M&C SP Series User manual

Gas Sample Probe Series SP®
SP3110 /..
SP3110V /..
II 2 G
Instruction Manual
Version 1.00.02

2 SP3110../SP3110V.. | 1.00.02 www.mc-techgroup.com
Dear customer,
Thank you for buying our product. In this instruction manual you will find all necessary information
about this M&C product. The information in the instruction manual is fast and easy to find, so you can
start using your M&C product right after you have read the manual.
If you have any question regarding the product or the application, please don’t hesitate to contact
M&C or your M&C authorized distributor. You will find all the addresses in the appendix of this manual.
For additional information about our products and our company, please go to M&C’s website
www.mc-techgroup.com. There you will find the data sheets and manuals of our products in German
and English.
Disclaimer
This manual does not claim to be complete and it may be subject to
technical modifications.
© 12/2020 M&C TechGroup Germany GmbH. Reproduction of this
document or its content is not allowed without permission from M&C.
SP®is a registered trademark.
Version: 1.00.02

www.mc-techgroup.com SP3110../SP3110V.. | 1.00.02 3
Contents
1General information.................................................................................................................. 5
2Declaration of conformity......................................................................................................... 5
3Device standard........................................................................................................................ 6
4Safety information .................................................................................................................... 6
5Information on use in potentially explosive atmospheres..................................................... 7
6Warranty.................................................................................................................................... 7
7Terms and symbols used in these operating instructions..................................................... 8
8Application.............................................................................................................................. 10
9Description.............................................................................................................................. 10
9.1 SP3110 and SP3110V (combustible gases):........................................................................ 10
10 Options.................................................................................................................................... 14
10.1 Back-purging unit type RS:................................................................................................... 15
10.2 Option /R, /BB and /BBF for feeding of calibration gas or back-purging via check valve
R 1/4“, BB 3/8“ or BBF 3/8“:.................................................................................................. 15
10.3 Option /C/I feeding of test gas via check valve behind the probe filter with pneumatic
stop valve for the probe outlet to the process ....................................................................... 16
10.4 Option 2-Way ball valve /VA................................................................................................. 16
10.5 Option spun glass cartridge FW............................................................................................ 16
10.6 Option /3VA feeding of test gas and back-purging via 3/2-Way ball valve............................. 16
10.7 Ball valve drive MS1............................................................................................................. 18
10.8 Option /2X Second sample gas outlet on the probe.............................................................. 18
10.9 Probe heating....................................................................................................................... 18
11 Technical data......................................................................................................................... 19
11.1 Maximum surface temperature of the gas sample probe ...................................................... 22
12 Receipt and storage................................................................................................................ 22
13 Preparations for installation................................................................................................... 23
14 Installation............................................................................................................................... 24
14.1 Connection of the sample line .............................................................................................. 27
15 Electrical connections............................................................................................................ 29
16 Start-up.................................................................................................................................... 30
17 Maintenance............................................................................................................................ 31
17.1 Replacement of the filter element......................................................................................... 32
17.2 Replacement of the preliminary filter .................................................................................... 32
17.3 Back-purging Option RS....................................................................................................... 32
17.4 Ball valve VA or 3VA ............................................................................................................ 32
17.5Ball valve drive MS1............................................................................................................. 32
17.6 Cleaning of the probe........................................................................................................... 33
18 Shutdown ................................................................................................................................ 33
19 Proper disposal of the device ................................................................................................ 33
20 Spare parts list........................................................................................................................ 34
21 Appendix ................................................................................................................................. 34

4 SP3110../SP3110V.. | 1.00.02 www.mc-techgroup.com
Figures
Figure 1 Probes SP3110(V) without options with preliminary filter type V20.................................. 12
Figure 2 Schematic view of the options for back-purging and feeding of calibration gas................ 14
Figure 3 Function schema of option 3/2-way ball valve /3VA........................................................ 17
Figure 4 Schematic drawing of the filter housing cover.................................................................. 25
Figure 5 Removal of the filter housing cover.................................................................................. 26
Tables
Table 1 Markings for sampling from zone 1 flammable gases...................................................... 12
Table 2 Sample tubes for use with the probe SP3110(V) ............................................................. 13
Table 3 Possible filters and preliminary filters for use inside the probe......................................... 13
Table 4 Extension tubes............................................................................................................... 13
Table 5 Operating parameters...................................................................................................... 24

