Marantz DV6001 User manual

Single Disc DVD Player
Quality universal players are difficult to find. But the DV6001 combines universality and quality in a uniquely Marantz
fashion. It handles movie DVDs, DVD-As, SA-CDs, conventional music CDs, recordable CD-R/-RWs, VCD 2.0 discs,
MP-3 and WMA audio discs, even JPEG picture discs! The Marantz audio tradition now includes internal Dolby
Digital and DTS decoders. Six 192 kHz/24-bit digital-to-analog converters make everything sound exceptionally
lifelike. Shut off the DV6001’s video circuitry completely for the purest audio signal path possible. Internal bass
management circuits route DVD-A and SA-CD audio channels directly to the proper speakers. Video technology
includes advanced 3:2 pull down circuitry and wide bandwidth video D/A converters for exceptional picture quality.
Composite, S-Video, and component outputs? Progressive scan? Of course! Connectivity options include a variety of
audio and video outputs. There’s a D-BUS connector for total Marantz system control. The three-year warranty
increases your peace of mind.
• Plays DVD-V, DVD-A, SACD-Multi, SACD-Stereo, DVD-R/RW, DVD+R/RW, SVCD, VCD, CD,
CD-R/CD-RW, MP3, WMA, JPEG, DiVX
• Faroudja DCDi processing and NSV (Noise Shaped Video)
• HDMI Output with Scaling (1080p, 1080i, 720p and 480p)
• CD Text and CD Up-Sampling
• RS-232C Terminal for System Control
• 192kHz/24-Bit Audio DAC
• Direct IR Input
• 216MHz/12-Bit Video DAC
• D-BUS remote Connection
• Progressive Scan w/3:2 Pull-Down
• Detachable AC Cord
• Dolby Prologic II and DTS Decoders
Life Amplified

DV6001
-
•
•
(Dolby Prologic II)
1
•
•
DVD-V, DVD-A, SACD-Multi, SACD-Stereo, DVD-R/RW ,
DVD+R/RW , SVCD, VCD, CD, CD-R/RW , MP3, WMA, JPEG, DiVX
216MHz/12-Bit
192kHz/24-Bit
-
-
•
-
-
-
•
•
-
AI
Metal
-
1
1
1
1
1
1
1
1
-
•
1/1
•
Life Amplied
©2007 Marantz America,Inc. • www.marantz.com
FEATURES
Separate Power Supply for Audio
DTS® Decoder
Dolby Digital® Decoder
Disc Capacity
Progressive Scan
3:2 Pulldown
Playback Formats
Video DAC
Audio DAC
HDAM
Video Circuit O
Display On/O
Zero-Impedance Plate
Double Layerd Bottom Plates
Headphone
Video Scaler
Bass Management
Gold Plated Terminals
SOUND ENHANCEMENT
Power Transformer
Chassis
Lip-sync (digital audio delay)
IN/OUTPUTS
VIDEO
HDMI Out
Component Out
S-Video Out
Composite Out
AUDIO
Analog Out (RCA)
5.1ch Analog Out
Digital Optical Out
Digital Coaxial Out
i.Link (IEEE1394)
OTHER
External control (RS232C)
D-Bus Remote (RC-5) In/Out
Direct IR input
4Hz - 44kHz (DVD fs:96kHz)
110db
100db
0.0030%
Black
Aluminum
•
AC120-230V 50/60Hz
25w, 0.8w in standby mode
17 5/16" x 3 1/16" x 12 9/16"
8.8 lbs
SPECIFICATIONS
Freq. Response (Digital Audio)
S/N Ratio
Dynamic Range
THD (1 kHz)
GENERAL
Color
Front Panel
Remote Control
Power Requirement
Power Consumption
Dimensions W x H x D (Inches)
Weight (lbs)
*All specifications, dimensions and weights are subject to change without notice.
D&M Holdings, Marantz, Marantz America, Inc. or any of its subsidiaries will not assume any liability for errors in this
spec sheet which may result in consequential errors being made by retail dealers, designers, custom installers,
cabinet makers or end users, etc based upon information contained within this document.

Model DV6001 User Guide
Super Audio CD/DVD Player
CLASS 1 LASER PRODUCT
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT

2
CONGRATULATIONS ON YOUR PURCHASE OF THIS
FINE MARANTZ PRODUCT.
MARANTZ is on the leading edge of DVD research for
consumer products and this unit incorporates the latest
technological developments.
We are sure you will be fully satisfied with the DVD player.
Thank you for your support.
This product incorporates copyright protection technol-
ogy that is protected by methods claims of certain U.S.
patents and other intellectual property rights owned by
Macrovision Corporation and other rights owners.
Use of this copyright protection technology must be
authorized by Macrovision Corporation, and is intended
for home and other limited viewing uses only unless oth-
erwise authorized by Macrovision Corporation.
Reverse engineering or disassembly is prohibited.
Operating Environment
Operating environment temperature and humidity:
+5°C to +35°C (+41°F to +95°F); less than 85%RH
(cooling vents not blocked)
Do not install in the following locations
÷Location exposed to direct sunlight or strong artificial
light
÷Location exposed to high humidity, or poorly ventilated
location
NOTE:
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s au-
thority to operate the equipment.
Please read through these operating instructions so you
will know how to operate your model properly. After you
have finished reading the instructions, put them away in
a safe place for future reference.
CAUTION
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AVOID
EXPOSURE TO BEAM (WARNING LOCATION: INSIDE ON LASER
COVERSHIELD)
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product’s enclosure that may be of suffi-
cient magnitude to constitute a risk of electric shock
to persons.
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION:
POUR ÉVITER LES CHOCS ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS
LA BORNE CORRESPON-DANTE DE LA PRISE ET POUSSER
JUSQU’AU FOND.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
LASER SAFETY
This unit employs a laser. Only a qualified service person should remove
the cover or attempt to service this device, due to possible eye injury.
CAUTION :
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURE OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
Copy protection
Many DVD discs are encoded with copy protection. Because
of this, you should only connect your DVD player directly to
your TV, not to a VCR. Connecting to a VCR results in a dis-
torted picture from copy-protected DVD discs.

