Manitowoc Frymaster BIELA14 Series User manual

BIELA14 Series
Gen II LOV™ Electric Fryer
Installation, Operation and Maintenance Manual
This manual is updated as new information and models are released. Visit our website for the latest manual.
This equipment chapter is to be installed in the Fryer Section of the Equipment Manual.
Part Number: FRY_IOM_8196442 08/2016
OriginalInstructions
*8196442*

FOR YOUR SAFET
Y
Do Not Store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
CAUTION
READTHEINSTRUCTIONSBEFOREUSINGTHEFRYER.


NOTICE
IF,DURINGTHEWARRANTYPERIOD,THECUSTOMERUSESAPARTFORTHISMANITOWOCFOODSERVICEEQUIPMENT
OTHERTHANANUNMODIFIEDNEWORRECYCLEDPARTPURCHASEDDIRECTLYFROMFRYMASTERDEAN,ORANYOFITS
FACTORYAUTHORIZEDSERVICERS,AND/ORTHEPARTBEINGUSEDISMODIFIEDFROMITSORIGINALCONFIGURATION,
THISWARRANTYWILLBEVOID.FURTHER,FRYMASTERDEANANDITSAFFILIATESWILLNOTBELIABLEFORANYCLAIMS,
DAMAGESOREXPENSESINCURREDBYTHECUSTOMERWHICHARISEDIRECTLYORINDIRECTLY,INWHOLEORINPART,
DUETOTHEINSTALLATIONOFANYMODIFIEDPARTAND/ORPARTRECEIVEDFROMANUNAUTHORIZEDSERVICER.
NOTICE
Thisapplianceisintendedforprofessionaluseonlyandistobeoperatedbyqualifiedpersonnelonly.AFrymaster
AuthorizedServicer(FAS)orotherqualifiedprofessionalshouldperforminstallation,maintenance,andrepairs.
Installation,maintenance,orrepairsbyunqualifiedpersonnelmayvoidthemanufacturer’swarranty.SeeChapter1of
thismanualfordefinitionsofqualifiedpersonnel.

NOTICE
Thisequipmentmustbeinstalledinaccordancewiththeappropriatenationalandlocalcodesofthecountryand/or
regioninwhichtheapplianceisinstalled.SeeNATIONALCODEREQUIREMENTSinChapter2ofthismanualforspecifics.

NOTICETOU.S.CUSTOMERS
ThisequipmentistobeinstalledincompliancewiththebasicplumbingcodeoftheBuildingOfficialsandCode
AdministratorsInternational,Inc.(BOCA)andtheFoodServiceSanitationManualoftheU.S.FoodandDrug
Administration.
NOTICE
Thisapplianceisintendedtobeusedforcommercialapplications,forexampleinkitchensofrestaurants,canteens,
hospitalsandincommercialenterprisessuchasbakeries,butcheries,etc.,butnotforcontinuousmassproductionof
food.

NOTICE
Drawingsandphotosusedinthismanualareintendedtoillustrateoperational,cleaningandtechnicalproceduresand
maynotconformtoonsitemanagementoperationalprocedures.
NOTICETOOWNERSOFUNITSEQUIPPEDWITHCOMPUTERS
U.S.
ThisdevicecomplieswithPart15oftheFCCrules.Operationissubjecttothefollowingtwoconditions:1)Thisdevice
maynotcauseharmfulinterference,and2)Thisdevicemustacceptanyinterferencereceived,includinginterference
thatmaycauseundesiredoperation.WhilethisdeviceisaverifiedClassAdevice,ithasbeenshowntomeettheClassB
limits.
CANADA
ThisdigitalapparatusdoesnotexceedtheClassAorBlimitsforradionoiseemissionsassetoutbytheICES‐003
standardoftheCanadianDepartmentofCommunications.
Cetappareilnumeriquen’emetpasdebruitsradioelectriquesdepassanyleslimitesdeclasseAetBprescritesdansla
normeNMB‐003edicteeparleMinistredesCommuncationsduCanada.
DANGER
Improperinstallation,adjustment,maintenanceorservice,andunauthorizedalterationsormodificationscancause
propertydamage,injury,ordeath.Readtheinstallation,operating,andserviceinstructionsthoroughlybeforeinstalling
orservicingthisequipment.

