4000 C Series NVR
Installation Guide

About March Networks
March Networks™(TSX:MN; AIM:MNW) is a leading provider of innovative video and
data applications used for security surveillance, monitoring, analysis and business
optimization. The company’s software and IP-based hardware solutions allow businesses
to increase operational efficiencies, address risk, and manage assets with an integrated
set of video-based intelligence tools and business intelligence applications. The ISO
9001:2000 certified company serves the needs of leading financial institutions, retailers,
transportation authorities, commercial/industrial organizations and government/homeland
security agencies in approximately 50 countries throughout the world. For more infor-
mation, please visit www.marchnetworks.com.
Accessing Customer Care
For technical support and assistance, contact us at:
Telephone: [phone]
Toll free: 1-800-472-0116
Fax: [phone]
E-mail: [email protected]
If you purchased this product from a third-party organization, such as a March Networks
certified reseller, please contact the organization’s technical support staff.
Providing Documentation Feedback
At March Networks, our goal is to produce documentation that is technically accurate
and informative. If you have comments or suggestions about our interactive Help and
documentation, you can e-mail us at: [e-mail]

© 2007. March Networks Corporation. All rights reserved. MC-16312 Rev 4.0
Information in this document is subject to change without notice. MARCH NETWORKS and the
MARCH NETWORKS logo are trademarks of March Networks Corporation. Windows® is a registered
trademark of Microsoft Corporation. All other trademarks are the property of their respective owners.
The software described in this document is furnished under a license agreement or nondisclosure
agreement. The software may be used or copied only in accordance with the terms of those agreements.
The contents of this manual and accompanying software are protected by copyright. No part of this
publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, recording, or otherwise without the prior written permission of March Networks
Corporation.

Contents
ii
Mandatory Regulations ....................................................................................................................... iii
Electromagnetic Interference (EMI) Information ................................................................................................ iii
Battery Notices ...................................................................................................................................................... iv
NiCd Battery Pack Notice .................................................................................................................................. iv
Lithium Battery Notice ..................................................................................................................................... iv
Power Cord Notice ................................................................................................................................................ iv
Anti-Static Precautions .......................................................................................................................................... iv
Servicing Notice ...................................................................................................................................................... v
Shipping Notice ...................................................................................................................................................... v
Environmental Directive Compliance .................................................................................................................... v
4000 C Series NVR Overview ................................................................................................................. 1
Key Features ........................................................................................................................................................... 1
Packaging/Shipment Contents .............................................................................................................................. 2
Specifications .......................................................................................................................................................... 3
Dimensions, Weight, Temperature Ranges, and Power Ratings .................................................................... 3
Video Capture Rates .......................................................................................................................................... 4
Front Panel LEDs ..................................................................................................................................................... 5
Keyed Power Switch, Provisioning Port, and USB Port ........................................................................................ 6
Video Inputs, Video Termination Switches, and LEDs ......................................................................................... 7
Power Connector and Fuse Compartment ........................................................................................................... 8
Network Port, USB Port, and Video Output ......................................................................................................... 9
Expansion Port ...................................................................................................................................................... 10
PCI Expansion Slots ............................................................................................................................................... 10
Hard Drives ........................................................................................................................................................... 11
NiCd Battery Pack and Lithium Battery .............................................................................................................. 12

4000 C Series NVR Installation Guide
ii
Unit Setup ............................................................................................................................................ 13
Setting the Station ID ........................................................................................................................................... 13
Mounting the Docking Station ............................................................................................................................ 14
Rack-Mounting ................................................................................................................................................. 14
Wall-Mounting ................................................................................................................................................. 15
Desk-Mounting ................................................................................................................................................. 18
Installing Hard Drives ........................................................................................................................................... 19
Turning the Unit On and Off ............................................................................................................................... 20

