Marco MRCVH064ZD-TE Operating instructions
INSTALLATION INSTRUCTIONS AND RECOMMENDATIONS FOR USING
AND MAINTAINING
CERAMIC HOT PLATES TOUCH CONTROL
MRCVH064ZD-TE
2
1
Presentation
2
Minimum distances
Units in mm
Installation
A B C D
600 510 560 490
3
STANDARD INSTALLATION SYSTEM FAST-CLICK SYSTEM
Minimum distances
Oven
Units in mm
Installation
Oven
EN
4
Safety warnings:
If the ceramic glass
breaks or cracks,
immediately unplug
the hob to avoid
electric shocks.
This appliance is
not designed to work
with an external timer
(not built into the
appliance) or a
separate remote
control system.
Do not steam clean
this device.
The device and its
accessible parts may
heat up during
operation. Avoid
touching the heating
elements. Children
younger than 8 years
old must stay away
from the hob unless
they are permanently
supervised.
This device may
solely be used by
children 8 years old or
older, people with
impaired physical,
sensory or mental
abilities, or those who
are lack of experience
and knowledge, ONLY
when supervised or if
they have been given
adequate instruction
on the use of the
device and
understand the
dangers its use
involves. User
cleaning and
maintenance may not
be done by
unsupervised
children.
Children must not
play with the device.
Precaution. It is
dangerous to cook
with fat or oil without
being present, as
Never try to extinguish
this event disconnect
the device and cover
a plate or a blanket.
Do not put any
object on the cooking
areas of the hob.
Prevent a possible
“If the mains cord
is damaged, should
be replaced by the
manufacturer or its
after sales service”
CAUTION: Use
only cooktop
protectors
appropriately
designed by the
household
manufacturer or the
protectors already
used in this appliance.
The use of
inappropriate
protectors could
cause accidents.
Do not stare at
halogen lamps
directly on hob
Caution: The
cooking process has
to be supervised. A
short term cooking
process has to be
supervised
continuously.
green-yellow
blue
brown
grey
black
green-yellow
blue
brown
grey
black
green-yellow
blue
brown
grey
black
green-yellow
blue
brown
grey
black
green-yellow
blue
brown
grey
black
g. 1
DO NOT USE L3
EN
5
Installation
Emplacement with cutlery drawer
If you wish to mount furniture or a
drawer under the hob, a separation
board must be fitted between the
two. Accidental contact with the hot
surface of the device’s housing is thus
prevented.
the bottom cover of the hob.
Electrical connection
Before you connect the hob to the
mains, check if the voltage and
the hob label, which is placed under
the hob or on the Guarantee card, or if
applicable on the technical data sheet,
which you must keep together with
this manual throughout the product’s
service life.
The electrical connection will be via
an all-pole circuit breaker or plug,
whenever accessible, in accordance
with the current and with a minimum
3 mm distance between contacts. This
ensures disconnection in emergencies
and allows hob cleaning.
Only an official technical service
can handle or repair the appliance,
including replacement of the power
cable.
Ensure that the inlet cable does not
come into contact with the hob housing
or the oven housing, if it is installed in
the same unit.
Warning:
The electrical connection
must be properly grounded,
following current regulations,
otherwise the hob may malfunction.
Unusual high power surges
can damage the control system
(like with any electrical appliance).
Keep the Guarantee
Certificate or the technical data
sheet together with the instructions
manual throughout the product’s
service life. These contain important
technical information.
Use and
Maintenance
User instructions of the
Touch Control
HANDLING ELEMENTS
2 Hot plate selection touch keys.
Power and/or residual heat
displays*.
“Decrease” power touch key.
“Increase” power touch key.
Double burner selection touch key
Locking touch key for the rest of
touch keys.
Hot plate double zone indicatior
(only next to double burner hot
Lock icon*.
Timer touch key.
*Time set hot plate icon.
12 *Timer display
* Only visible while running.
The manoeuvres are done by means
of the touch keys. You do not need
to exert force on the desired touch
key, you only need to touch it with
function.