WARNING
Theappliancemustbeinstalledandusedinsuchawaythatanywatercannotcontactthefatoroil.

DANGER
Thefrontledgeofthisapplianceisnotastep!Donotstandontheappliance.Seriousinjurycanresultfromslipsor
contactwiththehotoil.


DANGER
Donotstoreorusegasolineorotherflammableliquidsorvaporsinthevicinityofthisoranyotherappliance.

DANGER
Thecrumbtrayinfryersequippedwithafiltersystemmustbeemptiedintoafireproofcontainerattheendoffrying
operationseachday.Somefoodparticlescanspontaneouslycombustifleftsoakingincertainshorteningmaterial.

WARNING
Donotbangfrybasketsorotherutensilsonthefryer’sjoinerstrip.Thestripispresenttosealthejointbetweenthefry
vessels.Bangingfrybasketsonthestriptodislodgeshorteningwilldistortthestrip,adverselyaffectingitsfit.Itis
designedforatightfitandshouldonlyberemovedforcleaning.

DANGER
Adequatemeansmustbeprovidedtolimitthemovementofthisappliancewithoutdependingonortransmittingstress
totheelectricalconduit.Arestraintkitisprovidedwiththefryer.IftherestraintkitismissingcontactyourlocalKES.

DANGER
Thisfryerhasapowercord(three‐phase)foreachfrypotandasinglefive‐wirecordfortheentiresystem.Priorto
movement,testing,maintenanceandanyrepaironyourFrymasterfryer;disconnectALLelectricalpowercordsfrom
theelectricalpowersupply.

DANGER
Keepallitemsoutofdrains.Closingactuatorsmaycausedamageorinjury.
NOTICE
TheinstructionsinthismanualforusingabulkoilsystemforfillinganddiscardingoilareforanRTIsystem.These
instructionsmaynotbeapplicabletootherbulkoilsystems.

WARNING
Thisapplianceisnotintendedforusebychildrenundertheageof16orpersonswithreducedphysical,sensoryor
mentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeengivensupervisionconcerninguseofthe
appliancebyapersonresponsiblefortheirsafety.Donotallowchildrentoplaywiththisappliance.

WARNING
Iftheelectricalpowersupplycordisdamaged,itmustbereplacedbyaFrymasterFactoryAuthorizedServicerora
similarlyqualifiedpersoninordertoavoidahazard.

WARNING
NEVERdrainboiloutorcleaningsolutionintoashorteningdisposalunit(SDU),abuilt‐infiltrationunit,aportablefilter
unit,oranOQS(OilQualitySensor).Theseunitsarenotintendedforthispurpose,andwillbedamagedbythesolution
andvoidthewarranty.

WARNING
Usecautionandwearappropriatesafetyequipmenttoavoidcontactwithhotoilorsurfacesthatmaycausesevere
burnsorinjury.

M3000MenuSummaryTree

ReflectedbelowarethemajorprogrammingsectionsintheM3000andtheorderinwhichsubmenuheadings
willbefoundunderthesectionsintheInstallationandOperationManual.

AddingNewProductMenuItems(ProductSelection)  Seesection4.10.2
StoringProductMenuItemsinProductButtonsSeesection4.10.3
Draining,Refilling,andDisposingofOilSeesection4.10.4
   3