iii
Mandatory Regulations
You must be familiar with the following mandatory regulations governing the product’s operations.
You should also adhere to these instructions to ensure the installation meets regulatory compliance.
Electromagnetic Interference (EMI) Information
Canada - Industry Canada This Class A digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations. Cet équipement a été testé et certifié conformément aux
limites imposées par la réglementation en vigueur pour un équipement numérique de classe A.
United States - Federal Communications Commission This equipment has been tested and
found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy, and if not
installed and used in accordance with the installation guide, is liable to cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case users will be required to correct the interference at their own expense.
Europe This equipment complies with the following EU directives: 89/336/EEC and 73/23/EEC. A
Declaration of Conformity is available upon request.

iv
4000 C Series NVR Installation Guide
Battery Notices
NiCd Battery Pack Notice
The unit contains an internal NiCd battery pack that is used during power shortages. The NiCd battery
pack may explode, leak, or get hot, causing personal injury if the following precautions are not
followed:
•Do not remove the NiCd battery pack and use it in a device other than the recorder.
•The unit has a built-in battery charger. Do not attempt to charge the NiCd battery pack using
another battery charger.
•Replace only with an approved NiCd battery pack.
•Do not disassemble the NiCd battery pack.
•Do not open or try to open the individual NiCd battery pack cells.
•Do not dispose of the NiCd battery pack in fire.
•Do not short circuit the NiCd battery pack terminals.
Dispose of the NiCd battery pack in accordance with all applicable federal, state, provincial, and local
regulations. Inquire with your local recycling office for recycling guidelines.
Lithium Battery Notice
The unit contains an internal lithium battery that powers the clock and other system operations. Ensure
you consider the lithium battery when disposing of the unit. Dispose of the lithium battery in
accordance with all applicable federal, state, provincial, and local regulations. Inquire with your
recycling office for recycling guidelines.
Power Cord Notice
An AC power cord is provided with a grounded attachment plug. To avoid electrical shock, always use
the AC power cord and plug with a properly grounded outlet.
To maintain safety compliance, ensure the AC power cord has the appropriate safety approvals for the
country in which the equipment is to be installed.
Anti-Static Precautions
Ensure proper use of an anti-static guard during installation to avoid damage to the unit from
electrostatic discharge.
WARNING!
•Before you access any components located inside the unit, turn the key counter-clockwise, to
the OFF position. After the health and status LEDs turn off, remove the power cord from the
unit to prevent injury.

Mandatory Regulations
v
Servicing Notice
The procedures contained in this publication outline how to install or service components located
inside the unit, requiring the removal of the cover. Installation and maintenance procedures requiring
internal unit access are to be performed by qualified service personnel only.
Shipping Notice
Shipment of the unit and components may expose the unit to temperature extremes. We recommend
you allow the unit to return to room temperature prior to operation.
Environmental Directive Compliance
March Networks is committed to doing our part to protect the environment. As a result, we have
embraced the RoHS and WEEE Directives in the design and manufacture of our products. You can
review further details at the following location on our corporate Web site:
http://www.marchnetworks.com/User_Files/Downloads/Products/RoHS-WEEE_Compliance_Statement_EN.pdf

1Section
1
4000 C Series NVR Overview
The 4000 C Series NVRs are converged video management platforms, providing analog and
high-resolution IP camera support, outstanding video compression and storage,
and R5Visual Intelligence applications for superior surveillance and operational efficiency.
Figure 1: NVR Sliding Out of Docking Station
Key Features
Some of the key features and benefits of the unit include:
•60 to 480 frames per second (FPS) of video capture across 16 BNC inputs, for up to 30 FPS of
high-quality recording per analog input.
•Four additional Internet Protocol (IP) camera inputs, supporting 3.0 MPixel high-resolution
cameras seamlessly.
•16 alarm inputs, plus six two-way audio ports, for enhanced audio/video security coverage.
•Programmable increase of capture rate on alarms for high-quality event records.
•MPEG-4 compression with Adaptive Compression Technology, for the most advanced, efficient
video processing.
•High-capacity internal storage (up to 1.6 TB), with disk mirroring for added reliability and Smart
Archiving for storage optimization.
•External RAID and Network Attached Storage (NAS) options for further archiving.
•Internal back-up battery for power brown-out protection.
•Docking station architecture for easy installation and maintenance.