www.mc-techgroup.com SP3110../SP3110V.. | 1.00.02 5
Head Office
M&C TechGroup Germany GmbH Rehhecke 79 40885 Ratingen Germany
Telephone: 02102 / 935 - 0
Fax: 02102 / 935 - 111
E - mail: [e-mail]
www.mc-techgroup.com
1 GENERAL INFORMATION
The product described in this instruction manual has been built and tested in our production facility.
All M&C products are packed to be shipped safely. To ensure the safe operation and to maintain the
safe condition, all instructions and regulations stated in this instruction manual need to be followed.
This instruction manual includes all information regarding proper transportation, storage, installation,
operation and maintenance of this product by qualified personnel.
Follow all instructions and warnings closely. Read this manual carefully before commissioning and
operating the device. If you have any questions regarding the product or the application, please don’t
hesitate to contact M&C or your M&C authorized distributor.
2 DECLARATION OF CONFORMITY
CE - Certification
The product described in this operating manual complies with the following EU directives:
ATEX-Directive
The product described in this manual is produced in accordance with the EU directive for devices and
protection systems for appropriate use in hazardous areas 2014/34/EU appendix II. The type of
protection depends on the variant of the probe (see table 1).
EMV-Instruction
The requirements of the EU directive 2014/30/EU “Electromagnetic compatibility“ are met.
Low Voltage Directive
The requirement of the EU directive 2014/35/EU “Low Voltage Directive“ are met.
The compliance with this EU directive has been examined according to DIN EN 61010.
RoHS Directive
The requirements of the RoHS2 (‘Restriction of Hazardous Substances 2’) directive 2011/65/EU and
its annexes are met.
Declaration of conformity
The EU Declaration of conformity can be downloaded from the M&C homepage or directly requested
from M&C.

6 SP3110../SP3110V.. | 1.00.02 www.mc-techgroup.com
3 DEVICE STANDARD
The respective protection class depends on the gas sample probe version (see Table 1).
Hersteller : M&C TechGroup GmbH
Rehhecke 79
40885 Ratingen –Germany
Tel.: [phone]
E-Mail: [e-mail]
www.mc-techgroup.com
4 SAFETY INFORMATION
Observe the following fundamental safety precautions when using the device:
•Read these operating instructions carefully before start-up and use of the device! The
information and warnings given in these operating instructions must be heeded.
•Pay attention to the declaration of conformity (see appendix).
•Work on electrical equipment may only be carried out by qualified personnel in accordance
with the current valid regulations.
•The requirements of VDE 0100 and its associated standards and regulations must be observed
when erecting high-voltage power installations with rated voltages to 1000 V.
•Relevant national and international standards and regulations must be observed when using
the device in potentially explosive environments.
•The device must be connected to a mains supply with the same voltage as specified on the
rating plate.
•Protection against contact with high electrical voltages:
The device must be safely isolated from the mains supply before it is opened. The same
applies to any connected external control circuits.
•Only use the device within the permissible temperature ranges.
•Check that the instalment location is weather protected. Do not expose directly to rain or to
moisture.
•Installation, maintenance, inspection, and repair work may only be carried out by authorised
personnel. Such work must be carried out in accordance with applicable rules and regulations.

www.mc-techgroup.com SP3110../SP3110V.. | 1.00.02 7
5 INFORMATION ON USE IN POTENTIALLY EXPLOSIVE ATMOSPHERES
See Table 1 for the markings of the individual variants.
Detailed information and a copy of the declaration of conformity are contained
in the appendix to these operating instructions. The devices must be installed
and used in accordance with the conditions and installation instructions given
in the EX-Certificate (see appendix). Only then, a safe operation in potentially
explosive atmospheres is guaranteed.
Any changes to the standard configuration with unspecified parts or parts not
authorised by M&C as well as repair or service work with unspecified parts
mean to an immediate loss of ex-certification.
- In case of any doubt, please contact M&C directly or your M&C franchise
dealer.
6 WARRANTY
In case of a device failure, please contact immediately M&C or your M&C authorized distributor.
We have a warranty period of 12 months from the delivery date. The warranty covers only
appropriately used products and does not cover the consumable parts. Please find the complete
warranty conditions in our terms and conditions.
The warranty includes a free-of-charge repair in our production facility or the free replacement of the
device. If you return a device to M&C, please be sure that it is properly packaged and shipped with
protective packaging. The repaired or replaced device will be shipped free of delivery charges to the
point of use.

