08H)
Vibration damper Working card 610-04.00 (01H)
Crankshaft Plate 61001-15H
Crankshaft Plate 61001-21H
Resilient gear wheel Plate 61002-07H
Coupling for central drive lub. oil pump Plate 61002-11H
Coupling for central drive lub. oil pump Plate 61002-12H
Coupling for central drive lub. oil pump Plate 61002-13H
Coupling for central drive lub. oil pump Plate 61002-14H
Resilient gear wheel Plate 61002-15H
Resilient gear wheel Plate 61002-16H
Resilient gear wheel Plate 61002-17H
Flywheel with gear rim Plate 61003-02H
Flywheel with gear rim Plate 61003-05H
Flywheel with gear rim Plate 61003-06H
Torsional vibration damper Plate 61004-05H
Torsional vibration damper Plate 61004-12H
Torsional vibration damper Plate 61004-13H
Torsional vibration damper Plate 61004-14H
Torsional vibration damper Plate 61004-15H
Torsional vibration damper Plate 61004-16H
Tuning wheel Plate 61004-06H
Engine frame/Oil pan 511/611
Engine frame and base frame Description 611.01 (07H)
Functional test of crankcase safety relief valves Working card 611-01.00 (04H)
Frame with main bearings Plate 61101-11H
Front cover for lubricating oil pump Plate 61102-09H
Front cover for lubricating oil pump and cooling water pump Plate 61102-07H
Front cover for lubricating oil pump and cooling water pumps Plate 61102-10H
Covers on frame Plate 61106-20H
Cover on frame Plate 61106-14H
Turbocharger 512/612
Turbocharger system Description 612.01 (28H)
Cleaning the turbocharger in service, water washing of compressor Description 612.05 (07H)
Cleaning the turbocharger in service, dry cleaning - turbine Description 612.10 (09H)
Cleaning the turbocharger in service, water washing - turbine side Description 612.15 (02H)
Overhaul of charging air cooler Working card 612-01.00 (02H)
Charge air cooler housing - draining Working card 612-01.05 (02H)
Water washing of compressor side - turbochager type NR15/R -
NR20/R - NR24/R - NR26/R Working card 612-05.00 (03H)
Dry cleaning of turbocharger - turbine side Working card 612-10.00 (02H)
Water washing of turbine side Working card 612-15.00 (01H)
Charging air cooler - freshwater Plate 61201-12H
Charging air cooler - freshwater Plate 61201-13H
Charging air cooler - freshwater Plate 61201-14H
Charging air cooler - freshwater Plate 61201-15H
Charging air cooler - seawater Plate 61201-16H
Charging air cooler - seawater Plate 61201-17H
Charging air cooler Plate 61201-29H
Exhaust pipe arrangement Plate 61202-23H
Exhaust pipe arrangement with welded compensator Plate 61202-32H
Exhaust pipe arrangement Plate 61202-26H

MAN Diesel
IndexGenSet
L28-2
Text Index Drawing No.
Exhaust pipe arrangement with welded compensator Plate 61202-28H
Exhaust pipe arrangement Plate 61202-27H
Exhaust pipe arrangement with welded compensator Plate 61202-42H
Water washing of compressor side Plate 61205-02H
Steam trap Plate 61208-01H
Blowgun for dry cleaning of turbocharger Plate 61210-02H
Compressed air system 513/613
Compressed air system Description 613.01 (20H)
Air filter Working card 613-01.21 (02H)
Overhaul, test and inspection of turbine starter Working card 613-01.30 (02H)
Main starting valve Working card 613-01.40 (01H)
Check of compressed air piping system Working card 613-01.90 (02H)
Turbine starter Plate 61309-05H
Main starting valve Plate 61310-03H
Muffler Plate 61312-02H
Emergency starting valve Plate 61313-03H
Starting valve Plate 61314-03H
Main stop valve Plate 61315-03H
Air strainer Plate 61316-03H
Safety valve Plate 61319-01H
ON-OFF valve for jet system Plate 61320-05H
ON-OFF valve for jet system Plate 61320-06H
Air filter Plate 61321-03H
Pressure reduction valve Plate 61322-04H
Turning gear Plate 61325-07H
Pneumatic turning gear (motor power unit) Plate 61325-08H
Pneumatic turning gear (spindle, gear case and gearing) Plate 61325-09H
Fuel oil system 514/614
Internal fuel oil system Description 614.01 (25H)
Fuel injection pump and fuel injection pipe Working card 614-01.05 (02H)
Fuel injection pump and fuel injection pipe Working card 614-01.05 (05H)
Fuel injection valve Working card 614-01.10 (03H)
Fuel oil split filter Working card 614-01.15 (01H)
Check of fuel oil piping system Working card 614-01.90 (01H)
Adjustment of the maximum combustion pressure Working card 614-05.01 (02H)
Fuel injection pump Plate 61401-03H
Fuel injection pump Plate 61401-09H
Fuel injection valve Plate 61402-04H
Fuel injection valve, cooled Plate 61402-07H
Fuel oil filter duplex Plate 61403-15H
Fuel injection pipe Plate 61404-06H
Pipes on cylinder section - forced lubrication with cooling oil pipes Plate 61430-03H
Nozzle cooling pump Plate 61440-05H
Lubricating oil system 515/615
Internal lubricating oil system Description 615.01 (29H)
Lubricating oil cooler Description 615.06 (02H)
Centrifugal by-pass filter Description 615.15 (05H)
Crankcase ventilation Description 615.31 (03H)
Lubricating oil pump, engine driven Working card 615-01.00 (01H)
Prelubricating pump Working card 615-01.05 (02H)
Lubricating oil filter Working card 615-01.10 (01H)