2
4000 C Series NVR Installation Guide
•Advanced networking features for unlimited scalability and dependable remote access.
•Advanced health management features for centralized support and maximum up-time.
Packaging/Shipment Contents
The following items are included in each system shipment, and should be located/verified before
installation begins:
•NVR and docking station
•Keys for locking the unit in the docking station and activating unit power
•Desk- or wall-mounting kits
•AC power cord
•Hard drive mounting screws
•R5Visual Intelligence CD
•Supporting technical publications
WARNING!
•The procedures contained in this section outline how to install or service components located
inside the unit, requiring the removal of the cover. Installation and maintenance procedures
requiring internal unit access are to be performed by qualified service personnel only.
•When working inside the unit, ensure you take anti-static precautions.
•You cannot service the unit’s internal power supply or any components covered by the metal
plate. If you attempt to service these components, you will invalidate your warranty.

4000 C Series NVR Overview
3
Specifications
Dimensions, Weight, Temperature Ranges, and Power Ratings
Feature Specifications
Weight
With docking station (no hard drives):
21.0 pounds / 9.5 kilograms
Each hard drive:
Approximately 2.0 pounds / 0.9 kilograms
Operating and storage
temperature
Operating temperature:
50 to 104°Fahrenheit / 10 to 40°Celsius
Storage temperature:
-40 to 158°Fahrenheit / -40 to 70°Celsius
Important: The NVR and docking station must be mounted in accordance with
the mounting guidelines in this publication to ensure the unit remains within the
recommended operating temperature range. For more information, see
“Mounting the Docking Station” on page 14.
Power ratings
Power input: 115/230 volts AC input (autosensing)
Current rating: 2.3 A
Frequency range: 47-63 Hz
Power consumption: 70 W (typical)
17.5 inches/44.5 centimeters
19.2 inches/48.8 centimeters
18.4 inches/46.7 centimeters
20.1 inches/51.1 centimeters
18.4 inches/46.7 centimeters
3.5 inches/28.9 centimeters
0.9 inches/2.3 centimeters

4
4000 C Series NVR Installation Guide
Video Capture Rates
The following illustration and table provide details on the video inputs and associated video capture
rates. Details on connecting cameras are provided in “Video Inputs, Video Termination Switches, and
LEDs” on page 7 and “PCI Expansion Slots” on page 10.
Analog video inputs (BNC connectors)
NVR NTSC inputs PAL inputs
4516 C
CIF — 120 FPS across all video inputs in each of
the four camera groups
4CIF — 60 FPS across all video inputs in each of
the four camera group
Total Unit Capture Rate (CIF): 480 FPS
CIF — 100 FPS across all video inputs in each of
the four camera groups
4CIF — 50 FPS across all video inputs in each of
the four camera groups
Total Unit Capture Rate (CIF): 400 FPS
4416 C
CIF — 60 FPS across all video inputs in each of
the four camera groups*
4CIF — 30 FPS across all video inputs in each of
the four camera groups
Total Unit Capture Rate (CIF): 240 FPS
CIF — 50 FPS across all video inputs in each of
the four camera groups
4CIF — 25 FPS across all video inputs in each of
the four camera groups
Total Unit Capture Rate (CIF): 200 FPS
4316 C
CIF — 30 FPS across all video inputs in each of
the four camera groups
4CIF — 15 FPS across all video inputs in each of
the four camera groups
Total Unit Capture Rate (CIF): 120 FPS
CIF — 25 FPS across all video inputs in each of
the four camera groups
4CIF — 12 FPS (nominal) across all video inputs
in each of the four camera groups
Total Unit Capture Rate (CIF): 100 FPS
4216 C
CIF — 15 FPS across all video inputs in each of
the four camera groups
4CIF — 8 FPS (nominal) across all video inputs in
each of the four camera groups
Total Unit Capture Rate (CIF): 60 FPS
CIF — 12 FPS across all video inputs in each of
the four camera groups
4CIF — 6 FPS (nominal) across all video inputs
in each of the four camera groups
Total Unit Capture Rate (CIF): 50 FPS
*For example, two enabled video inputs, each set to 30 FPS.
Or, four enabled video inputs, each set to 15 FPS.
IP camera inputs
• Up to 2 mbps per attached IP camera.** The capture rate is dependent on the resolution and quality of
the images being captured.
** For details about cameras supported by the 4516 C NVR, contact your representative.
Analog Video Inputs
(Divided into Four
Camera Groups)
IP Camera Inputs