3
English
IMPORTANT SAFETY INSTRUCTIONS
READ BEFORE OPERATING EQUIPMENT (for U. S. A only)
This product was designed and manufactured to meet strict quality and
safety standards. There are, however, some installation and operation
precautions which you should be particularly aware of.
1. Read Instructions – All the safety and operating instructions should be read
before the product is operated.
2. Retain Instructions – The safety and operating instructions should be retained
for future reference.
3. Heed Warnings – All warnings on the product and in the operating instructions
should be adhered to.
4. Follow Instructions – All operating and use instructions should be followed.
5. Cleaning – Unplug this product from the wall outlet before cleaning. Do not
use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
6. Attachments – Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
7. Water and Moisture – Do not use this product near water-for example, near
a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near
a swimming pool, and the like.
8. Accessories – Do not place this product on an unstable cart, stand, tripod,
bracket, or table. The product may fall, causing serious injury to a child or
adult, and serious damage to the product. Use only with a cart, stand, tripod,
bracket, or table recommended by the manufacturer, or sold with the product.
Any mounting of the product should follow the manufacturer’s instructions,
and should use a mounting accessory recommended by the manufacturer.
9. CART – A product and cart combination should be
moved with care. Quick stops, excessive force, and
uneven surfaces may cause the product and cart
combination to overturn.
10. Ventilation – Slots and openings in the cabinet are
provided for ventilation and to ensure reliable
operation of the product and to protect it from overheating,
and these openings must not be blocked or covered. The openings should
never be blocked by placing the product on a bed, sofa, rug, or other similar
surface. This product should not be placed in a built-in installation such as a
book case or rack unless proper ventilation is provided or the manufacturer’s
instructions have been adhered to.
11. Power Sources – This product should be operated only from the type of power
source indicated on the marking label. If you are not sure of the type of power
supply to your home, consult your product dealer or local power company. For
products intended to operate from battery power, or other sources, refer to the
operating instructions.
12. Grounding or Polarization – This
product may be equipped with a
polarized alternating-current line
plug (a plug having one blade
wider than the other). This plug will fit into the power outlet only one way. This
is a safety feature. If you are unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose of the polarized
plug.
AC POLARIZED PLUG
13. Power-Cord Protection – Power-supply cords should be routed so that they are
not likely to be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience receptacles, and the
point where they exit from the product.
14.
Protective Attachment Plug – The product is equipped with an attachment plug
having overload protection. This is a safety feature. See Instruction Manual for
replacement or resetting of protective device. If replacement of the plug is
required, be sure the service technician has used a replacement plug specified by
the manufacturer that has the same overload protection as the original plug.
17. Power Lines – An outside antenna system should not be located in the vicinity
of overhead power lines or other electric light or power circuits, or where it
can fall into such power lines or circuits. When installing an outside antenna
system, extreme care should be taken to keep from touching such power lines
or circuits as contact with them might be fatal.
18 Overloading – Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of fire or electric shock.
19. Object and Liquid Entry – Never push objects of any kind into this product
through openings as they may touch dangerous voltage points or short-out
parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
20. Servicing – Do not attempt to service this product yourself as opening
or removing covers may expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
21. Damage Requiring Service – Unplug this product from the wall outlet and
refer servicing to qualified service personnel under the following conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as
an improper adjustment of other controls may result in damage and will often
require extensive work by a qualified technician to restore the product to its
normal operation.
e. If the product has been dropped or damaged in any way, and
f. When the product exhibits a distinct change in performance – this indicates
a need for service.
23. Safety Check – Upon completion of any service or repairs to this product,
ask the service technician to perform safety checks to determine that the
product is in proper operating condition.
24. Wall or Ceiling Mounting – The product should be mounted to a wall or
ceiling only as recommended by the manufacturer.
25. Heat – The product should be situated away from heat sources such as
radiators, heat registers, stoves, or other products (including amplifiers)
that produce heat.
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la Classe B est conforme à la norme
NMB-003 du Canada.
15.
Outdoor Antenna Grounding – If an outside antenna or cable system is connected
to the product, be sure the antenna or cable system is grounded so as to provide
some protection against voltage surges and built-up static charges. Article 810 of
the National Electrical Code, ANSI/NFPA 70, provides information with regard to
proper grounding of the mast and supporting structure, grounding of the lead-in
wire to an antenna discharge unit, size of grounding conductors, location of
antenna-discharge unit, connection to grounding electrodes, and requirements
for the grounding electrode. See Figure 1.
16. Lightning – For added protection for this product during a lightning storm, or when
it is left unattended and unused for long periods of time, unplug it from the wall
outlet and disconnect the antenna or cable system. This will prevent damage to
the product due to lightning and power-line surges.
22. Replacement Parts - When replacement parts are required, be sure the
service technician has used replacement parts specified by the manufacturer
or have the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other hazards.
FIGURE 1
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
GROUND
CLAMP
NEC - NATIONAL ELECTRICAL CODE
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
ELECTRIC
SERVICE
EQUIPMENT
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)