MAN Diesel
Index GenSet
L28-2
Text Index Drawing No.
Lubricating oil, thermostatic valve Working card 615-01.20 (01H)
Check of lubricating oil piping system Working card 615-01.90 (01H)
Lubricating oil cooler Working card 615-06.00 (02H)
Centrifugal by-pass filter Working card 615-15.00 (01H)
Lubricating oil pump (central driven) Plate 61501-12H
Lubricating oil pump (gear driven) Plate 61501-22H
Lubricating oil filter (Type A) Plate 61502-11H
Lubricating oil filter (Type B) Plate 61502-12H
Lubricating oil filter (suppl. for plate 61502-11H/12H) Plate 61502-15H
Lubricating oil thermostatic valve Plate 61503-08H
Prelubricating pump with el-motor Plate 61504-04H
Lubricating oil cooler Plate 61506-10H
Centrifugal by-pass filter Plate 61515-09H
Hand wing pump Plate 61525-02H
Lubricating oil separator Plate 61530-07H
Lubricating oil pipes on engine Plate 61530-02H
Cooling water system 516/616
Cooling water system Description 616.01 (17H)
Cooling water thermostatic valve Description 616.04 (15H)
Check of cooling water system Working card 616-01.90 (01H)
Cooling water thermostatic valve Working card 616-04.00 (01H)
Cooling water thermostatic valve Plate 61604-07H
High temperature fresh water pump Plate 61610-05H
Low temperature fresh water pump Plate 61610-07H
Low temperature fresh water pump Plate 61610-10H
Sea water pump Plate 61615-04H
Pipes on cylinder head Plate 61625-04H
Cooling water pipes on engine Plate 61630-01H
Preheater - fresh water Plate 61635-06H
Special equipment 517/617
Kit for cylinder unit Kit 61704-02H
Kit for overspeed device Kit 61743-01H
Kit for covers on frame Kit 61751-01H
Specific plant information 519/619
Resilient mounting of generating sets Description 619.03 (10H)
Fitting instructions for resilient mountings of gensets Working card 619-03.00 (21H)
Fitting instructions for resilient mountings of gensets Working card 619-03.00 (22H)
Fitting instructions for resilient mountings of gensets Working card 619-03.00 (23H)
Replacement of conicals Working card 619-03.05 (01H)
Maintenance of conicals Working card 619-03.10 (01H)
Flexible external connections Plate 61902-03H
Conical element Plate 61903-04H
Tools 520/620
Introduction to spare part plates for tools Description 620.01 (01H)
Function of the hydraulic tools Working card 620-01.05 (03H)
Application of hydraulic tools Working card 620-01.06 (01H)
Hand lever pump Working card 620-01.07 (01H)
Maintenance of hydraulic tools Working card 620-01.10 (01H)
Tightening with torque spanner Working card 620-01.15 (01H)

