Manhattan Comfort 2GMCF User manual

ASSEMBLY HANDBOOK –
FORTRESS 31.5" MOBILE
GARAGE CABINET WITH
DRAWER AND SHELVES
View our assembly video online
www.manhattancomfort.com
Stuck? Questions? We are here to help.
1-888-230-2225
[email protected]
1000008415 - 15/03/2018
2GMCF

Do not place the parts directly onto the floor.
Use a cardboard sheet or a mat to place the
parts, during the separation and assembly.
In order to ease the assembly,
you should separate and identify the parts first
Necessary hardware for the assembly
Stuck? Questions? We are here to help.
1-888-230-2225
[email protected]
View our assembly video online
www.manhattancomfort.com
IMPORTANT
In order to avoid severe or even fatal injuries, follow the instructions carefully.
* Included in the kit

P10
Upper Back
3000007312
P7
Bottom
3000007271
P15
Drawer Fund
3000007334
P28
Drawer Front
3000007355
P27
Left Door
3000007351
P26
Right Door
3000007348
P17
Column
3000007344
P5
Top
3000007270
P9
Lower Back
3000007366
P19
Shelf
3000007311
P2
Right Side
3000007308
P12
Drawer Right Side
3000007360
P3
SideLeft
3000007316
P14
Drawer Back
3000007365
P13
SideDrawer Left
3000007337
ASSEMBLY HANDBOOK – FORTRESS 31.5" MOBILE GARAGE
CABINET WITH DRAWER AND SHELVES
Hardware list
Qty. 30
F7
1000008301
Qty. 4
F15
1000008280
Qty. 1
F9
1000008368
Qty. 4
F10
1000008352
F11
1000008354
Qty. 2 Qty. 2
F3
1000008391
Qty. 16
* Only in cabinets without caster * Only in cabinets with caster
lb
55lb
31lb
55lb
55lb
Maximum weight
supported by
shelf and
drawer
WARNING
F13
1000009033
Qty. 1
F1
1000009500
F17
1000008285

1 - Fit part P2 inside part P7
2 - Fit both parts in the frontal side, with
F1
1 - Fit part P7 inside part P3
2 - Fit both parts in the frontal side, with
F1
STEP 2
STEP 1
2x
F1
2x
F1
P7
P3
P7
P3
P2

1 - Fit part P5 between part P2 and P3
2 - Check that all 4 tabs have been fitted
3 - Fit part P5 to parts P2 and P3, at the frontal
side, with F1
STEP 4
STEP 3
4x
F1
8x
F1
P7
P7
P2 P2
P5 P5
P3
P3
180°
180°
1 - Turn the cabinet with the back side
upwards
2 - Fit parts P2 and P3 to parts P5 and P7 with
F1
P7
P3
P5
P2
1
2
3

STEP 5
1 - Fit part P10 into parts P2, P3 and P5
Check that all fits are supported over the
bolts
1 - Fit part P9 into parts P2, P3 and P7
Check that all fits are supported over the
bolts
P7
P2 P5
P10
P3
2 - After fitting the parts, screw the bolts until
locked
STEP 6
P7
P10
P9
P2
P3
2 - After fitting the parts, screw the bolts until
locked
1
2
1
2
WARNING
Position part P10
on the P5 side for
mounting the
cabinet.

STEP 7
STEP 8
4x
F9
1 - To assembly the cabinet with shoe fit the
accessory F9 in part P7 as illustrated here
below and turn to screw. To level the
height or the cabinet, turn the shoe either
clockwise or counterclockwise to align it.
16x
F3
2x
F10
2x
F11
* Only in cabinets without caster * Only in cabinets with caster
2 - To assembly the cabinet with caster, align
the F10 and F11 to the holes in part P7
and fix them with F3
3 - WARNING: Casters with lock (F11) must be
fitted in the frontal side of the cabinet
P7 P7
P5
P5
P2
P2
P3
P3
4x
F7
1- Turn the cupboard so that it will stand in the position of use
2- Fix F7 to parts P2 and P3, as shown here below
P7
P5
P2
P3
1
2

STEP 9
1 - Fit the lower part P19 in diagonal position to insert it inside the cupboard
2 - Lean part P19 in part P2, P3 and place it over the F7 detailed in the figure here
below
3 - Lower the other side of part P19, leaning it over the left F7
P7
P19
P5
P2
P3
STEP 10
2x
F1
1 - Insert part P17 inside the cabinet, in
diagonal position.
Fit part P17 in cut-offs of parts P2 and P3,
as detailed here below
3 - Fix part P17 in parts P2 and P3, with F1
F7
P7
P19
P17
P5
P2
P3
1
2

STEP 11
STEP 12
1 - To assembly the doors, fit door P26 lower hinge bolt inside the bushing fixed in part P7
2 - Then, pull down the pin of door P26 upper hinge; align the door and release the pin to fit
the bushing fixed in part P17
3 - Repeat the step for part P27 1º
2º
1 - Fit part P15 to part P28
2 - Fit them with F1
3x
F1
P5
P3
P19
P2
P7
P17
P26
P27
P15
P28

STEP 14
STEP 13
4x
F1
5x
F1
1 - Align parts P12 and P13 to part P15,
until it leans against part P28
1 - Insert part P14 over part P15 and between
parts P12 and P13
2 - Then, fix part P14 to parts P12, P13 and P15,
with F1
P15
P13
P28 P12
P14
P13
P15
P28
P12
2 - Fit them with F1

1 - Fit the drawers – already assembled – between parts P2 and P3, through the slidings
2 - Check that slidings of both sides are properly fitted. Move the drawer, opening and
closing it, testing
STEP 14
P5
P3
P2
1 -Insert product log
STEP 15
