Rosenbauer RS 14 EFI SUPER SILENT EFI User manual

Operation manual
RS14 EFI / RS14 EFI Super silent
Article number: 06642B-003
Edition: 06/2021
Revision number: 00
Language: English

2 / 89
Table of contents
1 Legal notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Manufacturer and customer service address. . . . . . . . . . . 5
1.2.1 Manufacturer address . . . . . . . . . . . . . . . . . . . . . . . 5
1.2.2 Service and sales international . . . . . . . . . . . . . . . . 5
2 Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.1 Declaration of conformity RS 14 EFI . . . . . . . . . . . . . . . . . 6
2.2 Declaration of conformity RS 14 SUPER SILENT EFI. . . . 6
3 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.2 Liability and injury . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.3 Identification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.4 Use of the operation manual . . . . . . . . . . . . . . . . . . . . . . . 10
3.4.1 Validity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.4.2 Key to the symbols . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2 Markings and warning signs . . . . . . . . . . . . . . . . . . . . . . . 12
4.3 Other regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.4 Training and qualifications . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.5 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . 15
4.6 List of the safety symbols used . . . . . . . . . . . . . . . . . . . . . 16
4.6.1 Meaning of the warning signs . . . . . . . . . . . . . . . . . 16
4.6.2 Meaning of the prohibitory signs . . . . . . . . . . . . . . . 18
4.6.3 Meaning of the caution signs. . . . . . . . . . . . . . . . . . 19
4.7 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5 Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.1 Power generators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.2 Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.3 Generator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.4 Rosenbauer Body Components Logic Control System
(RBC LCS). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.4.1 RBC LCS Compact . . . . . . . . . . . . . . . . . . . . . . . . . 29
6 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.1 Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.2 LCS operation panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.2.1 Function switches . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.2.2 Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6.3 Optional equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
6.3.1 Exhaust gas hose . . . . . . . . . . . . . . . . . . . . . . . . . . 36

3 / 89
6.3.2 Holder for exhaust gas hose. . . . . . . . . . . . . . . . . . 36
6.3.3 45° exhaust adapter . . . . . . . . . . . . . . . . . . . . . . . . 37
6.3.4 Exhaust gas deflector . . . . . . . . . . . . . . . . . . . . . . . 37
6.3.5 Wheel set with pulling device . . . . . . . . . . . . . . . . . 38
6.3.6 Trolley . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
6.3.7 Refuelling set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
6.3.8 External refuelling set . . . . . . . . . . . . . . . . . . . . . . . 40
6.3.9 MAGCODE battery charger . . . . . . . . . . . . . . . . . . 40
6.3.10 Socket distributor . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.3.11 Tool kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.3.12 RLS1000 LED lighting system . . . . . . . . . . . . . . .41
6.4 Functional options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
6.4.1 FIRECAN remote monitoring (interface according to
DIN14700). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
6.4.2 Insulation monitoring. . . . . . . . . . . . . . . . . . . . . . . . 43
6.4.3 Remote start/stop connection cable . . . . . . . . . . . . 44
6.4.4 Battery temperature monitoring . . . . . . . . . . . . . . . 45
7 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7.1 Preparation for initial operation . . . . . . . . . . . . . . . . . . . . . 46
7.2 Transport. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
7.2.1 Transporting manually . . . . . . . . . . . . . . . . . . . . . . 47
7.2.2 Transporting using wheel set (optional) . . . . . . . . . 47
7.3 Preparation for startup . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
7.4 Positioning the power generator . . . . . . . . . . . . . . . . . . . . 48
7.5 Monitoring during operation . . . . . . . . . . . . . . . . . . . . . . . 50
7.6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
7.6.1 Start power generator. . . . . . . . . . . . . . . . . . . . . . . 50
7.6.2 Insulation fault test . . . . . . . . . . . . . . . . . . . . . . . . . 53
7.6.3 Connect consumer . . . . . . . . . . . . . . . . . . . . . . . . . 54
7.6.4 Shut down power generator . . . . . . . . . . . . . . . . . . 55
7.6.5 Refuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
7.6.6 Functional options. . . . . . . . . . . . . . . . . . . . . . . . . . 59
8 Service and cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
8.1 Maintenance work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
8.1.1 Clean device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
8.1.2 Maintenance and cleaning of 3M Scotchcaltm and
Controltactm films . . . . . . . . . . . . . . . . . . . . . . . . . . 65
8.1.3 Dry vehicle and equipment . . . . . . . . . . . . . . . . . . . 66
8.2 Service plan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
8.2.1 Maintenance according to the manufacturers opera-
tion manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
8.3 Torque tables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
8.4 Testing and inspection work . . . . . . . . . . . . . . . . . . . . . . . 67
8.4.1 Hose lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