4000 C Series NVR Overview
5
Front Panel LEDs
Feature Specifications
Front Panel LEDs
The LEDs indicate the unit’s status, as outlined below:
LEDs marked Unit
Green:
The unit is operating properly.
Yellow:
The unit is powering up, powering down, or operating on internal battery.
Red:
The unit detects a hardware problem.
LEDs marked Operation
Green:
The unit is powered and running (solid); the unit is powering up (flashes).
The unit can only be accessed with the provided software applications when
the green LED is on solid.
Yellow:
A non-critical fault has occurred.*
Red:
A critical error has occurred.*
LED marked Hard Drive
The LED flashes while the unit is accessing the hard drives.
LEDs marked Network
Green:
A link is established with the network point of presence (POP) (solid);
network activity is occurring (flashing).
Yellow (on solid):
A 100 BaseT link is negotiated on the network port.
Yellow (off):
A 10 BaseT link is negotiated on the network port.
*Information about errors can be retrieved using the R5Administrator Console. The LED turns off when the
status is acknowledged or the error has been resolved. For more information, see the
R5Administrator Console User Manual or Help panel.
Front Panel LEDs

6
4000 C Series NVR Installation Guide
Keyed Power Switch, Provisioning Port, and USB Port
Feature Specifications
Keyed power switch
When the unit is powered on, the locking mechanism prevents the unit
from being undocked. Turning the key to the left initiates shut down.
Once the LEDs are off, the unit can be safely removed from the docking
station.
Provisioning port
Connector: Provisioning port on DB-9 connector
Details:
• Provides an RS-232 interface for connection of a provisioning device,
such as a laptop computer or Personal Digital Assistant (PDA).
• Requires a null modem cable, commonly referred to as a file transfer
cable, to connect to a standard laptop computer or PDA.
• Use a terminal emulation program, such as HyperTerminal or VT100,
to log on to the provisioning interface. For more information, see the
Provisioning Interface Technical Instructions.
• The provisioning port uses the following port settings:
o Bits per second: 9600
oData bits: 8
oParity: None
o Stop bits: 1
oFlow control: None
• The pinout for this functionality on the unit’s DB-9 male connector is:
o DB-9 pin 2: RXD (input)
oDB-9 pin 3: TXD (output)
o DB-9 pin 5: GND
Front USB port Connector: Front USB port
Details:
• Provides a USB port for connection of an external peripheral.
• Provides up to 500 mA to power peripherals using a USB cable.
• Supports USB version 1.1.
• An additional USB port is also available at the rear of the unit. For
details, see “Network Port, USB Port, and Video Output” on page 9.
Keyed Power Switch Provisioning
Port
USB Port
23 5