SWITCHING ON THE DEVICE
time, it will be locked and the related
touch locking touch key
1 Touch the switching on touch key
The Touch Control is activated and a 0
appears with 50% brightness on all
If any zone has residual heat indication
before switch on ,the display continue
s showing ''H'' instead of 0.
If you do not take any action in the next
10 seconds the touch control will
SWITCHING ON A HOT PLATE
Once the Touch Control has been
activated by means of the touch key
1Press the touch key for the selected
and brightness of indicator will
increase.
2Using the touch key or
choose the desired power level.
The and touch keys are
repetitive, so if you keep them pressed
they increase or decrease with a 0.5
second interval.
EN
6
Only one hot plate can be selected at
the same time
Warning:
To operate a hot plate, it must
use a hot plate,check the brightness
of the power indicator.After
choosing hot plate, brightness of
power indicator should increase.
Quick switch-on at maximum
power: Once you have selected the
hot plate, press the touch key
once. The hot plate will be activated at
full power.
SWITCHING OFF THE HOT PLATE
1The hot plate must previously be
selected.
2Using the touch key
the power level to 0.
sensor for 2 seconds, the related zone
and
RESIDUAL HEAT INDICATOR
The power indicator of the hot plate will
display an H when the glass surface
reaches a temperature that could
cause burning.
When this risk disappears,
Warning:
In a first run, H indication may
appear in a short time on the power
display. This showing is related
with setup operation and it does
Warning:
H indication is used for the safety
purposes in any case. Even if the
power on, H indication appears.
SWITCHING OFF THE DEVICE
touch key
H will appear in the zones that are hot.
The rest of the displays will not light up.
Double burner hot plate
If your cooker has this option, the
double burner hot plate offers the
possibility of using the inside ring or
also, in addition, the outside one,
depending on the size of the pot or
pan.
SWITCHING ON THE DOUBLE
HOT PLATE
1The related hot plate must be
selected.
2Select the desired power (from 1
or
3 Press the double hot plate touch
key
burner. When the double zone will
be activated, double zone indicator
SWITCHING OFF THE DOUBLE
HOT PLATE
1The key, by which its double burner
hot plate was switced on previously
is selected.
2Press the double hot plate touch
key to deactivate the double
burner. The double burner indicator
be deactivated
Locking of the touch keys
of the cooking hob
To prevent undesired manipulation
you can lock the entire unit, except
for the on/off touch key, using the
locking touch key
is useful for child safety. When the lock
comes on.
However, remember when the touch
the lock is activated (the lock indicator
On the other hand, if the touch control
To deactivate the locking function,
press the locking touch key
and touch control will be ready for use.
CHILD LOCK
complicated than key lock. User can
activate key lock via one sensor. But
child lock need a sensor sequence.
The Child Lock is being used to
prevent children from turning on
the hob.
Activating Child Lock :
1. The hob is switched on via
2. Any zone should not be selected.
When any zone is not selected,
and minus sensors is hold for 3
seconds at same time. At the end
of this period, a short buzzer sound
is heard
3. After buzzer signal , the
locking touch key is touched (there
is no need to keep press for a long
heard and the Child Lock will be
activated and all power display
shows “L”.
During Child Lock, if user touch any
Warning : Child lock status is not
being stored. If the energy of the hob
is butted, child lock status could not
be preserved.
Deactivating Child Lock :
EN
7
To be able to deactivate Child Lock,
the Child Lock should be activated
before and all power display show “L”
1.
and
key and minus sensors is hold for
3 seconds at same time. At the end
of the this period, a short buzzer
sound is heard,
2. After buzzer signal , is touched to
the
is no need to keep press for a long
heard and the Child Lock will be
de activated and “Indication will
Flash Cooking
(Automatic cook start)
This function facilitates cooking as
you do not need to be present while
it is being done. The touch control
pre-programmes the chosen hot
plate at the maximum power and
subsequently lowers it to the desired
after an approximate amount of time
Table 1
-
0
1
2
3
4
5
6
7
8
0
60
180
288
390
510
150
210
270
9
Selected
power
Automatic Cook Start
Function
SWITCHING THE AUTOMATIC
COOK START FUNCTION ON
1The hot plate must be selected.
