Manhattan 168229 Installation and operation manual

Line Interactive UPS
1000 VA / 500 W
Model
168229
Protect critical equipment and data assets against
power losses.
MANHATTAN®Line Interactive UPS systems protect computer and electronic equipment
against power brownouts, blackouts, sags and surges. Surge-only outlets offer protection
for printers and other peripherals while reserving backup battery capacities for critical
data processing and storage devices. Reliable battery backup maintains sufficient
power to save work when power fails. Ideal for use with equipment with larger power
requirements.
Additional Security and Protection for Equipment
MANHATTAN protects properly connected equipment up to $100,000 (U.S. and Canada
only). Its heavy-duty batteries are warranted for three years.
Lifetime Warranty
Strict manufacturing standards ensure the highest quality in all MANHATTAN products.
Line Interactive UPS products also carry a full Lifetime Warranty protecting materials
and workmanship — the strongest quality commitment anyone can make.

Features
• Advanced protection for PC and Macintosh systems
against power outages, sags, surges and line noise
• Built-in microprocessor maintains proper charge and
provides diagnostics to help extend battery life
• Cold start capability provides temporary battery
backup during power disruptions
• 220 Joules telephone, fax and network surge protection
• Circuit breaker protection offers quick recovery from
overload and short circuit events
• LED and audible alert system and power management
software help monitor critical functions
• $100,000 connected equipment guarantee (U.S. and
Canada only)
• Lifetime Warranty, UPS; Three-year Warranty, battery
Specifications
GENERAL AVAILABLE IN 120 V (NEMA) AND 220 V (IEC) MODELS
• Outlets: 6 NEMA (120 V), 3 backup + surge / 3 surge only; 6 IEC (220 V),
3 back-up + surge / 3 surge only
• Times: backup, 5 minutes at full load; 12 minutes at 50% load and 35 minutes
at varying loads (typical with PC and 15” LCD monitor at 85 W); recharge, 8
hours typical (12 hours maximum); transfer: 4-6 ms typical (10 ms maximum)
• Communications port: USB (120 V); USB (220 V)
• Telephone/fax/network ports: RJ-11/RJ-45 (1 in / 1 out), surge protected
• Nominal voltage: input, 100 V/110 V/120 V (220 V/230 V/240 V);
output, 120 V (230 V)
• Voltage range: input, 96 V – 138 V (174 V – 262 V)
• Frequency range: input, 50/60 Hz +/- 5 Hz (auto sensing)
• Voltage regulation: output, +/- 10% (battery mode)
• Frequency regulation: 50/60 Hz +/- 1%
• Automatic voltage regulation(AVR): Available 220 V model only
• Waveform: simulated sine wave
• Battery: capacity, 12 V / 9 Ah; type, sealed and maintenance-free (lead acid)
• Temperatures (°C): operation, 0 to 40; storage, -15 to 50
• Operation relative humidity: 0 to 95% (non-condensing)
• LED indicators: Online, Overload, On Battery and Bad Battery
• Audible alarms: Overload, On Battery, Low Battery and Self-test
• UL/cUL listed
PACKAGE CONTENTS
• Line Interactive UPS, 1000 VA / 500 W
• Power Management Software CD (Windows 98/SE/Me/2000/XP compatible)
• Cables, USB, 6 ft. (1.8 m); telephone (RJ-11), 6 ft. (1.8 m); power cable,
6 ft. (1.8 m)
• User manual
Model
168229
MH-168229-DS-1206-03
Copyright © MANHATTAN
All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and reproduction of this document, and use and disclosure of
the contents herein, are prohibited unless specifically authorized.
For more information on MANHATTAN products, consult your
local dealer or visit www.manhattan-products.com .
NEMA model
IEC model