4000 C Series NVR Overview
7
Video Inputs, Video Termination Switches, and LEDs
Feature Specifications
Video inputs
Connector: Video inputs on BNC coaxial connector
Details:
• Video input connections for up to 16 cameras. The video inputs are
divided into four camera groups, each containing four video inputs.
• Supports NTSC (North American) and PAL inputs.
• Additional IP cameras can be connected using the four provided
network ports. For details, see “PCI Expansion Slots” on page 10.
Video termination switches
and LEDs
• When the video termination switch is pressed in, the LED is on and
video termination is set to 75Ω (typical setting).
• When the video termination switch is not pressed in, the LED is off and
video termination is set to Hi-Z (for looping to another device, such as
a monitor).
Video Termination Switch and LED
(One for Each Video Input)
Video Inputs
(Camera Group 1)
Video Inputs
(Camera Group 2)
Video Inputs
(Camera Group 3)
Video Inputs
(Camera Group 4)

8
4000 C Series NVR Installation Guide
Power Connector and Fuse Compartment
Feature Specifications
Power connector
Details:
• Connects the docking station to a power source via a connected
power cord.
• For the unit’s power ratings, see “Specifications” on page 3.
• For information on powering the unit, see “Turning the Unit On and
Off” on page 20.
Fuse compartment
Details:
• Contains two type “T” 5 millimeter x 20 millimeter glass fuses, rated
for 2.5 A and 250 volts AC.
Replacing fuses
• The fuses are located in the fuse compartment at the base of the AC
power cord connector.
• To replace the fuses, power down the unit, remove the AC power
cord from the rear of the docking station, and then remove the fuse
compartment.
• Replace the damaged fuses with two type “T” 5 millimeter x 20
millimeter glass fuses, rated for 2.5 A and 250 volts AC.
WARNING!
Do not attempt to replace the fuses while the unit is powered or while the AC power cord is attached to
the docking station because you may suffer serious personal injury. Please consult an electrician or a
qualified service technician if you are unfamiliar with fuse replacement. For information about powering
down the unit, see “Turning the Unit On and Off” on page 20.
Fuse Compartment Power Connector

4000 C Series NVR Overview
9
Network Port, USB Port, and Video Output
Feature Specifications
Network port and LEDs
Connector: Ethernet port on RJ-45 connector
Details:
• 10/100 BaseT auto-negotiated Ethernet connection on a standard
network pinout.
Green:
• The LED is on solid when a link is established with the network point
of presence (POP) and flashes to indicate network activity.
Yellow (on solid):
• A 100 BaseT link is negotiated on the network port.
Yellow (off):
• A 10 BaseT link is negotiated on the network port.
Rear USB port
Connector: USB port
Details:
• Provides a USB port for connection of an external peripheral.
• Provides up to 500 mA to power peripherals using a USB cable.
• Supports USB version 1.1.
• An additional USB port is also available at the front of the unit. For
details, see “Keyed Power Switch, Provisioning Port, and USB Port” on
page 6.
Video output
Connector: Switched video output on BNC coaxial connector
Details:
• Outputs video to an external monitor.
• You can specify how video is output to an external monitor using the
R5Administrator Console. For example, you can set the unit to cycle
video from multiple cameras or display video when an action you
specify occurs. For more information, see the R5Administrator Console
User Manual or Help panel.
• Supports NTSC/PAL output (matches input format).
Network Port and LEDs
Video Output
USB Port

10
4000 C Series NVR Installation Guide
Expansion Port
PCI Expansion Slots
Feature Specifications
Expansion port
Connector: 15-pin D-sub connector
Details:
• Allows you to connect an optional alarm and switch module.
For more information, see the Installing an Alarm and Switch Module
Technical Instructions accompanying the module.
Expansion Port
Feature Specifications
PCI expansion slots
Details:
• Lets you install up to two PCI cards to support the connection of
optional devices, such as audio devices, dataport accessories, and SCSI
devices for external data storage.
• The unit includes a pre-installed PCI card that provides four ports for
IP cameras. Please note that the ports supporting IP cameras fill one
PCI slot.
• For more information, see the documentation accompanying each
card.
PCI Expansion Slots
