M&C SP Series User manual

Gas Sample Probe Series SP®
SP3000 /xx....
II 1 D/ 2 GD
SP3100V /xx.., SP3100 /xx..
II 1 G/ 2 GD or II 2 G/ 2 GD
Instruction Manual
Version 1.00.02

2 SP3000../SP3100.. | 1.00.02 www.mc-techgroup.com
Dear customer,
Thank you for buying our product. In this manual you will find all necessary information about this
M&C product. The information in the manual is fast and easy to find, so you can start using your M&C
product right after you have read the manual.
If you have any question regarding the product or the application, please don’t hesitate to contact
M&C or your M&C authorized distributor. You will find all the addresses in the appendix of this
instruction manual.
For additional information about our products, please go to M&C’s website www.mc-techgroup.com.
There you can find the data sheets and manuals of our products in German and English.
This instruction manual does not claim completeness and may be
subject to technical modifications.
©
10/2020 M&C Techgroup Germany GmbH. Reprodu
ction of this
document or its content is not allowed without permission from
M&C.
SP
®is a registered trade mark.
Version: 1.00.02

www.mc-techgroup.com SP3000../SP3100.. | 1.00.02 3
Contents
1General information ................................................................................................................. 5
2Declaration of conformity ........................................................................................................ 6
3Safety information.................................................................................................................... 7
4Information on use in potentially explosive atmospheres .................................................... 8
5Warranty ................................................................................................................................... 8
6Terms and symbols used in these operating instructions.................................................... 9
7Application.............................................................................................................................. 11
8Description ............................................................................................................................. 11
8.1 SP3000 (combustible dusts) .............................................................................................. 11
8.2 SP3100 (combustible gases) ............................................................................................. 13
8.3Sample tubes and pre-filters for the SP3000...................................................................... 14
8.4 Sample tubes, pre-filters and option FW for SP3100.......................................................... 16
9Options ................................................................................................................................... 17
9.1 Back purging unit type RS:................................................................................................. 17
9.2 Option 2-way ball valve /VA ............................................................................................... 17
9.3 Option /3VA feeding of test gas and back purging via 3/2-Way ball valve .......................... 18
9.4 Ball valve drive MS1 .......................................................................................................... 19
9.5 Option /2X Second sample gas outlet on the probe ........................................................... 19
9.6 Probe heater ...................................................................................................................... 19
10 Technical data ........................................................................................................................ 20
10.1 Maximum surface temperature of the gas sample probe.................................................... 21
11 Receipt and storage ............................................................................................................... 21
12 Preparations for installation.................................................................................................. 22
13 Installation .............................................................................................................................. 24
13.1 Connection of the sample line............................................................................................ 26
14 Electrical connections ........................................................................................................... 28
15 Start-up ................................................................................................................................... 29
16 Maintenance ........................................................................................................................... 30
16.1 Replacement of the filter element....................................................................................... 31
16.2 Replacement of the preliminary filter.................................................................................. 31
16.3 Blow back Option RS ......................................................................................................... 31
16.4 Ball valve VA or 3VA.......................................................................................................... 31
16.5 Ball valve drive MS1 .......................................................................................................... 31
16.6 Cleaning of the probe......................................................................................................... 32
17 Shutdown................................................................................................................................ 32
18 Proper disposal of the device................................................................................................ 32
19 Appendix................................................................................................................................. 33

4 SP3000../SP3100.. | 1.00.02 www.mc-techgroup.com
List of Figures
Figure 1 Probes SP3000/3100(V) without options with preliminary filter type V20 ........................ 15
Figure 2 Function schema of option 3/2-way ball valve /3VA ....................................................... 18
Figure 3 Schematic drawing of the filter housing cover ................................................................. 24
Figure 4 Removal of the filter housing cover................................................................................. 25
List of Tables
Table 1 Marking for gas sampling from processes with combustible dusts .................................... 12
Table 2 Marking for gas sampling from processes with combustible gases ................................... 14
Table 3 Possible preliminary filter combinations ........................................................................... 15
Table 4 Extension tubes ............................................................................................................... 15
Table 5 Sample tubes for use with the probe SP3100 and SP3100V............................................ 16
Table 6 Technical data .................................................................................................................. 20
Table 7 Operating parameters ....................................................................................................... 23