Table of Contents
Warranty Statement............................................................................................. i
Section 1 Introduction.......................................................................................................1-1
Section 2 Installation.........................................................................................................2-1
Section 3 Operation Instructions .....................................................................................3-1
Section 4 M3000 Controller Instructions.........................................................................4-1
Section 5 Operating the Built-In Filtration System ........................................................5-1
Section 6 Preventative Maintenance ...............................................................................6-1
Section 7 Operator Troubleshooting...............................................................................7-1
Appendix A RTI (Bulk Oil) Instructions................................................................................ A-1
Appendix B JIB Preparation with Solid Shortening Option...............................................B-1
Appendix C Solid Shortening Melting Unit Use ..................................................................C-1
Appendix D Using the Oil Quality Sensor (OQS) ................................................................ D-1
Appendix E Oil Quality Sensor (OQS) Setup........................................................................E-1













Part Number: FRY_IOM_8196442 4

i
LOV™ ELECTRIC WARRANTY STATEMENT
Frymaster, L.L.C. makes the following limited warranties to the original purchaser only for this
equipment and replacement parts:
A. WARRANTY PROVISIONS - FRYERS
1. Frymaster L.L.C. warrants all components against defects in material and workmanship for a
period of two years.
2. All parts, with the exception of the frypot, O-rings and fuses, are warranted for two years
after installation date of fryer.
3. If any parts, except fuses and filter O-rings, become defective during the first two years after
installation date, Frymaster will also pay straight-time labor costs up to two hours to replace
the part, plus up to 100 miles/160 km of travel (50 miles/80 km each way).
B. WARRANTY PROVISIONS - FRYPOTS
The frypot has a lifetime parts and labor warranty. If a frypot develops a leak after installation,
Frymaster will replace the frypot, allowing up to the maximum time per the Frymaster time
allowance chart hours of straight-time labor. Components attached to the frypot, such as the
high-limit, probe, gaskets, seals, and related fasteners, are also covered by the lifetime warranty
if replacement is necessitated by the frypot replacement. Leaks due to abuse or from threaded
fittings such as probes, sensors, high-limits, drain valves or return piping are not included.
C. PARTS RETURN
All defective in-warranty parts must be returned to a Frymaster Authorized Servicer within 60
days for credit. After 60 days, no credit will be allowed.
D. WARRANTY EXCLUSIONS
This warranty does not cover equipment that has been damaged due to misuse, abuse, alteration,
or accident such as:
•improper or unauthorized repair (including any frypot which is welded in the field);
•failure to follow proper installation instructions and/or scheduled maintenance procedures as
prescribed in your MRC cards. Proof of scheduled maintenance is required to maintain the
warranty;
•improper maintenance;
•damage in shipment;
•abnormal use;
•removal, alteration, or obliteration of either the rating plate or the date code on the heating
elements;
•operating the frypot without shortening or other liquid in the frypot;

ii
•no fryer will be warranted under the ten-year program for which a proper start-up form has not
been received.
This warranty also does not cover:
•transportation or travel over 100 miles/160 km (50 miles/80 km each way), or travel over two
hours;
•overtime or holiday charges;
•consequential damages (the cost of repairing or replacing other property which is damaged), loss
of time, profits, use or any other incidental damages of any kind.
There are no implied warranties of merchantability or fitness for any particular use or purpose.
This warranty is applicable at the time of this printing and is subject to change.

1-1
BIELA14 SERIES GEN II LOV™ ELECTRIC FRYER
CHAPTER 1: INTRODUCTION
1.1 General
Read the instructions in this manual thoroughly before attempting to operate this equipment. This
manual covers all configurations of McDonald’s BIELA14 LOV™ models. The fryers in this model
family have most parts in common, and when discussed as a group, will be referred to as “LOV™
fryers.
Although similar in appearance to the RE14 McDonald’s electric fryers, the BIELA14 fryers feature
a low oil volume frypot, automatic oil top off and an automatic intermittent filtration unit. The
Euro-Look design incorporates a rounded topcap and a large round drain, which ensures that fries
and other debris, will be washed into the filter pan. The BIELA14 LOV™ fryers are controlled with
an M3000 computer. Fryers in this series come in full- or split-vat arrangements, and can be
purchased in batteries of up to five fryers.
1.2 Safety Information
Before attempting to operate your unit, read the instructions in this manual thoroughly.
Throughout this manual, you will find notations enclosed in double-bordered boxes similar to the
one below.
DANGER
Hot oil causes severe burns. Never attempt to move a fryer containing hot oil or to
transfer hot oil from one container to another.
CAUTION boxes contain information about actions or conditions that may cause or result in a
malfunction of your system.
WARNING boxes contain information about actions or conditions that may cause or result in
damage to your system, and which may cause your system to malfunction.
DANGER boxes contain information about actions or conditions that may cause or result in
injury to personnel, and which may cause damage to your system and/or cause your system to
malfunction.
The BIELA14 LOV™ fryers incorporate a high-temperature detection feature which shuts off power
to the elements should the temperature controls fail.
NOTE: The Frymaster BIELA14 fryer requires a start-up, demonstration and training
before normal restaurant operations can begin.