2Select power 9 and then press
power touch key
the touch key you must lower the
continuous cooking power to the
When the automatic cook function
desired power level on the display.
SWITCHING THE AUTOMATIC
COOK START FUNCTION OFF
After at least 10 seconds have elapsed
since the beginning of the automatic
cook start function:
1The hot plate must be selected.
2Press touch key
indicator reaches level 9 and the
automatic cook start function will
be deactivated.
Timer Function
This function makes it easier to cook,
as you do not need to be present
throughout the process: the timed hot
after the set time has lapsed. There
is a separate timer for each hot plate,
which allows all of the hot plates to be
timed simultaneously.
With these models you can use the
clock as a timer for the hotplates for
times ranging from 1 to 99 minutes. All
the cooking areas can be programmed
individually and in a simultaneous
manner.
TIMING ONE HOTPLATE
1The cooking zone to be timed must
be selected.
2Select a power level for the hotplate
from 1 to 9 using the touch keys
or
3Press clock touch key
4Immediately afterwards, enter a
cooking time between 1 and 99
minutes,by using the touchkeys or
time automatically. The respective
When the clock reaches 01, it will
switch from counting down minutes
to seconds.
Once the selected cooking time has
elapsed, the heating zone being timed
series of beeps for several seconds.
The timer indicator will display a
has been disconnected.
If you wish to time another hotplate at
the same time, repeat steps 3 and 4.
indicator displays an H or otherwise an
any sensor.
CHANGING THE PROGRAMMED
TIME
To change the progrmmed time, you
must press the touch key of the timed
clock
change the time.
DISCONNECTION OF THE TIMER
If you want to stop the timer before the
programmed time is up
1First select the hotplate and then
press clock touch key
2Use the touch key
recude the time to 00. The clock is
cancelled.
Alternative metod :
After zone selection if timer touch key
is pressed for two seconds, the related
timer will be cancelled.
EN
8
If due to an error one or several hot
will be automatically disconnected after
1
2
3
4
5
6
7
8
9
10
Table 2
5
5
4
3
2
2
2
1
Selected
power
level
MAXIMUM OPERATION
TIME
(in hours)
has been triggered, a 0 is displayed
if the glass surface temperature is not
dangerous for the user or an H if there
is a burn risk.
To reconnect the appliance, switch it
and then switch it on again.
Keep the control panel of the
heating areas clean and dry at all times.
In case of operating problems
or incidents not mentioned in this
manual, disconnect the appliance
and contact the technical service.
Recommendation for the
good use of vitroceramic
hobs
* Use pots or pans with thick,
* Pans with a smaller diameter than
the shown heating area are not
recommended.
* Do not slide pots and pans over the
glass as they may scratch it.
* Although the glass can withstand
knocks from large pots and pans
without sharp edges, try not to
knock it.
* To prevent damage to the ceramic
glass induction surface, try not to
slide the pots and pans over the
glass, and keep the bottoms of the
vessels clean and in good condition.
Try not to spill sugar or
products containing sugar on the
glass while the surface is hot as
these could damage it.
Cleaning and maintenance
To keep the appliance in good
condition, clean it using suitable
products and implements once it has
cooled down. This will make the job
easier and avoid the build-up of dirt
Never use harsh cleaning products or
tools that could scratch the surface, or
steam-operated equipment.
Light dirt not stuck to the surface can
be cleaned using a damp cloth and a
gentle detergent or warm soapy water.
However, for deeper stains or grease
use a special cleaner for ceramic hot
plates and follow the instructions on
to being burned repeatedly can be
removed using a scraper with a blade.
Slight tinges of colour are caused by
pots and pans with dry grease residue
underneath or due to grease between
the glass and the pot during cooking.
These can be removed using a nickel
scourer with water or a special cleaner
for ceramic hot plates. Plastic objects,
sugar or food containing a lot of sugar
that have melted onto the surface
must be removed immediately using
a scraper.