8 SP3110../SP3110V.. | 1.00.02 www.mc-techgroup.com
7 TERMS AND SYMBOLS USED IN THESE OPERATING INSTRUCTIONS
Danger
The ‘Danger’ warning sign indicates that death, serious injury and/or
significant material damage will be the consequence, if the appropriate
precautions should not be taken.
Warning
The ‘Warning’ warning sign indicates that death, serious injury or damage
to property may occur if the relevant precautionary measures are not
observed.
Caution
The ’Caution’ warning sign indicates that slight personal injury can occur if
the appropriate safety precautions are not observed.
Note
‘Note’ indicates important information relating to the product or highlights
parts of the documentation for special attention.
Qualified personnel
‘Qualified personnel’ are experts who are familiar with the installation,
commissioning, maintenance, and operation of these types of products.
The following knowledge is at least required for the work:
•Instructed person in EX-protection
•Trained person in the electrotechnical field
•Detailed knowledge of the manual and the applicable safety regulations
‘Ex‘ indicates important information about the product or about the
corresponding parts in the instruction manual, relating to usage in
potentially explosive atmospheres.
High voltages!
Protect yourself and others against damages which might be caused by
high voltages.
Hot surface!
Contact may cause burn! Do not touch!

www.mc-techgroup.com SP3110../SP3110V.. | 1.00.02 9
Corrosive!
These substances destroy living tissue and equipment upon
contact.
Do not breathe vapors; avoid contact with skin and eyes.
Wear protective gloves!
Working with chemicals, sharp objects or extremely high
temperatures requires wearing protective gloves.
Wear safety glasses!
Protect your eyes while working with chemicals or sharp objects.
Wear safety glasses to avoid getting something in your eyes.
Wear protective clothes!
Working with chemicals, sharp objects or extremely high
temperatures requires wearing protective clothes.

10 SP3110../SP3110V.. | 1.00.02 www.mc-techgroup.com
8 APPLICATION
The probes of type SP3110.. and SP3110V.. are used for continuous gas sampling in dust-laden
processes or processes with high temperatures (according to Table 5, chapter 13) or high gas
moisture. The modular construction of the probes and the variety of possible options guarantee
optimum adaptation of the probes to complex process and environmental conditions.
The probes of the type SP3110.. and SP311V.. are available in both, an unheated and an electrically
heated version.
The probes must not be used for sampling of gases or gas mixtures that could
be explosive, even in absence of air or which change safety-relevant material
properties. The gases or gas mixtures must also not contain any solid particles
that could generate ignitable friction or percussion sparks in combination with
the materials of the probe.
It is not allowed that during operation potential sources of ignition (e.g.
smouldering or burning particles, glowing embers, foreign objects) are brought
into the gas sample probe.
9 DESCRIPTION
The probes type SP3110(V).. have been designed for easy use, long life and uncomplicated service
and maintenance.
The internal filter element can be replaced without the need of tools or dismounting of the sample line.
After having removed the internal filter element, both the filter chamber and the sample tube can be
cleaned easily.
9.1 SP3110 AND SP3110V (COMBUSTIBLE GASES):
The gas sample probes type SP3110.. and SP3110V.. are suitable for the sampling of gases and
installation in hazardous areas of zone 1 (combustible gases). The only difference between both types
is the sealing material of the filter housing. Version SP3110 has got a filter housing sealing out of
graphite for special types which are heated above 185 °C [365 °F]. Version SP3110V has got filter
housing sealings of Viton®for special types which are heated below or up to 185 °C [365 °F]. The
probe housing and all options are suitable for use in hazardous areas of zone 1 (combustible gases).
Please read the identification in Table 4.
The filter system of type SP3110(V) is suitable for dusts with a fineness up to 2 µm.
After the filtration, i.e. at the outlet of the gas sample probe, the sample gas is free of dust. This means
that in the absence of explosive sample gas downstream analysers can be used without any special
protective measures.