4
WARRANTY
For warranty information, contact your local Marantz dis-
tributor.
RETAIN YOUR PURCHASE RECEIPT
Your purchase receipt is your permanent record of a valua-
ble purchase. It should be kept in a safe place to be referred
to as necessary for insurance purposes of when corre-
sponding with Marantz.
IMPORTANT
When seeking warranty service, it is the responsibility of the
consumer to establish proof and date of purchase. Your pur-
chase receipt or invoice is adequate for such proof.
FOR U.K. ONLY
This undertaking is in addition to a consumer’s statutory
rights and does not affect those rights in any way.
CE marking (for Europe only)
This product is in conformity with the
EMC directive and low-voltage directive.
Disc Storage
Be careful not to harm the disc because the data on these
discs is highly vulnerable to the environment.
• Do not keep under direct sunlight.
• Keep in a cool ventilated area.
• Store vertically.
• Keep in a clean protection jacket.
Maintenance of Cabinet
For safety reasons, be sure to disconnect the AC power cord
from the AC outlet.
• Do not use benzene, thinner, or other solvents for clean-
ing.
• Wipe the cabinet with a soft cloth.
WARNINGS
-Do not expose the equipment to rain or mois-
ture.
- Do not remove the cover from the equipment.
-Do not insert anything into the equipment
through the ventilation holes.
- Do not handle the mains lead with wet hands.
-Do not cover the ventilation with any items
such as tablecloths, newspapers, curtains, etc.
-No naked flame sources, such as lighted can-
dles, should be placed on the equipment.
-When disposing of used batteries, please
comply with governmental regulations or envi-
ronmental public instruction’s rules that apply
in your country or area.
FCC NOTE (for U. S. A only):
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC rules. These limits are designed to provide reason-
able protection against harmful interference in a residential
installation. This equipment generates, uses and can radi-
ate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures.
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and re-
ceiver.
• Connect this equipment into an outlet on a circuit differ-
ent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
NOTE: Changes or modifications may cause
this unit to fail to comply with Part 15 of the
FCC Rules and may void the user’s authority to
operate the equipment.
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la Classe B est
conforme á la norme NMB-003 du Canada.
This product satisfies FCC regulations when shielded cables
and connectors are used to connect the unit to other equip-
ment. To prevent electromagnetic interference with electric
appliances, such as radios and televisions, use shielded
cables and connectors for connections.
A NOTE ABOUT RECYCLING
This product’s packaging materials are
recyclable and can be reused. This product
and the accessories packed together are the
applicable product to the WEEE directive except
batteries.
Please dispose of any materials in accordance
with your local recycling regulations.
When discarding the unit, comply with your local
rules or regulations.
Batteries should never be thrown away or
incinerated but disposed of in accordance with
your local regulations concerning chemical
wastes.
-Do not place anything about 0.1 meter above
the top panel.
-Make a space of about 0.1 meter around the
unit.
-No objects filled with liquids, such as vases,
shall be placed on the apparatus.
-When the switch is in the OFF position, the
equipment is not completely switched off from
MAINS.
-The equipment shall be installed near the
power supply so that the power supply is
easily accessible.

5
English
Table Of Contents
1 Before You Start
Features.......................................................................................6
What’s in the box......................................................................7
Putting the batteries in the remote control........................7
Using the remote control .......................................................7
Discs compatible with this player .........................................8
DVD-Video regions...................................................................9
General information .................................................................9
MP3 compatibility information .............................................9
WMA compatibility information............................................9
JPEG compatibility information .............................................9
DivX compatibility information .............................................9
2 Connecting Up
Easy setup................................................................................10
Home theater video connections .......................................11
Home theater audio connections.......................................12
3 Controls & Displays
Front panel...............................................................................13
Remote control .......................................................................14
4 Getting Started
Playing discs ............................................................................15
Basic playback controls.........................................................15
Resuming playback from the last stopped point.............15
Navigating DVD disc menus.................................................16
Navigating Video CD PBC menus .......................................16
5 Playing Discs
Introduction.............................................................................17
Preview function......................................................................17
Fast Forward/Fast Reversed..................................................19
Still Frame/Slow Play/Frame Advance Playback.............. 20
Using the page........................................................................21
Using the Repeat Play ...........................................................21
Looping a section of a disc ................................................. 22
Using the Random (SHUFFLE) Play................................... 22
Switching Camera Angles..................................................... 23
Switching the Subtitle Language ....................................... 23
Switching the Audio Language ......................................... 24
Switching the audio channel............................................... 24
Switching Super Audio CD Playback layer....................... 24
Switching Super Audio CD Playback area........................ 24
Using the Zoom Function.................................................... 24
Play back Information........................................................... 25
Playing an MP3/DivX/JPEG/Windows Media™
Audio disc ............................................................................... 28
Playing a JPEG image file (slide show) .............................. 29
Playing MP3/WMA music and JPEG pictures
simultaneously........................................................................ 30
Playing a DivX disc.................................................................31
Using the Setup Menu ......................................................... 32
6 DVD Setup Menu
Setting up the GENERAL SETUP page.............................. 34
Setting up the AUDIO SETUP page .................................. 37
Setting up the VIDEO SETUP page................................... 42
Setting up the PREFERENCE page..................................... 47
7 Additional Information
Language Codes .....................................................................51
Handling discs ........................................................................ 52
Storing discs ........................................................................... 52
Discs to avoid......................................................................... 52
Cleaning the pickup lens...................................................... 52
Problems with condensation............................................... 52
Hints on installation.............................................................. 53
Moving the player.................................................................. 53
Precautions on using the power cord ............................... 53
Troubleshooting..................................................................... 54
Specifications ......................................................................... 57