4 / 89
8.5 Service work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
8.5.1 Preparatory activities for changing RS14 EFI Super
Silent oil filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
8.5.2 Preparatory activities for changing air filter . . . . . . . 69
8.5.3 Replace fuel filter with external refuelling . . . . . . . . 70
8.5.4 Electrical protection and switching devices . . . . . . . 71
8.5.5 Fuse strip. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
8.5.6 Main breaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
8.5.7 Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
8.5.8 General guidelines for handling electronic compo-
nents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
8.6 Preserving and storing. . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
8.7 Service menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
8.7.1 Call up/exit service menu . . . . . . . . . . . . . . . . . . . . 77
8.7.2 Set display language . . . . . . . . . . . . . . . . . . . . . . . . 78
8.7.3 Set service interval . . . . . . . . . . . . . . . . . . . . . . . . . 78
9 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
9.1 Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
9.1.1 Power generator . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
9.2 Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
9.2.1 RS14 power generator . . . . . . . . . . . . . . . . . . . . . . 82
10 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
11 Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
12 Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
13 Index of abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Original operating manual
5 / 89
Copyright
Original opera ting manual
ORIGINAL OPERATION MANUAL
1Legal notice
1.1 Copyright
All rights to this manual and its attachments lie with Rosenbauer
International AG.
The documents are only entrusted to the recipient for their personal use.
Reproduction, reprinting (electronically or mechanically), translations in
other languages or all other duplication, also of parts of the manual, are only
allowed with written permission.
Information from this manual may not be passed on to or made accessible
to third persons, in particular competitors.
1.2 Manufacturer and customer service address
1.2.1 Manufacturer address
Rosenbauer International AG
Paschinger Strasse 90
4060 Leonding, Austria
The Rosenbauer customer service department or one of our worldwide rep-
resentatives will gladly assist you if you need further information.
1.2.2 Service and sales international
Rosenbauer International AG
Paschinger Strasse 90
4060 Leonding, Austria
Telefon-Nr.: [phone] - 0
Telefax-Nr.: [phone] - 312
E-Mail: [e-mail]
Internet: www.rosenbauer.com
Telephone: [phone] - 0
Fax: [phone] - 312
Email: [e-mail]
Internet: www.rosenbauer.com

Declaration of conformity
6 / 89
Declaration of conformity RS 14 EFI
2 Declaration of conformity
2.1 Declaration of conformity RS 14 EFI
According to EC Machinery Directive 2006/42/EC, Annex II, part 1A
Herewith declares
Rosenbauer International AG
Fire fighting technology
A - 4060 Leonding, Paschinger Str. 90
Address: Postbox 176, 4021 Linz, Austria
Telephone: +43 (0)732 / 6794-0
that the Power generator
Type RS 14 EFI
Serial number A0515
complies with the following regulations:
1) 2006/42/EC - EC Machinery Directive
2) 2014/30/EU - Directive on the harmonization of regulations relating to
electromagnetic compatibility
3) ECE R10 - Electromagnetic compatibility for vehicles
The following harmonized standards (or parts thereof) have been ap-
plied:
1) ÖBFV-RL ET-01 (Austrian Federal Fire Brigade Association)12
2) DIN 14685-13
3) EN 55012 / EN 61000-6-2
4) IEC 60364-5-55:2010
2.2 Declaration of conformity RS 14 SUPER SILENT EFI
According to EC Machinery Directive 2006/42/EC, Annex II, part 1A
Herewith declares
Rosenbauer International AG
1apart from Chap. 3.4, subchap. 6
2except for devices with special voltage
3except for devices with special voltage

Declaration of conformity
7 / 89
Declaration of conformity RS 14 SUPER SILENT EFI
Fire fighting technology
A - 4060 Leonding, Paschinger Str. 90
Address: Postbox 176, 4021 Linz, Austria
Telephone: +43 (0)732 / 6794-0
that the Power generator
Type RS 14 SUPER SILENT EFI
Serial number A0516
complies with the following regulations:
1) 2006/42/EC - EC Machinery Directive
2) 2014/30/EU - Directive on the harmonization of regulations relating to
electromagnetic compatibility
3) ECE R10 - Electromagnetic compatibility for vehicles
The following harmonized standards (or parts thereof) have been ap-
plied:
1) ÖBFV-RL ET-01 (Austrian Federal Fire Brigade Association)1
2) DIN 14685-12
3) EN 55012 / EN 61000-6-2
4) IEC 60364-5-55:2010
1except for devices with special voltage
2except for devices with special voltage