www.mc-techgroup.com SP3110../SP3110V.. | 1.00.02 11
The maximum surface temperature of the gas sample probe depends on the
process media temperature and the used options (blow back unit RS, ball valve
drive MS1 and probe heating HEX4 or HEX1). The permissible process media
temperatures are not allowed to exceed 185°C [365 °F] at options 2-way-ball-
valve VA and 3/2-way-ball-valve 3VA.
For variants without these last mentioned options it is not allowed to exceed
200 °C [392 °F]. The consequential maximum surface temperatures and the
derivable temperature classes of the gases are shown in Table 1.
The intended use limits the process media temperature and the choice of
options insofar as the maximum surface temperature has to be below the limit
temperature of the flammable process dust mentioned in Table 5 resp. it has to
correspond to the temperature class of the flammable process gases.
SP3110 for sampling from zone 1 flammable gases
Type
Ex-
marking
Max.
process-
media
tempera-
ture
T-
class
Max.
surface
tempe-
rature
Type
Ex-
marking
Max.
process
media
tempera-
ture
T-
class
Max.
surface
temperat
ure
SP3110 with graphite sealing
SP3110/V with Viton®sealing
SP3110
II 2 G / 2
GD
< 68
[154.4 °F]
T6
85
[185 °F]
SP3110/V
II 2 G / 2 GD
< 68
[154.4°F]
T6
85
[185 °F]
II 2 G/ 2
GD
< 80
[176 °F]
T5
100
[212 °F]
II 2 G/ 2
GD
< 80
[176 °F]
T5
100
[212 °F]
II 2 G/ 2
GD
< 108
[226.4 °F]
T4
135
[275 °F]
II 2 G/ 2
GD
< 108
[226.4°F]
T4
135
[275 °F]
II 2 G/ 2
GD
< 160
[320 °F]
T3
200
[392 °F]
II 2 G/ 2
GD
< 160
[320 °F]
T3
200
[392 °F]
II 2 G/ 2
GD
< 200
[392 °F]
T2
250
[482 °F]
II 2 G/ 2
GD
< 185
[365 °F]
T2
232
[449.6°F]
Blow back RS with solenoid valve
SP3110/R
S
II 2 G / 2
GD
< 130
[266 °F]
T4
135
[275 °F]
SP3110/V/
RS
II 2 G/ 2
GD
< 130
[266 °F]
T4
135
[275 °F]
II 2 G / 2
GD
< 195
[383 °F]
T3
200
[392 °F]
II 2 G/ 2
GD
< 185
[365 °F]
T3
190
[374 °F]
II 2 G / 2
GD
< 200
[392 °F]
T2
205
[401 °F]
2-way ball valve VA
SP3110/V
A
(Option
MS1
pneumatic
drive
implies at
least
temperatur
e class
T4.)
II 2 G/ 2
GD
< 68
[154.4 °F]
T6
85
[185 °F]
SP3110/V/
VA
(Option
MS1
pneumatic
drive
implies at
least
temperatur
e class
T4.)
II 2 G/ 2
GD
< 68
[154.4°F]
T6
85
[185 °F]
II 2 G/ 2
GD
< 80
[176 °F]
T5
100
[212 °F]
II 2 G/ 2
GD
< 80
[176 °F]
T5
100
[212 °F]
II 2 G/ 2
GD
< 108
[226.4 °F]
T4
135
[275 °F]
II 2 G/ 2
GD
< 108
[226.4°F]
T4
135
[275 °F]
II 2 G/ 2
GD
< 160
[320 °F]
T3
200
[392 °F]
II 2 G/ 2
GD
< 160
[320 °F]
T3
200
[392 °F]
II 1 G/ 2
GD
< 185
[365 °F]
T2
232
[449.6°F]
II 2 G/ 2
GD
< 185
[365 °F]
T2
232
[449.6°F]

12 SP3110../SP3110V.. | 1.00.02 www.mc-techgroup.com
3-way ball valve 3VA
SP3110/3
VA
(Option
MS1
pneumatic
drive
implies at
least
temperatur
e class
T4.)
II 2 G/ 2
GD
< 80
[176 °F]
T6
85
[185 °F]
SP3110/V/
3VA
(Option
MS1
pneumatic
drive
implies at
least
temperatur
e class
T4.)
II 2 G/ 2
GD
< 80
[176 °F]
T6
85
[185 °F]
II 2 G/ 2
GD
< 95
[203 °F]
T5
100
[212 °F]
II 2 G/ 2
GD
< 95
[203 °F
T5
100
[212 °F]
II 2 G/ 2
GD
< 130
[266 °F]
T4
135
[275 °F]
II 2 G/ 2
GD
< 130
[266 °F]
T4
135
[275 °F]
II 2 G/ 2
GD
< 185
[365 °F]
T3
190
[374 °F]
II 2 G/ 2
GD
< 185
[365 °F]
T3
190
[374 °F]
Blow back RS with solenoid valve and 2-way ball valve VA
SP3110/R
S/VA
II 2 G / 2
GD
< 130
[266 °F]
T4
135
[275 °F]
SP3110/V/
RS/VA
II 2 G / 2
GD
< 130
[266 °F]
T4
135
[275 °F]
II 2 G / 2
GD
< 185
[365 °F]
T3
190
[374 °F]
II 2 G / 2
GD
< 185
[365 °F]
T3
190
[374 °F]
Blow back RS with solenoid valve and 3-way ball valve 3VA
SP3110/R
S/3VA
II 2 G / 2
GD
< 130
[266 °F]
T4
135
[275 °F]
SP3110/V/
RS/3VA
II 2 G / 2
GD
< 130
[266 °F]
T4
135
[275 °F]
II 2 G / 2
GD
< 185
[365 °F]
T3
190
[374 °F]
II 2 G / 2
GD
< 185
[365 °F]
T3
190
[374 °F]
Option 2X second sample gas outletzweiter Messgasausgang possible for every version.
Option FW spun glass possible for every version.
Option MS1 pneumatic drive Drehantrieb implies at least temperature class T4.
Option HEX4-135 implies at least temperature class T4.
Option HEX4-180 implies at least temperature class T3.
Table 1 Markings for sampling from zone 1 flammable gases
The following figure shows the basic version of the gas sample probe SP3110(V).
Figure 1 Probes SP3110(V) without options with preliminary filter type V20
Warning
SP3110 and SP3110V:
In case the gas-dust mixture to be examined must be classified as potentially
explosive because it contains combustible gases, only downstream devices
(flowmeters, analysers) with corresponding marking according to directive
2014/34/EU must be used.
Suitable explosion isolation with a flame arrestor must be established. This
instruction manual does not cover any downstream units.