Metallic sheens are caused by
dragging metal pots and pans over
the glass. They can be removed by
cleaning thoroughly using a special
cleaner for ceramic glass hot plates,
although you may need to repeat the
cleaning process several times.
Warning:
Use the glass scraper carefully. The
If you use the scraper
incorrectly, the blade could break
and a fragment could get caught
between the surrounding trim and
the glass. If this happens, do not try
to remove it using your hands,
fig. 3
Only use the blade on the
ceramic surface, avoiding the
scraper casing coming into contact
with the glass because this could
scratch it.
Use blades in perfect
condition. Immediately replace the
blade if it is damaged in any way.
the scraper, withdraw the blade and
fig. 4
Blade protected Blade unprotected
Using the scraper
A pot or pan may become
stuck to the glass due to a product
having melted between them. Do
not try to lift the pot while the hot
glass break.
Do not step on the glass or
lean on it as it could break and
cause injury. Do not use the glass
as a surface for putting objects.
Marco reserves the right to make
changes to its manuals that it deems
the product’s essential features.
Environmental
considerations
The symbol on the product
or its packaging means that this
product cannot be treated like
ordinary household waste.This
product must be taken to a recycling
EN
9
collection point for electrical and
electronic appliances. By ensuring
that this product is disposed of
correctly, you will avoid harming
the environment and public health,
which could happen if this product
is not handled properly. For more
detailed information about recycling
this product, please contact your
local authority, household waste
service or the store where you
purchased the product.
The packaging materials used are
environmentally-friendly and can
be recycled completely. Plastic
components are marked >PE<, LD<,
>EPS<, etc. Dispose packaging
materials, like household waste, in
your local container.
If something does not work
Before calling the technical service,
perform the verifications specified
below.
The appliance does not work:
Ensure that the power cable is plugged
in.
The pot sticks to the glass:
If there is molten material between
the pot and the glass, set the hot
plate to maximum power and try to
separate them.
Single Sensor Error :
If any of the sensors is active more
than 10 seconds, this error situation
occurs and error code”F1” is showed.
roots. One of them is that there may
of the sensor.
Make sure that there is no any object
on the control unit, hob glass is wiped
with a dry cloth. If error situation
continue after this solution, please
for 10 second.
Plural Sensor Error:
If more than 2 sensors are sensed at
same time, this error situation occurs
and error code”F2” is displayed.
Potential root reasons of the
problem :
sensors
• Touch control location may
exposure more heat or steam
Please be sure that there is no any
all steam and heat sources. Then,hob
glass is wiped with a dry cloth. If error
situation continue after this solution,
switch for 10 second.
FC Error:
Fc message on the control and the
hot plates switch off: Overheating
in the electronics. Let thestove cool
for a while.
AR
1
8
green-yellow
blue
brown
grey
black
green-yellow
blue
brown
grey
black
green-yellow
blue
brown
grey
black
green-yellow
blue
brown
grey
black
green-yellow
blue
brown
grey
black
g. 1
DO NOT USE L3
AR
2
20
3
2
2
9
7
9
1 1
50%0
3
0H
10
1
30
AR
3
1
2
3
2
4
1
42
i
2
ii
H
i
0ii
H
H
H
H 1
1
912
3
6
8
1
2
6
8
7
9
1
9
1
7
9
AR
4
1
1
2
5
5
3
73
L
L
L
51
3
72
1
Table 1
-
0
1
2
3
4
5
6
7
8
0
60
180
288
390
510
150
210
270
9
Selected
power
Automatic Cook Start
Function
1
92
6
A
10
1
5 2
9
991
1
912
10 3
0012
11
9914
3
11
01
00
43
0H
2
10
1
10
AR
5
42
00
2
1
2
3
4
5
6
7
8
9
10
Table 2
5
5
4
3
2
2
2
1
Selected
power
level
MAXIMUM OPERATION
TIME
(in hours)
0is
H
1
3
fig. 3
4
fig. 4
Blade protected Blade unprotected
Using the scraper
AR
6
Marco
LDPE
EPS
10
F1
10
F2
10
FC
Fc
P22105R00
Table of contents
Languages:
Other Marco Cooktop manuals