Before You Start1
6
Features
An HDCP-compatible HDMI*
1
terminal is provided for fully digital
transmission that ensures the very
highest picture and digital sound
quality.
This unit comes with a High-Definition
Multimedia Interface (HDMI) jack; an
extended DVI interface for next-generation
televisions. This interface allows transfers
of uncompressed digital video and digital
audio (audio streams such as Dolby Digital
and DTS as well as linear PCM) with a
single connector. HDMI standard Ver. 1.1
compatibility means the unit can also
transfer DVD-Audio multi-channel audio
over HDMI.
End-to-end full-digital transfers with all
digital processing allow the enjoyment
of realistic video without any image
degradation caused by AD/DA conversions.
And the unit can up-convert 480p video
signals to 720p, 1080i, and 1080p video
output signals using the scaling function
and the HDMI jack (see pages 11, 45).
High quality 12-bit/216 MHz Video
D/A converter*
2
The unit uses a Video D/A converter that
performs D/A conversion of all video
signals in 12-bits and can perform 8x over-
sampling to let you enjoy beautiful video
possible with DVD. Furthermore, NSV
technology suppresses noise during DA
conversion.
DCDi *
3
DCDi (Directional Correction
Deinterlacing) computes and tracks the
angle of the screen edge to fill in the
missing pixels on the TV screen. DCDi
significantly optimizes the image quality,
especially during slow motion playback.
This function is available only for
progressive scan output.
High quality 24-bit/192 kHz DAC
The high specification 24-bit/192 kHz DAC
delivers dynamic, smooth and expansive
analog sound from CDs and DVDs.
Superlative audio performance with
Super Audio CD, DVD-Audio, Dolby*
4
Digital and DTS*
5
software
Logos:
The DV6001 delivers breathtaking sound
quality with Super Audio CD, DVD-Audio,
Dolby Digital and DTS discs.
DivX *
6
You can enjoy DivX®files which are
recorded on DVD±R/RW or CD-R/RW.
Plays DivX5.2, DivX4, DivX3 and DivX
VOD Video content (see pages 28, 31).
• This player supports Quarter Pixel.
• This player supports GMC.
MP3 and WMA*
7
compatibility
This player is compatible with CD-R, CD-
RW and CD-ROM discs that contain MP3
and WMA audio tracks (see pages 28, 30).
JPEG compatibility
This player is compatible with CD-R, CD-
RW and CD-ROM discs that contain JPEG
data (see pages 28, 29, 30).
*1HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.
*2“NSV” is a registered trademark of Analog Device
Co. Ltd.
*3“DCDi” is a registered trademark of Faroudja, a
division of Genesis Microchip, Inc.
*4 Manufactured under license from Dolby
Laboratories. “Dolby” “Pro Logic” and the
double-D symbol are trademarks of Dolby
Laboratories.
*5 “DTS” and “DTS Digital Surround” are registered
trademarks of DTS, Inc.
*6“DivX”, and “DivX Ultra” Certified, and associated
logos are trademarks of DivX, Inc. and are used
under license.
*7Windows Media and the Windows logo are
trademarks, or registered trademarks of Microsoft
Corporation in the United States and/or other
countries.

1Before You Start
7
English
What’s in the box
Thank you for buying this MARANTZ
product. Please confirm that the following
accessories are in the box when you open
it.
• Remote control
• AAA/R03 dry cell batteries x2
• Audio/Video cable (yellow/red/white)
• System control cable
• Power cable
• User Guide (this manual)
• Warranty card
Putting the batteries in the remote
control
1 Open the battery
compartment cover on
the back of the remote
control.
2 Insert two AAA/R03
batteries into the battery
compartment following
the indications (ª, ·)
inside the compartment.
3 Close the cover.
Note
Incorrect use of batteries can result in hazards such
as leakage and bursting. Please observe the following:
• Don’t mix new and old batteries together.
• Don’t use different kinds of battery together.
Although they may look similar, different batteries
may have different voltages.
• Make sure that the plus and minus ends of each
battery match the indications in the battery
compartment.
• Remove batteries from equipment that isn’t going
to be used for a month or more.
When disposing of used batteries, please comply
with governmental regulations or environmental
bylaws that apply in your country or area.
Using the remote control
Keep in mind the following when using the
remote control:
• Make sure that there are no obstacles between
the remote control and the remote sensor on the
unit.
• Use within the operating range and angle, as
shown.
• Remote operation may become unreliable if
strong sunlight or fluorescent light is shining on
the unit’s remote sensor.
• Remote controllers for different devices can
interfere with each other. Avoid using remotes for
other equipment located close to this unit.
• Replace the batteries when you notice a fall off in
the operating range of the remote control.
Note
• When using this player independently, set the
REMOTE CONTROL switch on the rear panel to
INT. (INTERNAL) (see page 10).
30 30
5m (16 feet)

Before You Start1
8
Discs compatible with this player
Any disc that displays one of the following
logos should play in this player. Other
formats, including DVD-RAM, DVD-ROM,
CD-ROM (except those that contain MP3/
DivX/WMA/JPEG files) and Photo CD will
not play.
DVD-Video compatibility:
• Logos:
• Single-sided or double-sided discs
• Single layer or dual layer discs
• Dolby Digital, DTS, MPEG or Linear PCM digital
audio
• MPEG-2 digital video
Discs are generally divided into one or more titles.
Titles may be further subdivided into chapters.
DVD-Audio compatibility:
• Logos:
• Single sided discs
• Single layer or dual layer discs
• Linear or packed PCM digital audio
• Some discs may contain MPEG-2 video, and
Dolby Digital, DTS or MPEG digital audio
Discs are generally divided into one or more groups.
Groups may be further subdivided into tracks.
DVD-R compatibility:
This unit can play DVD-R discs. Please note the
following points when using these discs:
• Logo:
• This unit can play DVD-R discs recorded as DVD-
Video format.
DVD-RW compatibility:
This unit can play DVD-RW discs. Please note the
following points when using these discs:
• Logo:
• This unit can play DVD-RW discs recorded as
DVD-Video format, and DVD-VR format.
• DVD-RW discs that were recorded with copy-
once only permission can be played.
DVD+R/+RW compatibility:
• Logo:
• This unit can play DVD+R/+RW discs. Please
note the followings points when using these
discs.
Super Audio CD compatibility:
• Logo:
• Single layer, dual layer or Hybrid layer
• 12cm (5in.) or 8cm (3in.) discs
• Digital audio (DSD)
Super Audio CDs are divided into tracks.
Audio CD compatibility:
• Logos:
• 12cm (5in.) or 8cm (3in.) discs
• Linear PCM digital audio
• Audio CD, CD-R* and CD-RW* formats
CDs are divided into tracks.
*This unit can play CD-R and CD-RW discs recorded
in Audio CD or Video CD format, or with MP3 audio
files or Windows Media audio files or picture files or
DivX files.
*Some copy-controlled CDs may not conform to
official CD standards. They are special discs and may
not play on the DV6001.
*The DV6001 does not support the non-DVD side
of a Dual Disc.
Video CD compatibility:
• Logo:
• 12cm (5in.) or 8cm (3in.) discs
• MPEG-1 digital audio
• MPEG-1 digital video
Video CDs are divided into tracks.
Super VCD compatibility:
• Logo:
• 12cm (5in.) or 8cm (3in.) discs
• MPEG-1 digital audio
• MPEG-2 digital video
Super VCDs are divided into tracks.