1-2
1.3 Computer Information for the M3000 Computers
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC rules. While this device is a verified Class A device, it has been
shown to meet the Class B limits. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of
the equipment in a residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at their own expense.
The user is cautioned that any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
If necessary, the user should consult the dealer or an experienced radio and television technician for
additional suggestions.
The user may find the following booklet prepared by the Federal Communications Commission
helpful: "How to Identify and Resolve Radio-TV Interference Problems". This booklet is available
from the U.S. Government Printing Office, Washington, DC 20402, Stock No. 004-000-00345-4.
1.4 European Community (CE) Specific Information
The European Community (CE) has established certain specific standards regarding equipment of
this type. Whenever a difference exists between CE and non-CE standards, the information or
instructions concerned are identified by means of shadowed boxes similar to the one below.
CE Standard
Example of box used to distinguish CE and
Non-CE specific information.
1.5 Installation, Operating, and Service Personnel
Operating information for Frymaster equipment has been prepared for use by qualified and/or
authorized personnel only, as defined in Section 1.6. All installation and service on Frymaster
equipment must be performed by qualified, certified, licensed, and/or authorized installation
or service personnel, as defined in Section 1.6.
1.6 Definitions
QUALIFIED AND/OR AUTHORIZED OPERATING PERSONNEL
Qualified/authorized operating personnel are those who have carefully read the information in this
manual and have familiarized themselves with the equipment functions, or who have had previous
experience with the operation of the equipment covered in this manual.

1-3
QUALIFIED INSTALLATION PERSONNEL
Qualified installation personnel are individuals, firms, corporations, and/or companies which, either
in person or through a representative, are engaged in and are responsible for the installation of
electrical appliances. Qualified personnel must be experienced in such work, be familiar with all
electrical precautions involved, and have complied with all requirements of applicable national and
local codes.
QUALIFIED SERVICE PERSONNEL
Qualified service personnel are those who are familiar with Frymaster equipment and who have been
authorized by Frymaster, L.L.C. to perform service on the equipment. All authorized service
personnel are required to be equipped with a complete set of service and parts manuals, and to stock
a minimum amount of parts for Frymaster equipment. A list of Frymaster Factory Authorized
Servicers (FAS’s) is located on the Frymaster website at www.frymaster.com. Failure to use
qualified service personnel will void the Frymaster warranty on your equipment
1.7 Shipping Damage Claim Procedure
What to do if your equipment arrives damaged:
Please note that this equipment was carefully inspected and packed by skilled personnel before
leaving the factory. The freight company assumes full responsibility for safe delivery upon
acceptance of the equipment.
1. File Claim for Damages Immediately - regardless of extent of damage.
2. Inspect For and Record All Visible Loss or Damage, and ensure that this information is noted
on the freight bill or express receipt and is signed by the person making the delivery.
3. Concealed Loss or Damage- If damage is unnoticed until equipment is unpacked, notify the
freight company or carrier immediately upon discovery and file a concealed damage claim.
This must be submitted within 15 days of date of delivery. Be sure to retain container for
inspection.
Frymaster DOES NOT ASSUME RESPONSIBILITY FOR DAMAGE OR LOSS
INCURRED IN TRANSIT.