www.mc-techgroup.com SP3000../SP3100.. | 1.00.02 5
Head Office
M&C TechGroup Germany GmbH Rehhecke 79 40885 Ratingen Germany
Telephone: 02102 / 935 - 0
Fax: 02102 / 935 - 111
E - mail: [e-mail]
www.mc-techgroup.com
1 GENERAL INFORMATION
The product described in this instruction manual has been built and tested in our production facility.
All M&C products are packed to be shipped safely. To ensure the safe operation and to maintain the
safe condition, all instructions and regulations stated in this instruction manual need to be followed.
This instruction manual includes all information regarding proper transportation, storage, installation,
operation and maintenance of this product by qualified personnel.
Follow all instructions and warnings closely.
Read this manual carefully before commissioning and operating the device. If you have any questions
regarding the product or the application, please don’t hesitate to contact M&C or your M&C authorized
distributor.

6 SP3000../SP3100.. | 1.00.02 www.mc-techgroup.com
2 DECLARATION OF CONFORMITY
CE - Certification
The product described in this operating manual complies with the following EU directives:
ATEX-Directive
The product described in this manual is produced in accordance with the EU directive for devices and
protection systems for appropriate use in hazardous areas 2014/34/EU appendix II. The system of
protection depends on the variant of the probe (see tables 1+2).
EMV-Instruction
The requirements of the EU directive 2014/30/EU “Electromagnetic compatibility“ are met.
Low Voltage Directive
The requirement of the EU directive 2014/35/EU “Low Voltage Directive“ are met.
The compliance with this EU directive has been examined according to DIN EN 61010.
RoHS Directive
The requirements of the RoHS2 (‘Restriction of Hazardous Substances 2’) directive 2011/65/EU and
its annexes are met.
Declaration of conformity
The EU Declaration of conformity can be downloaded from the M&C homepage or directly requested
from M&C.

www.mc-techgroup.com SP3000../SP3100.. | 1.00.02 7
3 SAFETY INFORMATION
Observe the following fundamental safety precautions when using the device:
•Read these operating instructions carefully before start-up and use of the device! The
information and warnings given in these operating instructions must be heeded.
•Pay attention to the certificate of conformity (see appendix).
•Work on electrical equipment may only be carried out by suitably qualified personnel in
accordance with valid regulations.
•The requirements of VDE 0100 and its associated standards and regulations must be observed
when erecting high-voltage power installations with rated voltages to 1000 V.
•Relevant national and international standards and regulations must be observed when using
the device in potentially explosive environments.
•The device must be connected to a mains supply with the same voltage as specified on the
rating plate.
•Protection against contact with high electrical voltages:
The device must be safely isolated from the mains supply before it is opened. The same applies
to any connected external control circuits.
•Only use the device within the permissible temperature ranges.
•The device must be installed such that it is protected against weather conditions. Do not expose
directly to rain or liquids.
•Installation, maintenance, inspection and repair work may only be carried out by authorised
personnel. Such work must be carried out in accordance with applicable rules and regulations.

8 SP3000../SP3100.. | 1.00.02 www.mc-techgroup.com
4 INFORMATION ON USE IN POTENTIALLY EXPLOSIVE ATMOSPHERES
See Table 1 and Table 2 for the markings of the individual variants.
The devices are certified by DEKRA EXAM GmbH.
Detailed information and a copy of the certificate are contained in the appendix
to these operating instructions. The devices must be installed and used in
accordance with the conditions and installation instructions given in the EC-
Type
Examination Certi
ficate (see appendix). Only then safe operation in potentially
explosive atmospheres is ensured.
Any changes to the standard configuration with unspecified parts or parts not
authorised by M&C and repair or service work with unspeci
fied parts lead to an
immediate loss of ex-certification.
- In case of doubt please contact M&C directly or your M&C franchise dealer.
5 WARRANTY
In the event of a device failure please contact M&C directly or your M&C franchise dealer.
The device is covered by a one-year warranty starting from the day of delivery and subject to correct
use and our terms and conditions of sale. Wearing parts are not covered by the warranty. The warranty
includes free repair at our factory or free replacement of devices sent to us carriage paid and correctly
packed.

