RAPID SILVER WORKSHOP TROLLEYS
TCT2, TCT3 & TCT4
IMPORTANT - ASSEMBLY INSTRUCTIONS
AIW004
For model TCT2
1Fit castors Cand Dto base tray B.
2Fix uprights Ato the base trolley Busing screws and
washers H. Fix upright outside tray.
3Fix shelf tray Eto the top of uprights A, using screws
and washers H.
4Fix handle K, using screws and washers G.
For model TCT3
1Follow instructions for TCT2 model but add the
middle shelf tray before fitting the top shelf tray.
For model TCT4
1Follow instructions for the TCT2 model, but place tool
box Ionto bars Jbefore fitting the top shelf E.
ASSEMBLY
If you have any problems whatsoever please call 01285 686868 where a team of experts will be pleased to help.
A
Illustration shown - TCT2
We advise the use of
protective gloves and
goggles, or eyeglasses
when assembling this
product.
Tools required: Spanners, socket and
wrench (provided)
Illustration shown - TCT4
with tool cabinet
A
B
C
D
E
F
K
I
J
H
G
All manuals and user guides at all-guides.com

If you have any problems whatsoever please call 01285 686868 where a team of experts will be pleased to help.
Uprights
COMPONENTS
RAPID SILVER WORKSHOP TROLLEYS
TCT2, TCT3 & TCT4
IMPORTANT - ASSEMBLY INSTRUCTIONS
AIW004
A
Keep heavier items
on the bottom shelves
Do not climb
on your shelving
Make sure it is on a
level and even floor
Keep your
shelving dry
BBase tray
SAFETY
4 of per unit
1 of per unit
CSwivel castor
2 of per unit
DSwivel/brake castor
2 of per unit
ETray
410 mm D x 810mm W
1 of per TCT2 unit
2 of per TCT3 unit
FCastor nuts and bolts
16 per unit
KHandle
1 of per unit
JShelf bars
410 mm D
2 of per TCT4 unit
(Includes 8 tray screws
and washers H)
ITool cabinet
1 of per TCT4 unit
GHandle bolts
4 of per unit
HTray screws and
washers
16 per tray
