Double Cabinet
Model: 11GMC1 / 11GMC2 / 11GMC3 / 11GMC4
Assembly Guide
1000010416 - 31/07/2019

In order to ease the assembly,
you should separate and identify the parts first
Do not place the parts directly onto the floor.
Use a cardboard sheet or a mat to place the
parts, during the separation and assembly.
*Tools Needed (not supplied)
IMPORTANT
In order to avoid severe or even fatal injuries, follow the
instructions carefully.
IDENTIFICATION OF PARTS
Nº
DESCRIPTION
BLACK
MATT
WHITE MATT BLUE GRAY MATERIAL LENGTH WIDTH THICKNESS
P1 LEFT SIDE SM ART 3000009260 3000009313 3000009263 - STEEL 1 PC 25,31'' 13,74'' 0,67''
P2 RIGHT SIDE SM ART 3000009261 3000009314 3000009265 - STEEL 1 PC 25,31'' 13,74'' 0,67''
P3 CEILING 2 DOORS SM ART 3000009397 3000009393 3000009395 - STEEL 1 PC 27,48'' 13,70'' 0,94''
P4 REAR 2 DOORS SM A RT 3000009397 3000009330 3000009284 - STEEL 1 PC 27,48'' 13,43'' 1,26''
P5 SHELF SM ART 3000009203 3000009335 3000009285 - STEEL 1 PC 27,52'' 12,76'' 0,63''
P6 TOP B A CK 2 DOORS SM A RT 3000009215 3000009336 3000009286 - STEEL 1 PC 26,65'' 11,85'' 0,67''
P7 B OTTOM BACK 2 DOORS SM ART 3000009216 3000009337 3000009287 - STEEL 1 PC 26,65'' 12,17'' 0,67''
P8 DOOR RIGHT SM A RT 3000009338 3000009357 3000009288 3000009208 STEEL 1 PC 23,70'' 12,91'' 0,63''
P9 DOOR LEFT SM A RT 3000009340 3000009359 3000009290 3000009211 STEEL 1 PC 23,70'' 13,23'' 0,63''
P10 FRA M E SM ART FRONT 3000009224 3000009331 3000009292 - STEEL 2 PC 27,52'' 8,74'' 0,59''
QUANTITY
IDENTIFY THE COLOR OF YOUR CABINET
DIMENSION

ASSEMBLED PRODUCT:
H: 29.92'' W:27.55'' L:13.77''
LW
H
Lbs
Maximum weight
supported distributed
P10
P10
P3
P6
P5
P7
P4
P1
P2
P9
P8
26 Lbs
26 Lbs
26 Lbs
CEILING
FRAME
FRAME
BOTTOM BACK
DOOR LEFT
DOOR RIGHT
SHELF
TOP BACK
LEFT SIDE
RIGHT SIDE
REAR

01
01
1 - Attach the FRAME part on the LEFT SIDE and RIGHT SIDE
parts in the indicated direction.
Hardware list
F1
1000008297
Qty. 2
F2
1000008616
Qty. 2
F3
1000009033
Qty. 1
F4
1000000281 - WHITE
1000007352 - BLACK
1000010221 - BLUE
Qty. 2
F5
1000010136
Qty. 2
F6
1000008285
Qty. 4
F8
1000008285
Qty. 1
F7
3000009645 - WHITE
3000009643 - BLACK
3000009649 - BLUE
3000009647 - GREY
Qty. 2
LEFT SIDE
RIGHT SIDE
FRAME
FRAME

01
03
01
02
1 - Check the alignment of the holes
on the fitted parts.
2 - The hole in the horizontal bar
of part FRAME, should be up.
4x 1 - With the end of F3, smash the safety claw,
locking part FRAME to part LEFT SIDE and
RIGHT SIDE.
F3
LEFT SIDE
RIGHT SIDE
FRAME

01
05
01
04
1- Identify the cutout on the top end of the BOTTOM BACK part.
1 - Attach the BOTTOM BACK part, on the LEFT SIDE, RIGHT SIDE and
FRAME parts.
2 - Slide part BOTTOM BACK to support on
parts LEFT SIDE and RIGHT SIDE.
BOTTOM BACK
BOTTOM BACK
BOTTOM BACK

01
07
01
06
2x
1 - With the end of F3, smash the safety claw,
locking part BOTTOM BACK to part LEFT SIDE
and RIGHT SIDE.
F3
1 - Attach the joint of the front of the
REAR part under the BOTTOM BACK part.
2 - Lower the REAR part as indicated.
BOTTOM BACK
REAR

01
09
01
08
1 - Check all the fittings before moving forward.
1 - Attach the TOP BACK part with both cutouts facing up, on parts
LEFT SIDE and RIGHT SIDE.
2 - Attach the TOP BACK part onto the BOTTOM SIDE part.
REAR
TOP BACK

01
10 1x
1x
2x 2x
1 - With the end of F3, smash the safety claw,
locking part BOTTOM BACK to part LEFT SIDE, RIGHT SIDE and
BOTTOM BACK.
F3
F3
TOP BACK

01
11
A
N
T
O
T
I
E
T
N
2x
1 - Attach the CEILING part on
the parts LEFT SIDE and
RIGHT SIDE.
2 - Pull the front of the CEILING part.
CEILING
CEILING
CEILING

