Mangar Health Archimedes User manual

English
user instrucons
Archimedes
Simple solutions for everyday independence

2
Archimedes
The Archimedes by Mangar Health, is a light weight
baery powered actuator driven bath li, designed
to be easily operated. The Archimedes will give many
years of trouble free bathing, requiring only roune
cleaning and baery recharging.
Contents
Standard Contents Pg 3
Geng Started Pg 3
Fing the Archimedes in the bath Pg 4
Hand Control Pg 5
Baery State Indicator Pg 5
Emergency ‘Stop’ Buon Pg 6
Using the Archimedes Pg 6
Removing the Archimedes from the bath Pg 6
Baery Charging Pg 7
Roune Cleaning Pg 7
Disinfecon Pg 7
Storage Pg 7
Maintenance Pg 8
Fault Finding Pg 8
Specicaons Pg 8
Parts List Pg 9
Symbols used on labels and instrucons Pg 9
Product Disposal Pg 10
Warranty Pg 10
Declaraon of Conformity Pg 11
• Ensure that you have read and fully understand
these instrucons before aempng to operate
the Archimedes.
• The Archimedes should only be used as a bathing
aid, NEVER use it out of a bath.
• Ensure that the sucon cups adhere rmly to the
bath before use.
• The Archimedes is designed to go as low as possible
in the bath. In baths with exceponally narrow or
curved sides/bases, it may be unsuitable. Always
check that the chair secon is free to lower to its
full extent and rise again freely. Be certain that it is
posioned correctly before use.
• Do not allow the Archimedes to lie on its back in
the bath water.
• Ensure that the transfer aps will be clear of any
obstrucons, such as bath handles and soap dishes,
as the seat secon is raised.
• Only recharge the baery with the Mangar Health
baery charger supplied with the Archimedes.
• NEVER recharge the baery in the bathroom,
outdoors or in a damp environment.
• Do not use in the presence of ammable anaesthec
mixtures with air, oxygen or nitrous oxide.
• Do not operate the actuator when it is disconnected
from the base.
• Do not use the Archimedes as a support to
steady yourself when cleaning the bath or when
reaching into the bath to retrieve items.
• Disconnect the hand control from the actuator
before transporng so as to avoid accidental
operaon of the liing mechanism.
• The sucon cups on the base secon and on the
hand control contain latex. No other part of the
product or associated packaging contains latex.
WARNINGS

Simple solutions for everyday independence 3
Archimedes
Standard Contents
1 x Archimedes Bath Li (inc.transfer aps) (A g.1).
1 x Sealed Hand Control (B).
1 x Baery charger (C).
1 x User Instrucons.
Geng Started
Unpacking - Remove the contents from the packaging
and check them to make sure that no damage has been
caused during transit. If it has, contact your supplier
immediately.
Baery - This must be put on charge before using your
Archimedes for the rst me as follows:
• Connect the hand control to the baery charger
and plug the charger into a mains power supply
OUTSIDE THE BATHROOM and allow the baery to
charge overnight (see “Baery Charging”).
Seat and base secons - The Archimedes can be
easily separated into three secons (g.2).
• Seat secon (A)
• Base secon (B)
• Actuator (C)
To separate the seat from the base
secon and actuator:
• Fold the transfer aps onto the seat.
• Release the transit e (A g.3) by pulling up the
‘O’ ring and liing the ball clear of the slot in the
locang collar on the actuator.
• Press the lower part of the latch at the back of
the seat (A g. 4) and li the seat suciently to
allow the actuator to disengage itself from the slot
(B g. 4) and the actuator locator bracket (C g. 4).
The actuator can now be removed from the base
secon.
• Li the seat secon clear of the base secon.
• Reassemble in the reverse order. Do not reaach
the transit e unless you are intending to carry the
assembled Archimedes.
NOTE: The transit e should only be reaached to
the back of the seat secon in order to keep both the
seat and base secons together whilst carrying the
Archimedes.
B
A
C
1
A
B
C2
A3
C
B
A
4