Introduction
8 / 89
Preface
3 Introduction
3.1 Preface
This manual is to be read through carefully and all regulations and advice
observed before commissioning the product.
Also observe the documents of the corresponding manufacturers supplied
in addition to this manual.
All persons, who deal with the operation and maintenance of the product,
must be correspondingly qualified, have read this manual fully and follow it
exactly.
The manual is always to be kept at the site of operation of the product.
3.2 Liability and injury
Due to the information in this manual Rosenbauer fundamentally accepts
no liability for direct damage or consequential damage, which arise from in-
correct operation or maintenance, as well as by unauthorised changes of
components or this manual.
The product may only be operated by persons who are familiar with the
manual, the product as well as the national laws, guidelines and regulations
pertaining to work, safety and accident prevention.
Rosenbauer assumes no responsibility for injury to persons or material
damage, which are caused by untrained personnel, also through non-com-
pliance with the regulations regarding work, safety and accident prevention.
If this manual contains a technical error or a typographical error,
Rosenbauer reserves the right to make change at any time and without no-
tice.
This manual may contains figures and descriptions, that are not built into
the delivered product.
No claims may be made for products that have already been delivered from
the information, figures and descriptions in this manual.
For your own safety only use spare parts and accessory products from
Rosenbauer. Rosenbauer accepts no liability for the use of other products
and the resulting damage!
Check the delivery immediately for transport damage and completeness.
• Faults and damages must be documented in writing immediately.
• Photograph damaged components.
• Send written damage report to the manufacturer - see chapter "Manu-
facturer and customer service address".
3.3 Identification
Identifying the serial number is important when referring to the manufactur-
er in regards to part and technical issues.
The serial number of the power generator is stamped on the type plate. The
type plate is on the bottom of the battery box cover,

Introduction
9 / 89
Identification
RS 14 EFI power generator:
RS 14 SUPER SILENT EFI power generator:
► Enter the serial number of the power generator into the table.
A0515L
A0516L

Introduction
10 / 89
Use of the operation manual
3.4 Use of the operation manual
3.4.1 Validity
This manual contains information needed for the operation of the product.
This manual contains descriptions of special equipment as well as some
abstractions and exemplary illustrations. The actual equipping of your prod-
uct may therefore differ in part from the descriptions and illustrations.
3.4.2 Key to the symbols
To ensure readability and clarity, various paragraphs and information are
structured with symbols.
Meaning of the symbols:
► Operating instructions. Execute the operating instructions one after the
other in the order described.
Results of an action.
• Enumerations.
Further information on this topic.
Supplementary information.
Follow the supplementary documentation or supplier's documentation.
Key figures
Texts are illustrated with additional drawings, if required. An image legend
is provided below the illustration.
The reference from the text to a position in the illustration is established by
a set position number (e.g. S1).
The safety information warns the user of risks and informs them how these
risks can be avoided.
Safety information stands at the beginning of a chapter before handling in-
structions from which a dangerous situation can occur. Further safety infor-
mation is found at the start of this manual.
Safety instructions that must be followed without fail are highlighted as fol-
lows:
DANGER!
This symbol warns of an extremely dangerous situation, in which non-
observation of the danger warning will lead to death or serious irreversible
injury.

Introduction
11 / 89
Use of the operation manual
WARNING!
This symbol warns of a dangerous situation, in which non-observation of
the danger warning can lead to death or serious irreversible injury.
CAUTION!
This symbol warns of a dangerous situation, in which non-observation of
the danger warning can lead to slight reversible injury.
NOTICE
This symbol warns of situations, in which non-observation of the warning
can lead to material damage.
Additionally, the information in the manual, the technical data and the safety
information in the supplier's documentation supplied must be observed.

Safety
12 / 89
Intended use
4 Safety
4.1 Intended use
Improper use of the product can result in personal injury. Additionally, the
product or other material assets of value may be damaged.
Rosenbauer can warrant the safety, reliability and performance of its prod-
uct only if the product is used in accordance with the stipulations in this
manual.
Unauthorised changes, unauthorised conversions or improper operation
can detract from the intended use and result in personal injury or property
damage.
Firefighting products may be used only in a flawless technical condition by
qualified personnel for the following purposes:
• Implementation of technical assistance
• Rescue of people from emergencies
• Firefighting
Only manufacturer-authorised persons may perform modifications, conver-
sions and repairs. Unauthorised changes, unauthorised conversions or im-
proper use will nullify all manufacturer liability for resulting damages.
The power generator generates electrical energy for feeding into a mobile
distribution system as part of a network replacement operation. In order for
the generator to be used for the supply of stationary consumers (building
feed), the power generator and the system must have a corresponding
electrical installation.
The power generator must not be connected to other power distribution
(e.g. public power supply) and power generation systems (e.g. other power
generators) (grid-parallel operation). The power generator may only be
used outdoors within the specified limits for voltage, power and rated speed
(see type plate). In emergency situations, use on a vehicle or equipment ex-
tension or swivel/rotary compartment in the inserted or swivelled state is
also permitted if the equipment is supplied with fresh air through sufficiently
dimensioned air intake openings in the body and, in particular, the air flow
at the air intake and air exhaust openings is not impaired and heat accumu-
lation is avoided. The exhaust gases must be discharged into the open air.
4.2 Markings and warning signs
Safe use is only possible, if all necessary information for a safety operation
are observed. These informations are especially including safety- and
warning instructions.
In addition to the instructions in this operating manual read and observe all
the safety- and warning signs affixed to the product.
4.3 Other regulations
This product has been manufactured in accordance with the applicable reg-
ulations and the state of the art.