01
13
01
12
2x
2x 2x
1 - With the end of F3, smash the
safety claw, locking part TOP BACK to part
CEILING.
F3
2x
P5
2x
1- Slightly turn the SHELF part and place it inside the cabinet, as indicated.
2- Check all the fittings before continuing.
CEILING
SHELF
SHELF
SHELF

01
15
01
14
2x 1 - Lay the cabinet against the wall and mark the hole.
IMPORTANT: CABINET MUST BE ATTACHED TO THE WALL
F1
2X
½”
1 - Drill the wall on the marked
point, using a ½” drill bit.
2 - Insert the metal part of
the bushing into the hole
until it overcomes the wall.
WALL

01
16
3 - Pull the bushing driving it against the wall and then
push the plastic ring until it leans close to the wall
4 - Break the bushing's rods
WALL
1
WALL
2
WALL
WALL
Plastic ring

01
18
01
17
2x
F5
2x
F4
1 - Insert the screw F2 into the hole of part TOP BACK.
2 - Turn screw F2 with part F3 clockwise.
3 - Press part F4 against the heads of the F2 screws.
4 - Attach the F5 into the FRAME part.
2x
F2
F3
F5
2X
F2
2X
F3
1X
F4
2X
1 - Attach the F7 handle to the doors DOOR LEFT and DOOR RIGHT
as indicated below
F7
F7
CLICK !
CLICK !
F7
F7
F7
2X
DOOR LEFTDOOR RIGHT

01
20
01
19
F6
2x
F6
2x
F6
4X
F8
1X
F8
1 - Attach the F6 into the DOOR LEFT and DOOR RIGHT holes.
2 - Glue F8 to part DOOR RIGHT in the indicated area..
1 - Attach part DOOR RIGHT to the right side of the enclosure on parts F5
and FRAME.
2 - Attach part DOOR LEFT to the left side of the enclosure on parts F5
and FRAME.
F5 F5
DOOR LEFT
DOOR RIGHT
DOOR LEFT
DOOR RIGHT

TAKING GOOD CARE OF YOUR CABINET
Cleaning and caring instructions:
- Avoid dragging objects on top of the cabinet. They might scratch the finishing.
- Only non-abrasive natural chemical products are recommended to clean your cabinet.
Simply wipe the cabinet down with a wet cloth to remove the cleaning product excess.
- Never clean the cabinet with scouring powders, steel scrubber pads or any other product
which can scratch its surface.
- Chemical products are not recommended.
- Cabinet surfaces should not be covered with colored plastic or paper sheets.
- Acid substances like salt, onion, ketchup and mustard must remain properly stored in
sealed containers.
- Avoid the direct contact of water with other surfaces than the sink, as the humidity can
affect the durability of the cabinets.
- Avoid cabinets exposure to direct Sun light. Drapers suggested.
- For technical assistance outside Brazil, please, contact the store where you purchased
your product.
- This guidance should be saved for future reference, if necessary.
BEWARE: Do not use a damp cloth to clean the cabinet. Excessive moisture can damage
its surface.
ATTENTION
To avoid serious or irreparable damage to the product, follow the instructions carefully.
WARRANTS TERMS
This product has the guarantee for a period of twelve (12) months, this limited warranty is effective from the date of the original consumer purchase.
Proof of original purchase date is required to obtain service or replacement under this limited warranty. Once the defect of manufacture has been
verified, the consumer should contact the store where he purchased the product. In the warranty period, any defective parts will be replaced free of
charge by another of the same line and model. The installation and assembly in the residence of the costumer is not the responsibility of the factory
or the store. The assembly must correctly follow the instructions inside the packaging of each module.
ITEMS EXCLUDED FROM WARRANTS
This limited warranty does not cover:
1. In-home service including, but not limited to, service calls to correct the installation of any Manhattan Comfort Smart Diy products or to instruct the
consumer on how to use or install them.
2. Damage resulting from improper handling or shipping of products, or products damaged by accident, alteration, misuse, abuse, fire, flood,
improper installation, acts of God, neglect, corrosion, modification or mishandling.
3. All travel, transportation, shipping or freight fees to deliver replacement products or to return defective products.
4. Factory specified replacement parts or product replacement when your product is used in other than normal, single-family household use, such as
a commercial environment or handled in a manner contrary to published user or operator instructions and/or installation instructions.
5. Aesthetic damages including scratches, dings, dents or cracks that do not affect the structural or functional capability of the product.
6. Any labor costs during the limited warranty period.
7. Damage resulting from improper loading beyond the specified maximum weight capacity outlined in the assembly instructions provided with the
product including overloading of hooks, baskets, shelves, cabinets, and other Manhattan Comfort Smart Diy accessories used with the product.
8. Surfaces damaged due to chemical interaction resulting in corrosion of paint or metal.
The cost of repair or replacement under these excluded circumstances shall be borne by the customer.
DISCLAIMER OF IMPLIED WARRANTY
Implied warranties, including any implied warranty of merchantability or implied warrant of fitness for a particular purpose, are limited to one year or
shortest period allowed by law.
LIMITATION OF REMEDIES; EXCLUSION OF INCIDENTAL AND CONSEQUENTIAL DAMAGES
Your sole and exclusive remedy under this limited warranty shall be product repair as provided herein. Manhattan Comfort Smart Diy shall not
be liable for incidental or consequential damages.