4
Archimedes
Fing the Archimedes in the bath
• Before placing the Archimedes in a bath, check
that the surface where the sucon cups will be
sing is clean and free from bath oil and cleaning
residue. Remove an-slip mang from this area.
WARNING: The sucon cups may not adhere
properly on textured and non-slip areas of a bath.
• Remove the actuator and seat secon from the
base (see “Geng Started”). Moisten each of the
sucon cups and place the base secon as close
to the back slope of the bath as possible.
• Fold the transfer aps onto the seat and slide the
seat secon onto the base secon.
• Slightly raise the seat secon enough so that you
can reposion the actuator in the socket at the
back of the base unit (A g. 5).
• Posion the top end of the actuator into the slot in
the latch (B g.5) at the back of the seat secon and
make sure that it ‘clicks’ into place as you lower the
seat again. NOTE: Ensure that the seat can slide freely
up and down before using the Archimedes (g. 6).
• Plug the hand control into the actuator lead and
close the retaining clip (A g. 7).
• Fill the bath with water at a suitable temperature.
A
B
5
6
A
7

Simple solutions for everyday independence 5
Archimedes
Hand Control
The hand control is a completely sealed unit containing
a rechargeable baery and baery state indicator light;
it contains no user serviceable parts. DO NOT aempt
to open.
Baery State Indicator
When either the ‘Up’ or ‘Down’ buons are pressed,
the indicator light (A g. 8) shows the state of the
baery as follows:
GREEN - OK to use.
FLASHING GREEN - OK to use but the baery needs to
be recharged aer this bath.
RED - The baery needs recharging before use. The
seat will not lower. NOTE: The microprocessor
in the hand control will not allow the seat to
be lowered if it detects that there will not be
enough baery power to raise it again.
The baery is not replaceable. When it reaches the
end of its working life, indicated by failure to accept or
retain charge (frequently showing red on the baery
state indicator), the complete hand control will need
to be replaced with a new one. It should be disposed
of in accordance with local regulaons or returned to
your supplier or to Mangar Health for safe disposal.
DO NOT dispose of the hand control with your normal
household waste.
Emergency Stop Buon
In an emergency, the seat movement can be stopped
at any me by pressing the ‘STOP’ buon on the hand
control (A g.9).
NOTE: Releasing the ‘Up’ or ‘Down’ buons at any
me will also stop the seat movement.
A8
A
9

6
Archimedes
Using the Archimedes
WARNING: Please note that the hand control
incorporates an important safety feature which will
ensure that the seat cannot be lowered unless there is
sucient baery power to raise it again. To acon this
feature eecvely ALWAYS RAISE THE SEAT USING THE
HAND CONTROL and USE IT to lower yourself into the
bath.
• Press the ‘Up’ buon on the hand control to raise
the seat.
• Release the ‘Up’ buon when the seat is level with
the edge of the bath. NOTE: Make sure that the
transfer ap is level with, and supported on, the
edge of the bath (g.10) before transferring.
• Sit on the ap and transfer across onto the seat.
• Press the ‘Down’ buon to lower yourself. Releasing
the buon at any point will stop the seat.
• To raise the seat, press the ‘Up’ buon. Release
the buon when the transfer ap is level with, and
supported on, the edge of the bath.
Removing the Archimedes from the bath
• Fully lower the seat.
• Fold the transfer aps onto the seat.
• Press the lower part of the latch at the back of the
seat (A g.11) and li the seat suciently to allow
the actuator to disengage itself from the slot (B) and
the actuator locator bracket (C). The actuator can
now be removed from the base secon.
• Li out the actuator.
• Li the seat secon clear of the base secon.
• Li the sucon cup release handle at the back of the
base secon (D g.11) and lt the base forwards.
• Connue lng the base forwards using the guide
bars. This will automacally release the sucon on
the front sucon cups and the base secon can then
be lied from the bath. NOTE: DO NOT use the
sucon cup release handle (D g.11) to fully lt or li
the base secon. NEVER aempt to release sucon
on the rear sucon cups by pulling on the guide bars.
10
D
11
B
A
C