www.mc-techgroup.com SP3000../SP3100.. | 1.00.02 9
6 TERMS AND SYMBOLS USED IN THESE OPERATING INSTRUCTIONS
Danger
The ‘Danger’ warning sign indicates that death, serious injury and/or
significant material damage will be the consequence, if the
appropriate precautions should not be taken.
Warning
The ‘Warning’ warning sign indicates that death, serious injury or
damage to property may occur if the relevant precautionary
measures are not observed.
Caution
The ’Caution’ warning sign indicates that slight personal injury can
occur if the appropriate safety precautions are not observed.
Caution
’Caution‘ indicates that damage to property can occur if the
appropriate safety precautions are not observed.
Attention
‘Attention’ indicates that an unintended result or situation can occur
if the corresponding information is not taken into account.
Note
‘Note’ indicates important information relating to the product or
highlights parts of the documentation for special attention.
Qualified personnel
‘Qualified personnel’ are experts who are familiar with the
installation, commissioning, maintenance,
and operation of these
types of products. The following knowledge is at least required for
the work:
•Instructed person in EX-protection
•Trained person in the electrotechnical field
•
Detailed knowledge of the manual and the applicable safety
regulations
‘Ex‘ indicates important information about the product or about the
corresponding parts in the instruction manual, relatin
g to usage in
potentially explosive atmospheres.
High voltages!
Protect yourself and others against damages which might be caused
by high voltages.
Hot surface!
Contact may cause burn! Do not touch!

10 SP3000../SP3100.. | 1.00.02 www.mc-techgroup.com
Corrosive!
These substances destroy living tissue and equipment upon contact.
Do not breathe vapors; avoid contact with skin and eyes.
Wear protective gloves!
Working with chemicals, sharp objects or extremely high
temperatures requires wearing protective gloves.
Wear safety glasses!
Protect your eyes while working with chemicals or sharp objects.
Wear safety glasses to avoid getting something in your eyes.
Wear protective clothes!
Working with chemicals, sharp objects or extremely high
temperatures requires wearing protective clothes.

www.mc-techgroup.com SP3000../SP3100.. | 1.00.02 11
7 APPLICATION
The probes of the type SP3000 and SP3100.. are used for continuous gas sampling in dust-laden
processes or processes with high temperatures (per Table 7, chapter 10) or high gas moisture. The
modular construction of the probes and the variety of possible options guarantee optimum adaptation
of the probes to complex process and environmental conditions.
The probes of the type SP3000 and SP3100.. are available in both an unheated and an electrically
heated version.
The probes may not be used to withdraw gases or gas mixtures that can be
explosive even in the absence of air or which change safety-
relevant material
properties.
The gases or gas mixtures may also not contain any sol
id particles that could
generate ignitable friction or percussion sparks in combination with the materials
of the probe.
It is not allowed that during operation po
tential sources of ignition (e.g.
smouldering or burning particles, glowing embers, foreign
objects) are brought
into the gas sample probe.
8 DESCRIPTION
The probes of the type SP3000 and SP3100.. have been designed for easy use, long life and
uncomplicated service and maintenance.
The internal filter element can be replaced without the need for tools or dismounting of the sample line.
When the internal filter element has been removed, both the filter chamber and the sample tube can be
cleaned easily.
8.1 SP3000 (COMBUSTIBLE DUSTS)
The gas sample probes of the type SP3000 are suitable for gas sampling from potentially explosive
atmospheres in Zone 20 (combustible dusts). The probe housing and all options are designed for use
in potentially explosive atmospheres in Zone 1 or 21 (combustible dusts or combustible gases).
The markings can be found in the following table.