www.mc-techgroup.com SP3110../SP3110V.. | 1.00.02 13
For the use of sample tubes in connection with the probe SP3110(V), please look into the following
table.
Sample
tube
Type
Part
No.
Max.
temp.
°C
Material
Tube/
Connection
Length
“L1” 1)
mm
Length
“L
max”
mm
Connec
tion
thread
“G”
Tube
ø
OD/ID
[mm]
Connec-
tion
ø OD
“EM”
[mm]
SP2000/SS
20S9065
600
Stainless
steel 316Ti
1000
2500
G 3/4“
male
25/22
37
SP2000/SS-
Vm
20S9067
600
Stainless
steel 316Ti
1000
2500
G 3/4“
male
25/06
37
SP2000/HC
20S9090
900
Hastelloy®C4
1000
2500
G 3/4“
male
25/22
37
SP2000/KA
20S9080
1300
Kanthal®/
316Ti
1000
1500
G 3/4“
male
27/20
37
SP2000/IC
20S9077
1100
Inconel®
1000
2500
G 3/4“
male
25/22
37
Table 2 Sample tubes for use with the probe SP3110(V)
In dependence on the dust composition, a filter or a preliminary filter can be selected from the table
below.
Type
Part No.
Material
Dimensions
[mm]
Filter fineness
[m]
Filter in the probe:
S-3 SS150
90F0126
316L
150 x 30
2
S-2K150
90S0020
Ceramic Aerolith
150 x 30
2
Option spun glass cartridge FW
Filter FW (spun glass)
93S2083
Spun glass, high
temperature resistant
Selectable preliminary filters:
SP2000ST/V20-T
20S9315
PTFE needled felt
(antistatic)
450 x 40
3
SP2000ST/V20-0
20S9105
316L
200 x 50
3
SP2000ST/V20-0/HC
20S9115
Hastelloy®x
200 x 50
3
SP2000ST/V20-1
20S9145
316L
500 x 60
3
SP2000ST/V20-1/HC
20S9155
Hastelloy®x
500 x 60
3
SP2000ST/V20-1/HC
0.5 µm
20S9156
Hastelloy®x
500 x 60
0.5
SP2000ST/V20-3
20S9300
316L
1000/300 x 31
3
Table 3 Possible filters and preliminary filters for use inside the probe
The preliminary filter can be extended with the following extension tubes.
Extension [mm] with volume displacer
Part No.
500
20S9165
1000
20S9170
1500
20S9175
Table 4 Extension tubes