Simple solutions for everyday independence 7
Archimedes
Storage
The Archimedes should be stored with the seat secon
fully lowered and the hand control disconnected.
During long term storage, it is recommended that at
approximately three month intervals, the baery is put
on charge overnight.
When stored for long periods, ensure that the
Archimedes is thoroughly dry and stored in a dry
environment.
The transit e (A g.13) should be aached to the seat
secon to allow the Archimedes to be easily picked up
and moved.
A
12
A
13
Roune Cleaning – Regularly clean the Archimedes with the same non-abrasive cleaners normally used to
clean the bath and wipe dry or leave to air dry. It is best to separate the base and seat secons before cleaning.
Disinfecon - All components should be pre-cleaned and then disinfected by wiping with a 1:10 soluon of
household liquid bleach and water - 1 part bleach to 10 parts cold water (10,000ppm (1%) Sodium Hypochlorite
soluon). Leave the soluon on the surface for approximately 10 minutes before thoroughly rinsing o with clean
cold water. Alternavely, a hard surface, alcohol impregnated wipe can be used.
NOTE: It is especially important to thoroughly clean the Archimedes aer each bath if ‘Deol’ or similar products
have been added to the bath water.
Baery Charging
• Disconnect the hand control from the actuator.
• Connect the hand control to the baery charger
(g.12). NOTE: The supplied baery charger may
dier in appearance from the image, however, the
connecng process is the same.
• Plug the baery charger into a mains power supply
outside of the bathroom and switch on. The light
on the charger (A g.12) will light up to indicate
that the charger is connected. NOTE: The supplied
baery charger may not have a light, however, the
baery will sll be charged.
When the baery needs recharging, the hand control
should be le on charge over night. The hand control
can be le on charge connuously without damaging
the baery or charger. We recommend that the hand
control is le connuously on charge when the
Archimedes is not in use, as a maer of roune.

8
Archimedes
Specicaons
Archimedes
Max.user weight: 165kg (26st/364lbs)
Total weight: 10kg
Seat secon only: 5,2kg
Base secon only: 2,8kg
Actuator: 2kg
Seat height (Min/Max): 8cm/45cm
Actuator power input: 12V: 7,5A
Environmental protecon: IP66
Baery Charger
AC Input: 230V: 1,22VA: 50-60Hz
DC Output: 17.4V: 70mA
Internal protecon: Self reseng thermal cut-out
Environmental protecon: IP50
Double insulated Class II Equipment
This product is suitable for transporng in aircra.
Hand Control (Baery)
Type: Ni-Cd
Output (Max): 14V: 10A
Internal protecon: Self reseng fuse
Environmental protecon: IP67
Maintenance
Other than roune cleaning, the Archimedes has been designed to be maintenance free, however, we recommend
that your Archimedes is inspected annually by either your supplier or other suitably qualied person.
NOTE: If the Archimedes is used with the assistance of a professional carer, the Archimedes becomes classed as
‘work equipment’ under the ‘Liing Operaons and Liing Equipment Regulaons 1998 (LOLER)’ and we would
recommend that the Archimedes undergoes a thorough examinaon at intervals not exceeding 24 months, in
accordance with the ‘Thorough Examinaon Schedule’ - available through Mangar Health.
If required, Mangar Health can provide the above inspecon within an annual service contract. Please contact our
Customer Service Department for further details.
There are no user-serviceable parts in the Archimedes. Repairs or servicing must only be carried out by your
supplier or other authorised person.
Fault Finding
If the seat fails to rise:
• Check that the hand control plug is FULLY pushed into
the actuator lead socket (g.14).
If the seat fails to lower:
• Check to see if the baery state indicator light is
showing RED. If it is, put the hand control on charge
overnight.
• Check that the hand control plug is FULLY pushed into
the actuator lead socket (g.14).
39.5cm
Seat Height
45cm (Max)
8cm (Min)
72.5cm
61cm
29.5cm 44.5cm
17cm
66.5cm
14