1Before You Start
9
English
DVD-Video regions
All DVD-Video discs carry a region mark
on the case somewhere that indicates
which region(s) of the world the disc is
compatible with. Your DVD player also has
a region mark, which you can find on the
rear panel. Discs from incompatible regions
will not play in this player. Discs marked
ALL will play in any player.
General information
• This player can recognize in total about 650 files
per folders and 300 folder per disc for MP3/
DivX/WMA.
• When writing MP3/WMA/JPEG/DivX files to CD-
R/RW discs, always be sure to set the writing
format to ISO 9660 Level 1.
• For MP3 and WMA files recorded in Variable Bit
Rate (VBR), the unit may not display the actual
elapsed time.
MP3 compatibility information
• Files should be MPEG1 Audio Layer 3 format.
The sampling rate is 8 kHz to 48 kHz, but it is
depends on the bit rate. Incompatible files will
not play.
• Audio encoded at 128 kbps should sound close
to regular audio CD quality. Although this player
will play 32 kbps to 320 kbps, but it is depends
on the sampling rate.
• This player is compatible with ID3 ver.1.1 Tag.
But the information display on the display on the
Front panel and TV screen is only ID3 ver. 1.0
Tag.
• Maximum 30 characters can be displayed on the
display on the Front panel and TV screen.
• This player cannot play DVD-R/RW discs with
recorded MP3 music data.
• This player only plays tracks that are named
containing the file extension “.mp3” or “.MP3”.
• This player is not compatible with multi-session
discs. If you try and play a multi-session disc,
only the first session will be played.
WMA compatibility information
• The sampling rate is 44.1 kHz (bit rate: 64
kbps-192 kbps) and 48 kHz (bit rate: 128
kbps-192 kbps).
• This player only plays tracks that are named with
the file extension “.wma” or “.WMA”.
• This player can not play the disc contents
protected by Windows Media Digital Right
Management (DRM).
JPEG compatibility information
• While this player is designed to be able to
handle image data recorded in JPEG format,
no assurances are given that the player will be
able to display image data recorded in all JPEG
formats.
• This player can not display progressive JPEG
images.
• This player can not display HD JPEG images.
• Always be sure to specify a file extension of “.JPG”
or “JPEG” for JPEG files. The file will not be able
to be displayed if a file extension other than “.JPG”
or “JPEG” is specified or if no file extension is
assigned to the file. (Note that this means that
JPEG files created on a Macintosh will not be able
to be displayed as is.)
• Depending on the file size and compression
ratio, some JPEG pictures cannot be displayed
correctly.
DivX compatibility information
• A file with an extension of “.avi” or “.divx” is called
a DivX file.
• Maximum 30 characters can be displayed on the
display on the Front panel and TV screen.
• Maximum 4 Gbyte of file size can be displayed.
• File should be MPEG1 Audio Layer 3 format and
MPEG2 format.
Caution!
• DVD±R/RW and CD-R/RW discs recorded using
a personal computer or a DVD or CD recorder
may not play if the disc is damaged or dirty, or if
there is dirt or condensation on the player’s lens.
• If you record a disc using a personal computer,
even if it is recorded in a compatible format,
there are cases in which it may not play because
of the settings of the application software used
to create the disc. (Check with the software
publisher for more detailed information.)
• There may be times when it is impossible
to replay a CD-R/RW disc because of the
characteristics of the disc being used or because
of dirt or scratches on the disc.
• Unfinalized DVD-R/RW discs cannot be played.
• Unfinalized CD-R/RW discs cannot be played.
• For more information on using DVD-R/RW and
CD-R/RW discs, see “Handling discs” on page
52.
• Never try to replay anything other than a music
CD (CDA format) or a CD-R/RW on which MP3
and/or JPEG files have been stored. Depending
on the type of file, there may be times when
doing so will result in problems or erroneous
operation.

Connecting Up2
10
Connecting audio/video cables
Be sure to insert each
plug fully for the best
connection. The plugs
and jacks are color-coded
to make connection
easier.
Connecting system control cables
By connecting this DVD player to another
Marantz audio component using a supplied
system control cable, you can remotely
operate the components as a single system.
• When connecting to a component with a
remote sensor, be sure to connect the REMOTE
CONTROL IN jack of this DVD player to
the REMOTE CONTROL OUT jack of the
component with the remote sensor.
• When connecting to component which is
not equipped with a remote sensor, be sure
to connect the component to the REMOTE
CONTROL OUT jack of this DVD player.
Easy setup
This easy setup is the minimum set of
connections you need to start watching
DVD-Video discs. Both sound and picture
are fed directly to your TV using the
supplied audio/video cables. For other
possible connections, see pages 11 and 12 .
Important
• Before making or changing any rear panel
connections, make sure that all components are
switched off and unplugged from the wall outlet.
• While a connected component is turned on,
do not unplug the power cord of this DVD
player from the wall outlet. The speaker may be
damaged.
Note
• When connecting to a standard TV, select
4:3 LETTER BOX or 4:3 PAN SCAN in the TV
Aspect setting (see page 43).
• Connect the video output of the player directly
to your TV. Because the player is designed to
support an Analog Protection System copy card,
there are cases when proper playback will be
not be possible if the player is connected to the
TV through a VCR and images are recorded and
played on the VCR.
• The player’s video output and S1 output are not
be progressive.
• Remote switch
When using this DVD player independently, set
this switch to INT. (INTERNAL). When using this
DVD player in a system with a Marantz receiver
equipped with a remote sensor, set the switch to
EXT. (EXTERNAL).
• Flasher Input
This is used when controlling components
from different rooms with a keypad or other
input device. Set the remote switch to EXT.
(EXTERNAL) when using a flasher input.
AC IN
C
VIDEO
S1
RS-232C
IN
OUT
C
Y
R
B
A/V EUROCONNECTOR
REMOTE CONTROL
L
COAX. SUB W. OPT. SURR.
R
FRONT MIXED 2CH
CENTER
R
LL
R
Ver1.1 HDMI
INT. EXT.
FLASHER
IN
AUDIO OUT
COMPONENT
21
3
EXT. INT.
Connect to a composite video
input on your TV using the
supplied Audio/Video cable.
Plug into a standard
AC wall outlet.
Connect to a pair of stereo
audio inputs on your TV using
the supplied Audio/Video cable.
You can connect a subwoofer
to the SUBWOOFER Jack.
RS-232C terminal/
FLASHER IN
Control terminal for use by
custom installers.
See Note:
Remote Switch