14 SP3110../SP3110V.. | 1.00.02 www.mc-techgroup.com
10 OPTIONS
The following options 10.1 to 10.9 are available for use in potentially explosive atmospheres. Please
seeTable 4 for the markings for the respective zones.
Warning
Attention must be paid to the operating parameters when selecting options.
Diagram with Feeding of calibration gas or back-purging
Entnahmesonde
Sample Probe
Entnahmesonde
Sample Probe
Option
VA
Meßgasausgang
Sample out
Meßgasausgang
Sample out
Option
2X
Entnahmesonde
Sample Probe
Meßgasausgang
Sample out
Meßgasausgang
Sample out
Entnahmesonde
Sample Probe
Entnahmesonde
Sample Probe
Entnahmesonde
Sample Probe
Meßgasausgang
Sample out
Prüfgas/Rückspülung
Cal. gas/ pure gas
Option
R / BB
CCFOption
Meßgasausgang
Sample out
Prüfgas/Rückspülung
Cal. gas/ pure gas
Option
BBF
CCOption
Meßgasausgang
Sample out
Prüfgas
Cal. gas
Option
C/I
i-Luft
I-Air
Entnahmesonde
Sample Probe
Option
RS
Meßgasausgang
Sample out
Rückspülung
Pure gas
Entnahmesonde
Sample Probe
Option
3VA
Meßgasausgang
Sample out
Prüfgasoder Rückspülung
Cal. gasor pure gas
Figure 2 Schematic view of the options for back-purging and feeding of calibration gas

www.mc-techgroup.com SP3110../SP3110V.. | 1.00.02 15
General safety instructions for back-purging and feeding of calibration gas
Warning
A back-purging gas suitable for the sampling point must be selected for back-
purging.
The back-purging pressure must always be higher than the process pressure.
This minimum pressure must be monitored with a press switch at the inlet side
of the accumulator or the check valve. If the flush gas pressure drops below the
process pressure, the back-purging solenoid valve must not be operated.
The maximum permissible pressures of 6 bar abs. must not be exceeded (see
technical data).
Do not choose back flush intervals longer than 3 seconds because in case of
strong pollution of the pre-filter pressure inside the probe would be rising and
then discharging to the analyzer via the patented pressure control valve in the
outlet of the probe due to a defined leak rate of this valve.
At sampling points with inerting, back-purging must be performed with
corresponding inert gas. It must be ensured that the inert gas does not
introduce oxygen or combustible gases into the system.
10.1 BACK-PURGING UNIT TYPE RS:
The back-purging unit type RS consists of a pressure relief valve, solenoid valve, accumulator and
patented pressure control valve in the probe outlet.
The cyclical operation of the solenoid valve and monitoring of the back-purging pressure must be
effected externally. The electrical connection of the solenoid valve must be made in an Ex e
connection box. An additional solenoid valve in the sample gas outlet of the probe is not necessary
because the patented pressure control valve shuts the probe outlet during back-purging in order to
protect the downstream analysis against the pressure push of the back purge.
10.2 OPTION /R, /BB AND /BBF FOR FEEDING OF CALIBRATION GAS OR BACK-PURGING VIA
CHECK VALVE R 1/4“, BB 3/8“ OR BBF 3/8“:
For back-purging of the probe tube or the preliminary filter, flush gas is fed via the check valve.
Hereby, it is recommended to separate the downstream analysing system from the probe in order to
avoid pressure pushes to the system (Option /I). The opening pressure of the check valve is 0.7 bar.
The flush gas or calibration gas pressure should be higher than 0.7 bar.
Options /R and /BB are for backflush of the inside space of the probe and the preliminary filter, the
option BBF is for backflush of the probe filter and the preliminary filter.
Note
In order to avoid the cooling down of the inside probe, it is recommended to
effect the backflush in short intervals of < 1 s.
During the feeding of test gas, the analyze system remains connected. The quantity of test gas should
be at least 25 % higher than the quantity of measuring gas which is taken in by the analysing system,
thus avoiding a mixture with the test gas.