MAN Diesel
IndexGenSet
L28-2
Text Index Drawing No.
Tool combinations for tightening of connecting rod screws Working card 620-01.20 (01H)
Max. pressure indicator Working card 620-01.25 (02H)
Tools for cylinder head Plate 62005-03H
Tools for piston, connecting rod and cylinder liner Plate 62006-11H
Tools for operating gear for inlet valves, exhaust valves and fuel
injection pumps Plate 62008-03H
Tools for control and safety systems, automatics and instruments Plate 62009-02H
Tools for crankshaft and main bearing Plate 62010-07H
Tools for crankshaft and main bearing Plate 62010-10H
Tools for crankshaft and main bearing Plate 62010-11H
Tools for fuel oil system and injection equipment Plate 62014-02H
Tools for lubricating oil system Plate 62015-02H
Hydraulic tools Plate 62021-08H
Tools for low overhaul height, piston, cylinder liner and connecting
rod Plate 62050-01H
Operating manual for testing tool (Fuel injection valve) Description GXO-D001

Engine data
500/600

MAN Diesel & Turbo
MAN Diesel & Turbo Identification No. for Instruction Manual.
Identification No. for Description: 000 . 00
Function
Section No.
Identification No. for Working Card: 000 - 00 . 00
Sub-function
Function
Section No.
Identification No. for Plates: 00000 - 00 H
H for Holeby
Edition
Section No. and Function
Instruction Manual for:
For ordering of spare parts, see page 500.50 / 600.50
All data provided in this document/manual is non-binding. This data serves informational purposes only and
is especially not guaranteed in any way.
Depending on the subsequent specic individual projects, the relevant data may be subject to changes and
will be assessed and determined individually for each project. This will depend on the particular characteri-
stics of each individual project, especially specic site and operational conditions.
If this document/manual is delivered in another language than English and doubts arise concerning the
translation, the English text shall prevail.
Original instructions
2011.06.28

MAN Diesel & Turbo
PrimeServ Holeby
GenSet & Powerplant
Service & Spare Parts
Fax : [phone]
After ofce hours : [phone]
[email protected]
MAN Diesel & Turbo | PrimeServ
The MAN Diesel & Turbo Group offers worldwide round-the-clock service, 365 days a year. Apart from the MAN
Diesel & Turbo service headquarters in Augsburg, Copenhagen, Frederikshavn, Holeby, Stockport, St. Nazaire, Tur-
bocharger and service centres on all continents provide comprehensive and continuous support. The long service
life associated with MAN Diesel engines dictates a spare parts programme that ensures components are available
for engines in operation for decades. Based on high-capacity machines, MAN Diesel & Turbo service production
facilities are able to comply with special customer requests with the utmost precision and flexibility.
24-hour hotline number:
[phone]
http://www.mandieselturbo.com/primeserv
MAN Diesel & Turbo
H. Christoffersensvej 6
4960 Holeby
Denmark
Phone: [phone]
Fax: [phone]
[email protected]
www.mandieselturbo.com
MAN Diesel & Turbo
Branch of MAN Diesel & Turbo SE,
Germany
CVR No.: 31611792
Head ofce: Teglholmsgade 41
2450 Copenhagen SV, Denmark
German Reg.No.: HRB 22056
Amtsgericht Augsburg
Copyright 2011 © MAN Diesel & Turbo, branch of MAN Diesel & Turbo SE, Germany, registered with the Danish
Commerce and Companies Agency under CVR Nr.: 31611792, (herein referred to as “MAN Diesel & Turbo”).
This document/manual must not, either wholly or partly, be copied, reproduced, made publich or in any other way made
available to any third party without the written to this effect from MAN Diesel & Turbo.
2011.06.28

MAN Diesel & Turbo
Description
Page 1 (1) Warning
Warning !
(Marine engines only)
It is important that all MAN Diesel & Turbo engines
are operated within the given specifications and
performance tolerances specified in the engines'
Technical Files and are maintained according to
the MAN Diesel & Turbo maintenance instructions
in order to comply with given emissions regulations.
In accordance with Chapter I of the Code of Federal
Regulations, Part 94, Subpart C, §94.211 NOTICE
is hereby given that Chapter I of the Code of Federal
Regulations, Part 94, Subpart K, §94.1004 requires
that the emissions related maintenance of the die-
sel engine shall be performed as specified in MAN
Diesel & Turbo instructions including, but not limited
to, the instructions to that effect included in the
Technical File.
12.06 - ES0
General