2Connecting Up
11
English
AC IN
C
VIDEO
S1
RS-232C
IN
OUT
C
Y
R
B
A/V EUROCONNECTOR
REMOTE CONTROL
L
COAX. SUB W. OPT. SURR.
R
FRONT MIXED 2CH
CENTER
R
LL
R
Ver1.1 HDMI
INT. EXT.
FLASHER
IN
AUDIO OUT
COMPONENT
1
4
32
Home theater video connections
This player outputs video in a number
of different ways. Choose the one most
suitable for your system using the guide
below.
Connecting SCART (for Europe only)
and S-Video cables
SCART and S-Video cables will only plug in
one way, so make sure the plug is correctly
lined up with the jack before inserting. Be
sure to fully insert for a good connection.
Note
• The A/V EURO CONNECTOR can output
composite or RGB component video. If you
connect just one TV, use the A/V EURO
CONNECTOR. You can select the type of video
output by changing the COMPONENT setting in
the DVD Setup Menu (page 46).
S-Video or composite video?
S-Video should give a better picture, so if
you have an S-Video input, use it. S-Video
cables are available from any good audio/
visual dealer.
Connecting HDMI cables
With an HDMI cable, both uncompressed
video data and digital audio data (e.g.,
LPCM or bit stream data such as Dolby
Digital, DTS, MPEG data or DVD Audio
Multi channel) can be transmitted with just
a single connector.
By transmitting DVD image data directly as
digital data without it being first converted
into analog format, it becomes possible to
provide the very finest in image quality (see
pages 6, 39, 40, 45).
Note
• The HDMI output of this unit can be connected
to a DVI jack on a TV or other device using a
conversion adapter. In this case, it is necessary
to use a TV or display with an HDCP-compatible
DVI input.
• There may be no image output if connected to
a TV or display that is not compatible with the
above format.
• Refer to the instruction manual of the TV or
display to be connected to this unit for detailed
information regarding the HDMI terminal.
• When connecting a progressive input TV with the
component output of the player, select ON in
the Progressive setting (see page 43).
If your TV has a component video input, we
recommend using it to connect directly to the
COMPONENT VIDEO OUT of this player. Use
the standard 3-jack component video output.
If a component input is not
available to you, connect this
player to your TV or AV receiver
using either the VIDEO or S1
jacks.
Plug into a standard
AC wall outlet.
If your TV and projector have
a HDMI terminal for Video and
Audio Input, we recommend
using it to connect directly to
the HDMI out of this player.
If your TV has a SCART input, we
recommend using it to connect directly
to the A/V EURO CONNECTOR on
this player. (for Europe only)
Important
• Before making or changing any rear panel
connections, make sure that all components are
switched off and unplugged from the wall outlet.
• While a connected component is turned on,
do not unplug the power cord of this DVD
player from the wall outlet. The speaker may be
damaged.

Connecting Up2
12
AC IN
C
VIDEO
S1
RS-232C
IN
OUT
C
Y
R
B
A/V EUROCONNECTOR
REMOTE CONTROL
L
COAX. SUB W. OPT. SURR.
R
FRONT MIXED 2CH
CENTER
R
LL
R
Ver1.1 HDMI
INT. EXT.
FLASHER
IN
AUDIO OUT
COMPONENT
2
4
3
1
COAX
Connecting analog audio cables
Be sure to fully insert each plug for the
best connection. The plugs and jacks are
color-coded to make connection easier.
Connecting coaxial cables
Use an interconnector with a pin-type
(also called RCA
or phono) plug on
each end to connect
up digital coaxial-
type jacks. Make
sure that the plug is
pushed fully home.
Connecting optical cables
Optical intercon-
nects only plug in
one way, so make
sure the plug is
correctly lined up
with the jack before
insertion. When
inserting the plug,
Home theater audio connections
This player outputs multi-channel audio
in digital form. Check the manual for your
amplifier/receiver to see what equipment it
is compatible with (especially which digital
formats such as Dolby Digital, DTS, etc. It
can decode).
Important
• Before making or changing any rear panel
connections, make sure that all components are
switched off and unplugged from the wall outlet.
• While a connected component is turned on,
do not unplug the power cord of this DVD
player from the wall outlet. The speaker may be
damaged.
If your amplifier has stereo inputs
only, connect them here. You
can connect a subwoofer to the
SUBWOOFER Jack.
Connect to the coaxial or
optical input of your amplifier
if it has digital inputs.
Plug into a standard
AC wall outlet.
the protective shutter will open and you
should hear it click into position when fully
inserted. Be careful that you do not force
the plug, because this could result in dam-
age to the protective shutter, the cable, or
the unit itself.
Note
• If you listen to multichannel DVD-Audio through
one of the digital outputs, it will be downmixed
to stereo. Also, high sampling rate DVD-Audio
(192 kHz or 176.4 kHz) will be downsampled
to 96 kHz, 88.2 kHz, 48 kHz or 44.1 kHz,
depending on the disc. Multi channel and high
sampling rate DVD-Audio are only available
through the analog outputs.
• All DVD-Audio and all Super Audio CD audio are
output only through the analog outputs. (see
page 38)
OPT
If your amplifier has 5.1 channel analog
inputs, connect them here. Connect to the
L (left)/R (right), SURR.L/.R (SURROUND
L/R), CENTER and SUB WOOFER inputs
of your amplifier.