Simple solutions for everyday independence 9
Archimedes
1Archimedes Seat LA0010 6Archimedes Actuator LA0015
2Archimedes Flap LA0011 7Archimedes Transit Tie LA0017
3Archimedes Flap Hinge LA0012 8Archimedes Charger- UK LA0019
4Archimedes Base LA0013 9Archimedes Charger- EU LA0023
5Archimedes Sucon Cup Set LA0014 10 Archimedes Hand Control LAA4765
IP 66
IP 67
IP 50
Aenon
Consult instrucons
Alternang Current
Direct Current
Class II Double
Insulated Equipment
Do not connect
to mains power
in a bathroom or
outdoors
Dangerous Voltage
Duty cycle
I = Operang me
0 = Non operang me
Sealed against the
eects of immersion
in water to a depth
of 1 metre
Press to raise seat
Press to lower seat Sealed against the
eects of showers
No protecon
against water
ingress
Baery State
Indicator
Emergency ‘STOP’
buon
Maximum user
weight limit
Date of manufacture
Recycle do not
dispose of in
household waste
Symbols used on labels and instrucons
Max/Min Operang
Environmental
Temperature
Parts List
1
2
2
3
5
4
6
7
10
5
Hot Surface
Type BF equipment
(Protecon against
electric shock)
89
Ni-Cd
+45º
ºC
+4º

10
Archimedes
Archimedes serial number: ..................................
Date of purchase: ..................................
Invoice/Delivery note number: ..................................
Product Disposal
Dispose of in accordance with local regulaons. For further guidance, please contact your supplier.
Warranty
The warranty is given against defects in material and workmanship and comprises piece, parts and labour. The
warranty is not valid in the case of fair wear and tear, wilful damage, common neglect, misuse or unauthorised
alteraon or repair by unqualied persons.
The following statements do not aect the consumer’s statutory rights. This product is sold on the understanding
that in the event of any defect of manufacture or material appearing within the warranty period, the defect will
be reced free of charge providing that:
(a) Reasonable evidence is provided (e.g. purchase invoice, delivery note) that the claim is being made within
the warranty period.
(b) The defect is not aributable to accidental damage (either in transit or otherwise), misuse or
unauthorised repair.
We strive to provide our customers with reliable and durable products of the highest quality. In addion to
our standard warranty, and for added peace of mind, our Customer Service Department oers an Annual Service
and Clean package.
To nd out more about this service please call our Customer Service Department on Freephone 0800 2800 485.
Mangar Internaonal Ltd, trading as Mangar Health, reserves the right to alter product specicaons and/or any of the informaon
contained within this document without noce.

Simple solutions for everyday independence 11
Archimedes
DECLARATION OF CONFORMITY
This is to cerfy that:-
The
Archimedes - LAA3702A
complies with:-
The requirements for Class 1 devices according to Annex VII of the Medical
Devices Direcve 93/42/EEC as amended by 2007/47/EC
Mangar Internaonal Ltd
Presteigne, Powys, Wales,UK. LD8 2UF
tel: [phone]
fax: [phone]
heado[email protected]
www.mangarhealth.com
Signed:
Date: April 2017
C. Butcher (Finance Director)

Simple solutions for everyday independence
Mangar Internaonal Ltd
Presteigne, Powys, Wales, LD8 2UF
United Kingdom
Tel: [phone]
Fax:[phone]
E-mail: [e-mail]
www.mangarhealth.com
MI0173 issue 17
(10/18)