Questionnaire – Technical Documentation
MAN Diesel & Turbo
Your opinion counts!
Your opinion counts!
Your opinion is valuable to us as it helps us to evaluate our services and to continuously improve the
quality of our Technical Documentation.
May we ask you for a few minutes of your time to complete and then return this questionnaire to
[e-mail]:
Your company:
Your position: Very
satisfied
Rather
Satisfied
Rather
dissatisfied
Very
dissatisfied
How do you rate the overall level of satisfaction with the
manuals supplied?
Which improvements would you suggest to be made in the future?
Ring binders and organisation
Comments/suggestions:
Labelling of ring binders
Comments/suggestions:
Structuring of information and documents
Comments/suggestions:
Access aids (contents page, index, register, etc.)
Comments/suggestions:
Preparation of CDs/DVDs (navigation, etc.)
Comments/suggestions:
Readability of texts and drawings (paper, CD/DVD)
Comments/suggestions:
Comprehensibility of contents
Comments/suggestions:
Scope of information provided
Comments/suggestions:
1 (1)
Customer satisfaction

MAN Diesel & Turbo
Description
Page 1 (1)
L28/32H
Cycle : 4-stroke
Configuration : In-line
Cyl. Nos. available : 5-6-7-8-9
Power range : 1050-1980 kW
Speed : 720/750 rpm
Bore : 280 mm
Stroke : 320 mm
Stroke/bore ratio : 1.14:1
Piston area per cyl. : 616 cm2
Swept volume per cyl. : 19.7 ltr.
Compression ratio : 13.9:1
Max. combustion pressure : 130 bar
Turbocharging principle : Constant pressure system and inter cool ing
Fuel quality acceptance : HFO (up to 700 cSt/50° C, RMK700)
MDO (DMB) - MGO (DMA, DMZ)
according ISO8217-2010
Main Particulars
11.36 - ES1 - Tier II - WB2 - GenSet
Power lay-out
Speed
Mean piston speed
Mean effective pressure
Max. combustion pressure
Power per cylinder
rpm
m/sec.
bar
bar
kW/cyl.
720
7.7
17.8
130
210
750
8.0
17.9
130
220
Power per cylinder kW/cyl. 230 240
Overload rating (up to 10%) allowable in 1 hour for every 12 hours
MCR version
600.00
Edition 07H

08028-0D/H5250/94.08.12
MAN Diesel & Turbo
Description
Page 1 (1) Introduction 600.01
Edition 08H
Introduction
This instruction book provides general information
on the engine design, operation and maintenance.
It can also be used as a reference when ordering
spare parts. Reliable and economical operation of
the plant is conditional upon its correct operation
and maintenance in accordance with MAN Diesel &
Turbo’s instructions.Emissions-related maintenance
of the diesel engine shall be performed as speci-
fied in MAN Diesel & Turbo’s instructions and any
additional instructions to that effect included in the
Technical File. Consequently, it is essential that the
engine room personnel are fully acquainted with the
contents of this book and the Technical File.
Every care is taken to ensure that all information in
this instruction book is present and correct.
This book must not, either wholly or partly, be copied,
reproduced, made public or in any other way made
available to any third party without the written consent
to this effect from MAN Diesel & Turbo.
If an instruction book is delivered in another language
than English and doubts arise concerning the trans-
lation, the English text shall prevail.
10.47 - ES0
General
Description
The book is a basic instruction manual for the particu-
lar engine supplied, with plant-adapted information
such as basic media-system drawings, electrical
wiring diagrams and test bed reports.
The first five sections (500-504) of the book serve
as a guide to engine operation, and the next fifteen
sections (505-519) contain technical descriptions,
spare parts illustrations with appurtenant parts lists,
as well as working cards.
The last section (520) comprises tools.
The engine is divided into a number of main com-
ponents/assemblies, each of which is described in
a section of this book (section 505-519).
Each of these sections starts with technical de-
scriptions of the systems/components, followed by
working cards and the spare parts illustration plates
and parts lists.
Fig. 1. Structuring of instruction book.