3Controls & Displays
13
English
Front panel
1 STANDBY indicator
• Lights when the unit is in standby.
2 Disc tray
• Place the disc here.
3 SA-CD indicator
• Lights when the player detects a Super Audio CD
signal.
4 DVD-AUDIO indicator
• Lights when the player detects a DVD-AUDIO
signal.
5 MULTI-CH indicator
• Lights when playing a multi-channel audio source.
6 AUDIO EX
• Lights when the AUDIO EX is activated using the
AUDIO EX button on the remote control.
• The sound quality of analog audio output is
improved by turning off analog video signal
output and the front panel display.
• It is applied to CDDA, Super Audio CD, DVD
Audio and DTS CD in Play mode.
7 HDMI – page 45
• The HDMI on/off state toggles when pressed
for three seconds or more. When on, the HDMI
indicator is lit.
• Pressing this button while HDMI is enabled
displays the current resolution. Pressing this
button again while the resolution is displayed
allows you to select the resolution in the
sequence below:
480p Æ576p Æ720p Æ1080i Æ1080p Æ
480p
8 HDMI indicator
• When the connected device is HDMI/DVI
compatible, the light flashes red.
9 3(PLAY)
• Begins playing the disc play.
10 7(STOP)
• Stops playing the disc play.
11 8(PAUSE)
• Pauses playing the disc play.
12 POWER ON/STANDBY
• Press to turn the power on, and press it again to
enter STANDBY mode.
13 Display
• Operation indications are displayed here.
14 0(OPEN/CLOSE)
• Press to open and close the disc tray.
15 4/1
• Press to skip reverse title/group, chapter, or track.
You can also press and hold this button for Fast
Reversed.
16 ¡/¢
• Press to skip forward title/group, chapter, or
track. You can also press and hold this button for
Fast Forward.
STANDBY
POWER
PAUSE PLAY
OPEN/CLOSE
STOP
ON/STANDBY
HDMI
SUPER AUDIO CD/DVD PLAYER DV6001
DVD-
AUDIO
SA-CD MULTI
CH
AUDIO
EX.
6
45
2
18
39
70
=~!@
#
-

Controls & Displays3
14
Remote control
1 AUDIO EX – Press to turn AUDIO EX off
and on
• The sound quality of analog audio output is
improved by turning off analog video signal
output and the front panel display.
• HDMI video output cannot be switched off.
2 OPEN/CLOSE – Disc tray open/close –
page 15
3 ZOOM – pages 24, 29
4 HDMI – page 45
• The HDMI on/off state toggles when pressed
for three seconds or more. When on, the HDMI
indicator is lit.
• Pressing this button while HDMI is enabled
displays the current resolution. Pressing this
button again while the resolution is displayed
allows you to select the resolution in the
sequence below:
480p Æ576p Æ720p Æ1080i Æ1080 p Æ
480p
1
2
3
4
5
6
7
8
~
-
=
0
9
_
#
$
%
^
&
*
(
)
@
!
™
¡
+
5 REPEAT – pages 21, 28
A–B – page 22
6 ANGLE – pages 23, 29
7 INPUT (%/fi) button – These buttons
can switch between devices compatible with
MARANTZ receivers. Refer to the receiver
instruction manual for further details.
• Applicable models: PM-11S1, PM-15S1,
PM6001, PM7001, PM8001, SR9600.
(These models may not be handled depending on
the area.)
Non-applicable models: MARANTZ Amplifiers
and receivers which had released before 2006,
including PM-14, PM-17 and PM4001 except
above models.
8 4(PREV.)/¢(NEXT)– Skip – pages
15, 16, 18, 19, 28, 29, 49
• Allows you to search forward/backward through a
disc. Use to skip the title, chapter or track.
• Press and hold (4) for Fast Reversed.
• Press and hold (¢) for Fast Forward.
9 SCAN – pages 17, 18
10 TOP MENU (TOP-M)/RETURN – page 16
11 Cursor (2/3/5/∞) / ENTER button
12 DISPLAY (DISP.) – page 25
13 DISC SKIP – It is not used on this set.
14 POWER – Switches the player on or into
standby – page 15
15 SOUND MODE– Selects Audio out mode
and change the Super Audio CD Play back
area – pages 24, 37
16 PA G E – Turns the pages of DVD-Audio still
pictures – page 21
17 RANDOM – page 22
18 A U D I O – Changes the Hybrid Super Audio
CD Play back layer – page 24
19 SUBTITLE – pages 23, 31
20 VOLUME (5/∞) button – These buttons
can adjust the volume of devices compatible
with MARANTZ receivers. Refer to the
receiver instruction manual for further details.
21 MUTE button – This button can activate
the mute function of devices compatible with
MARANTZ receivers. Refer to the receiver
instructions for further details.
22 3(PLAY) – pages 15, 19, 20, 28, 30, 31
23 8(PAUSE) – pages 15, 20
24 7(STOP) – pages 15, 29, 30, 32, 47
25 MENU – pages 16, 18, 23
26 SETUP – pages 32, 34, 37, 42, 47
27 Number buttons
Note
• HDMI ON is set when the unit is shipped from
the factory.
• Set HDMI under the DVD Setup Menu to use
HDMI functions (see pages 39, 40, 45).