12 SP3000../SP3100.. | 1.00.02 www.mc-techgroup.com
The maximum surface temperature of the gas sample probe depends on the
process media temperature and the used options (blow back unit RS,
ball valve
drive MS1 and probe heating HEX4).
The permissible process media temperatures are not allowed to exceed 185 °C
[365 °F] at options 2-way-ball-valve VA and 3/2-way-ball-valv
e 3VA. For
variants without these last-mentioned options it is not allowed to exceed 200 °C
[392 °F]. The consequential maximum surface temperatures and the der
ivable
temperature classes of the gases are shown in Table 1.
The intended use limits the process media temperature and the choice of
options insofar as the maximum surface temperature has to be
below the limit
temperature of the flammable process dust mentioned in Table 7 resp. it
has to
correspond to the temperature class of the flammable process gases.
SP3000 for sampling from zone 20 resp. 21 flammable dust
Type
Ex-marking
Max. process media
temperature in °C [°F]
T-class
Max. surface
temperature in °C [°F]
SP3000 with graphite sealing
SP3000
II 1 D / 2 GD
< 80 [176 °F]
T6
85 [185 °F]
II 1 D / 2 GD
< 95 [203 °F]
T5
100 [212 °F]
II 1 D / 2 GD
< 130 [266 °F]
T4
135 [275 °F]
II 1 D / 2 GD
< 195 [383 °F]
T3
200 [392 °F]
II 1 D / 2 GD
< 200 [392 °F]
T2
205 [401 °F]
Option blow back with solenoid valve
SP3000/RS
II 1 D / 2 GD
<130 [266 °F]
T4
135 [275 °F]
II 1 D / 2 GD
<195 [383 °F]
T3
200 [392 °F]
II 1 D / 2 GD
<200 [392 °F]
T2
205 [401 °F]
Option 2-way ball valve VA
SP3000/VA
(Option MS1 pneumatic
drive implies at least
temperature class T4.)
II 1 D / 2 GD
<80 [176 °F]
T6
85 [185 °F]
II 1 D / 2 GD
<95 [203 °F]
T5
100 [212 °F]
II 1 D / 2 GD
<130 [266 °F]
T4
135 [275 °F]
II 1 D / 2 GD
<185 [365 °F]
T3
190
Option 3-way ball valve 3VA
SP3000/3VA
(Option MS1 pneumatic
drive implies at least
temperature class T4.)
II 1 D / 2 GD
<80 [176 °F]
T6
85 [185 °F]
II 1 D / 2 GD
<95 [203 °F]
T5
100 [212 °F]
II 1 D / 2 GD
<130 [266 °F]
T4
135 [275 °F]
II 1 D / 2 GD
<185 [365 °F]
T3
190 [374 °F]
Option blow back RS with solenoid valve and 2-way ball valve VA
SP3000/RS/VA
II 1 D / 2 GD
<130 [266 °F]
T4
135 [275 °F]
II 1 D / 2 GD
<185 [365 °F]
T3
190 [374 °F]
Option blow back RS with solenoid valve and 3-way ball valve 3VA
SP3000/RS/3VA
II 1 D / 2 GD
<130 [266 °F]
T4
135 [275 °F]
II 1 D / 2 GD
<185 [365 °F]
T3
190 [374 °F]
Option 2X second sample outlet, possible for every version.
Option MS1 pneumatic drive implies at least temperature class T4.
Option HEX4-135 implies at least temperature class T4.
Option HEX4-180 implies at least temperature class T3.
Table 1 Marking for gas sampling from processes with combustible dusts