Safety
13 / 89
Other regulations
In addition to this manual the relevant national legislation, regulations and
directives in the latest version are to be observed (e.g. guidelines for per-
sonal protective equipment, road traffic regulations, country-specific train-
ing regulations for the fire department, accident prevention guidelines, fire
department duty regulations, occupational medicine and technical environ-
mental rules, country legislation for fire and disaster protection).

Safety
14 / 89
Training and qualifications
4.4 Training and qualifications
Operator errors caused by inadequate qualifications can cause serious ac-
cidents or endanger the success of the operation. Safe operations can be
assured only when operation and consistent maintenance of the product is
performed exclusively by specially trained personnel.
Only qualified training by experienced firefighting experts and continuous
practice of operating procedures ensure safe operations.
One-time instruction is not sufficient!
The product may only be operated by persons who have successfully com-
pleted appropriate firefighting training.
The operator is responsible for defining responsibilities and supervision of
personnel as well as for adequate instruction and training according to ap-
plicable regulations.
Even during operation, make sure that persons without technical knowl-
edge never operate the product.
Personnel must exhibit physical and mental aptitude. Minors and persons
without firefighting training may not operate the product.
Modifications and conversions to the product may be performed only with
written authorization from Rosenbauer and must be performed by a manu-
facturer-authorised person.

Safety
15 / 89
General safety instructions
4.5 General safety instructions
The following instructions give an overview of how the product is used safe-
ly. This general overview will be supplemented by the safety instructions in
the individual chapters.
Take note of general danger possibilities that could occur when handling
machines.
Use the prescribed personal protective equipment.
Make sure that the product corresponds to the respective valid safety reg-
ulations and the local fire departments guidelines and is always operation-
ally ready.
On contact with dangerous chemicals (e.g. dry powder) make sure that the
manufacturer's safety datasheets and information is followed.
Dry powder and foam compound can endanger the environment.
► Do not dispose of dry powder and foam compound in bodies of water
or in the sewage system.
Foam compound and dry powder in particular are very corrosive.
► Carefully clean the product of extinguishing agent residue after every
operation.
Should emergencies occur where people are injured, appropriate first aid
measures must be taken. If necessary, emergency personnel are to be
called to provide professional treatment.
Observe the operation and maintenance manuals of additional products.
If you cannot fix faults yourself or repairs could not be carried out by spe-
cially trained workshop personnel, Rosenbauer or the nearest Rosenbauer
service partner must be contacted immediately.

Safety
16 / 89
List of the safety symbols used
4.6 List of the safety symbols used
4.6.1 Meaning of the warning signs
Danger from electricity.
Impending fire risk.
Impending risk of explosion.
Risk from oxidising materials.
Risk of harmful or irritating materials.
Impending risk of explosion.
Impending acid burn risk.
Impending hearing damage.
Risk of inhalation of toxic vapours.
Risk from hot surfaces.

Safety
17 / 89
List of the safety symbols used
Impending crushing risk.
Threat of environmental contamination.
Threat of shearing.

Safety
18 / 89
List of the safety symbols used
4.6.2 Meaning of the prohibitory signs
Handling fire and naked flames forbidden!
Do not touch or reach in!
Do not stay in the danger area!

Safety
19 / 89
List of the safety symbols used
4.6.3 Meaning of the caution signs
Use hearing protection.
Wear a protective helmet.
Wear a protective suit.
Maintain distance.
Special caution.

Safety
20 / 89
Warnings
4.7 Warnings
DANGER!
Mortal danger or serious injury from electric shock!
Maintenance work on live parts may only be carried out by qualified
specialist personnel.
Observe the safety distance from voltage-carrying parts at all times.
Inhalation of toxic exhaust fumes can cause death or serious health
damage!
Toxic gases are produced when running a combustion engine. If operation
of internal combustion engines in enclosed spaces is absolutely necessary,
note the following:
Extract the exhaust gases by means of the exhaust gas hose.
Ensure there is adequate ventilation.