4
Getting Started
15
English
Playing discs
The basic playback controls for playing
discs are covered here. Further functions
are detailed in the next chapter.
Note
• Throughout this manual, the term “DVD” means
DVD-Video, and DVD±R/RW. If a function is specific
to a particular kind of DVD disc, it is specified.
1 Press the POWER ON/STANDBY button
on the front panel or POWER button on
the remote control.
If you are playing a DVD or Video CD, also turn on
your TV and make sure that it is set to the correct
video input.
2 Press OPEN/CLOSE to open the disc tray.
3 Load a disc.
Load a disc with the label side facing up, using the
disc tray guide to align the disc (if you’re loading
a double-sided DVD disc, load it with the side you
want to play face down).
4 Press 3(PLAY) to start playback.
If you are playing a DVD or Video CD, a menu may
appear (see page 16).
Note
• For one-sided, two-layer discs containing movies, etc.,
there may be a short image stoppage at the point
where the layers change. This is not a malfunction.
• Depending on the DVD or VIDEO CD, some
operations may be different or restricted.
Basic playback controls
Button What it does
3Starts playback.
In title menu, it functions as the Enter
key.
8
Pauses a disc that’s playing.
Each time the button is pressed, a new
frame will appear.
7Stops playback.
4• Skips to the start of the current track or
chapter, then to previous tracks/chapters.
• Press and hold for Fast Reversed.
¢• Skips to the next track or chapter.
• Press and hold for Fast Forward.
Numbers Playback starts from the selected track/
chapter number.
ENTER Select the current menu option.
Resuming playback from the last
stopped point
This DVD system is able to resume disc
playback from its last stopped point (only
possible for the last 10 discs that were
recorded without a menu).
1 Load one of the last 10 discs played.
2 While “LOADING” appears on the display
panel, press PLAY 3to start playback from
the last stop point.
To cancel the resume mode
• Press
7
twice.
Important
While using the DVD playback controls, you may see
the mark displayed on-screen. The mark means
that the operation is not allowed by the player and
disc.

Getting Started4
16
Navigating DVD disc menus
Many DVD discs contain menus. Sometimes
these are displayed automatically when you
start playback; others only appear when you
press MENU or TOP-M.
Note
• Some DVD-Audio discs feature a “Bonus Group”. To
access this group you have to input a password that
you can find on the disc’s packaging (see page 34).
Button What it does
TOP-M Displays the “top menu” of a DVD disc. This
varies with the disc.
MENU Displays a DVD disc menu—this varies with
the disc and may be the same as the “top
menu”.
RETURN Returns to the previously displayed menu
screen.
Cursor Moves the cursor around the screen.
(2/3/5/∞)
ENTER Selects the current menu option.
Numbers Selects a numbered menu option
(some discs only).
Navigating Video CD PBC menus
Some Video CDs have menus from which you
can choose what you want to watch. These
are called PBC (Playback control) menus.
Press the MENU to turn the PBC function on
or off.
Note
• Some discs don’t allow PBC menus.
Button What it does
RETURN Displays the PBC menu.
Numbers Selects a numbered menu option.
ENTER Selects the current menu option.
4Displays the previous menu page
(if there is one).
¢Displays the next menu page
(if there is one).

5
Playing Discs
17
English
Introduction
• Many of the functions covered in this
chapter apply to DVD discs, Video CDs
and CDs, although the exact operation
of some varies slightly with the kind of
disc loaded.
• When playing DVD discs, if the icon
appears on-screen when you try to use
a particular function, either the player
or the disc doesn’t allow the use of that
function.
• When playing Video CDs, some of the
functions are not available in PBC mode.
If you want to use them, press the
MENU to turn the PBC function off (see
page 16).
Preview function
Video-CD
SVCD
DVD-Video CD
1 Press SCAN.
SVCD VCD
SELECT DIGEST TYPE
TRACK DIGEST
DISC INTERVAL
TRACK INTERVAL
DVD
SELECT DIGEST TYPE
TITLE DIGEST
TITLE INTERVAL
SELECT DIGEST TYPE
GROUP DIGEST
TRACK DIGEST
GROUP INTERVAL
TRACK INTERVAL
2 Use the 5/∞keys to select one of the
following options and press ENTER.
This option is only available during playback mode.
• TRACK/TITLE/CHAPTER DIGEST – View six
different TRACK/TITLE/CHAPTER on one screen
each time. This allows you to have a quick glance
at all the TRACK/TITLE/CHAPTER on the disc.
• DISC INTERVAL – View the whole disc in six
thumbnail pictures. It divides a disc into six
portions at regular intervals and displays them on
one screen.
• TRACK INTERVAL – View the content of a single
track in six thumbnail pictures. It divides a single
track into six portions at regular intervals and
displays them on one screen.
• TITLE INTERVAL/CHAPTER INTERVAL – View
the content of a single TITLE/single CHAPTER in
six thumbnail pictures. It divides a single TITLE/
CHAPTER into six portions at regular intervals
and displays them on one screen.
• GROUP/TRACK DIGEST – GROUP/TRACK
DIGEST will playback the first 3 to 4 seconds of
every title/chapter available in the disc/current
title.

Playing Discs5
18
• GROUP/TRACK INTERVAL – GROUP/TRACK
INTERVAL will divide the current title disc/chapter
time by 6 and playback the first 3 to 4 seconds of
each of these intervals.
• Use (2/3/5/∞)to select a track or use
the numeric buttons to enter the selected
track number.
• To go to the previous or next page, press
4/¢.
• Press ENTER on the selected thumbnail
picture to start playback from there.
• To return to the main menu, select MENU
on the screen and press ENTER.
3 To exit the preview menu, select EXIT on
the screen and press ENTER.
For CD
• At stop mode, press SCAN on the remote
control. Each track will be played for a few
seconds.
Note
• You can select “Track Interval”only during playback
with PBC off.
• Some discs don’t allow the Scan mode.