www.mc-techgroup.com SP3000../SP3100.. | 1.00.02 13
8.2 SP3100 (COMBUSTIBLE GASES)
The gas sample probes of the type SP3100 and SP3100V are suitable for gas sampling from potentially
explosive atmospheres in Zone 0 resp. 1 (combustible gases). They differentiate only in the material of
the gaskets for the filter housing.
The version SP3100 has a gasket out of graphite for probe types heated up to more than 185 °C
[365 °F]. The version SP3100V has a gasket out of Viton for probe types non-heated or heated up to
max. 185 °C [365 °F].
The probe housing and all options are designed for use in potentially explosive atmospheres in Zone 1
or 21 (combustible dusts or combustible gases). The markings can be found in the following table.
The maximum surface temperature of the gas sample probe is depending on
the process media
temperature and the used options (blow back unit RS, ball
valve drive MS1 and probe heating HEX4).
The permissible process media temperatures must not exceed 185 °C for the
options filter housing seal Viton®V, 2-way ball valve VA and 3/2-
way ball valve
3 VA. For variants without these last-
mentioned options, 200 °C must not be
exceeded. The resulting maximum surface temperatures and the resulting
temperature classes of the gases are shown in Table 2.
The intended use limits the process media
temperature and the choice of
options insofar as the maximum surface temperature has to be below the limit
temperature of the flammable process dust mentioned in Table 7 resp. it
has to
correspond to the temperature class of the flammable process gases.
SP3100 for sampling from zone 0 resp. 1 flammable gases
Type
Ex-marking
Max.
process-
media
temperatu
re
T-
class
Max.
surface
tempe-
rature
Type
Ex-
marking
Max.
process
media
temper
ature
T-
class
Max.
surface
tempera-
ture
SP3100 with graphite sealing
SP3100/V with Viton sealing
SP3100
II 1 G / 2 GD
< 68
[154.4 °F]
T6
85
[185 °F]
SP3100/V
II 1 G / 2 GD
< 68
[154.4
°F]
T6
85
[185 °F]
II 1 G/ 2 GD
< 80
[176 °F]
T5
100
[212 °F]
II 1 G/ 2
GD
< 80
[176 °F]
T5
100
[212 °F]
II 1 G/ 2 GD
< 108
[226.4 °F]
T4
135
[275 °F]
II 1 G/ 2
GD
< 108
[226.4
°F]
T4
135
[275 °F]
II 1 G/ 2 GD
< 160
[320 °F]
T3
200
[392 °F]
II 1 G/ 2
GD
< 160
[320 °F]
T3
200
[392 °F]
II 1 G/ 2 GD
< 200
[392 °F]
T2
250
[482 °F]
II 1 G/ 2
GD
< 185
[365 °F]
T2
232
[449.6 °F]
Blow back RS with solenoid valve
SP3100/
RS
II 2 G / 2 GD
< 130
[266 °F]
T4
135
[275 °F]
SP3100/V/R
S
II 2 G/ 2
GD
< 130
[266 °F]
T4
135
[275 °F]
II 2 G / 2 GD
< 195
[383 °F]
T3
200
[392 °F]
II 2 G/ 2
GD
< 185
[365 °F]
T3
190
[374 °F]
II 2 G / 2 GD
< 200
[392 °F]
T2
205
[401 °F]

14 SP3000../SP3100.. | 1.00.02 www.mc-techgroup.com
2-way ball valve VA
SP3100/V
A
(Option
MS1
pneumatic
drive
implies at
least
temperatur
e class
T4.)
II 1 G/ 2 GD
< 68
[154.4
°F]
T6
85
[185 °F]
SP3100/V/V
A
(Option MS1
pneumatic
drive implies
at least
temperature
class T4.)
II 1 G/ 2
GD
< 68
[154.4
°F]
T6
85 [185 °F]
II 1 G/ 2 GD
< 80
[176 °F]
T5
100
[212 °F]
II 1 G/ 2
GD
< 80
[176 °F]
T5
100
[212 °F]
II 1 G/ 2 GD
< 108
[226.4
°F]
T4
135
[275 °F]
II 1 G/ 2
GD
< 108
[226.4
°F]
T4
135
[275 °F]
II 1 G/ 2 GD
< 160
[320 °F]
T3
200
[392 °F]
II 1 G/ 2
GD
< 160
[320 °F]
T3
200
[392 °F]
II 1 G/ 2 GD
< 185
[365 °F]
T2
232
[449.6
°F]
II 1 G/ 2
GD
< 185
[365 °F]
T2
232
[449.6 °F]
3-way ball valve 3VA
SP3100/3
VA
(Option
MS1
pneumatic
drive
implies at
least
temperatur
e class
T4.)
II 2 G/ 2 GD
< 80
[176 °F]
T6
85
[185 °F]
SP3100/V/3
VA
(Option MS1
pneumatic
drive implies
at least
temperature
class T4.)
II 2 G/ 2
GD
< 80
[176 °F]
T6
85
[185 °F]
II 2 G/ 2 GD
< 95
[203 °F]
T5
100
[212 °F]
II 2 G/ 2
GD
< 95
[203 °F
T5
100
[212 °F]
II 2 G/ 2 GD
< 130
[266 °F]
T4
135
[275 °F]
II 2 G/ 2
GD
< 130
[266 °F]
T4
135
[275 °F]
II 2 G/ 2 GD
< 185
[365 °F]
T3
190
[374 °F]
II 2 G/ 2
GD
< 185
[365 °F]
T3
190
[374 °F]
Blow back RS with solenoid valve and 2-way ball valve VA
SP3100/R
S/VA
II 2 G / 2 GD
< 130
[266 °F]
T4
135
[275 °F]
SP3100/V/R
S/VA
II 2 G / 2
GD
< 130
[266 °F]
T4
135
[275 °F]
II 2 G / 2 GD
< 185
[365 °F]
T3
190
[374 °F]
II 2 G / 2
GD
< 185
[365 °F]
T3
190
[374 °F]
Blow back RS with solenoid valve and 3-way ball valve 3VA
SP3100/R
S/3VA
II 2 G / 2 GD
< 130
[266 °F]
T4
135
[275 °F]
SP3100/V/R
S/3VA
II 2 G / 2
GD
< 130
[266 °F]
T4
135
[275 °F]
II 2 G / 2 GD
< 185
[365 °F]
T3
190
[374 °F]
II 2 G / 2
GD
< 185
[365 °F]
T3
190
[374 °F]
Option 2X second sample gas outletzweiter Messgasausgang possible for every version.
Option FW spun glass possible for every version.
Option MS1 pneumatic drive Drehantrieb implies at least temperature class T4.
Option HEX4-135 implies at least temperature class T4.
Option HEX4-180 implies at least temperature class T3.
Table 2 Marking for gas sampling from processes with combustible gases
8.3 SAMPLE TUBES AND PRE-FILTERS FOR THE SP3000
The gas sample probe SP3000 has a two-stage filter system:
1. In-situ preliminary filter
Various filter materials are available for this filter. The material is selected on the basis of the
quality of the dust at the sampling point.
For a valid Ex-approval according to ATEX, only operate the probe SP3000
with one of the pre-filters from Table 3.

