Manhattan 308250 User manual

DISPLAYPORT
TO VGA
CONVERTER
QUICK
INSTALL
GUIDE
Model 308250
Thank you for purchasing this
MANHATTAN®DisplayPort to VGA
Converter, Model 308250.
This handy device helps establish a
fast, simple and convenient link between
newer DisplayPort-equipped desktop
or notebook computers and other
media sources with existing VGA
monitors. (See back for connection
instructions and specications.)
MAN-308250-miniQIG-0209-03
• Delivers a high-quality digital
video signal – ideal
for extending the
service of legacy
VGA equipment
• Supports Deep Color,
high-bandwidth 10.8 Gbps
applications and resolutions up
to 1080p on 1920 x 1200 (WUXGA) displays
• Integrated design simplies connections and eliminates cable tangles
and clutter
• Plug and Play – Windows and Mac compatible
• Lifetime Warranty
Copyright © MANHATTAN
All products mentioned are trademarks or registered trademarks of their respective owners.
MANHATTAN®offers a complete line of PC Components, Peripherals, Cables and
Accessories. Ask your local computer dealer for more information or visit us online at
www.manhattan-products.com

SPECIFICATIONS
CONNECTIONS
1. Connect the male (DisplayPort) end of
the converter (right) to the DisplayPort
source device.
2. Connect the female (VGA) end of the
converter (right) to the display unit.
NOTE: Always insert and remove cable
connectors gently to avoid possible
damage to the connectors or the devices.
Standards and Certications
• UL, FCC, CE, DisplayPort 1.1
Contacts
• (1) DisplayPort 20-pin male
• (1) HD 15-pin female
• Nickel plated
General
• Power supply: +3.3 V (from DisplayPort
source)
• Measured power: active, 1.4 W;
standby, 100 mW
• Automatic sink detection (based on
DDC return) and standby mode
• EDID pre-fetch (VGA EDID conversion)
Signal Input/Output
• Single link range, 1920 x 1200, 1080p
(max.)
• Supports VGA video, 1920 x 1200
(max.)
• Analog video output (RGB): 700 mV
swing
• Display resolution up to 1920 x 1200
(WUXGA-R), 60 Hz, 8 bpc; 154 MHz
• Supports up to 10.8 Gbps bandwidth
• Deep Color support, 8-bit and 10-bit
• Auxiliary channel support, 1 Mbps
• 1 lane, 1 direction, 4-line connection
support
• Video amplier bandwidth, 8 bpc /
10 bpc
Operating Frequency
• Frequency, 154 MHz / 144 MHz
• Vertical range, 60 Hz
Environmental
• Temperatures: operating, 0–70°C;
storage, -10–80°C
• Humidity: operating, 10–85% RH (no
condensation); storage, 5–90% RH
(no condensation)
Physical
• Plastic housing
• Length: 116 x 39 x 20.5 mm
(4.5 x 1.5 x 0.8 in.)
• Weight: 40 g (1.4 oz.)
Package Contents
• DisplayPort to VGA Converter
• Quick install guide
MANHATTAN
DisplayPort to VGA
Converter
PC VGA
cable
Display