16 SP3110../SP3110V.. | 1.00.02 www.mc-techgroup.com
For processes with overpressure, this kind of feeding the test gas is not recommended. In this case,
you should use an integrated ball valve in the inlet of the probe as stop valve.
In principle, you need only a small quantity of test gas for probes with an integrated ball valve,
because the probe is separated from the process when the ball valve is activated so that there is no
danger of a mixture with the process gas.
In case of manual operation, please turn the turning handle to the right side until the limit stop in order
to shut off the probe.
Note
In case of low pressure operation, please take into consideration that as from
300 mbar secondary air will be taken in via the non-closed check valve.
10.3 OPTION /C/I FEEDING OF TEST GAS VIA CHECK VALVE BEHIND THE PROBE FILTER
WITH PNEUMATIC STOP VALVE FOR THE PROBE OUTLET TO THE PROCESS
By activating the pneumatic stop valve with compressed air, the measuring gas way behind the probe
filter is shut off. Now, you can feed test gas via the check valve to the sample gas outlet of the probe
without any loss.
10.4 OPTION 2-WAY BALL VALVE /VA
For any service work, eg. changing of the filter element or cleaning works, the stop valve in the probe
inlet is actuated from outside with the turning handle. This becomes necessary eg. in case of
overpressure or in case of toxic gas components.
Danger
In case of toxic gas components, the probe must be flushed after shut off and
before opening!
10.5 OPTION SPUN GLASS CARTRIDGE FW
For option FW the filter element is dropped and a spun glass cartridge is mounted at the filter housing
lid. This spun glass cartridge is filled with a high temperature resistant spun glass. The option FW is
used at sample points with risk of quickly blocking filter surfaces due to soot or sticky substances.
The use of standard filter elements S-3SS150 or S-2K150 is not possible with option FW.
10.6 OPTION /3VA FEEDING OF TEST GAS AND BACK-PURGING VIA 3/2-WAY BALL VALVE
With the 3/2-way ball valve, you can execute both functions „back-purging“ and „test gas feeding“ one
after the other. Only one operation each may be automated via the pneumatic actuation.
This kind of gas feeding provides the advantage that during back-purging the downstream analyse
system is automatically separated from the process, respectively, the probe is automatically separated
from the process during test gas feeding. For that reason, you need a lower quantity of test gas as no
mixture with the process gas may occur.
For the measuring operation, the ball valve must be put into the central position.
For back-purging, the ball valve must be put into the corresponding position.
This means in case of manual operation to turn the handle from the central position to the left side as
far as it will go.

www.mc-techgroup.com SP3110../SP3110V.. | 1.00.02 17
For the test gas feeding, the ball valve must be turned to the right side as far as it will go.
For the measuring operation, return the ball valve into the neutral position.
Figure 3 Function schema of option 3/2-way ball valve /3VA
Warning
For back-purge, a back-purge gas suitable for the sampling point must be
selected. At sampling points with inerting, the back-purging must be performed
with the appropriate inert gas. It is essential to prevent oxygen and flammable
gases from being introduced into the system by the inert gas.
The back-purge pressure and test gas pressure must always be higher than the
process pressure. This minimum pressure must be monitored on the inlet side
with a pressure switch. If the purging gas pressure drops below the process
pressure, the ball valve must not be operated.
The permissible maximum pressures of 6 bar abs. must not be exceeded (see
chapter 11 Technical data)
The probes SP3110 with back-purge option or test gas option 3VA must not be
used for gas sampling from zone 0.
Ball valve position
Measuring
Ball valve position
Blow back
Ball valve position
Test gas

18 SP3110../SP3110V.. | 1.00.02 www.mc-techgroup.com
10.7 BALL VALVE DRIVE MS1
The following drives are available:
Pneumatic drive with spring return type MS/ NC or NO
Hereby 2 operating conditions can be realised:
a. Using a shut off ball valve VA the conditions:
"Open=measuring" and "shut".
b. Using a 3/2-way ball valve 3VA either the conditions:
"Open=measuring" and "blow back" or
"Open=measuring" and "test gas feeding"
Type MS-C for test gas feeding and type MS-B for blow back.
When placing the order specify, if the ball valve is
NC, (shut without control air), or
NO, (open without control air). Standard = NC
10.8 OPTION /2X SECOND SAMPLE GAS OUTLET ON THE PROBE
With this option, the probe has got two sample gas outlets ¼“ NPT female.
10.9 PROBE HEATING
The probe heating type HEX1-1 is suitable for temperature ranges of 0 to 185 °C [32 to 365 °F]
(temperature class T3). It consists of a heating plate with heating cartridges and a control electronic
Ex-de.
Please read the technical data in the separate operating instructions.
The probe heating type HEX1-3 is suitable for temperature ranges of 0 to 185 °C [32 to 365 °F]
(temperature class T3). It consists of a heating plate with heating cartridges and a control electronic for
mounting in Ex-free area. Please read the technical data in the separate operating instructions.
The probe heating type HEX4-.. is designed for two temperature ranges. It consists of a heating plate
with two self-regulating heating cartridges, terminal box and weather protection shield.
Please read the technical data in the separate operating instructions of electrical heater type HEX 4 .