www.mc-techgroup.com SP3000../SP3100.. | 1.00.02 15
2. Filter in filter holder part
This large filter element is made of stainless steel or a ceramic. The seals are made of graphite
or Viton. The housing is made of anodised aluminium.
The filter system is suitable for dusts with a fineness of up to 2 µm.
Behind the filter system, i.e. at the outlet of the gas sample probe, the sample gas is dust-free. This
means that in the absence of explosive sample gas downstream analysers can be used without any
special protective measures.
The following figure shows the basic version of the gas sample probe SP3000/SP3100(V).
Figure 1 Probes SP3000/3100(V) without options with preliminary filter type V20
The filter system of the gas sample probe SP3000 consists of a process-side preliminary filter and a
stainless steel filter element in the probe.
A preliminary filter from the table below must always be selected when using the probe at sampling
points with explosive atmosphere due to combustible dusts.
Type
Part No.
Material
Dimensions [mm]
Filter fineness [µm]
Filter in the probe:
S-3 SS150
90F0126
1.4404
150 x 30
2
S-2K150
90S0020
Ceramic Aerolith
150 x 30
2
Probe 3100/FW: (option FW only for SP3100)
Filter FW (spun glass) 93S2083
Spun glass, high
temperature
resistant
Selectable preliminary filters:
SP2000ST/V20-T 20S9315
PTFE needled felt
(antistatic)
450 x 40 3
SP2000ST/V20-0
20S9105
1.4404
200 x 50
3
SP2000ST/V20-0/HC
20S9115
Hastelloy®x
200 x 50
3
SP2000ST/V20-1
20S9145
1.4404
500 x 60
3
SP2000ST/V20-1/HC
20S9155
Hastelloy®x
500 x 60
3
SP2000ST/V20-1/HC 0.5 µm
20S9156
Hastelloy®x
500 x 60
0.5
SP2000ST/V20-3
20S9300
1.4404
1000/300 x 31
3
Table 3 Possible preliminary filter combinations
The preliminary filter must be selected with a filter fineness suitable for the quality of the dust.
The preliminary filter can be extended with the following extension tubes.
Extension [mm] with volume displacer
Part No.
500
20S9165
1000
20S9170
1500
20S9175
Table 4 Extension tubes