08028-0D/H5250/94.08.12
MAN Diesel
Description
Page 1 (2) Safety 600.02
Edition 06H
General
Proper maintenance, which is the aim of this book,
constitutes the crucial point in obtaining optimum
safety in the engine room. The general measures
mentioned here should therefore be a natural routine
to the entire engine room staff.
Cleanliness
The engine room should be kept clean above and
below the floor plates. If grit or sand blows into the
engine room when the ship is in port, the ventilation
should be stopped and ventilating ducts, skylights,
and doors in the engine room should be closed.
Inparticular,weldingorworkwhichcausesspreading
of grit and chips must be avoided near the engine,
unless this is closed or covered, and the turbochar-
ger air intake filters are covered.
The exterior of the engine should be kept clean and
thepaintwork maintained so that leakagescaneasily
be detected.
Fire
If the crankcase is opened before the engine is cold,
welding and the use of naked light will involve the risk
ofexplosions and fire.Thesameappliestoinspection
of oil tanks and the space below the fooler. Attention
is furthermore drawn to the danger of fire when using
paint and solvents with a low flash point. Porous
insulating material drenched with oil from leakages
is easily inflammable and should be renewed. See
also: "Ignition in crankcase" in section 603.
Order
Hand tools should be placed easily accessible on
tool boards. Special tools should be fastened to tool
panels (if supplied) in the engine room close to the
area of application. No major objects must be left
unfastened, and the floor and passages should be
kept clear.
91.12 - ES0U
General
Spares
Large spare parts should, as far as possible, be pla-
ced well strapped near the area of application and
accessible by crane.The spare parts should be well
preserved against corrosion and protected against
mechanical damage. The stock should be checked
at intervals and replenished in time.
Light
Ample working light should be permanently installed
at appropriate places in the engine room, and port-
able working light, in explosion-proof fittings, should
be obtainable everywhere.
Freezing
If there is a risk of damage due to freezing when the
plant is out of service, engines, pumps, coolers, and
pipe systems should be emptied of cooling water.
Warning
The opening of cocks may cause discharge of hot
liquids or gases.The dismantling of parts may cause
springs to be released.
The removal of fuel valves (or other valves in the
cylinder head) may cause oil to run down to the
piston crown, and if the piston is hot, an explosion
may then blow out the valve.
When testing fuel valves with the hand pump, do not
touch the spray holes, as the jet may pierce the skin.
Think out beforehand which way the liquids, gases
or flames will move, and keep clear.
Crankcase work
Check beforehand that the starting air supply to the
engine is shut off.

MAN Diesel
Description
Page 2 (2)
Feeling over
Whenever repairs or alterations have been made to
the running gear, apply the "Feel-over sequence"
until ensured that there is no undue heating, oil-
mist formation, blow-by, or failure of cooling water
or lubricating oil systems.
Feel-over sequence
Feel-over after 5-15 and 30 minutes' idle running and
finally when the engine is running at full load. See
also "Starting-up sequence" in the section 602.
Safety
91.12 - ES0U
General
600.02
Edition 06H
Turning with air
After prolonged out-of-service periods or overhaul
work which may involve a risk of accumulation of
liquid in the combustion spaces, turning with open
indicator cocks should always be effected, through
at least two complete revolutions.
Check and maintain
Lubricating oil condition, filter elements and mea-
suring equipment.

MAN Diesel & Turbo
10.36 - ES1
600.05
Edition 07H
L28/32H
Cross Section
Description
Page 1 (1)

08028-0D/H5250/94.08.12
MAN Diesel
Key for Engine Designation
General
No of cylinders
5, 6, 7, 8, 9
12, 16, 18
Engine Type
L : In-line
V : V-built
Cyl. diam/stroke
16/24 : 160/240
21/31 : 210/310
23/30 : 225/300
27/38 : 270/380
28/32 : 280/320
32/40 : 320/400
Design Variant
Rating
MCR : Maximum continuous rating
ECR : Economy continuous rating
6 L 28/32 H MCR
04.08 - ES1
Description
Page 1 (1)
Engine Type Identification
The engine types of the MAN B&W programme are identified by the following figures:
600.10
Edition 02H

08028-0D/H5250/94.08.12
MAN Diesel
Designation of Cylinders
L28/32H
89.17 - ES1S-L
Description
Page 1 (1) 600.11
Edition 01H
Front End Flywheel end
Exhaust Side / Right Side
Control Side / Camshaft Side / Left Side