www.mc-techgroup.com SP3110../SP3110V.. | 1.00.02 19
11 TECHNICAL DATA
Gas sample probe type
SP3110V
(up to 185 °C [365 °F])
SP3110
(more than 185 °C [365 °F])
Part No.
20S5615
20S5610
Weather protection cover
Yes
Filter housing material
Stainless steel 316/316Ti
Sealing materials
Graphite, FKM
Graphite
Probe flange sealing material
Graphite
Pre-filter/sample tubes
Optional, see data sheet 2.14 and 2.17
Sample pressure max.
0.5 to 6 bar abs.
Ambient temperature
-20 to +60 °C [-4 to 140 °F]
Permissible process gas temperature
Depending on the temperature class, however max. 200 °C [392 °F]
at the probe entry
Filter chamber volume
120 cm3
Filter element, porosity
F-3SS150= stainless steel*, 3 µm S-2K150= ceramic**, 2 µm
Sample gas outlet connection
1x 1/4“ NPT female for max. 8 mm-tube connectors
Connection gas outlet at option RS
6 mm Swagelok®connector
Mounting flange
DN 65 PN 6, Form B, SS316Ti* >DN or ANSI possible**
Weight
7 kg [≈ 15.4 lb]
Marking
II 2G/2GD -20°C ≤ Ta ≤ +60°C EXAM BVS 04 ATEX H 045X
Admissible medium temperature
The admissible medium temperature is limited by the used materials
(< 200 °C [392 °F]) and further by the maximum admissible surface
temperatures as shown in Table 4.
Option heating type HEX4
HEX4-135
HEX4-180
Part No.
20S5510
20S5520
Mounting controller
In the Ex-zone 1, 2 or 21, 22
Control
Self-regulating
Power supply
115 V –230 V 50/60 Hz
Electrical connection
Cable gland, terminal range 7 –12 mm, terminals max. 4 mm2
Marking
II 2 G Ex em T3..T4 / II 2 D IP66 135°C...180°C EXAM BVS
04 ATEX E 253
Case protection
IP66, EN 60529
Power
400 W
Max. temperature
120 °C [248 °F]
160 °C [320 °F]
Min. temperature
90 °C [194 °F]
120 °C [248 °F]
Ambient temperature
-20 to +60 °C [-4 to 140 °F]
Low temperature alarm contact
< 60 °C [140 °F], 1 contact MC-
NO, 230 V 1.5 A AC, 0.5 A DC
< 100 °C [212 °F], 1 contact MC-
NO, 230 V 1.5 A AC, 0.5 A DC
Option heating type HEX1
HEX1-3
Part No.
20S9037(a)
Mounting controller
Outside the Ex-zone

20 SP3110../SP3110V.. | 1.00.02 www.mc-techgroup.com
Gas sample probe type
SP3110V
(up to 185 °C [365 °F])
SP3110
(more than 185 °C [365 °F])
Control
Electronic
Power supply
230 V 50/60 Hz or 115 V 50/60 Hz (a)
Electrical connection
3 x 1.5 mm2
Marking
II 2 G Ex d ib IIC T3*, others on request
Power
400 W
Case protection
IP54, EN 60529
Temperature
0 to 180 °C [32 to 356 °F] T3 or 0 - 135 °C [32 to 275 °F] T4
Ambient temperature
-20 to +40 °C [-4 to 104 °F]
Low temperature alarm contact
<120 °C [248 °F], 1 change-over contact, 230V 1.5 A AC, 0.5 A DC
Option heating type HEX1
HEX1-1
Part No.
20S903(a)
Mounting controller
Inside the Ex-zone 1, 2
Control
Electronic
Power supply
230 V 50 Hz or 115 V 60 Hz (a)
Electrical connection
3 x 1.5 mm2
Marking
II 2 G Ex d e ib IIC T3*, others on request
Power
400 W
Case protection
IP54, EN 60529
Temperature
0 to 180 °C [32 to 356 °F] T3
Ambient temperature
-20 to +40 °C [-4 to 104 °F]
Low temperature alarm contact
< 120 °C [248 °F], 1 change-over contact, 230 V 1.5 A AC, 0.5 A DC
Option back purge unit type RS
RS
Part No.
20S5560(a)
Power supply
230 V 50/60 Hz 9 W or 115 V 50/60 Hz 9 W (a)
Electrical connection
Cable 3 x 1 mm2
Marking
II 2GD Ex m II 135 °C
Connection
G 1/2”i at the buffer vessel
Max. back purge pressure
6 bar abs.
Volume buffer vessel
2 liters
Ambient temperature
-20 to 60 °C [-4 to 140 °F]
Option 2-way-ball valve in the
probe entrance
/VA
Part No.
20S9050
Operating temperature
-20 up to 185 °C [-4 up to 365 °F]
Option 2/3-way-ball valve in the
probe entrance
/3VA
Part No.
20S9325
Backflush / Test gas connection
6 mm tube