16 SP3000../SP3100.. | 1.00.02 www.mc-techgroup.com
8.4 SAMPLE TUBES, PRE-FILTERS AND OPTION FW FOR SP3100
Warning
SP3100 and SP3100V:
If the gas-dust mixture that is to be examined can be cl
assified as potentially
explosive because it contains combustible gases, only downstream devices
(flowmeters, analyz
ers) with corresponding marking according to directive
2014/34/EU may be used.
Suitable explosion isolation with a flame arrester must be e
stablished. These
operating instructions do not cover any downstream units.
For probe SP3100 also option FW spun glass is available.
For option FW the filter element is dropped, and a spun glass cartridge is mounted at the filter housing
lid. This spun glass cartridge is filled with a high temperature resistant spun glass. The option FW is
used at sample points with risk of quickly blocking filter surfaces due to tar or sticky substances.
The use of standard filter elements S-3SS150 or S-2K150 is not possible with option FW.
When using the gas sample probe SP3100 and SP3100V at sampling points with explosive atmosphere
due to combustible gases, a preliminary filter can be dispensed with. In this case sample tubes
according to the following table can be selected.
Sample tube
Type
Part No.
Max. temp.
°C
Material
Tube/
Connection
Length
“L1” 1)
mm
Length
“L max”
mm
Connec-
tion
thread
“G”
Tube ø
o/i
[mm]
Connec-
tion
øo“EM”
[mm]
SP2000/SS
20S9065
600
[1112 °F]
Stainless
steel 1.4571
1000
2500
G 3/4“o
25/22
37
SP2000/SS-
Vm
20S9067
600
[1112 °F]
Stainless
steel 1.4571
1000
2500
G 3/4“o
25/06
37
SP2000/HC
20S9090
900
[1652 °F]
Hastelloy®C4
1000
2500
G 3/4“o
25/22
37
SP2000/KA
20S9080
1300
[2372 °F]
Kanthal®/1.45
71
1000
1500
G 3/4“o
27/20
37
SP2000/IC
20S9072
1200
[2192 °F]
Incoloy®956
1000
2000
G 3/4“o
25/22
37
Table 5 Sample tubes for use with the probe SP3100 and SP3100V
Pre-filters and extension tubes from Table 3 and Table 4 are also possible.

www.mc-techgroup.com SP3000../SP3100.. | 1.00.02 17
9 OPTIONS
The following options 9.1 to 9.6 are available for use in potentially explosive atmospheres. Please see
Table 1 and Table 2 for the markings for the respective zones (combustible dusts and gases).
Warning
Attention must be paid to the operating parameters when selecting options.
9.1 BACK PURGING UNIT TYPE RS:
The back purging unit type RS consists of a pressure relief valve, solenoid valve, accumulator, and
patented pressure control valve in the probe outlet.
Warning
A back purging gas suitable for the sampling point must be selected for back
purging.
The back purging pressure m
ust always be higher than the process pressure.
This minimum pressure must be monitored at the inlet side of the accumulator
with a pressure monitoring switch. If the flush gas pressure drops below the
process pressure, the back purging solenoid valve may not be operated.
The maximum permissible pressures of 6 bar may not be exceeded (see
technical data, chapter 10).
Do not choose back flush intervals long
er than 3 seconds because in case of
strong pollution of the pre-filter p
ressure inside the probe would be rising and
than discharging to the analyzer via the patented
pressure control valve in the
outlet of the probe due to a defined leak rate of this valve.
At sampling points with inerting, back purging must be performed w
ith
corresponding inert gas. It must be ensured that the inert gas does not introduce
oxygen or combustible gases into the system.
The probe SP3100 and SP3100V with back purging
option may not be used for
gas sampling from Zone 0.
The cyclical operation of the solenoid valve and monitoring of the back purging pressure must be
effected externally. The electrical connection of the solenoid valve must be made in an Ex e connection
box.
9.2 OPTION 2-WAY BALL VALVE /VA
For any service work, e.g. changing the filter element or cleaning works, the stop valve in the probe
inlet is actuated from outside with the turning handle. This becomes necessary e.g. in case of
overpressure or in case of toxic gas components.
Danger
In case of toxic gas components, the probe must be flushed after shutting off and
before opening!

18 SP3000../SP3100.. | 1.00.02 www.mc-techgroup.com
9.3 OPTION /3VA FEEDING OF TEST GAS AND BACK PURGING VIA 3/2-WAY BALL VALVE
The 3/2-way ball valve allows both functions “back purging“ and “test gas feeding“ to be made
one after the other. Only one operation each can be automated via the pneumatic drive and must
be specified with the order.
This kind of gas feeding provides the advantage that during back purging the downstream analyse
system is automatically separated from the process, respectively, the probe is automatically separated
from the process during test gas feeding. For that reason, you need a lower quantity of test gas as no
mixture with the process gas may occur.
For measuring operation, turn ball valve into central position.
For blow back, turn ball valve into the corresponding position.
This means in case of manual operation to turn the handle from the central position to the left side up
to the stop.
For test gas feeding, the ball valve has to be turned to the right side up to the stop.
For measuring operation, return the ball valve into the central position.
Figure 2 Function schema of option 3/2-way ball valve /3VA
Warning
A back purging gas suitable for the sampling point must be selected for back
purging. At sampling points with inerting, back purging
must be performed with
corresponding inert gas. It must be ensured that the inert gas does not introduce
oxygen or combustible gases into the system.
The back purging
pressure must always be higher than the process pressure.
This minimum pressure must be monitored with a pressure
switch at the inlet
side of the accumulator or the check valve. If the flush gas pressure drops below
the process pressure, the back purging solenoid valve must not be operated.
The maximum permissible pressures of 6 bar
abs. must not be exceeded (see
technical data, chapter 10).
The probes SP3100
with blow back option or test gas option 3VA must not be
used for taking sample from zone 0.
Ball valve position
Measuring
Ball valve position
Blow back
Ball valve position
Test gas

www.mc-techgroup.com SP3000../SP3100.. | 1.00.02 19
9.4 BALL VALVE DRIVE MS1
The following drives are available:
Pneumatic drive with spring return type MS/ NC or NO
Hereby 2 operating conditions can be realized:
a. Using a shut off ball valve VA the conditions:
"Open=measuring" and "shut".
b. Using a 3/2-way ball valve 3VA either the conditions:
"Open=measuring" and "blow back" or
"Open=measuring" and "test gas feeding"
TypeMS-C for test gas feeding and type MS-B for blow back.
When placing the order specify, if the ball valve is
NC, (shut without control air), or
NO, (open without control air). Standard = NC
9.5 OPTION /2X SECOND SAMPLE GAS OUTLET ON THE PROBE
With this option, the probe has got two sample gas outlets ¼“ NPT i.
9.6 PROBE HEATER
The probe heater type HEX4-.. is designed for two temperature ranges. It consists of a heating plate
with two self-regulating heating cartridges, connection box and a weatherproof cover.
Please see the separate operating instructions, Electric Heater Type HEX 4 …, for the technical data
of the heater.

20 SP3000../SP3100.. | 1.00.02 www.mc-techgroup.com
10 TECHNICAL DATA
Gas sample probe SP 3000 (combustible dusts)
Gas sample probe SP 3100(V) (combustible gases)
Standard mounting flange
DN 65 PN 6
Sampling pressure
0.5 to 6 bar abs.
Material of medium-contacting parts
1.4571, 1.4404 cover gasket graphite (heated up to
more than 180 °C [356 °F]) or Viton®(version V
,
heated up to max. 180 °C [356 °F])
Marking:
Gas sample probe SP3000 (combustible
dusts)
Gas sample probe SP3100(V) (combustible
gases)
II 1 D / 2 GD TX -20°C ≤Ta≤+ 60°C
II 1 G / 2 GD TX -20°C ≤Ta≤+ 60°C or
II 2 G / 2 GD TX -20°C ≤Ta≤+ 60°C (for option
back purging unit RS)
Permissible temperature of the medium
The permissible temperature of the medium is limited
firstly by the materials used (< 200 °C [392 °F]
) and
secondly by the maximum permissible surface
temperatures given in table.
Sample gas outlet connection
¼" NPT internal, for max. 8 mm tube connections
Sample gas outlet connection with option RS
6 mm Swagelok®connection
Option: Back purging unit type RS
Power supply back purging unit RS
230 V 50/60 Hz 9 W or 115 V 50/60 Hz 9 W
Electrical connection back purging unit RS
Cable 3 x 1 mm²
Marking:
Back purging unit RS
II 2 GD EEx m II 135°C
Connection back purging unit option RS
½“ at accumulator
Maximum back purging pressure
6 bar abs.
Ambient temperature
-20 °C to 60 °C [-4 to +140 °F]
Option /VA: 2 way ball valve in the probe inlet
Operating temperature
-20 °C to + 185 °C [-4 to +365 °F]
Option /3VA: 2/3 way ball valve in the probe inlet
Connection test gas / blow back gas
6 mm tube
Max. blow back pressure
6 bar abs.
Operating temperature
-20 °C to + 185 °C [-4 to +365 °F]
Option ball valve drives MS1
Connection control air
G ¼“
Control air
4 to 8 bar
Table 6 Technical data
